Digital Noise Reduction STAR LIGHT ES-6030ESHDV23712 User manual

STAR LIGHT SERIES VANDAL PROOF DOME
ES-6030ESHDV23712
ES-6030SHDVM23012
ES-6030SHCVM23012
OPERATING MANUAL
Warning: To prevent fire or electric shock hazard, do not expose
the appliance to rain or moisture
Star Light IR Vandal Proof
Dome
Star Light Vandal Proof Dome

-2 -
General
The vandal dome series offers a complete range from basic 420TVL varifocal
type to the flagship model that comes in 540TVL, DNR function and built in IR
LEDs with ICR D/N varifocal lens. The sophisticated mechanical design
enhanced the accessibility and conveniency in terms of installation. Sturdy and
IP66 enclosure ensures the camera to stay in best condition even under most
critical environment
This color CCD video camera employs a 1/3 inch charge coupled device
solid-state imaging device with 470/410 k or 310/270k picture elements, This
unit is equipped with a newly developed DNR DSP (Digital Signal Processor)
for processing the video signal.
The DNR function is a newly developed technology which suppressed all
significant noise while AGC is activated. So the camera is able to deliver
smooth and more even noise picture that enhanced readability and saved
video signal transmission traffic
Features(Day and Night ICR Series)
*420/540TV Lines resolution, providing fine, crisp and vivid high-resolution
* Advanced digital noise reduction deliver low noise image under low lux
environment
* ICR D/N switching mechanism allows changing between color and
monochrome
* ICR D/N mode to work correctly with daytime (visible light) and nighttime
(invisible light)
* IR accuracy: vivid color performance in the daytime and sharp B/W image
with no focus shift in the nighttime
* Infrared light sensing responses wavelength from 700 to 1100nm
* Outstanding artwork & mechanism design, suitable for all installation
environments
* Heavy-duty, weather & vandal proof IP66
* Selectable lenses providing a wide range selection for different viewing
applications
* Built-in horizontal/ vertical adjusting mechanism for multi-dimensional
adjustment
* Advanced wide range Auto Tracing White Balance (ATW), automatically
adjusts the white balance according to the color temperature in the
environment
* Smart digital control Auto Back Light Compensation (BLC)
* Dynamic spherical Vari-focal A.I lens option to deliver sharp resolution

-3 -
* Simple & quick combination providing user-friendly installation &
maintenance
* Special design distortion-free acrylic vandal dome cover
* Outstanding signal to noise ratio better than 50dB
* Low power consumption and DC 12v AC 24V auto switching
Features(Standard Series)
* 420/540TV Lines resolution, providing fine, crisp and vivid high-resolution
* Advanced digital noise reduction deliver low noise image under low lux
environment
* Smart Optical Low Pass Filter (OLPF) switching mechanism allows changing
between color and monochrome
* D/N OLPF mode to work correctly with daytime (visible light) and nighttime
(invisible light)
* IR accuracy: vivid color performance in the daytime and sharp B/W image
with no focus shift in the nighttime
* Infrared light sensing responses wavelength from 700 to 1100nm
* Outstanding artwork & mechanism design, suitable for all installation
environments
* Heavy-duty, weather & vandal proof IP66
* Selectable lenses providing a wide range selection for different viewing
applications
* Built-in horizontal/ vertical adjusting mechanism for multi-dimensional
adjustment* Advanced wide range Auto Tracing White Balance (ATW),
automatically adjusts the white balance according to the color temperature in
the environment
* Smart digital control Auto Back Light Compensation (BLC)
* Dynamic spherical Vari-focal A.I lens option to deliver sharp resolution
* Simple & quick combination providing user-friendly installation &
maintenance
* Special design distortion-free acrylic vandal dome cover
* Outstanding signal to noise ratio better than 50dB
* Low power consumption and DC 12v AC 24V auto switching

-4 -
A
Name of Parts and Functions
A
B
C
D
E
F
I
G
G
J
H

-5 -
10
9
8
7
6
5
4
3
2
1
SENS-UP
IR ON
VIDEO
OFF
OFF
BLC OFF
ATW
AGC
AE
A.IRIS
OFF
OFF
COLOR
V-MIR
H-MIR
ON
AWB
OFF
FL
AE
7
6
5
4
3
2
1
SENS-UP
OFF
OFF
BLC OFF
ATW
AGC
A.IRIS
OFF
V-MIR
H-MIR
ON
AWB
OFF
AE
A. Camera
B. Bracket
C. Bottom housing
D. Vari-focal lens
E. Safety string
F. Upper housing
G. Screw hole
H. Cable hole
I. Led board
J. Control board
I. Power source: AC24V/DC12V (Non-polarity)Block Terminal
II. Video out
III. DC auto iris level adjustment
Adjusting DC drive auto iris lens driving level for
obtaining correct exposure light.
IV. RCA Video out
Installation Procedure
Step 1: Removing dome cover
Remove dome cover from the main body by
loosening the four dome cover mounting
screws.
The dome cover is fixed with tamperproof
screw. Loosen the four dome cover mounting
screws by using the supplied bit for
tamperproof screw.
ⅢⅢ
ⅣⅣ
Ⅰ
Ⅱ
Ⅰ
Ⅱ
Day and Night ICR Series Standard Series

-6 -
Step 2: Securing camera
Place mounting plate at position which the camera will be mounted and fix the
screw holder and then screw ∮4*26mm screws *4
Step 3: Cable arrangement
The right side
connection
should be
made by
qualified
service person
or system
installers. It is necessary to make sure that the cable hole has been protected
with waterproof installation process when the cable connect from the side by
metal pipe which is G1/2 format
Step 4: Adjust 3 Axes bracket while checking video from monitor
Installation friendly, allowing
service persons to check video
performance by simply
connecting a LCD monitor to
RCA jack
Loosen the tilt screw and then adjust the 3 Axis
bracket to get what position will you monitor
Mounting
∮4*26 screws *4

-7 -
Three axes mechanical
design allows 90° side views
for wall mount and furthest
angle for ceiling mount when
guarding a hall way.
Horizontal angle adjustment –by turning the platform to adjust the horizontal
angle180 degrees:360 degrees
Vertical angle adjustment –by turning the platforms to adjust the vertical
angle: 90 degrees
Step 5: Focus adjustment
Focus adjustment should be done with Step 4 at the
same time
The default setting for zoom position is WIDE
zStandard series focus adjustment
Loosen the zoom ring thumbscrew.
Turn the zoom ring to set to the desired
zoom.
Tighten the zoom ring thumbscrew.
Loosen the focus ring thumbscrew.
Turn the focus ring to set to the desired
focus.
Tighten the focus ring thumbscrew.
zDay and Night ICR focus adjustment
Loosen the zoom ring
thumbscrew.
Turn the zoom ring to set to
the desired zoom.
Tighten the zoom ring
thumbscrew.
Use the screw driver to loosen
the focus ring thumbscrew.
Turn the IR LED board to set
to the desired focus.
Use screw driver to tighten the
focus ring thumbscrew
Zoom ring Screw
Focus screw

-8 -
10
9
8
7
6
5
4
3
2
1
SENS-UP
IR ON
VIDEO
OFF
OFF
BLC OFF
ATW
AGC
AE
A.IRIS
OFF
OFF
COLOR
V-MIR
H-MIR
ON
AWB
OFF
FL
AE
7
6
5
4
3
2
1
SENS-UP
OFF
OFF
BLC OFF
ATW
AGC
A.IRIS
OFF
V-MIR
H-MIR
ON
AWB
OFF
AE
Step 6: Auto iris level adjustment
If using DC type auto-iris lens, you
will need to set the level volume
when shooting in the condition
described below.
zIf shooting simultaneously in
a dark room and through a
bright window
zIf the subject background is
extremely bright or dark
zIf the brightness of the picture
on the monitor is not correct
L (counterclockwise): To decrease the contrast
H(clockwise): To increase the contrast
Step 7: Function Setting
You can select the function according your condition the function description
please check below topic
Please check picture at right for factory default values whenever a camera
needs to be set to default again during installations
Day and Night ICR Series
Standard Series

-9 -
Step 8: Reinstall the dome cover to the
main body by tighten four dome cover
mounting screws
Auto Iris and AES Adjusting
If you would use Auto Electronic Shutter, please select this mode to control
exposure with the electronic shutter. The range of shutter speed is from 1/50
(1/60) set to 1/100,000 sec.
If you are using an auto iris lens, please select this mode, In this mode, the
shutter speed is fixed to 1/60 sec. for NTSC and 1/50 sec. for PAL.
Flickerless Function Adjusting
If camera is installed into different frequency, the flickerless function will reduce
the flicker of video. The shutter of NTSC is 1/100; shutter of PAL is 1/120.
When dip the switch at AES/FL side, the shutter will stay at Flickerless
situation.
Super AGC
If you are to install the camera for low lux environment, by switching to SAGC,
it will increase the camera sensitivity.
This mode is factory default setting SAGC.
White Balance Adjusting
AWB mode—Conventional auto white balance
This mode is factory default setting

-10 -
ATW mode—Advanced white balance
This mode is limited the color temperature into 2500°K-9000°K
Auto Back-light Compensation
This intelligent auto BLC is a newly developed digital light level control
system. It is activated automatically by screen histogram (contrast) and 225
area window weighting integration to control iris gain and white balance
simultaneous, so that the clear object with adequate light level can always be
optimized.
Central Window Weighted average Backlight compensation
This method is suited for cases where the main subject is fixed within the
screen.
Histogram Backlight Compensation
This method is suited for cases where the main subject moves about within
the screen.
The combination of two types Backlight makes it easier to arrange
Backlight compensation operation to match the imaging conditions and
installation location.
Mirror Adjusting
If the camera is installed in the elevators, lifts or viewing directly to the mirror,
please adjust to horizontal mirror mode.
If the camera must be installed upside down due to installation limit, please adjust to
vertical mirror mode.
Day and Night Adjusting
The smart day and night mechanical filter removable allows changing between
color and monochrome mode, and user could define the filter to work correctly
during day time (visible light) and night time (invisible light).
Day and Night Filter Automatic mode:
****Notice: The D/N should be at on position and make sure the AGC/Sense up
at SAGC / Sense up position. If the switchers are at NAGC/ Sense up off, the
filter will be stayed at day time position.
Sense Up Adjusting
Sense up stand for frame integration that is useful for the low lux environment,
the default sense up rate is 4x similar 1/15 sec.

-11 -
Specification (Standard Series)
Image device 1/3” interline transfer SONY Super HAD CCD
Signal system NTSC PAL NTSC PAL
Picture Elements 510 (H) × 492 (V) 500 (H) × 582 (V) 768 (H) × 494 (V) 752 (H) × 582 (V)
Scanning system 525 lines. 2:1 interlace 625 lines, 2:1 Interlace 525 lines. 2:1 interlace 625 lines, 2:1 Interlace
Sync system Internal Lock
Horizontal resolution 420 TV lines 540 TV lines
0.1 lux at F1.2 (30 IRE, AGC on)
Minimum Illumination
0.01lux at F1.2 (B/W mode, AGC on, sense up on)
AGC Auto Gain 36 dB
S/N ratio Better than 50dB
White balance control ATW (2500°K-9000°K)/AWB
Digital Noise
Reduction
Automatic
Gamma 0. 45
Function Dipswitch board in the dome
ALC/AE ALC(1/60 )/AES ALC(1/50 )/AES ALC(1/60 )/AES ALC(1/50 )/AES
AGC ON(36dB)/OFF
ATW/AWB ATW (2500°K-9000°K)/AWB
BLC ON/OFF
H mirror function ON/OFF
V mirror function ON/OFF
Sense up ON(4X)/OFF
IP ratio IP66
Video output signal Composite: 1.0 V p-p at 75Ωload
Lens selection 3.0-12mm F1.4-360 A.I lens (default)
Operating temperature -10°C to 50°C
Power source DC 12V / AC 24V
Power consumption max. average 110-120mA
Dimension ￠155x102(H)mm

-12 -
Specification (Day and Night ICR Series)
Image device 1/3” interline transfer SONY Super HAD CCD
Signal system NTSC PAL NTSC PAL
Picture Elements 510 (H) × 492 (V) 500 (H) × 582 (V) 768 (H) × 494 (V) 752 (H) × 582 (V)
Scanning system 525 lines. 2:1 interlace 625 lines, 2:1 Interlace 525 lines. 2:1 interlace 625 lines, 2:1 Interlace
Sync system Internal Lock/Line Lock
Horizontal resolution 420 TV lines 540 TV lines
0.1 lux at F1.2 (30 IRE, AGC on)
0.001lux at F1.2 (B/W mode, AGC on, sense up on)
Minimum Illumination
0 lux under infrared illumination
Infrared wavelength from 780 to 1100nm
D/N OLPF switch delay
time
5 ~ 8 sec
Color / Mono switching Chain reaction with D/N filter
Frame integration 4x factory default (2x~32x customization)
Infrared LED 35 PCS
IR distance range 20-25M
AGC Auto Gain 36 dB
S/N ratio Better than 50dB
White balance control ATW (2500°K-9000°K)/AWB
Digital Noise Reduction Automatic
Gamma 0. 45
Function Dipswitch board in the dome
ALC/AE ALC(1/60 )/AES ALC(1/50 )/AES ALC(1/60 )/AES ALC(1/50 )/AES
AGC ON(36dB)/OFF
ATW/AWB ATW(2500°K-9000°K)/AWB
BLC ON/OFF
H mirror function ON/OFF
V mirror function ON/OFF
Video / Color ON/OFF
Day/Night Control ON/OFF
Sense up ON(4X)/OFF
IP ratio IP66
Video output signal Composite: 1.0 V p-p at 75Ωload
Lens selection 3.0-12mm F1.6-360 A.I lens(default)
Operating temperature -10°C to 50°C
Power source DC 12V / AC 24V

-13 -
Power consumption max. average 350-360mA
Dimension ￠155x102(H)mm
Standard Accessories
Camera mounting screw*5
Tamperproof screw driver *1 User Manual
