Digital Spectrum MemoryFrame MF-1201 User manual

Digital Spectrum
Incorporated
digital picture frame
Start Here
MemoryFrame Quick Start Guide
erm
Pui
m
er
Pum
i
m
After entering the security key, select
"Enter” on the keyboard, and press the
"ENTER" button on the remote to go to
the "Which site would you prefer" screen.
Windows LiveSpace, Webshots, Flickr).
Select your preferred site and press
"ENTER".
A list of albums will be displayed.
Select your preferred album and press
"ENTER"on the remote. The slide show
will begin automatically.
Which site would you prefer?
Windows Live Spaces
Webshots
FLICKR
If no album is displayed, or you encountered an error, please do the following:
1. The Digital Picture Frame might be too far away from the access point. Move the
frame closer.
2. Wrong security key might be entered. Check your access point security key and re
enter it to the Digital Picture Frame
Configuring wireless photo sharing 2.
Configure for photo sharing:
- Press MENU. to open the Main Menu
- Select Settings and press ENTER
- Scroll down the Settings options and
select Configure photo sharing
Select the "Configure photo sharing"
option and press "ENTER".
Select your chosen site (Windows
LiveSpace,Webshots, Flickr). and press
"ENTER".
Need a photo sharing account?
In order to display pictures from a photo sharing site you need to either
have an existing account or create a free account with one of the photo
sharing sites listed below:
Http://www.webshots.com
Http://www.flickr.com
Http://spaces.live.com/
Once you have an account set
up and have uploaded some
pictures follow the steps
below to configure the frame
for photo sharing.
1
2
3
4
Configuring for photo sharing
1Follow the same procedures for playing
picture slideshow.
When prompted for the source location,
select From photo sharing site and press
ENTER
2Select the photo sharing site of choice.
Press ”ENTER”.
You must be connected to your wireless
network for this feature to function .
Consult the user guide for network
configuration.
3The folders for the chosen photo
service will display after a few
moments. Select the folder you wish to
view and press “ENTER”
Select a photo and press “PLAY”. The
slide show will start automatically.
Select photo sharing site
Windows Live Spaces
Webshots
FLICKR
All Albums (28 pictures)
Huntington Birthday New Car Petes Wedding
Retrieving pictures from photosharing sites
Once you have set up a
photo sharing account enter
the user id for that account
using the remote to
navigate the keyboard.Once
the key is highlighted, press
the ”ENTER” button to
select the character. If you
enter the wrong character,
select “BS” to clear the
character. Up
Set site info
Enter your user id
1 2 3 4 5 6 7 8 9 0 - BS
Q w e r t y u i o p Space
A s d f g h j k l Enter
Z x c v b n m . Shift
[email protected]
Set site info
Enter your password
1 2 3 4 5 6 7 8 9 0 - BS
Q w e r t y u i o p Space
A s d f g h j k l Enter
Z x c v b n m . Shift
Example12345
Once you are done entering the user id, select ”Enter” on
the keyboard, and press the ”ENTER” button on the
remote to go to the next screen.
This screen allows you to enter the password that
you created when setting
up your photo sharing
account.
Configuring for photo sharing 2.
Using the MemoryFrame with Windows Vista or Windows XP
MemoryFrame can automatically play images from Vista orWinXP (equipped with
Windows Media Player 11). In order to share pictures from you Vista pictures folder or
Windows XP using Media Player 11 you will need to configure both to allow sharing
with the MemoryFrame. Please refer to page 14 of the manual (To play slideshow from
Media server (XP or Vista))
.
You must be connected to your wireless network for this feature to operate.
Consult “Configure Digital Picture Frame”on page 6 of the manual.
Follow the same procedures for
playing picture slideshow.
When prompted for the source
location, select From WinXP or
Vista and press ENTER
How do you want to get
media?
From WinXP or Vista
From local storage
From photo sharing site
Change settings
Once the available networks are displayed,
select the network where you media resides.
You will then be able to browse available
media by “tag”, “date taken”, “folder” or “rating”
Select your choice by pressing “ENTER” on the
remote and your media will start playing.
Pictures by tag
Pictures by date taken
Pictures by folder
Pictures by rating
All music
1
2
1
Additional features
78
910 11
Remote
Use the / buttons to
navigate the keyboard. Press the
“ENTER” button once you have
made your selection

Ó2007 Digital Spectrum Solutions, Inc. All rights reserved. Specifications and items shown subject to change
without notice. MemoryFrameÔis a registered trademark, and the Digital Spectrum logo, and Digital Spectrum
ÒTM
are trademarks of Digital Spectrum, Inc. Microsoft , Windows Vista and the Windows Vista logo are registered
trademarks of the Microsoft Corporation. All other trademarks are the property of their respective owners.
* Protected by United States Patent No: 6,826,863 B1 Assembled in China.
Ò
What’s in the box?
Before setting up your
frame check the contents of the box
Before setting up your
frame check the contents of the box
Software CD MemoryFrame Power Supply USB card reader
USB Cable Stand Remote
Back panel connectors
SD/MMC
CF Slot USB
to PC
USB
device
Power
supply
Play/Pause/Enter
Right
Left
Built-in Wireless Antenna
Down
Up
Menu
Mounting Holes
Built-in Stereo Speaker
Built-in Stereo Speaker
Frame Lock
Adjustable Stand
(Landscape/Portrait)
Ilustration for information only.
Actual product and frame may vary slightly
Removable frame
Getting to know your memoryFrame
Security Lock
(not included)
Connecting the frame
1Plug in the power cable to the back
of the unit
2Plug the power adapter into a power
outlet
3Turn on the power switch
After a few moments the unit will
automatically begin playing a photo
slideshow.
Playing a slide show
1MemoryFrame automatically plays your
previous slideshow. If you insert a new
media device, MemoryFrame will
automatically play from that device if
pictures are present.
2To specify a differents urce for your pictureso
- Press MENU
- Select Picture and pr ss ENTERe .
- Se ect Play Slides w and press ENTE
l ho R
- Specify source l cation of picture fi es
o l
and p ess ENTERr
- Select Play all pict es and press ENTERur
3Note: For Compact Flash, SD/MMC
insert the memory card into the
slot as shown in the diagram. For
USB storage insert the USB card
reader or thumb drive into the
“USB device” slot. Press “ENTER”
To confirm selection.
Use the / buttons to navigate
the menu bar press the “ENTER” button
once you have made your selection
Up
Right
Left
Down
Remote
Back panel connectors
SD/MMC
CF Slot USB
client
USB
host
Power
supply
Enter
4MemoryFrame allows you to easily play
background music with your slideshow.
To play background music,
- Press MENU
- Select Music and press ENTER
5- Select Play music and press Enter
- Select Previous or New song list and
press ENTER
-If Previous song list selected, music
playback will begin.
- If New song list selected, specify source
location and press ENTER
6While music is playing, you can restart
your previous picture slideshow by
pressing PLAY on the remote.
Use the Mute/Vol+/Vol- buttons on the
remote to adjust music volume.
Refer to the User Guide to disable
background music.
Up
Right
Left
Down
Use the / buttons to navigate
the menu bar press the “PLAY” button
once you have made your selection
Remote
Playing a slide show with music
Network requirement: To enable wireless network connectivity, an 802.11b/g
wireless router/access point must be available and accessible. Please refer to
the manufacturer’s information on the router/ access point to ensure that a
connection is permissible and that the wireless settings match those of your
MemoryFrame. For Internet access, make sure your access point is online.
To access an Internet photo sharing site or a Windows PC*
1- Follow the previous steps to play picture slideshow.
2- When prompted to specify a source location,select
Photosharing or Windows.
3- MemoryFrame will display all the available wireless
networks. Select the preferred network.**
*Photo sharing with Windows requires Media Player 11 with
media sharing enabled.
**Once a network connection has been made, MemoryFrame
will remember the connection preference.
Security Key
Type security access key for: MYSERVEREXAMPLE
1 2 3 4 5 6 7 8 9 0 - BS
Q w e r t y u i o p Space
A s d f g h j k l Enter
Z x c v b n m . Shift
1234xvsaaexample
If the access point is configured
for encryption, MemoryFrame will
display an onscreen keyboard so
you can enter the security key. Use
the remote to navigate the
characters, and press the "ENTER"
button to select the character.
Select "BS" key to backspace a
character.
Configuring wireless photo sharing
21 3
4 5
6
Remote
Enter
Remote
dsicentral.com
Power switch
MENU
Video
Music
Setting
Pictures
Play slideshow
Copy picture(s)
Delete picture(s)
Some routers allow users to enter a “passphrase” to generate
a security key. MemoryFrame requires the actual security key
rather than the passphrase. Please refer to your router
User manual to determine the required security key.
