DigiDesign Focusrite d2 User manual

Focusrite d2 and d3
Version 8.0
™™

Legal Notices
This guide is copyrighted ©2008 by Digidesign, a division of
Avid Technology, Inc. (hereafter “Digidesign”), with all rights
reserved. Under copyright laws, this guide may not be
duplicated in whole or in part without the written consent of
Digidesign.
003, 96 I/O, 96i I/O, 192 Digital I/O, 192 I/O, 888|24 I/O,
882|20 I/O, 1622 I/O, 24-Bit ADAT Bridge I/O, AudioSuite,
Avid, Avid DNA, Avid Mojo, Avid Unity, Avid Unity ISIS,
Avid Xpress, AVoption, Axiom, Beat Detective, Bomb Factory,
Bruno, C|24, Command|8, Control|24, D-Command, D-Control,
D-Fi, D-fx, D-Show, D-Verb, DAE, Digi 002, DigiBase,
DigiDelivery, Digidesign, Digidesign Audio Engine, Digidesign
Intelligent Noise Reduction, Digidesign TDM Bus, DigiDrive,
DigiRack, DigiTest, DigiTranslator, DINR, D-Show, DV Toolkit,
EditPack, Eleven, HD Core, HD Process, Hybrid, Impact,
Interplay, LoFi, M-Audio, MachineControl, Maxim, Mbox,
MediaComposer, MIDI I/O, MIX, MultiShell, Nitris, OMF,
OMF Interchange, PRE, ProControl, Pro Tools M-Powered,
Pro Tools, Pro Tools|HD, Pro Tools LE, QuickPunch, Recti-Fi,
Reel Tape, Reso, Reverb One, ReVibe, RTAS, Sibelius,
Smack!, SoundReplacer, Sound Designer II, Strike, Structure,
SYNC HD, SYNC I/O, Synchronic, TL Aggro, TL AutoPan, TL
Drum Rehab, TL Everyphase, TL Fauxlder, TL In Tune, TL
MasterMeter, TL Metro, TL Space, TL Utilities, Transfuser,
Trillium Lane Labs, Vari-Fi Velvet, X-Form, and XMON are
trademarks or registered trademarks of Digidesign and/or Avid
Technology, Inc. Xpand! is Registered in the U.S. Patent and
Trademark Office. All other trademarks are the property of their
respective owners.
Product features, specifications, system requirements, and
availability are subject to change without notice.
Guide Part Number 9329-59282-00 REV A 11/08
Documentation Feedback
At Digidesign, we're always looking for ways to improve our
documentation. If you have comments, corrections, or
suggestions regarding our documentation, email us at
[email protected].

Contents iii
contents
Chapter 1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Contents of the Boxed Version of Your Plug-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
System Requirements & Compatibility Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Register Your Plug-ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Working with Plug-ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Conventions Used in This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About www.digidesign.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 2. Installing, Authorizing, and Removing Plug-ins . . . . . . . . . . . . . . . . . . . . . . . 1
Installing Plug-ins for Pro Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Authorizing Plug-ins for Pro Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Uninstalling Plug-ins for Pro Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 3. Focusrite D2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Focusrite D2 Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Adjusting Plug-in Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
D2 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using D2 in Stereo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 4. Focusrite D3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Focusrite D3 Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjusting Plug-in Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
D3 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
D3 Compressor Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
D3 Limiter Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the Side-Chain Input in Focusrite D3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Focusrite D2 and D3 Plug-ins Guideiv
Appendix A. DSP Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Focusrite DSP Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Appendix B. DSP Delays Incurred by TDM Plug-ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Focusrite D2 and D3 DSP Delay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Chapter 1: Introduction 1
chapter 1
Introduction
Congratulations on your purchase of the Focus-
rite D2 or D3 plug-in for Pro Tools®systems. Fo-
cusrite D2 is a high-quality digital equalizer
plug-in, and Focusrite D3 is a high-quality dy-
namics processor plug-in.
The Focusrite D2 and D3 plug-ins are TDM,
RTAS®, and AudioSuite™ plug-ins that retain
the look and sound of Focusrite’s renowned
hardware units.
The D2 and D3 plug-ins provide support for
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz,
and 192 kHz sessions.
Contents of the Boxed
Version of Your Plug-in
Your Focusrite D2 or D3 plug-in package con-
tains the following components:
• Installation disc
• Digidesign®Registration Information Card
• One of the following authorization cards for
authorizing plug-ins with an iLok USB Smart
Key (not supplied):
• Activation Card with an Activation Code
– or –
•LicenseCard
On 176.4 kHz or 192 kHz stereo tracks, Fo-
cusrite is only available as a multi-mono
plug-in.
References to Pro Tools LE® in this guide
are usually interchangeable with Pro Tools
M-Powered™, except as noted in the
Pro Tools M-Powered Setup Guide.

Focusrite D2 and D3 Plug-ins Guide2
System Requirements &
Compatibility Information
To use Focusrite D2 or D3, you need the following:
• An iLok USB Smart Key
• An iLok.com account for managing iLok li-
censes
• One of the following:
• A Digidesign-qualified Pro Tools system.
• A Digidesign-qualified Pro Tools system
and a third-party software application that
supports the Digidesign TDM, RTAS, or
AudioSuite plug-in standard.
• A qualified Avid®Xpress®, Avid Xpress DV
or Avid DNA™ system.
• A Digidesign-qualified VENUE system
(TDM only)
Digidesign can only assure compatibility and
provide support for hardware and software it has
tested and approved.
For complete system requirements and a list of
Digidesign-qualified computers, operating sys-
tems, hard drives, and third-party devices, refer
to the latest information on the Digidesign web-
site:
www.digidesign.com/compatibility
Register Your Plug-ins
If you purchase a plug-in online from the Digi-
Store (www.digidesign.com) using Internet Acti-
vation, you are automatically registered.
If you purchase a plug-in boxed version, check
the included Digidesign Registration Informa-
tion Card for information about how to register
online.
Registered users receive periodic software update
and upgrade notices.
Please refer to the Digidesign website
(www.digidesign.com) or the Digidesign Regis-
tration Information Card for information on
technical support.
Working with Plug-ins
Besides the information provided in this guide,
refer to the Pro Tools Reference Guide for general
information on working with plug-ins, includ-
ing:
• Inserting Plug-ins on Tracks
• Clip Indicators
• The Plug-in Window
• Adjusting Parameters
• Automating Plug-ins
• Using the Librarian

Chapter 1: Introduction 3
Conventions Used in This
Guide
All Digidesign guides use the following conven-
tions to indicate menu choices and key com-
mands:
The names of Commands, Options, and Settings
that appear on-screen are in a different font.
The following symbols are used to highlight im-
portant information:
About www.digidesign.com
The Digidesign website (www.digidesign.com) is
your best online source for information to help
you get the most out of your Pro Tools system.
The following are just a few of the services and
features available.
Product Registration Register your purchase on-
line.
Support and Downloads Contact Digidesign
Technical Support or Customer Service; down-
load software updates and the latest online
manuals; browse the Compatibility documents
for system requirements; search the online An-
swerbase or join the worldwide Pro Tools com-
munity on the Digidesign User Conference.
Training and Education Study on your own using
courses available online or find out how you can
learn in a classroom setting at a certified
Pro Tools training center.
Products and Developers Learn about Digidesign
products; download demo software or learn
about our Development Partners and their plug-
ins, applications, and hardware.
News and Events Get the latest news from
Digidesign or sign up for a Pro Tools demo.
Pro Tools Accelerated Videos Watch the series of
free tutorial videos. Accelerated Videos are de-
signed to help you get up and running with
Pro Tools and its plug-ins quickly.
To learn more about these and other resources
available from Digidesign, visit the Digidesign
website (www.digidesign.com).
Convention Action
File > Save Choose Save from the
File menu
Control+N Hold down the Control
key and press the N key
Control-click Hold down the Control
key and click the mouse
button
Right-click Click with the right
mouse button
User Tips are helpful hints for getting the
most from your Pro Tools system.
Important Notices include information that
could affect your Pro Tools session data or
the performance of your Pro Tools system.
Shortcuts show you useful keyboard or
mouse shortcuts.
Cross References point to related sections in
the Pro Tools Guides.

Focusrite D2 and D3 Plug-ins Guide4

Chapter 2: Installing, Authorizing, and Removing Plug-ins 1
chapter 2
Installing, Authorizing, and Removing Plug-
ins
Installing Plug-ins for
Pro Tools
Installers for your plug-ins can be downloaded
from the DigiStore (www.digidesign.com) or can
be found on the plug-in installer disc (included
with boxed versions of plug-ins).
An installer may also be available on the
Pro Tools installer disc or on a software bundle
installer disc.
Installation steps are essentially the same, re-
gardless of the package, system, or bundle.
Installation
To install a plug-in:
1 Do one of the following:
• Download the installer for your computer
platform from the Digidesign website
(www.digidesign.com). After downloading,
make sure the installer is uncompressed
(.ZIP on Windows or .SIT on Mac).
– or –
• Insert the Installer disc into your computer.
2 Double-click the plug-in installer application.
3 Follow the on-screen instructions to complete
the installation.
4 When installation is complete, click Finish
(Windows) or Quit (Mac).
When you open Pro Tools, you are prompted to
authorize your new plug-in
For information on installing plug-ins for
VENUE systems, see the D-Show guide that
came with your system.

Focusrite D2 and D3 Plug-ins Guide2
Authorizing Plug-ins for
Pro Tools
Plug-ins are authorized using the iLok USB
Smart Key (iLok), manufactured by PACE Anti-
Piracy, Inc.
The iLok is similar to a dongle, but unlike a don-
gle, it is designed to securely authorize multiple
software applications from a variety of software
developers.
This key can hold over 100 licenses for all of
your iLok-enabled software. Once an iLok is au-
thorized for a given piece of software, you can
use the iLok to authorize that software on any
computer.
Authorizing Download Versions of
Plug-ins for Pro Tools
If you purchased a download version of a plug-
in from the DigiStore (www.digidesign.com),
authorize the plug-in by downloading licenses
from iLok.com to an iLok.
Authorizing Boxed Versions of
Plug-ins for Pro Tools
If you purchased a boxed version of a plug-in, it
comes with an Activation Code (on the included
Activation Card).
To authorize a TDM plug-in using an Activation
Code:
1 Visit www.iLok.com and sign up for an
iLok.com account if you do not have an existing
iLok.com account.
2 Transfer the license for your plug-in to your
iLok.com account by doing the following:
• Visit http://secure.digidesign.com/
activation.
• Input your Activation Code (listed on your
Activation Card) and your iLok.com User
ID. Your iLok.com User ID is the name you
create for your iLok.com account.
3 Transfer the licenses from your iLok.com ac-
count to your iLok USB Smart Key by doing the
following:
• Insert the iLok into an available USB port
on your computer.
• Go to www.iLok.com and log in.
• Follow the on-screen instructions for trans-
ferring your licences to your iLok.
4 Launch Pro Tools.
5 If you have any installed unauthorized plug-
ins or software options, you are prompted to au-
thorize them. Follow the on-screen instructions
to complete the authorization process.
iLok USB Smart Key
The iLok USB Smart Key is not supplied
with your plug-in or software option. You
can use the one included with certain
Pro Tools systems (such as Pro Tools|HD®
systems), or purchase one separately.
See the iLok Usage Guide for details, or visit
the iLok Web site (www.iLok.com).
For information about iLok technology and
licenses, see the electronic PDF of the iLok
Usage Guide.

Chapter 2: Installing, Authorizing, and Removing Plug-ins 3
Uninstalling Plug-ins for
Pro Tools
If you need to uninstall a plug-in from your sys-
tem, follow the instructions below for your
computer platform.
Windows Vista
To remove a plug-in:
1 Choose > Control Panel.
2 Under Programs, click Uninstall a Program.
3 Select the plug-in from the list of installed ap-
plications.
4 Click Uninstall.
5 Follow the on-screen instructions to remove
the plug-in.
Windows XP
To remove a plug-in:
1 Choose > Start Control Panel.
2 Double-click Add or Remove Programs.
3 Select the plug-in from the list of installed ap-
plications.
4 Click the Remove button.
5 Follow the on-screen instructions to remove
the plug-in.
Mac OS X
To remove a plug-in:
1 Locate and open the Plug-ins folder on your
Startup drive (Library/Application Support
/Digidesign/Plug-ins).
2 Do one of the following:
• Drag the plug-in to the Trash and empty
the Trash.
– or –
• Drag the plug-in to the Plug-ins (Unused)
folder.

Focusrite D2 and D3 Plug-ins Guide4

Chapter 3: Focusrite D2 5
chapter 3
Focusrite D2
Focusrite D2 is a high-quality digital equalizer
plug-in for Pro Tools. Developed in cooperation
with Focusrite, the D2 is based on the highly-ac-
claimed Red Range 2™dual EQ, designed by Ru-
pert Neve.
D2 features include:
Up to six simultaneous bands of EQ, includ-
ing: high-pass, low-shelf, low-mid peak, high-
mid peak, high-shelf, and low-pass filters
A highly accurate Cartesian graph that dis-
plays EQ curves in real-time as EQ parameters
are adjusted
Focusrite D2 Configurations
There are three configurations of the Focusrite
D2 plug-in, each designed to use a different
amount of your system’s DSP.
1–2 Band EQ
This module uses the least DSP. You can use up
to two filters simultaneously, depending on
which you enable. The high-pass, low-shelf, and
low-pass filters each utilize the entire module
and cannot be used in combination with an-
other filter. The low-mid peak, high-mid peak,
or high-shelf filters can be used in combination
with each other (up to two bands total).
4-Band EQ
This module uses more DSP. You can use up to
four filters simultaneously. Unlike the 1–2 Band
EQ, any combination of filters can be engaged,
up to a total of four bands.
6-Band EQ
This module uses the most DSP. You can use up
to six filters simultaneously. By default, the low-
pass and high-pass filters are in Bypass mode
when the 6-Band EQ is first opened.
Focusrite D2

Focusrite D2 and D3 Plug-ins Guide6
Adjusting Plug-in Parameters
You can adjust plug-in controls by dragging the
control’s slider or knob, or by typing a value into
the control’s text box. Additionally, some plug-
ins have switches that can be enabled by click-
ing on them.
To adjust a plug-in control:
1 Begin audio playback so that you can hear the
control changes in real time.
2 Adjust the controls of the plug-in for the effect
you want. Refer to “Editing Parameters Using a
Mouse” on page 6 and “Editing Parameters Us-
ing a Computer Keyboard” on page 6.
Closing the plug-in will save the most recent
changes.
Editing Parameters Using a Mouse
You can adjust rotary controls by dragging hori-
zontally or vertically. Parameter values increase
as you drag upward or to the right, and decrease
as you drag downward or to the left.
Keyboard Shortcuts
For finer adjustments, Control-drag (Win-
dows) or Command-drag (Mac) the control.
To return a control to its default value, Alt-
click (Windows) or Option-click (Mac) the con-
trol.
Editing Parameters Using a Computer
Keyboard
Some controls have text boxes that display the
current value of the parameter. You can edit the
numeric value of a parameter with your com-
puter keyboard.
If multiple Plug-in windows are open, Tab and
keyboard entry remain focused on the plug-in
that is the target window.
To change control values with a computer
keyboard:
1 Click the text box corresponding to the con-
trol that you want to adjust.
2 Change the value.
• To increase a value, press the Up Arrow on
your keyboard. To decrease a value, press
the Down Arrow on your keyboard.
– or –
• Type the desired value.
3 Do one of the following:
• Press Enter on the numeric keyboard to in-
put the value and remain in keyboard edit-
ing mode.
– or –
• Press Enter on the alpha keyboard (Win-
dows) or Return (Mac) to enter the value
and leave keyboard editing mode.
Adjusting rotary controls
In fields that support values in kilohertz,
typing “k” after a number value will multi-
ply the value by 1,000. For example, type
“8k” to enter a value of 8,000.
To move forward through the different con-
trol fields, press the Tab key. To move back-
ward, press Shift+Tab.

Chapter 3: Focusrite D2 7
Editing Parameters Using a Scroll
Wheel
Some controls have text boxes that display the
current value of the parameter. You can edit the
numeric value of a parameter using a scroll
wheel.
To change control values using a scroll wheel:
1 Click the text box corresponding to the con-
trol that you want to adjust.
2 To increase a value, scroll up with the scroll
wheel. To decrease a value, scroll down with the
scroll wheel.
Toggling Switches
To toggle a switch:
Click the switch.
D2 Parameters
Input Level
Input Level allows you to attenuate signal input
level to the D2. The range of this control is from
–18dBto+12dB.
When you use D2 in stereo, each channel has its
own separate Input Level knob. To adjust input
levels for both channels simultaneously, select
the Link button, then drag either knob.
Output Level
Output Level allows you to adjust the overall
output gain. The range of this control is from
–18 dB to +12 dB.
When you use the D2 plug-in in stereo, each
channel has its own separate output level knob.
To adjust output levels for both channels simul-
taneously, select the Link button.
Meters
The D2’s high-resolution plasma-style meters
indicate signal levels and detect clipping at the
input, algorithm, or output stage. When D2 is
used in stereo, two meters appear, one for each
channel.
A Clip Indicator is located above each meter. It
indicates clipping by increasing its brightness as
successive samples are clipped. Click the Clip In-
dicator to clear it. Alt-clicking (Windows) or Op-
tion-clicking (Mac) clears both channels when
D2 is used in stereo.
input Level
Output Level
Meters (Stereo mode)

Focusrite D2 and D3 Plug-ins Guide8
Metering:
• Green = nominal levels.
• Yellow = pre-clipping at –6 below full scale
signal.
• Red = full scale signal (clipping).
The Cartesian Graph
The Cartesian Graph displays a visual represen-
tation of the current EQ settings. As you adjust
the parameters of any currently active filter, the
Cartesian Graph will plot the changes to the EQ
curve in real-time. If you are using D2 in stereo,
the Cartesian Graph displays the EQ curve for
the right channel in red and the left channel in
blue.
EQ Filter Controls
Each of the six different EQ filters has its own
controls and its own icon. The icons act as three-
state switches for enabling, disabling, or bypass-
ing the specific filter. The current state of a filter
is indicated by its color:
• White = enabled. In this state the filter is
active, audible, and using available DSP re-
sources.
• Black = disabled. In this state the filter is
not using any DSP resources and has no ef-
fect on audio.
• Gray = bypassed. In this state the filter is
not active, but is still using available DSP
resources. The effect of the filter is not au-
dible.
High-Pass Filter
The 18 dB/octave High-Pass Filter provides a ro-
tary control for adjusting the corner (cutoff) fre-
quency, variable from 20 Hz to 6.4 kHz.
The Plug-in window includes a Clip LED
that lights red to indicate plug-in clipping.
The Plug-in Clip LED follows Pro Tools set-
tings for clip indication. (For more informa-
tion, see the Pro Tools Reference Guide.)
Cartesian Graph
Alt-clicking (Windows) or Option-clicking
(Mac) the Cartesian Graph resets all D2 pa-
rameters to their default settings. To reset
parameters for both channels when in Stereo
mode, Alt-Shift-click (Windows) or Option-
Shift-click (Mac) the Cartesian Graph.
High-Pass Filter

Chapter 3: Focusrite D2 9
Low-Shelf Filter
The Low-Shelf Filter provides two rotary con-
trols: The upper rotary control adjusts the cor-
ner frequency, variable from 33 Hz to 460 Hz.
The lower rotary control adjusts the filter’s am-
plitude gain or attenuation. Amplitude range is
±15 dB from unity.
Low-Mid Peak Filter
The Low-Mid Peak Filter provides three rotary
controls. The upper rotary control adjusts the
center frequency, variable from 33 Hz to
6.4 kHz. The lower left rotary control adjusts the
filter’s amplitude gain or attenuation. Ampli-
tude range is ±15 dB from unity (utilizing a re-
ciprocal curve for both gain and attenuation).
The lower right rotary control adjusts filter “Q”
which is variable from 0.7 to 4.0.
High-Mid Peak Filter
The High-Mid Peak Filter provides three rotary
controls. The upper rotary control adjusts the
center frequency, variable from 120 Hz to
18 kHz. The lower left rotary control adjusts the
filter’s amplitude gain or attenuation. Ampli-
tude range is ±15 dB from unity (utilizing a re-
ciprocal curve for both gain and attenuation).
The lower right rotary control adjusts filter “Q”
which is variable from 0.7 to 4.0.
High-Shelf Filter
The High-Shelf Filter provides two rotary con-
trols: The upper rotary control adjusts the cor-
ner frequency, variable from 3.3 kHz to 18 kHz.
The lower rotary control adjusts the filter’s am-
plitude gain or attenuation. Amplitude range is
±15 dB from unity.
Low-Shelf Filter
Low-Mid Peak Filter
High-Mid Peak Filter
High-Shelf Filter

Focusrite D2 and D3 Plug-ins Guide10
Low-Pass Filter
The 18 dB/octave Low-Pass Filter provides a ro-
tary control for adjusting the filter’s corner cut-
off frequency, variable from 100 Hz to 18 kHz.
Enabling, Disabling and Bypassing
EQ Filters
You can enable, disable, or bypass specific EQ
filters by clicking them.
To disable a filter:
Start key-click (Windows) or Control-click
(Mac) the EQ Filter icon. When disabled, the
icon is black.
To re-enable a filter:
Click the EQ filter icon. When enabled, the
icon is white.
To bypass a filter:
Click the EQ filter icon a second time. When
bypassed, the icon is grey.
Using D2 in Stereo
Because Focusrite D2 has a single set of Filter pa-
rameter knobs, when it is used in stereo, you
must select which channel, left or right, you
want to edit.
Use the Left Channel, Right Channel, and Link
buttons to do this. These controls only appear
when D2 is used in stereo.
Left Channel and Right Channel Buttons
The Left Channel and Right Channel buttons
are used to select which channel is active for pa-
rameter editing.
Selecting the Left Channel button activates the
left channel for editing. Any changes made to
EQ parameters will affect the left channel of the
stereo signal.
Selecting the Right Channel button activates the
right channel for editing. Any changes made to
EQ parameters will affect the right channel of
the stereo signal.
Low-Pass Filter
If you are using all available bands of the
1–2 Band or 4–Band EQ and want to
change filter types, you must disable one fil-
ter before you can enable a different one.
Left Channel, Right Channel, and Link buttons

Chapter 3: Focusrite D2 11
Link Button
Selecting the Link button allows you adjust pa-
rameters for both channels simultaneously. By
default, Link mode is enabled so that you can
easily maintain parity between the parameter
settings for both channels.
You can also use Link mode to help you main-
tain a relative offset between parameters settings
on the two channels.
Maintaining an offset:
1 Deselect the Link button.
2 Select the desired channel button, left or right,
and adjust the parameters for that channel.
3 Select Link mode and adjust the same param-
eters for the opposite channel. D2 will maintain
the relative offset between the parameter set-
tings for the two channels.
Alt-click (Windows) or Option-click (Mac)
while linking channels with offsets to copy
the parameters of the active channel to the
opposite channel (including input and out-
put levels).

Focusrite D2 and D3 Plug-ins Guide12
