Doc. 065259-01 4/09 1
1 • Introduction to the AS-DV
1.1 Overview of the AS-DV
The AS-DV Autosampler is a compact autosampler that is capable of delivering
between 0.1 mL and 5.0 mL of sample (in 0.1 mL increments) to the sample loop
or concentrator column in an ion chromatography system (for example, an ICS-
900, ICS-1100, ICS-1600, ICS-2100, or ICS-3000).
The AS-DV holds 50 vials (either 0.5 mL or 5.0 mL, or a combination of the two
sizes). Vials can be sampled in any order and multiple samples can be taken from
each vial. The AS-DV remembers the vial size and volume delivered for each vial
position, allowing multiple samples to be taken from a vial non-sequentially.
The unique PolyVial™ sample vial incorporates a cap that acts as a simple piston
to force sample out of the vial. This eliminates the need for an external sampling
pump. Sample can be delivered to a sample loop or a concentrator column with
backpressures up to 690 kPa (100 psi). Caps with a 20 μm filter are available to
remove solid materials from the sample before injection.
The AS-DV can be configured either without a valve (the standard configuration)
or with an optional 6-port high-pressure valve or 10-port high pressure valve.
The AS-DV is controlled with a PC running Windows®XP or Windows®Vista®
and the Chromeleon®Chromatography Management System (version 6.80 SR6a
or later). The AS-DV connects to the Chromeleon PC via a USB cable.
The AS-DV can also be operated under relay control from a device capable of
executing timed events, such as a previous generation ion chromatography system
without USB connectivity.
The AS-DV can be ordered with the accessories needed for sampling from either
0.5 mL vials or 5.0 mL vials:
•Order P/N 068908 to sample from 0.5 mL vials (Ship Kit P/N 071115)
•Order P/N 068907 to sample from 5.0 mL vials (Ship Kit P/N 068887)
NOTE Vials must be ordered separately.

AS-DV Operator’s Manual
2Doc. 065259-01 4/09
1.2 About This Manual
1.2.1 Overview
The electronic version (i.e., PDF file) of the AS-DV operator’s manual
contains numerous hypertext links that can take you to other locations
within the file. These links include:
•Table of contents entries
•Index entries
•Cross-references (underlined in blue) to sections, figures, tables, etc.
If you are not familiar with how to navigate PDF files, refer to the Help
system for Adobe®Acrobat® or Adobe Reader®for assistance.
Chapter 1,
Introduction Introduces the AS-DV; explains the conventions used in this manual, including safety-related
information.
Chapter 2,
Description Describes AS-DV operating features and the software required for AS-DV control.
Chapter 3,
Operation and
Maintenance
Provides operating instructions for the AS-DV
and describes routine preventive maintenance
procedures.
Chapter 4,
Troubleshooting Lists problems and presents step-by-step procedures for how to isolate and eliminate the
cause of each problem.
Chapter 5,
Service Provides step-by-step instructions for routine service and parts replacement procedures that the
user can perform.
Appendix A,
Specifications Contains the AS-DV specifications and facility requirements.
Appendix B,
Installation Provides specifications and installation site requirements for the AS-DV.
Appendix C,
Relay Control of
the AS-DV
Provides details about setting up the AS-DV for
relay control operation.

1 • Introduction to the AS-DV
Doc. 065259-01 4/09 3
1.2.2 Safety Messages and Notes
This manual contains warnings and precautionary statements that, when
properly followed, can prevent personal injury to the operator and/or
damage to the AS-DV. Safety messages appear in bold type and are
accompanied by icons, as shown here.
Messages d’avertissement en français
Appendix D,
Reordering
Information
Lists part numbers of sample vials and other
supplies for convenience when reordering.
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. Also used to identify a situation or
practice that may seriously damage the instrument, but will not cause
injury.
Indicates that the function or process of the instrument may be
impaired. Operation does not constitute a hazard.
Signale une situation de danger immédiat qui, si elle n'est pas évitée,
entraînera des blessures graves à mortelles.
Signale une situation de danger potentiel qui, si elle n'est pas évitée,
pourrait entraîner des blessures graves à mortelles.
Signale une situation de danger potentiel qui, si elle n'est pas évitée,
pourrait entraîner des blessures mineures à modérées. Également
utilisé pour signaler une situation ou une pratique qui pourrait
gravement endommager l'instrument mais qui n'entraînera pas de
blessures.

AS-DV Operator’s Manual
4Doc. 065259-01 4/09
Warnhinweise in Deutsch
Informational messages also appear throughout this manual. These are
labeled NOTE and are in bold type:
NOTE NOTES call attention to certain information. They alert
you to an unexpected result of an action, suggest how to
optimize instrument performance, etc.
1.3 Safety and Regulatory Information
The AS-DV was manufactured by Dionex Corporation at the following location:
527 Lakeside Drive, Sunnyvale, CA 94088-3603 U.S.A. The AS-DV is designed
for use with IC (ion chromatography) systems and should not be used for any
other purpose. Operation of an AS-DV in a manner not specified by Dionex may
result in personal injury.
If there is a question regarding appropriate usage, contact Dionex Technical
Support. In the U.S., call 1-800-346-6390. Outside the U.S., call the nearest
Dionex office.
Bedeutet unmittelbare Gefahr. Mißachtung kann zum Tod oder
schwerwiegenden Verletzungen führen.
Bedeutet eine mögliche Gefährdung. Mißachtung kann zum Tod oder
schwerwiegenden Verletzungen führen.
Bedeutet eine mögliche Gefährdung. Mißachtung kann zu kleineren
oder mittelschweren Verletzungen führen. Wird auch verwendet, wenn
eine Situation zu schweren Schäden am Gerät führen kann, jedoch
keine Verletzungsgefahr besteht.

1 • Introduction to the AS-DV
Doc. 065259-01 4/09 5
1.4 Safety Labels
The EN 61010, cETLus, and CE safety marks on the AS-DV indicate that the AS-
DV is in compliance with the following standards.
EMC Susceptibility and Emissions
•EN 61326-1:2006
Safety
•CAN/CSA-C22.2 No. 61010-1:2004
•EN 61010-1:2001
•UL 61010-1:2004 + REV 02:2005
The symbols below appear on the AS-DV or on AS-DV labels.
Alternating current
Primary protective conductor terminal
Secondary protective conductor terminal
Power supply is on
Power supply is off
Indicates a potential hazard. Refer to this operator’s manual
for an explanation of the hazard and how to proceed.

AS-DV Operator’s Manual
6Doc. 065259-01 4/09

Doc. 065259-01 4/09 7
2 • Description
2.1 Operating Features
2.1.1 Front View
Figure 2-1 illustrates the main operating features of the AS-DV
Autosampler.
Figure 2-1. AS-DV Front View
Sampling
Head Tower
Vial
Carousel
LED Display Front Cover
Carousel Cover
Carousel
Release Button
(Not visible in
photo)

AS-DV Operator’s Manual
8Doc. 065259-01 4/09
LED Display
Four LEDs on the front panel of the AS-DV (see Figure 2-2) indicate the
status of the following autosampler functions.
Other status information and alarm messages are displayed in the Audit
Trail in Chromeleon. For a description of these messages, see Section 4.1.
Sampling Mechanism
The sampling mechanism consists of a sampling head tower, a vial
carousel, and a carousel cover (see Figure 2-1).
•The sampling head tower delivers sample from the sample vials to the
sample out line, which exits the front of the AS-DV (see
Section 2.1.2). For a description of how the sampling mechanism
operates, see Section 2.2.1.
•The carousel holds the PolyVials containing sample or rinse solution.
Vial numbers are molded into the top of the carousel to indicate the
sampling position. Vials can be placed in any order in the carousel.
The Chromeleon sequence controls the order in which sampling
occurs. For a description of how to create a sequence, see Section 3.6.
Sensors in the sampling mechanism detect the presence (and the size)
of the vial under the sampling head tower.
Figure 2-2. Status LEDs
CONNECTED This LED is on when the AS-DV is connected to
Chromeleon.
ALARM This LED flashes when a problem has occurred. Check
the Chromeleon Audit Trail for the cause.
CAROUSEL This LED is on when the carousel is engaged.
POWER This LED is on when the AS-DV power is on.
CONNECTED ALARM CAROUSEL POWER

2 • Description
Doc. 065259-01 4/09 9
•The carousel cover protects light-sensitive samples and the interior of
the AS-DV. To access the sampling head tower and carousel, lift up
the cover.
Carousel Release Button
The Carousel Release button on the inside of the chassis performs two
functions:
•Engages and disengages the carousel from the motor.
•Resets vial memory (clears presence, vial size, and volume remaining
information). Before starting a run, always press Carousel Release to
reset the vial information.
PolyVials
The vial carousel holds up to 50 0.5 mL or 5.0 mL disposable plastic
PolyVials or a combination of the two sizes. Vial adapters (P/N 071901,
package of 50) are required to load 0.5 mL vials into the carousel.
Adapters are included in the AS-DV Ship Kit for 0.5 mL vials
(P/N 071115). PolyVials serve both rinse and sample functions.
Vial Caps
Vial caps perform an important function in sample loading (see
Section 2.2.1). They also minimize evaporation, contamination, or spills
of sample while awaiting use. Caps with 20 μm filters are available. The
filter traps particulates that might contaminate the analytical system.
PolyVials and caps can be used for loading sample to either a sample loop
or a concentrator column. An insertion tool (P/N 037987), included in the
AS-DV Ship Kit, simplifies insertion of the caps.
Appendix D contains part numbers for PolyVials, vial caps, and other
accessories.
To avoid trapping dust particles in the vial caps, always operate the
AS-DV with the carousel cover closed.
Before starting a run, always press the Carousel Release button to
disengage the carousel and reset the vial information. After loading
the vials in the carousel, press the Carousel Release button again to
engage the carousel.

AS-DV Operator’s Manual
10 Doc. 065259-01 4/09
Vial Adapters
Before loading a 0.5 mL vial into the carousel, insert a vial adapter
(P/N 071901, package of 50) onto the vial (see Figure 2-3). After you
load the vial into the carousel, twist the adapter slightly to the right to lock
the adapter in place.
Vial Tray
Vial trays (either for 0.5 mL or 5.0 mL vials) are included in the
respective AS-DV Ship Kit (P/N 071115, Ship Kit for 0.5 mL vials; P/N
068887, Ship Kit for 5.0 mL vials). Place vials into the tray and then fill
them until the liquid in the vials reaches the top of the tray.
Figure 2-3. Vial Adapter for 0.5 mL Vials
Figure 2-4. Vial Tray (0.5 mL Version Shown)
Adapter for 0.5 mL vial Adapter installed on vial
Fill vials to
this level

2 • Description
Doc. 065259-01 4/09 11
2.1.2 Front Interior Features
Figure 2-5 illustrates the front interior of the AS-DV. To access the front
interior, remove the front cover by gripping the indentations at each side
and pulling the cover straight off toward you.
Sample Out Line
The sample out line is routed from the sampling mechanism through an
aperture in the front interior. From there, it is connected either to the high-
pressure valve in the AS-DV (if installed) or to the injection valve in the
IC system.
High-Pressure Valve (Optional)
Either a 6-port or a 10-port high-pressure valve can be installed in the AS-
DV. The valve can be configured to operate as an injection valve or an
auxiliary valve in an application (for example, it can be used as a bleed
valve or to load a concentrator column).
For details about operation of the high-pressure valve, see Section 2.2.3.
For valve installation instructions, see (see Section B.3.2).
Figure 2-5. Front Interior View with Optional High-Pressure Valve
Optional
Valve
Sample
Out line
11
22

AS-DV Operator’s Manual
12 Doc. 065259-01 4/09
2.1.3 Rear Panel
Figure 2-6 shows the features on the rear of the AS-DV.
Drain
Liquid from any spills exits the AS-DV enclosure through the DRAIN port.
Connect a drain hose (P/N 055075) to the port and place the free end of
the hose into either a waste container or an appropriate drain. The drain
hose is included in the AS-DV Ship Kit
Figure 2-6. AS-DV Rear Panel
Neutralize acidic and caustic wastes before disposal. Dispose of all
wastes in accordance with local regulations.
Neutralisez les déchets acides ou caustiques avant de les jeter. Jetez
les déchets aux règlements locaux.
Neutralisieren Sie säurehaltige und ätzende Abfälle vor ihrer
Entsorgung. Entsorgen Sie alle Abfälle entsprechend den lokalen
Bestimmungen.
Drain Port Power Switch, Fuse Drawer,
and Power Receptacle
Relay and TTL
Connector
USB
Connector
