Zircon StudSensor e50 User manual

When the full arrow
is first displayed,
the SpotLite®pointer
shines, and a steady
tone sounds, you have
located the edge of the
stud. Mark this spot.
Without releasing
Power button, continue
scanning beyond
marked spot until some
segments of the arrow
turn off. Slide unit in
reverse direction to
locate other edge
of stud.
Mark this second
spot. Middle of stud
is centered between
the two marks.
4. WIREWARNING®DETECTION
WireWarning®detection works continuously in
STUD SCAN and DEEPSCAN®modes. When live
AC voltage is detected, the WireWarning®indicator
will appear on the display. If scanning begins over
a live AC wire, the WireWarning®indicator will
flash continuously. Use extreme caution in these
circumstances or whenever live AC is present.
Electrical field locators may not
detect live AC wires if moisture
is present in the wall, or if wires are more than
2 in. (51 mm) from the scanned surface, in plastic
conduit or behind a plywood shear wall or
metallic wall covering. Do not rely exclusively on
the detector to locate items behind the scanned
surface. Use other information sources to help
1. INSTALLING THE BATTERY
Push in the battery
door tab at the bottom
of the tool and open
the door.
Insert a new 9-volt
battery, matching the
positive (+) and negative
(-) terminals to the icons
printed on the back. Snap
the battery into place and
replace the door.
2. SELECTING THE MODE
Move selector switch to the desired mode:
STUD SCAN for finding wood or metal studs or
DEEPSCAN®for finding studs behind walls more
than 3⁄4in. (19 mm) thick.
Unit will remain off if Power button is not depressed.
3. FINDING A STUD
Always scan for studs with the scanner placed
flat against the wall. Move the mode switch to
STUD SCAN, place the tool flat against the wall,
then press and hold the Power button. Wait for
beep to confirm calibration has completed before
moving scanner.
Continue to hold
the Power button,
then slowly slide unit
horizontally across
the wall, left or right.
As you begin to
approach a stud,
the arrow segments
will begin to turn on.
locate items before penetrating the surface.
Such additional sources include construction
plans, visible points of entry of pipes and
wiring into walls, such as in a basement, and in
standard 16 in. (41 cm) and 24 in. (61 cm) stud
spacing practices.
DO NOT ASSUME THERE
ARE NO LIVE ELECTRICAL
WIRES IN THE WALL. DO NOT TAKE ACTIONS
THAT COULD BE DANGEROUS IF THE WALL
CONTAINS A LIVE ELECTRICAL WIRE. ALWAYS
TURN OFF THE ELECTRICAL POWER, GAS,
AND WATER SUPPLIES BEFORE PENETRATING
A SURFACE. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN ELECTRIC
SHOCK, FIRE, AND/OR SERIOUS INJURY OR
PROPERTY DAMAGE.
5. OPERATING TIPS
For optimum scanning results:
         
the studs, and do not rotate the tool.
          
tilt, or press hard when slowly sliding across the
surface being scanned.
        
part of your body, on the surface being scanned.
       
or pipes to the wall surface, the scanner may
detect them in the same manner as studs.
Caution should always be used when nailing,
cutting, or drilling in walls, floors, and ceilings
that may contain these items.
You suspect electrical
wires, but do not
detect any.
Area of voltage
detection appears much
larger than actual wire
(AC only).
     
metallic wall coverings, plywood
shearwall, or other dense material,
or in conduit.
      
       
from surface may not be detected.
     
       
from each side of an actual
electrical wire.
All LCD icons
flash and the unit
beeps continuously.
        
over a stud.
     
      
(All these factors affect proper
calibration.)
       
wet for unit to operate.
          
press Power button, and start again.
          
wall, scanning over it to help slide unit more smoothly.
            
        
finger no higher than handgrips. Be careful not to
move your fingers after calibration.
          
perpendicular to the stud you’re trying to locate.
           
wallpapered wall, allow time to dry and try again.
Unable to detect studs
in STUD SCAN mode.
Middle LCD segment
doesn’t turn on or flash
in STUD SCAN mode.
          ®mode to locate the stud.
           
stud edge.
The TruCal®icon
turns on but, when
scanning, unit doesn’t
do anything else.
       
      ®mode
(DEEPSCAN®is lit), you may have
calibrated over a stud.
     ®strips on the back make
contact with wall.
         
Working in DEEPSCAN®
mode and can’t
detect studs.
      
stud. (The error condition is disabled
in DEEPSCAN®mode because it is
twice as sensitive as STUD SCAN.)
        
      
          
     ®strips on the back make
contact with wall.
Detects other objects
besides studs.
      
pipes may be near or touching back
surface of wall.
         
            
the same stud at several places directly above or
below the first scan area.
          
backing behind drywall, or thicker-than-normal walls.
            
detection, but turned off when working near electrical
wires.
Always turn off power when cutting, nailing, or
drilling near electrical wires.
           
edge of where wire was detected and scan again.
Always turn off power when cutting, nailing, or
drilling near electrical wires.
Probable Causes Solutions Situation
       
       
        1⁄in.
(38 mm) in width. Anything closer together
or a different width may not be a stud,
joist, or firebreak.
Always turn off the power when working near
electrical wires.
WORKING WITH DIFFERENT MATERIALS
StudSensor™      
walls only.
Note: Sensing depth and accuracy can vary due
to moisture, content of materials, wall texture,
and paint.
StudSensor™    
most sheet materials, including:
     ®mode)
    
     
    
       
thin piece of cardboard on ceiling and scan over
it to avoid damage to texturing)
StudSensor™     
materials such as:
   
   
    
        
take one week or longer to dry after application)
    
    
      
StudSensor™e50
Stud Finder
   SpotLite®Pointer
WireWarning®
Detection
Indicator
STUD SCAN
Mode
Power
Button
TruCal®Icon
DEEPSCAN®
Mode
Mode Switch
DeepScan, SpotLite, StudSensor, TruCal, WireWarning, and Zircon are registered trademarks or trademarks of Zircon Corporation.
Visit www.zircon.com/support for the most current instructions.
6. HELPFUL HINTS (See also number 5, Operating Tips)
The StudSensor™e  
scanning modes:
     
of wood and metal studs up to
3⁄4in. (19 mm) deep
 ®: Locates the edges
of wood and metal studs up to
1 1⁄in. (38 mm) deep
WireWarning®detection automatically
detects and alerts the user to live AC
wires in STUD SCAN and DEEPSCAN®
modes. When AC voltage is detected,
the AC WireWarning®icon will be
displayed on screen.
Note: This product is
intended for use in the
U.S.A. and Canada only.
   
