Designed by guitar fanatics in Salt Lake City, Utah 7 www.digitech.com 7 801.566.8800
R
6 DigiTech® Component-Based Modeling™
next generation amp modeling
6 43 amp models
6 24 cabinet models
6 DigiTech®’s exclusive GeNetX™ Mult-Modeling™
technology
6 Single coil and humbucking pick-up modeling
6 57 fully programmable effects, 11 at one time
6 195 presets: 130 factory, 65 user
6 Hands-Free™ computer recording via USB
6 XLR and ¼" direct stereo outputs for connecting a
mixer, amps and more
6 Included: ProTracks Plus™ multi-track recording
software and Lexicon® Pantheon™ reverb plug-in
6 6-channels of 24-bit audio – Record 4/Playback 2
6 X-Edit™ Editor/Librarian for Mac and PC
6 Built-in drum machine with over 80 patterns
6 Chromatic tuner
6 Learn-A-Lick™ and Jam-A-Long™
6 7 wide-spaced foot switches (up to 10 with optional
foot controller) and expression pedal
6 Rugged metal chassis and treadle
6 Power supply and USB cable included
6 Optional GNXFC foot controller
6 dbx® mic preamp with phantom power
6 3 assignable expression pedal functions at one time
STAGE: Plug directly into separate ¼" and
XLR outputs with adjustable level controls
to send your signal to amps and a PA.
The USB port
streams 6 channels
of 24-bit audio
(4 Record/2 Play-
back) to and from your computer.
Record guitar, acoustic, and line
level performances with ease.
STEREO 1/4" and XLR OUTPUTS WITH ADVANCED CIT™
USB PORT
GNX3000 GUITAR WORKSTATION®
Introducing a bold new addi- tion to the DigiTech® famed
Guitar Workstation® lineup,
the GNX3000, designed
with both the per-
forming and
recording guitar-
ist in mind. When
you’re onstage,
the GNX3000 is an
ideal workhorse.
Component-Based
Modeling™ captures an entire signal path of an
amp or cabinet. From the individual components
and acoustic behavior of an amp, to the details
that include: preamps, tone stage topology, type
of power stage, feedback and tube saturation
characteristics, speaker and output transformer
interaction. Even cabinet size and composition
are factored in. Get the picture, the tone.
Both ¼" and XLR outputs let you run to your
onstage rig and the house PA simultaneously,
each with independent level controls. When
you’re in the studio, the GNX3000’s built-in USB
audio/MIDI recording interface makes recording
easier than ever thanks to the included Hands
Free™ ProTracks Plus™ recording software suite.
All this plus DigiTech’s next generation amp
modeling, Component-Based Modeling™ with
43 new amp models and 2 new acoustic guitar
models make the GNX3000 an indispensable tool
for any serious guitar player. 6
THE
GNX3000™ Guitar Workstation®
perform Practice
create Record

GNX3000 Guitar Workstation Amp Models based on*:
6 ‘57 Fender® Tweed Champ® 6 ‘57 Fender® Tweed Deluxe®
6 ‘59 Fender® Tweed Bassman® 6 ‘62 Fender® Brownface
Bassman® 6 ‘65 Fender® Blackface Twin Reverb® 6 ‘65
Fender® Blackface Deluxe Twin Reverb® 6 Marshall® JTM-45™
6 ‘68 Marshall® 100 Watt Super Lead™ (plexi) 6 ‘68 Marshall®
Jump Panel® 6 ‘77 Marshall® Master Volume® 6 ‘83 Marshall®
JCM800™ 6 ‘93 Marshall® JCM900™ 6 ‘01 Marshall® JCM2000™
(solo channel) 6 ’81 Mesa/Boogie® Mark IIC 6 ’01 Mesa/Boo-
gie® Dual Rectifier® 6 Vox® AC15 6 Vox® AC30 Top Boost
6 ‘69 Hiwatt Custom 100 DR103 6 ‘88 Soldano SLO-100
6 Matchless® DC30 6 ‘99 Carvin® Legacy VL-100 6 Jumbo
Acoustic 6 Dreadnaught Acoustic 6 Ampeg® SVT™ Classic
6 Ampeg® B-15 6 Ashdown® ABM-C410H™ 6 Fender® Dual
Showman 6 Hartke® Model 2000 6 Trace-Elliott Commando
6 and more…
GNX3000 Guitar Workstation Stompbox models based on*:
6 Ibanez® TS-9® 6 Arbiter® Fuzz Face™ 6 Boss® DS-1™
6 Electro-Harmonix® Big Muff ® 6 DigiTech® Grunge®
6 Voodoo Labs® Sparkle Drive™ 6 Guyatone® OD2* 6 BOSS®
Metal Zone* 6 Pro Co Rat™* 6 DOD® Preamp/Overdrive
250* 6 Roger Mayer™ Octavia™ 6 and more…
GNX3000 Guitar Workstation Effects (up to 11 at a time):
6 Whammy® 6 Wah 6 Pick-up Modeling 6 Compressor
6 Intelligent Pitch Shifting 6 Acoustic Guitar Simulator
6 Chorus 6 Flanger 6 Phaser 6 Tremolo 6 Rotary Speaker
6 Detune 6 Noise Gate 6 Analog Delay 6 Unicord™ Univibe™
6 Detune 6 Noise Gate 6 Analog Delay 6 Ping-Pong Delay
6 Triggered Phaser 6 Reverb – Hall • Plate • Room • Spring
6 Talker™ 6 Vibrato 6 Synthtalk™ 6 and more…




A complete recording
environment…no
mixer required!
Footswitch Jack
Make it even
simpler to record
Hands-Free™ while
changing presets in
the GNX3000 via the
optional GNXFC
footswitch.
¼" Balanced Outputs
Send signals to your amp
rig onstage while routing
the XLR outputs to the
house mixer for a truly
huge sound.
¼" Stereo Line Inputs
Plug your keyboards, guitar
synths, or other line level
gadgets directly into the
GNX3000 eliminating the
need for a separate mixer.
dbx® Mic Preamp
with Phantom Power
Capture all of the nuances of
your vocal or acoustic perfor-
mances with this extremely
low-noise mic preamp. Phantom
Power lets you use the finest
studio condenser mics without
fear of improper power.
Separate ¼" & XLR outputs send sound to both the amp and PA
STUDIO
STAGE
Designed by guitar fanatics in Salt Lake City, Utah 7 www.digitech.com 7 801.566.8800
*DigiTech®, GNX4™, Guitar Workstation®, GNX3000™, Component-Based Modeling™, Whammy®, Talker™, dbx®, X-Series™, CIT™, Metal Master™,
Grunge®, DOD® and Audio DNA® are trademarks of the Harman Music Group Inc. Other names used in this document are trademarks of their respective
owners, which are in no way are associated or affiliated with DigiTech. These trademarks of other manufactures were used to identify products whose
sounds were reviewed in the making of this product.
USB Port
Transform your computer into a recording
studio. Stream 6 channels of 24-bit audio
(record 4, playback 2) with zero-latency
monitoring.
18-0375
Headphone Jack
Play loud in stereo
anytime you want
without disturbing
your neighbors.
GNX3000 GUITAR WORKSTATION®
Independent
Output Levels
No more fighting with
your sound guy just
because you need to turn
up your stage volume.
MIDI In/Out
Ports connect to MIDI keyboards,
sequencers and other MIDI devices.
Active Direct Box
Plug balanced XLRs directly
into your house mixer when
playing live or to your powered
studio monitors for zero-latency
monitoring for recording.
