Quick Installation Guide
Video Wall Decoder
VD Series
VD-0025/ VD-0036/ VD-0049/ VD-0064
Quality Service Group
1.0.0.1
Information in this document is subject to change without notice.
© Copyright 2014, DIGIEVER Corporation. All rights reserved

Quick Installation Guide
Thank you for choosing DIGIEVER Video Wall Decoder. The following quick
guide will lead you to complete the installation and configuration of the Video
Wall Decoder. Please read the following description carefully.
Pre-installation Notice
Please make sure the following items are prepared for installing DIGIEVER
decoder Video Wall Decoder Series.
Network connection
Configuration of network cameras and Video Wall Decoder
Compatibility of network cameras
Computer for configuring Video Wall Decoder
*For camera compatibility, please check our website
http://www.digiever.com/support/compatibility.php
Remote PC System Requirements
The following are minimum system requirements for a personal computer to
operate the Video Wall Decoder.
Operating System
Microsoft®Windows®Vista/ 7/ 8 (32 and 64-bit)
Browser (32-bit) in Windows OS
Microsoft® Internet Explorer 8.0 or above, Chrome 31.0.1650.57m or
above, Firefox 25 or above, Opera 17.0 or above, Safari5.1.7 or above

CD-ROM Drive
It is necessary to read the operating instructions in the provided CD-ROM.

Adobe Reader
It is necessary to read the operating instructions in the provided CD-ROM.
The audio function will not work if a sound card is not installed in the PC.
Audio may be interrupted depending on network traffic.
1

Package Contents
Video Wall Decoder Power Cord
Power adaptor
Ethernet Cable

Product CD
Stand
Remote Controller (optional)
2

Hardware Description
Front View Rear View
1. Power button
2. USB 2.0 x 2
3. Audio output(reserved)
4. Audio mic input(reserved)
5. USB 2.0 x 2
6. Gigabit LAN x 1
7. HDMI x 1
8. eSATA x 1(reserved)
9. DVI-I
10. USB 3.0 x 2
11. Power connector
3

Connection to DIGIEVER Video Wall Decoder
Please insert the product CD-ROM on a PC to install EZ Search. Finally, you
can start Quick Configuration on a web page.
Install EZ Search for finding video wall decoder in the network.
Connect to the configured video wall decoder
1. Install EZ Search
Please execute the product CD and click “Install EZ Search.”
Follow the instructions to install and the EZ Search will run automatically.
2. Connect to Video Wall Decoder
After setting the EZ Search, the user can connect to the monitoring page by
the following two options:
4

1) EZ Search
Once you click “Connect” or double click the selected video wall
decoder list, the IE browser will pop up automatically.
2) IE browser
Log in to the system by entering its IP address in web browser.
Note: There are 2 methods to set network:
Obtain an IP address automatically (Video Wall Decoder Default)
Obtain an available dynamic IP address assigned by a DHCP server. If
this option is selected, Video wall decoder will automatically obtain an
available dynamic IP address from the DHCP server once it connects to
the network.
Specify an IP address
If there is no DHCP server existing in network environments, the static IP
address will be given as 192.168.1.245. It should be adaptable in most
networking environment, and user can choose to maintain the default IP
address or change it in this page. However, it’s recommended setting
different IP address of video wall decoder if there is more than one video
wall decoder in the same LAN.
5

3. Enter a user name and password
Log in the video wall decoder with the default administer account (user
name: admin, password: admin).
Quick configuration
When you login Video Wall Decoder the system will direct you to set Quick
Configuration in 4 steps. Follow the instructions of the Overview of wizard to
complete the system setup.
Once the five steps of Quick Configuration are complete, you can click “Start”
to start liveview at local side.
For further details of Quick Configuration, please refer to the user manual.
When the live view is displayed, you have successfully installed the video wall
decoder. Congratulations!
