FP-770T User's Manual i
1) It is forbidden to copy the contents of this manual, in whole or in part, except for the
user's personal use, without the express permission of the Digital Electronics Corporation
of Japan.
2) The information provided in this manual is subject to change without notice.
3) This manual has been written with care and attention to detail; however, should you find
any errors or omissions, please contact the Digital Electronics Corporation and inform
them of your findings.
4) Please be aware that the Digital Electronics Corporation is not responsible for any dam-
ages resulting from the use of our products, regardless of article 3 above.
<Note>
Thank you for purchasing Digital's TFT type color display panel, the 'FP-770T'(hereafter referred
to as "the FP").
The FP is a TFT type color liquid crystal display monitor for IBM-PC compatible personal
computers (VGA, XGA and SVGA modes).
Please read this manual completely to insure the correct use and complete understanding of the
FP's functions.
The FP's analog interface is designed to comply with VESA standards. Please be aware that this
unit may not be able to be connected with devices using nonstandard VGA interfaces. For further
information,pleaserefertothischapter's"PCConnectionNotes"section.
Preface
All Company/Manufacturer names used in this manual are the registered trademarks of their
respective companies.
© Copyright 1998 Digital Electronics Corporation

ii FP-770T User's Manual
This section describes the safety precautions necessary for the correct use of the FP.
Please keep this manual close at hand and refer to it when necessary.
■!Safety Symbol Types
The following symbols are used throughout this manual to ensure the safe use of the
FP. Please be sure to follow all instructions given since they explain important
safety points.
Safety Symbols
This mark warns of a situation that could cause either serious or
fatal injury if the instruction is ignored and/or the unit is used
incorrectly.
This mark warns of a situation that could cause either personal injury
or property damage if the instruction is ignored and/or the unit is
used incorrectly.
!!
!!
!
Warning
Caution
!!
!!
!

FP-770T User's Manual iii
For the safe use of this unit, be sure to follow these guidelines:
"Because of the danger of electrical shock, be sure to unplug (disconnect) the power
cable from the FP before plugging the cable's other end into the power supply.
"Do not use power in excess of the unit's specified voltage range since it may cause a fire,
anelectricalshock,or damage the unit.
"Because the FP contains high voltage parts, an electric shock can occur when disassem-
blingtheunit.Therefore,besuretoalwaysunplugtheunitbeforedisassemblingit.
"Do not modify the FP in any way, since it may cause either a fire or an electrical shock.
"Whenchangingthebacklight,besuretoturnofftheunit'spowerfirst,topreventanelectric
shock.
"Donotusetouchpanelkeystoperformlife-threateningorvitallyimportantsafetyfunctions.
Use separate hardware switches to provide machine emergency stop or other safety
functions.
"Ifsubstantialamountsofmetallicdust,waterorliquidsentertheFP'scase,turnofftheFP's
powerimmediately, unplugthepower cord, and contact yourlocalFPdistributor.
"Wheninstalling the FP,besuretofollowtheinstructions given in “Chapter 3. Installation
andWiring,"toinsureitisperformedcorrectly.
"DonotusetheFPinanenvironment with flammable gas since it may causean
explosion.
"The FP is not intended for applications requiring extremely-high reliability and safety,
such as aircraft equipment, aerospace equipment, central communication equipment,
nuclear control equipment or life-supporting medical equipment.
"When the FP is used for equipment that must provide high reliability and safety in its
functions and accuracy, the entire system that uses the FP must have its safety features
designed to include redundancy and error-prevention.
Examples of such usage are: transportation (trains, automobiles, ships, etc.), disaster/
crime-prevention devices, numerous safety devices, and medical equipment not related
to life support.
Safety Instructions
!!
!!
!
Warning

iv FP-770T User's Manual
Do not press the screen's touch surface too strongly with either your finger or a hard
object, since the touch surface may be damaged.
Do not press on the touch panel's face with sharp objects, such as a mechanical
pencil or a screwdriver, since it can damage the panel surface.
Whenthesurfaceofthe displayscreenbecomesdirtyorsmudged,clean thedisplaywith
acloth soaked in a neutral detergent. Donot use paint thinner or organic solvent.
AvoidusingorstoringtheFPindirectsunlight,excessivelydustyordirtyenvironments,or
wherechemicals or their vapors are present in the air.
PleaseavoidusingtheFPinareaswheresudden,largechangesintemperaturemayoccur.
Thesechangescancausecondensationtoforminsidetheunit,possiblycausinganaccident.
AvoidrestrictingtheFP'snaturalventilation,orstoringandusingtheFPinanenvironment
that will raise the FP's internal temperature above its designated limits.
Do not use or store the FP in areas where chemical vapors are present or where
chemicals may come into contact the unit.
There are minute grid-points on the LCD surface. These points are not defects.
Thedisplayedcolor will look different when viewed from an angle outside thespecified
viewangle. This phenomenonis a commonattribute of LCD'sand is nota defect.
Displaying a single screen image for long periods of time can cause an afterimage to
remain on the screen. To correct this, turn the unit OFF for a short period (5 to 10
minutes), then ON again. This phenomenon is a common attribute of the LCDs, and
notadefect. Toprevent the creation of an afterimage, you can change the screen display
periodicallytopreventthedisplayingofasingleimageforalongperiodoftime.
For the correct use of this unit, please follow these guidelines:
Notes on the FP's Liquid Crystal Display (LCD)
Safety Instructions
Caution
!!
!!
!

FP-770T User's Manual v
UL Application Notes
The FP-770 is a (c)UL 1950 recognized product. (UL File No.190533). Please
pay special attention to the following instructions when applying for UL
approval for machinery which includes one of these FP units built in.
Machinery with an FP unit mounted in it requires UL inspection for the
combination of the FP and the machinery.
The FP-770T conforms as a component to the following standards:
UL 1950, Third Edition, dated April 30, 1998 (Standard for Safety of
Information Technology Equipment, including Electrical Business Equip-
ment)
CSA-C22.2 No. 950-M95 (Standard for Safety of Information Technol-
ogy Equipment, including Electrical Business Equipment)
FP-770T (UL Registration Model No.: 0880047)
If the FP is installed so as to cool itself naturally, be sure to install the
unit in a vertical position. Also, be sure that the FP is installed so that it
is at least 100mm away from any adjacent structures or devices. If these
requirements are not met, the heat generated by the PL’s internal compo-
nents may cause the unit to fail to meet UL standard requirements.
CE Marking Notes
The FP-770T is a CE marked, EC compliant product.
<Complies with the following EC Directives>
EMC Directives 89/336/EEC, 92/31/EEC, 93/68/EEC
Low Voltage Directives 73/23/EEC, 93/68/EEC
<Complies with the following Standards>
Safety
EN60950/A2:1993), VDE 0805/A2:1994
EMI (EN50081-2)
EN55022:1994(Class A), EN61000-3-2:1995, EN61000-3-3:1995
EMS (EN50082-2)
EN61000-4-2 :1995, EN61000-4-4:1995, EN61000-4-5:1995,
EN61000-4-11:1995, ENV50204:1995, ENV50140:1993,
ENV50141:1993

vi FP-770T User's Manual
Table of Contents
Preface ....................................................................................................................................... i
For the Safe And Correct Use of this Unit .....................................................................................ii
Warning: Safety Instructions..........................................................................................................iii
Caution: Safety Instructions ........................................................................................................... iv
UL Application/CE Marking Notes.................................................................................................v
Table of Contents .............................................................................................................................vi
PC Connection Notes .....................................................................................................................viii
FP-770T Features.............................................................................................................................ix
Package Contents .............................................................................................................................. x
Manual Symbol Information ..........................................................................................................xi
Chapter 1—Introduction
1-1 Connecting the FP to a PC.....................................................................................................1-1
1-2 Optional Equipment ................................................................................................................1-3
Chapter 2—Specifications
2-1 General Specifications ............................................................................................................2-1
1 Electrical Specifications .......................................................................................................2-1
2 Environment Specifications ..................................................................................................2-1
3 Structural Specifications .......................................................................................................2-2
2-2 Functional Specifications .......................................................................................................2-2
2-3 Interface Specifications ..........................................................................................................2-3
1 Analog RGB Interface ..........................................................................................................2-3
2 Serial Interface ......................................................................................................................2-4
3 Keyboard Interface................................................................................................................2-5
4 Mouse Interface ....................................................................................................................2-5
5 PC Interface............................................................................................................................2-5
2-4 Option Cable Pin Diagrams...................................................................................................2-6
2-5 Names and Descriptions of FP Parts ...................................................................................2-8
2-6 Flat Panel (FP) Dimensions ..................................................................................................2-9
1 FP-770T External Dimensions..............................................................................................2-9
2 Installation Brackets ...........................................................................................................2-10
3 FP Installation Hole Dimensions ........................................................................................2-10

FP-770T User's Manual vii
Chapter 3—Installation and Wiring
3-1 Installation............................................................................................................................ 3-1
1 Installation Procedures ..........................................................................................................3-1
3-2 Wiring .................................................................................................................................. 3-4
1 Power Cable Connection Precautions .................................................................................. 3-4
2 FP Power Cable Connection Procedures .............................................................................3-6
3 FP Power Supply Connection Procedures............................................................................3-7
4 FP Grounding Cautions ......................................................................................................... 3-7
5 FP Input/Output Signal Line Cautions .................................................................................. 3-7
3-3 Setup of Operation Mode and Positioning of Display ................................................... 3-8
1 Operation Mode Setup and Adjustment................................................................................3-8
Chapter 4—Touch Panel Commands
4-1 Command List........................................................................................................................ 4-1
4-2 Touch Panel Data Input........................................................................................................ 4-3
4-3 Boot-up Initialization ............................................................................................................ 4-7
Chapter 5—Troubleshooting
5-1 Troubleshooting .................................................................................................................... 5-1
1 Possible Device Problems.....................................................................................................5-1
2 No Display ............................................................................................................................5-2
3 The Touch Panel Does Not Function....................................................................................5-4
Chapter 6—Maintenance
6-1 Cleaning the FP's Display.................................................................................................... 6-1
6-2 Periodic Check-Up ............................................................................................................... 6-2
6-3 Changing the Backlight........................................................................................................ 6-3

viii FP-770T User's Manual
VESA standard
display mode Size Horizontal frequency Vertical frequency Dot clock frequency
VGA 640 x 480 31.5 kHz 60 Hz 25.175 MHz ± 0.4 %
37.9 kHz 72 Hz 31.500 MHz ± 0.4 %
37.5 kHz 75 Hz 31.500 MHz ± 0.4 %
SVGA 800 x 600 35.1 kHz 56 Hz 36.000 MHz ± 0.4 %
37.9 kHz 60 Hz 40.000 MHz ± 0.4 %
48.1 kHz 72 Hz 50.000 MHz ± 0.4 %
46.9 kHz 75 Hz 49.500 MHz ± 0.4 %
XGA 1024x 768 48.4 kHz 60 Hz 65.000 MHz ± 0.4 %
56.5 kHz 70 Hz 75.000 MHz ± 0.4 %
60.0 kHz 75 Hz 78.750 MHz ± 0.4 %
US Text 720 x 400 31.5 kHz 70 Hz 28.300 MHz ± 0.4 %
The FP's analog RGB interface offers normal display performance within the
following ranges:
Since some commercially-available video interface equipment also accomodates
tracking ranges in excess of those shown above, they may not offer normal display
performance when used with the PC. Before using a video interface, be sure to
check its specifications.
Also, even if the same type personal computer is used to transfer data to the PC,
the above mentioned problems can also occur when the PC's video board is
replaced.
The touch panel's PS/2 mouse connector can be used with equipment conforming
to PS/2 mouse standards, however specified performance cannot be guaranteed
with every PC and mouse combination.
Also, certain restrictions may apply to the touch panel's PS/2 mouse connector
depending on the OS being used.
If an extended mouse/keyboard cable is connected through the FP, the FP may not
operate normally, depending on the combination of the host and mouse/keyboard
or its cable length. In such a case, connect the mouse/keyboard cable directly to
thehost.
While the FP('s OS) is starting up, please do not touch the screen's touch panel.
PC Connection Notes

FP-770T User's Manual ix
•Large-sized, high-quality color LCD
The monitor uses a 13.8 inch TFT type color LCD, and the 260,000 display colors
allow a wide variety of screen designs. The features of this display are easy-to-
read images and text, wide view angle, high contrast, and fast response.
•FP's large-sized display is compatible with the XGA mode
The FP is compatible with XGA mode, allowing a large variety of information to
be displayed.
•Display mode is automatically selected (Multi-scan)
The FP's multi-scan feature automatically selects the display mode, according to
the host’s display mode (VGA, SVGA, XGA or US Test).
•PC data can be displayed on the FP
Since the FP is connected to the host through an analog RGB interface, it can also
be easily connected to a personal computer and used as a display.
For the available display modes, see “PC Connection Notes”)
•Rear-mounting type is designed to be built into other equipment
The slim and compact body is designed specifically to be built into machine cabinets
and panels. Since the FP can be easily used with other equipment, it can be used as
a monitor for your PC-based FA or PA system. Also, the FP front panel's moisture
resistant gasket provides a dust-proof and drip-proof seal between the FP's front
face and the installation panel. Thus, the FP can be used even in harsh industrial
environments.
• Touch panel can be operated while PLC data is monitored (Standard feature)
The FP's touch panel is standard equipment and is suitable for monitoring systems
that require touch operations. Also, the FP provides two types of interfaces between
the touch panel and the host: an RS-232C interface and PS/2 output via the mouse
port. These interfaces can be selected according to your system configuration needs.
FP-770T Features
Reference

xFP-770T User's Manual
The FP's packing box contains the items listed below. Please check to be sure each is included
and is not damaged.
FP unit (FP770-T41)
3.5 inch floppy disk *1 Mounting brackets (12)
Package Contents
Pro-face
Digital
FP-770T User's Manual
Pro-face
FP770T
User’s Manual
Theseitemshaveallbeen carefullypackedwithspecial attentiontoproductquality.
However, should you find any item(s) damaged or missing, please contact your local
distributor immediately for prompt service.
Moisture-resistant gasket Function key sticker
When creating function keys, attach
this sticker as shown below.
*1 For description and usage of the application programs stored in the floppy disk, see
that disk's English “READM_E.DOC” file.
Attach stickers
here

FP-770T User's Manual xi
Symbol Information
The list below describes the symbols used in this manual.
Symbol Meaning
Used to indicate situations where severe bodily injury, death or major
machine damage can occur.
Used to indicate situations where slight bodily injury or machine
damage can occur.
Used to indicate important information or procedures that must be
followed for correct and risk-free software/device operation.
*1 Footnote marker used to provide useful or important supplemental
information.
1) , 2) Indicates steps in a procedure. Be sure to perform these steps in the
order given.
Used to refer to useful or important supplemental information.
Used to provide useful or important supplemental information.
GP Screen
Editor Indicates the GP-PRO/PBIII or GP-PRO/PBIII for Windows 95 screen
editor software.
PLC Abbreviation for Programmable Logic Controller.
n:1 Indicates a multi-link type of connection is used.
!!
!!
!
Important
Reference
!!
!!
!
Warning
Caution
!!
!!
!
Note:

xii FP-770T User's Manual
MEMO

1-1
FP-770T User's Manual
The following diagram illustrates the connection options available between the FP
and a PC.
Chapter 1
Introduction
1. Connecting the FP to a PC
2. Optional Equipment
PS/2compatible keyboard
(Commercially available)
Microsoft Mouse
(Commercially available type)
Mouse/Keyboard cable
(Keyboard output)
FP-CK01
Mouse/Keyboard cable
(Mouse output)
FP-CK01
SIO cable (RS-232C)
FP61V-IS00-O
RGB cable
(Analog RGB input)
FP-CV00, FP-CV01
DOS compatible
personalcomputer
#
$
%
&
'
(
)
*
+
FP Unit
(FP770-T41)
For a description of each reference no. used (', etc.) refer to
the next page (page 1–2)
Reference
,
1-1 Connecting the FP to a PC

Introduction
1-2 FP-770T User's Manual
Display Protection Sheets (5 sheets/set)
FP77-COVER-5P
Optional Maintenance Parts
These parts are included in
either the FP or its package as
standard equipment, and are
also optionally available for FP
maintenance.
Optional Parts
(Sold separately)
Backlight (2 lights/set)
FP770T-BL00-MS
Mounting Brackets (4 brackets/set)
GP070-AT00-MS
Moisture-Resistant Gasket
FP77-WP00-MS
Page 1–1 Item Description
FP interface
,KEYBOARD/Keyboard
#MOUSE/Mouse
$KEYBOARD/PC
%MOUSE/PC
&RS-232C connector
'Analog RGB I/F connector
2-5 Names and Functions of FP Parts
Personal computer interface
(Keyboard interface
)Mouseinterface
*Serialinterface
+AnalogRGBinterface
Reference

Introduction
1-3FP-770T User's Manual
1-2 Optional Equipment
All optional equipment listed below are products of Digital Electronics Corp.
Item Name Model No. Description
SIO cable FP61V-IS00-O
Serial interface cable used for
transmission of touch panel data
between the FP and various hosts (PCs),
and for the transmission of commands to
the FP. (5 m)
Compatible with PC/AT (D-sub 9-pin
female connector) computers
RGB cable FP-CV00
Analog RGB interface cable used to
output image signals from various host
(PCs) to the FP. (2.5 m)
Compatible with analog RGB interface (D-
sub 15-pin male connector).
RGB cable FP-CV01
Analog RGB interface cable used to
output image signals from various host
(PCs) to the FP. (5 m)
Compatible with analog RGB interface (D-
sub 15-pin male connector).
Interface
Mouse/Keyboard
cable FP-CK01
Used to connect a mouse or keyboard
between the host and the FP. (2.5 m)
Compatible with PS-2 (mini DIN 4-pin
male connector) devices
Backlight FP770T-BL00-MS Replacement Backlights (2 lights/set)
Mounting
brackets GP070-AT00-MS Used to secure the FP to its installation panel. (4 brackets/set)
Maintenance
Parts Moisture resistant
gasket FP77-WP00-MS Used to prevent moisture from entering
the FP’s chassis. Same gasket as
originally included with the FP.
Optional
Parts Display protection sheets FP77-COVER-5P
Disposable sheets that protect the display
from dust and dirt. The touch panel can be
used when one of these sheets is
attached. (5 sheets/set)

Introduction
1-4 FP-770T User's Manual
MEMO

2-1-2 Environment Specifications
Chapter 2
Specifications
1. General Specifications 4. Option Cable Pin Diagrams
2. Functional Specifications 5. Names and Descriptions of FP Parts
3. Interface Specifications 6. Flat Panel (FP) Dimensions
This chapter includes general specifications, functional specifications, interface
specifications, and part names and dimensions of the FP.
FP-770T User's Manual 2-1
Operating
Temperature 0 to 40 degrees Celsius
Storage
Temperature - 10 to 60 degrees Celsius
Ambient Humidity 30 to 85 % RH (non-condensing)
Vibration
Resistance 2 Gs at 10 to 25 Hz (X, Y, Z directions: 30 minutes each)
Atmosphere Must be free of corrosive gas
Noise voltage : 1500 Vp-p
Pulse length : 50 ns/500 ns/ 1 µ s
Noise
Arise time (rise/fall): 1 ns
Grounding Meets Class 3 requirements
Rating*1
(with front panel closed) Equivalent to IP65f (JEM1030)
Input Voltage AC 85 V to 265 V 50/60 Hz
Power Consumption Less than 65 VA
Allowable Power
Failure Within 20 ms
Maximum Voltage AC 1500 V 20 mA 1 minute
(between the live wire and grounding terminals)
Isolation Resistance DC 500 V greater than 10 MΩ
(between the live wire and grounding terminals)
2-1-1 Electrical Specifications
2-1 General Specifications
*1 (See the next page's note)

FP-770T User's Manual
Specifications
2-2
2-2 Functional Specifications
Display Media TFT color LCD
Display Colors 260,000
Contrast Adjustment Possible via adjustment menu
Dot Pitch (mm) 0.273 W × 0.273 H
Touch Panel
Resolution 1024 ×1024
Display Area (mm) 279 W ×209 H
Display Mode
(selected with a
switch)
640 ×480 (VGA)
720 ×400 (US Text)
800 ×600 (SVGA)
1024 ×768 (XGA)
Interfaces Analog RGB input, RS-232C input,
PS/2 input and output ( both mouse and keyboard)
Backlight
CFL
(under continuous 24 hour operation, lifespan = 10,000
hours)
The front face of the GP unit, installed in a solid panel, has been tested using condi-
tions equivalent to the standard shown in the specification . Even though the GP
unit’s level of resistance is equivalent to the standard, oils that should have no effect
on the GP can possibly harm the unit. This can occur in areas where either vaporized
oils are present, or where low viscosity cutting oils are allowed to adhere to the unit
for long periods of time. If the GP’s front face protection sheet becomes peeled off,
these conditions can lead to the ingress of oil into the GP and separate protection
measures are suggested. Also, if non-approved oils are present, it may cause deforma-
tion or corrosion of the front panel’s plastic cover. Therefore, prior to installing the
GP be sure to confirm the type of conditions that will be present in the GP’s operating
environment.
If the installation gasket is used for a long period of time, or if the unit and its gasket
are removed from the panel, the original level of the protection cannot be guaranteed.
To maintain the original protection level, you need to replace the installation gasket
regularly.
2-1-3 Structural Specifications
External Dimensions
(mm)
405 W × 350 H × 75 D
(Unit only, including rear projections)
Weight 6.5 kg or less (Unit only)
Cooling System Natural air circulation
*1 (Continued from previous page)

FP-770T User's Manual
Specifications
2-3
2-3-1 Analog RGB Interface
2-3 Interface Specifications
Pin Assignments and Signal Names for Analog RGB Connector
Connector : Mini Dsub 15 pin BIOS
Connector set screw : Inch type (4-40)
Cable : Digital Electronic Corporation RGB cable
(FP61V-IV00-0) (conforms to VGA standards)
Please use Digital's optional cable. If any other cable is used, due to
possible noise interference, Digiltal cannot guarantee the FP will
perform as specified.
Input signal type Analog RGB
Input signal
characteristics
Image signal : analog RGB
Synchronous signal: TTL level, negative true or positive true
Scanning type : non-interlaced
Adjustment
features
Flicker adjustment (PHASE, CLOCK)
Contrast adjustment
BRIGHT (Brightness) adjustment
Color adjustment (R,G,B)
Horizontal display positioning
Vertical display positioning
Pin
No. Signal Name Condition Pin Location
1Analog R R signal input
2Analog G G signal input
3Analog B B signal input
4Reserved NC (reserved for input)
5Digital Ground Digital signal GND
6Return R R signal GND
7Return G G signal GND
8Return B B signal GND
9Reserved NC (reserved for input)
10 Digital Ground Digital signal GND
11 Reserved NC (reserved for input)
12 Reserved NC (reserved for input)
13 H. SYNC Horizontal synchronous
signal input
14 V. SYNC Vertical synchronous
signal input
15 Reserved NC (reserved for input)
VESA standard
display mode Size Horizontal frequency Vertical frequency Dot clock frequency
VGA 640 × 480 31.5 kHz 60 Hz 25.175MHz ± 0.4 %
37.9 kHz 72 Hz 31.500MHz ± 0.4 %
37.5 kHz 75 Hz 31.500MHz ± 0.4 %
SVGA 800 × 600 35.1 kHz 56 Hz 36.000MHz ± 0.4%
37.9 kHz 60 Hz 40.000MHz ± 0.4 %
48.1 kHz 72 Hz 50.000MHz ± 0.4 %
46.9 kHz 75 Hz 49.500MHz ± 0.4 %
XGA 48.4 kHz 60 Hz 65.000MHz ± 0.4 %
56.5 kHz 70 Hz 75.000MHz ± 0.4 %
1024
× 768 60.0 kHz 75 Hz 78.750MHz ± 0.4 %
US Text 720 × 400 31.5 kHz 70 Hz 28.300MHz ± 0.4 %
!!
!!
!
Important

FP-770T User's Manual
Specifications
2-4
2-3-2 Serial Interface
Pin Assignments and Signal Names for Serial Interface Connector
Connector : Dsub 9 pin female
Connector set screw :Inch type (4-40)
Cable : Digital Electronic Corporation SI0 cable (FP61V-IS00-0)
Serial Interface
Baud rate : 9600 bps
Data length : 8 bits
Parity : None
Stop bit : 1
Pin
No. Signal Name Condition Pin Location
1CD Carrier Detect (FP –> Host)
2RD Receive Data (FP –> Host)
3SD Send Data (FP <– Host)
4DTR Data Terminal Ready (FP <– Host)
5GND Ground
6DSR Data Set Ready(FP –> Host)
7RS Request to Send (FP <– Host)
8CS Clear to Send (FP –> Host)
9NC No connection
1
5
6
9
Signal Names
Signal names used for the FP's serial interface are designed to match the
pin order used on most PC serial interfaces, so that a straight cable can be
used to connect the two. Therefore, connect each pin's signal to the same
signal name on the PC connector.
For example, pin #2 'RD' should be connected to the 'RD' input terminal
on the FP's connector.
Refertosection "2-4 Option CablePinDiagrams" for information abouteach
signal'sdirection.
