DIODE LED VOLANTE LED Flood Light User manual

1 OF 4 IG112918-4.0
VOLANTE
®
LED Flood Light INSTALLATION GUIDE
®VOLANTE® LED Flood Light
INSTALLATION GUIDE
Input 120V-277VAC
Power 75w per module
Ambient
Temp
†-4° - 113°F (-20° - 45°C)
QUICK SPECS / MODELS
† Do not install product in environment outside
listed temperature.
DRY/WET LOCATION
UV RESISTANT
120V-
277V
AC
IP65
SAFETY & WARNINGS
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS
2. Install in accordance with national and local electrical code
regulations.
3. This product is intended to be installed and serviced by a
qualied, licensed electrician.
4. Do not use if there is any damage to xture or wiring. Inspect
periodically.
5. Do not submerge xture in liquids or use the product in the
vicinity of standing water or other liquids.
6. Do not install near areas with exposure to salt water or
chlorinated water.
7. Do not install in direct sunlight or damage to the LED
phosphor will occur.
8. Do not attempt to x this product in the eld.
9. Failure to follow safety warnings, and installation instructions
will be void the warranty for this product.

2 OF 4 IG112918-4.0
VOLANTE
®
LED Flood Light INSTALLATION GUIDE
VOLANTE® LED Flood Light
INSTALLATION GUIDE
INSTALLATION
TURN POWER OFF AT CIRCUIT
BREAKER
SHOCK HAZARD! May result in serious
injury or death.
Turn power OFF at circuit breaker prior to
installation.
DETERMINE LOCATION TO INSTALL
COMPONENTS
*NOT FOR USE IN SUBMERSIBLE APPLICATIONS, OR
WITHIN 5 FEET OF A SWIMMING POOL.
REQUIRED TOOLS
1
2
3
1. Phillips-head Screwdriver and/or Power Drill
2. Ruler
3. (3x) Appropriate Screws Wood/Concrete etc.
4. Junction Box
5. (3x) Twist-On Wire Connectors
6. Wire Strippers
9.0”
4.5”
MOUNTING BRACKET MEASUREMENTS
4
5
6
1
2

3 OF 4 IG112918-4.0
VOLANTE
®
LED Flood Light INSTALLATION GUIDE
VOLANTE® LED Flood Light
INSTALLATION GUIDE
To provide support for the VOLANTE® Flood Light, align
center screw with stud or post.
INSTALLATION (CONT.)
PLACING VOLANTE®ON STUD OR POST
a
PLACING VOLANTE BETWEEN STUDS
b
To provide support for VOLANTE® Flood Light, align
mounting screws with brace between studs.
STUD
STUD
STUD
MOUNT TO SURFACE
CONNECT WIRING
TURN POWER ON AT CIRCUIT BREAKER
GROUND (GREEN)
HOT (BLACK)
NEUTRAL (WHITE)
GROUND (GREEN)
HOT (BLACK)
NEUTRAL (WHITE)
Connect wiring to 120v-277v AC circuit within an
appropriately rated junction box.
If installing outdoors, ensure junction box is rated for
outdoor use, and sealed properly before continuing.
INSTALLING OUTDOORS?
3
4
5

4 OF 4
®Toll Free: 877.817.6028 | Fax: [phone] | www.DiodeLED.com | [e-mail]
© 2018 Elemental LED Inc. All rights reserved. Specicaons are subject to change without noce.
IG112918-4.0
VOLANTE
®
LED Flood Light INSTALLATION GUIDE
VOLANTE® LED Flood Light
INSTALLATION GUIDE
Lights are
ickering
• This product is not dimmable. Only install on
switching (On/O circuit).
• Verify xture is wired to a 120V-277VAC circuit.
Lights
will not
illuminate
• Ensure main power is turned On.
• Ensure breaker has not tripped.
TROUBLESHOOTING
TOOLS & RESOURCES
VOLANTE® SPECIFICATION SHEET
For full specicaons.
