Dickinson Spitfire 330 User manual

Quality Check: Date:
INSTALLATION AND OPERATING MANUAL
This manual MUST be read carefully
and all requirements carried
out to ensure satisfactory
performance
Dickinson Marine (1997) Ltd
40 -204 Cayer Street,
Coquitlam, B.C. Canada
V3K 5B1
Web Site www.dickinsonmarine.com
E mail [e-mail]

PA KING LIST
00-SPT-330 -
o MODEL 330 SPITFIRE MARINE GRILL
o Main Body Assembly with Thermometer
o 3 Stainless Steel Grilling Sections (2 Bottom, 1 Top)
o Owner’s Manual and Warranty Card
o Drip Tray
o Deck Feet (2)
o Bonus Black Canvas Cover
THIS IS A QUALITY DI KINSON PRODU T
Should you discover any shortages or defective parts please contact your dealer immediately and the
problem will be corrected. This product carries a one year warranty beginning from the date of purchase. A
three year warranty is extended to the burner elements of this appliance. These warranties can only be
activated by returning the warranty card.
OPTIONAL MOUNTING SYSTEMS
While your new marine grill does have feet that allow it to be used on a table, several mounting kits are
available to help you attach it to your Boat or RV.
PART NO
15-150A
Universal Rail Mount Kit
Use when attaching the BBQ to a round metal rail /8
th
-1.5” in diameter (2.2-3.8cm) or square
rail. Vertical, horizontal or angled rail can be used. For rail diameter larger than 1 1/8”
15-150F
FISHING ROD HOLDER MOUNT KIT
Use in a “rocket launcher” style or flush mount fish rod holder (1 ½). Universal angle, quick
release.
15-18
TAFF RAIL MOUNT KIT
Includes two sockets that are installed in the taff rail, cap rail or gunwale. Included stanchions
hold the grill over the side.
Standard
DE K LEGS
DANGER! THIS BBQ IS INTENDED FOR LOW PRESSURE GAS
ONLY. DO NOT ONNE T THIS APPLIAN E TO A GAS SUPPLY IN
THE ABSEN E OF A LOW PRESSURE REGULATOR (11” W/ ,
0.5PSI, 27.4 mBar.

THE SPITFIRE IS DESIGNED FOR LPG/LPG MIX ONLY
IMPORTANT:
Read this owner’s manual carefully and completely before trying to assemble, operate, or
service this barbeque. Improper use of this gas appliance can cause serious injury or death from
burns, fire, explosion, carbon monoxide poisoning and oxygen depletion.
WARNING:
DO NOT install this appliance in spaces containing internal combustion engines, their fuel
tanks, or joints and fittings of their fuel systems.
TEST ALL PROPANE LINES AND ONNE TIONS FOR LEAKS WITH A SOAPY
WATER SOLUTION. DO NOT FLAME TEST FOR LEAKS.
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch..
• Immediately call your gas supplier from a neighbour’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
LOSE THE LPG YLINDER VALVE WHEN BBQ IS NOT IN USE
LOSE THE LPG YLINDER VALVE IN THE EVENT OF AN EMERGEN Y
LOSE THE BBQ REGULATOR VALVES OPENING THE LPG YLINDER VALVE
IMPORTANT:
Save this manual for future reference.

THINGS TO KNOW
Your Thermometer:
The Spitfire 180 and the 330 are fitted out with a thermometer. Inspect the thermometer to ensure
no small white bits of plastic are around the edge, left over from the protective plastic used in the
manufacturing process. Be aware that bending or damaging the thermometer probe or dropping the Spitfire,
may cause the thermometer to stop working.
Your Igniter:
Your igniter has been installed for you. Two igniter lead wires connect the igniter to the burners.
Care to be taken to ensure these leads are not damaged. Should one of your igniters stop working, remove
the lead wires and clean all of the connections as a first step to repair.
The Burners :
Your Spitfire 330 Grill has two burners, each controlled by an independent gas valve. The burner
is made up of the following components: the burner cup; flame spreader; the orifice and the burner cap
plate. Screwed in to the top of the burner is the primary heat distribution plate and is not considered a
burner component for warranty purposes.
The burner components can be disassembled for cleaning and maintenance purposes but care must
be taken to ensure the parts are not damaged during cleaning or disassembly. Use a precision screwdriver to
carefully remove the stainless machine screws that hold down the burner cap plate. Remove the screws and
the flame spreader to access the burner cup.
The orifice component is the series of brass fitting in the bottom of the burner cup. The orifice jet
on the end can be removed and cleaned. If your Spitfire becomes much less hot, a blocked orifice assembly
could be the reason. Small pieces of rubber hose from the gas supply or dirt in the propane can clog an
orifice. When cleaning an orifice, do not enlarge the holes.
The Gas Valves :
Each burner is controlled by a gas valve. Do not detach or open the gas valves on your appliance
as this will damage the components. There should be no reason to remove or service these parts.

PROPANE FUEL SUPPLY
• Propane Bottle:
As shipped, the Spitfiure 330 is not set up to take high pressure propane from a disposable bottle but with
the correct regulator and fittings you will be able to use the disposable bottles. (Part 15-19 for the
regulator kit)
• Propane Tank (Low Pressure):
Your Spitfire 330 BBQ is designed to be connected directly to your existing low pressure propane system.
If your system includes an 11” W/C regulator (0.5psi / 2 .3 mBar) you can attach it directly to your 330
Grill. The fitting on the grill is a standard 45 degree 3/8ths male flare fitting in brass. Use Dickinson 19-
100-10 (10 ft.) or 19-100-20 (20 ft) for standard, CE approved propane supply hose.
• Propane Tank (High Pressure):
Use a propane BBQ hose (Part 15-188 for 6 ft or 15-189 for 8 ft) and a low pressure bbq regulator fittings
kit (15-19 ) to attach the Spitfire 330 to a high pressure propane tank (standard refillable cylinder)
• European disposable gas cartridges:
Use Euro-gas Adapter Coupling Part 15-194 can connect several commonly available European gas
cartridges directly to your Spitfire Grill. Use this part in conjunction with the 15-19 low pressure BBQ
regulator kit.
AUTION
• THE BBQ IS DESIGNED FOR LOW PRESSURE LPG ONLY
• CLOSE THE LPG CYLINDER VALVE WHEN THIS BBQ IS NOT IN USE
• CLOSE THE LPG CYLINDER VALVE WHEN THE BOAT IS UNATTENDED
• CLOSE THE LPG CYLINDER VALVE IN THE EVENT OF AN EMERGENCY
• CLOSE THE CONTROL VALVES BEFORE OPENING THE LPG CYLINDER VALVE
TEST ALL PROPANE LINES AND ONNE TIONS FOR LEAKS WITH A
SOAPY WATER SOLUTION. DO NOT FLAME TEST FOR LEAKS.
LIGHTING
1) SPITFIRE 330 control valves OFF position
2) Open Lid and turn on LPG gas supply at source
3) Open the gas valve of the burner you wish to light
4) Push igniter button on the front of the grill.
WARNING IF THE BURNER DOES NOT LIGHT IMMEDIATELY TURN CONTROL
VALVE TO OFF POSITION AND DO NOT ATTEMPT TO LIGHT THE BURNER FOR AT
LEAST 60 SECONDS .

OPERATION
When the burner is lit the control setting may be selected. With the lid closed the Spitfire will quickly
reach cooking temperatures (5 minutes).
WITH THE ONTROL VALVES AT HIGH AND THE LID LOSED FOR EXTENDED
PERIODS DAMAGE MAY BE AUSED TO THE SPITFIRE. HIGH GAS SETTINGS ARE
ONLY RE OMMENDED FOR A SHORT PRE-HEAT / LEANING PERIOD OR FOR
BARBEQUING WITH THE LID OPEN.
After cooking turn the grill off at the LPG source. Once the burner has extinguished turn the Control
Regulator to the LOCK-OFF position. This will de-pressurize the fuel line. This may be accomplished by
closing a solenoid if your system is equipped.
COOKING
The removable drip tray must be installed prior to cooking. DO NOT ALLOW GREASE TO
BUILD-UP IN THE GREASE TRAY OR IN THE BASE OF THE SPITFIRE.
The drip tray can be placed in or removed from the back of the Spitfire 330.
The stainless rod grill sections or the optional “Aussie Style” Griddle Pan can be sprayed or covered with
cooking oil to prevent food from sticking. Accumulated grease will burn off if the cooking plates are
turned over. For a thorough clean, a bbq brush or oven cleaner.
IMPORTANT NOTE : BARBECUES GET HOT AND WILL SPLASH AND LEAK
GREASE. FOR SAFETY REASONS IT IS THEREFORE ADVISABLE TO MOUNT THE UNIT
OUTBOARD.
GENERAL CLEANING AND MAINTENANCE
• Clean grease from the drip tray of the Spitfire after each use
• The burner orifice can be removed for thorough cleaning or cleaned in place with hot water and a
bronze wire brush, see section “ The Burners”.
• Stainless Spitfire top lid and main body will discolor with the heat. This is chromium reacting with
the heat and the oxygen to create chromium oxide, the component of stainless steel that gives it
corrosion resistance. While all quality stainless will react this way with heat, it should not be
confused with corrosion. The use of stainless steel polish.
• The Top Lid will loosen where it attaches to the Main Body. To tighten use two /16” wrenches.
Back off the outer acorn nut and tighten the inner hex nut. Re-tighten the acorn nut.

OPTIONAL MOUNTING SYSTEMS
PART NO
15-150A UNIVERSAL RAIL MOUNT KIT Will fit up to 1.5” rail.
15-18 TAFF RAIL MOUNT KIT
15-150F
FISHING ROD HOLDER MOUNT KIT
Universal angle, quick release, 1 ½”
Standard DE K LEGS
A ESSORIES AND PART IDENTIFIER
PART NO
15-188 Six Ft Propane Hose
15-189 Eight Ft Propane Hose
15-191 Six Ft T type Hose
15-192 Eight Ft T type Hose
19-100-10 Ten Ft Propane supply hose (Flare fittings)
19-100-20 Twenty Ft Propane supply hose (Flare fittings)
15-194 Euro-Gaz Adapter oupling allows the use of many European gaz cartridges.
15-19 Low Pressure BBQ regulator Fittings Kit
15-120 Thermometer
15-083 Drip Tray – Stainless
15-101 Igniter Assembly
15-196 Stainless Steel Rod Grill Section Each (Needs 2 Per Grill)
- Top Rack for Spitfire 330
- Primary Heat Diffuser disk for Spitfire 330
15-066 Heat Diffuser Panel Spitfire 330
15-204 “Aussie Style” Griddle Pan for Spitfire 330
15-1 2 Black anvas over Spitfire 330
15-0 5 Orifice Pair. Spitfire 330

LIMITED WARRANTY
WARRANTY PROVISIONS : dickinson warrants this product to be free of defects in workmanship
and materials for a period of one year. This warranty is limited to claims submitted in writing within a one-
year period following the date of purchase. The burner bar or burner element of this appliance is under
warranty for three years from purchase date. If any part of your new product fails because of a
manufacturing defect within the warranty period dickinson offers to replace said parts free of charge,
provided, however, that such parts have not been improperly repaired, altered or tampered with or
subjected to misuse, abuse or exposed to corrosive conditions. This warranty, however, is limited by
certain exclusions, time limits and exceptions as listed below. Read these limitations and exclusions
carefully. RETURN OF THE WARRANTY CARD IS REQUIRED TO ACTIVATE THE WARRANTY
TIME LIMIT : This warranty is given too and covers only the original purchaser. Coverage terminates
one year from the date of purchase for parts replacement (except burner: see above).
EX LUSIONS : This warranty does not cover or include : (a) Any normal deterioration of the product and
appearance of items, due to wear and/or exposure; (b) any guarantees, promises, representations, warranties
or service agreements given or made by an authorized distributor or other person selling this product, other
than those specifically stated herein; (c) any damage or defect due to accident, improper repair, alteration,
unreasonable use including failure to provide reasonable and necessary maintenance, misuse or abuse of
the equipment, or exposure to corrosive conditions. This warranty is conditioned upon normal use,
reasonable and necessary maintenance and service of your product, and written notice being given
promptly upon Buyer's discovery of a warranty claim, pursuant to paragraph 6 below. Reasonable and
necessary maintenance is maintenance, which you are expected to do yourself or have done for you. It is
maintenance, which is necessary to keep your product performing its intended function and operating at a
reasonable level of performance.
DAMAGE LIMITATION WARNING : IN NO EVENT SHALL dickinson BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING (BUT NOT LIMITED TO) LOSS OF
USE OF THE PRODUCT, LOSS OF TIME, INCONVENIENCE, EXPENSES FOR TRAVEL,
LODGING TRANSPORTATION CHARGES, LOSS BY DAMAGE TO PERSONAL PROPERTY OR
LOSS OF INCOME, PROFITS OR REVENUE.
ORAL OR IMPLIED WARRANTY LIMITATIONS : The foregoing warranty is exclusive and in lieu
of all other warranties, written or oral, expressed or implied, including but not limited to any warranty or
merchantability or fitness for a particular purpose.
TRANSFER LIMITATIONS : This warranty is not assignable or transferable. It covers only the original
purchaser.
LAIM PRO EDURE : In the event of a defect, problem or that a breach of this warranty is discovered,
in order to protect any warranty rights you must promptly notify dickinson. Give name, address, and
model name, location of unit, description of problem and where you can be reached during business hours.
RESERVED RIGHT TO HANGE : dickinson reserves the right to make changes or improvements to
products it produces in the future without imposing on itself any obligations to install the same
improvements in the products it has previously manufactured.
SE OND OR SUBSEQUENT OWNER : dickinson does not give any warranty to secondary or
subsequent purchasers, and it disclaims all implied warranties to such owners.
INSPE TION : To assist you in avoiding problems with your product and to validate this warranty you
are required to do the following : (a) read the warranty; (b) inspect the product. Do not accept delivery
until you have examined the product with your supplier; (c) ask questions about anything you do not
understand concerning the product.
OWNER REGISTRATION : Fill out the WARRANTY ARD within 30 days from the date of delivery.
WARRANTY : RETURN OF THE ARD IS ONDITION PRE EDENT TO WARRANTY
OVERAGE AND PERFORMAN E. IF YOU DO NOT FILL OUT AND MAIL THE ARD AS
DIRE TED, YOU WILL NOT HAVE A WARRANTY.
LEGAL RIGHTS : This warranty gives you specific legal rights and you may also have other rights,
which may vary within different government jurisdictions.
