SAFETY INFORMATION
Read the safety information before installing the water purifier
2.1 WARNING LABELS
Before reading the manual, please get familiarized with the following icons used in this manual.
Electric Shock
Warnings
Specific Information non safety related
2.2 SAFETY INSTRUCTIONS
To ensure the product SAFETY and RELIABILITY, all repairing must be realized with spare parts available with
our after-sales service. If the power cable is damaged, it must be replaced.
Unplug the water purifier power plug. Don’t pull on the wire.
Before all maintenance on the water purifier, turn off the power supply switch and
unplug the power plug.
Use exclusively tap water to supply the water purifier.
- MAXIMUM NETWORK PRESSURE = 6 BAR
- Maximum supply water temperature = 38 °C.
This water purifier needs a main tension 100-240V~ 1.2A 50/60 Hz
Don’t connect too many devices on the same plug in order to not risk fire or
electrical shock.
The low voltage electrical installation must comply with local standards.

Operator’s manual version: 2021.06 4
INTRODUCTION TO THE SYSTEM
3.1 INTRODUCTION
The water purifier system «O maxi+» produces water of Class 2 as defined in ISO 3696 standard, which is
intended to be used by clinical analyzers.
The principle of purification uses two technologies:
-the REVERSE OSMOSIS, which is currently the most effective membrane separation process,
-the demineralization by ion exchange resin.
These two associated technologies allow getting water with excellent quality regarding physical composition,
chemical composition (mineral and organic) and micro-organic population.
3.2 TECHNICAL SPECIFICATIONS
Power supply voltage 100-240V~ 1.2A 50/60 Hz
Production flow at 25 ° C 55 liters / hour
Production flow at 10 ° C 40 liters / hour
Resin type Mixed-bed ions exchange resins
Resin volume 11 liters
Maximum supply water temperature 38 °C (100°F)
Maximum hardness without protection 4 mmol/L
Admissible pH 3 to 11
Mini / maxi supply pressure 2 / 6 bar (29 / 87 PSI)
Dimensions (l × h × w) 56 X 84 X 46 cm
Indicative weight 49 kg
This system is recommended for daily consumption over 50 liters.

Operator’s manual version: 2021.06 5
3.3 OVERVIEW OF THE SYSTEM (FRONT VIEW)
5µm
sediment
filter
Active
carbon
filter
1µm
sediment
filter
Storage
tank
Controller

Operator’s manual version: 2021.06 6
3.4 OVERVIEW OF THE SYSTEM (BACK VIEW)
3.5 GENERAL DESCRIPTION
The "O maxi+" water purifier includes a set of prefiltration cartridges for filtering the inlet water: 5 µm
sediment filter + carbon block filter + 1 µm sediment filter.
After this stage, the water is injected via a booster pump into a reverse osmosis membrane.
After the reverse osmosis membrane, 90% of the organic and inorganic compounds are already removed.
In order to remove most of all remaining minerals, the water goes through an ion exchange resin bottle and is
then filtered by a 1 μm post-treatment filter.
The electromechanical assembly is managed by an electronic controller.
Resin Bottle
Post
treatment
filter
Reverse osmosis membrane

Operator’s manual version: 2021.06 7
1.0
US/CM
READY
3.6 CONTROLLER DESCRIPTION
Main display
The conductivity of the produced water is displayed continuously on the main screen.
System status
Conductivity of
produced water
Detailed information button
Unit
Menu access (press 2 seconds)
Flush(wash) button

Operator’s manual version: 2021.06 8
SELECT:PRESS SET 2 SEC
SETTINGS
CALIBRATION
TELEMETRY
CONTRAST
SERVICE
Menu display
The setting menu is displayed after pressing the SET button 2 seconds with a tool.
Detailed information display
From the main menu, when pressing shortly on the ‘+’ button, the values from various sensors are displayed
momentarily.
DETAILS
INLET
MEMBRANE
3.3
2.0
PRESSURE (BAR)
EC (US/CM)
PRODUCTION
MEMBRANE
1.4
20
This screen is displayed for 10 seconds.
Pressure after the
membrane (BAR)
Conductivity of
produced water
(µS/cm)
Conductivity of the
water after the
membrane (µS/cm)
screen’s name
Water inlet pressure
(BAR)
Menu’s title
Different choices
Selection (press 2 seconds)
Moving in the menu

Operator’s manual version: 2021.06 9
Functioning display
1.0
US/CM
120
FLUSH
The conductivity of the produced water can be
different from 1.0.
The remaining time to finish the purge process is
displayed (seconds).
The water purifier is rinsing the membrane after start-
up, periodically (by default each 6 hours), or when
pressing shortly on the ‘FLUSH’ button.
1.0
US/CM
59
PURGE
The conductivity of the produced water can be
different from 1.0.
The remaining time to finish the purge process is
displayed (seconds).
The water purifier is rejecting momentarily the water
which was stagnated in the membrane.
1.0
US/CM
PROD
The conductivity of the produced water can be
different from 1.0.
The water purifier is producing water and its pump is
running.
1.0
US/CM
READY
The conductivity of the produced water can be
different from 1.0.
The water purifier is ready to use.

Operator’s manual version: 2021.06 10
Setting menu
The settings menu is accessible by pressing with a tool on the SET button for 2 seconds.
SELECT:PRESS SET 2 SEC
SETTINGS
CALIBRATION
TELEMETRY
CONTRAST
SERVICE
The available sub-menus are:
•Calibration of the conductivity electrodes
•Telemetry management
•Screen contrast adjustment
•Tools reserved for service technicians
Screen contrast adjustment
The intensity of display is adjustable.
Press shortly on ‘+’ or ‘-‘ to adjust. The rendering is immediate.
When adjusted, validate by pressing the ‘SET’ button with a tool during 2 seconds.
SELECT:PRESS SET 2 SEC
SETTINGS
CALIBRATION
TELEMETRY
CONTRAST
SERVICE
INC:+
DEC:-
OK:PRESS SET 2 SEC
CONTRAST ADJUST

Operator’s manual version: 2021.06 11
General comments on the calibration of the conductivity electrodes
The calibration process is not forced by the system. It is possible to adjust the displayed value on the
controller’s screen if it is different from the value measured with an external calibrated conductivity meter.
For the calibration of the electrodes, it is necessary to use a precise external
conductivity meter which must be calibrated (in option, conductivity meter reference
950026).
There is no necessity to calibrate after each change of membrane, filter, or resin
cartridge
3.6.7.1 How to use the external calibrated conductivity meter
1. Let flow the water to test 15 to 30 seconds.
2. Remove the conductivity meter protection cap.
3. Rinse the protection cap and the conductivity meter probe with the water to test.
4. Renew the operation 2 to 3 times.
5. Fill protection cap of the conductivity meter with the water to test. Plunge the conductivity meter.
Read the measured value.
6. Renew the operation 2 to 3 times; the retained value will be the last one.
7. Switch off the conductivity meter and put the protection cap back.
3.6.7.2 Calibration menu access
SELECT:PRESS SET 2 SEC
SETTINGS
CALIBRATION
TELEMETRY
CONTRAST
SERVICE
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY

Operator’s manual version: 2021.06 12
3.6.7.3 Use of the adjustment screen
The calibration of the integrated conductivity electrodes is processed with the inner water. In parallel, the
conductivity of this water has to be measured with an external conductivity meter which needs to be
previously calibrated.
OK:PRESS SET 2 SEC
xxxxxx POINT x
CONDUCTIVITY
CALIBRATION
1.5
US/CM
...details…..
•Measure the conductivity with the external calibrated conductivity
meter
•Press on ‘+’ or ‘-‘ until displaying the same value on the controller’s
screen
•Save the calibration point by pressing with a tool on the ‘SET’ button
for 2 seconds
The 2 points of calibrations can not be defined at the same time. The second point of calibration can be useful
after a significant increase of the conductivity. The conductivity of the second point must above the
conductivity of the first point.

Operator’s manual version: 2021.06 13
3.6.7.4 Calibration curve with one point
As the electrodes are not accessible by the user, they are able to measure only the conductivity of the water
crossing the system.
The system uses by default its own calibration curve.
It is recommended to calibrate the 1st point of calibration when installing the system, or when replacing filters,
the RO membrane, resin cartridge, électrodes, or the electronics controller (in all these cases, delete the 2nd
point).
•Point of calibration: grey vertical line.
•The calibration curve goes from 0 to the point of calibration.
•Above the point of calibration, the values are adjusted by a
shift from the values measured by the electrode.

Operator’s manual version: 2021.06 14
3.6.7.5 Calibration curve with 2 points
As the electrodes are not accessible by the user, they are able to measure only the conductivity of the water
crossing the system.
A 2nd point of calibration can not be used when the conductivity is too close to the conductivity of the 1st point,
without a risk of miscalibration.
It is recommended to choose the 2nd point of calibration with a conductivity close to the maximum.
It is recommended to recalibrate the 2nd point of calibration when filters, the RO membrane or the resin is
close to the saturation.
•Points of calibration: where are the 2 grey
vertical lines.
•The calibration curve goes from 0 to the 1st point
of calibration. The slope is then adjusted.
•The calibration linear curve goes from the 1st
point to the 2nd point of calibration. The slope is
then adjusted.
•Above the 2nd point of calibration, the values are
adjusted by a shift from the values measured by
the electrode. The slope is the default one.

Operator’s manual version: 2021.06 15
Calibration of the production conductivity electrode
The calibration of the production conductivity electrode is made by taking water directly from the output of
the purified water. The points of calibration must have conductivity values strictly under 10 µS/cm.
3.6.8.1 To define a 1st point of calibration
This is the initial case, before any
saving of calibration point.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
CONDUCTIVITY CAL
SET PRODUCTION POINT 1
3.6.8.2 To delete the 1st point of calibration
It is possible to come back to the default conductivity values by deleting the 1st point of calibration.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
DELETE PROD. POINT 1
CONDUCTIVITY CAL
SET PRODUCTION POINT 1
SELECT:PRESS SET 2 SEC
CONFIRMDELETION OF
PRODUCTION
POINT 1
Delete the point of
calibration by pressing
with a tool 2 seconds on
the ‘SET’ button
3.6.8.3 To define a 2nd point of calibration
When a 1st point of calibration is
already defined, it is possible to
define a 2nd point.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
CONDUCTIVITY CAL
SET PRODUCTION POINT 1
SET PRODUCTION POINT 2
DELETE PROD. POINT 2
3.6.8.4 To delete the 2nd point of calibration
It is possible to come back to one only point of calibration by deleting the 2nd point of calibration.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
SET PRODUCTION POINT 2
CONDUCTIVITY CAL
SET PRODUCTION POINT 1
DELETE PROD. POINT 2
SELECT:PRESS SET 2 SEC
CONFIRMDELETION OF
PRODUCTION
POINT 2
Delete the point of
calibration by pressing
with a tool 2 seconds on
the ‘SET’ button

Operator’s manual version: 2021.06 16
Calibration of the membrane conductivity electrode
3.6.9.1 How to take water after the membrane
1. Remove the transparent covers.
2. Take out the resin bottle (Figure1).
3. Close the valve on top of the pressurized water tank.
4. Close the hand valve No. 1.
5. Remove the cap at the extremity of the T tubing. Open the hand valve No. 2 (Figure 2).
6. Plunge its extremity in a clean bowl
7. Switch ON the water purifier
8. Fill the bowl with enough water to enable conductivity measurement with an external calibrated
conductivity meter.
9. Switch OFF the water purifier.
10. Refer to the paragraph explaining how to measure water conductivity in the bowl using the external
calibrated conductivity meter (paragraph 3.6.7.1).
11. Put the cap back on, close the hand valve No. 2, open the hand valve No. 1.
12. Put the resin bottle back in the device.
13. Switch ON the water purifier
The points of calibration must have conductivity values strictly below 100 µS/cm.
Figure 2
Hand valve No. 1
Hand valve No. 2
Cap
Figure 1

Operator’s manual version: 2021.06 17
3.6.9.2 To define a 1st point of calibration
This is the default configuration, before any saving of calibration point.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
CONDUCTIVITY CAL
SET MEMBRANE POINT 1
3.6.9.3 To delete the 1st point of calibration
It is possible to come back to the default conductivity values by deleting the 1st calibration point.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
DELETE MEMB. POINT 1
CONDUCTIVITY CAL
SET MEMBRANE POINT 1
SELECT:PRESS SET 2 SEC
CONFIRMDELETION OF
MEMBRANE
POINT 1
Delete the point of
calibration by pressing
with a tool 2 seconds on
the ‘SET’ button

Operator’s manual version: 2021.06 18
3.6.9.4 To define a 2nd point of calibration
This is the default configuration, before any saving of calibration point.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
CONDUCTIVITY CAL
SET MEMBRANE POINT 1
SET MEMBRANE POINT 2
DELETE MEMB. POINT 2
3.6.9.5 To delete the 2nd point of calibration
It is possible to come back to only one point of calibration by deleting the 2nd point of calibration.
SELECT:PRESS SET 2 SEC
CALIBRATION
PROD CONDUCTIVITY
MEMBRANE CONDUCTIVITY
SELECT:PRESS SET 2 SEC
SET MEMBRANE POINT 2
CONDUCTIVITY CAL
SET MEMBRANE POINT 1
DELETE MEMB. POINT 2
SELECT:PRESS SET 2 SEC
CONFIRMDELETION OF
MEMBRANE
POINT 2
Delete the point of
calibration by pressing
with a tool 2 seconds on
the ‘SET’ button

Operator’s manual version: 2021.06 19
Telemetry management
The telemetry feature allows to monitor and to record the measurements of conductivity, pressure,
temperature, and status of the water purifier on a PC connected by a USB cable.
On the activation screen, to active/unactivate the telemetry function, press with a tool for 2 seconds on the
‘SET’ BUTTON.
When activated, the telemetry remains active even after restart of the water purifier.
SELECT:PRESS SET 2 SEC
SETTINGS
CALIBRATION
TELEMETRY
CONTRAST
SERVICE
WAITING USB
CONNECTION
..PRESS SHORTLY
SET KEY TO ABORT..
NO USB
SELECT:PRESS SET 2 SEC
USB TELEMETRY
TURN ON
The delay between 2 successive sending is 10 seconds.
The data are transmitted in one text line of ASCII characters, followed by the carriage and line feed
characters (CR+LF) using the following CSV format:
* A;B;C;D;E;F;G
with
•A =PRODUCTION CONDUCTIVITY
•B=PRODUCTION TEMPERATURE
•C= MEMBRANE CONDUCTIVITY
•D=MEMBRANE TEMPERATURE
•E=INLET PRESSURE
•F= MEMBRANE OUTPUT PRESSURE
•G=ERROR CODE
As the USB connection emulates a serial port, a terminal emulator software as the open-source software «
TERMITE» can be used to receive the data on the PC.
The copy of the data in a file with the extension « .CSV » allows to open it later in a spreadsheet with the
data organized in columns.
