DIP Grinders DKS-65 User manual

OPERATION AND MAINTENANCE MANUAL
Precise dosing and fresh
On Demand
DKS-65
Devoted to perfect grinding

- 2 -
Notification of CEE requirements:
D.I.P. IMPEX SRL, located at 287 Theodor Pallady Blvd., 032258 Bucharest, Romania,
manufactures the DKS-65 On demand Grinder in compliance to CEE requirements:
N73/23 (low tension)
N89/392 (machines)
The DKS-65 On demand Grinder has been tested in accordance the following norms:
• EN 60 335-1
• EN 55011
• EN 61000-3-2
• IEC/EN 61000-4-2, -4, -5, -6, -8, -9, -11, -29 (safety regulations for domestic
or similar use)
• EN 335/264 (2nd part: safety regulations for professional kitchen
instruments).
D.I.P. IMPEX SRL
Technical office
Bucharest, 13/07/2013

- 3 -
GENERAL WARNINGS
• Read this manual before using the appliance as it contains important
instructions for the safety, operation and maintenance of the appliance.
• Before plugging in the appliance, make sure that voltage and frequency
values of the power supply correspond to the rating plate.
• The wall socket must be fitted with an earth contact and a 10A fuse.
• Before performing any work on the appliance, including cleaning or
maintenance, disconnect it from the power supply.
• Turning off the appliance by using its master switch does not assure the same
conditions of safety.
• The manufacturer cannot be held responsible for bodily injury or property
damage if the above warnings are not respected and the warranty will be void.
PARTICULAR WARNINGS
• Do not tamper with the appliance, for maintenance or repair contact an
authorized service center.
• Do not pull the power cable in order to unplug the appliance from the socket.
• This appliance has been designed solely for grinding coffee beans.
• Place the appliance at minimum of 5 cm from the wall to allow proper
ventilation.
• Keep the appliance at a safe distance from water sources.
• Never leave the machine unintended, keep it out of the rich of children or
people with handicap.
• Do not switch on an appliance that looks damaged.
• Use only original accessories and parts.
• To avoid the danger of fire, never cover the appliance.
• Unplug the appliance from the mains when it is not in use.
• Let the appliance cool down before moving it.
• Be aware that the grinding blades may continue rotating for a short period of
time after the appliance is switched off.
• Do not let liquids of any kind come in contact with the internal or external
parts of the appliance.
• Never pour ground coffee in the hopper, the grinder is designed only for
coffee beans.
• Do not touch the appliance with damp or wet hands/feet.
• THE HOPPER MUST BE FASTENED TO THE GRINDER BY MEANS OF THE
RELEVANT SCREW which must be inserted in the threaded hole located on
the coffee grinding Adjustment disk (fig. 1).
• The manufacturer cannot be held responsible for bodily injury or property
damage if the above warnings are not respected and the warranty will be
void.
ATTENTION: Moving parts.

- 4 -
Introduction:
Since immemorial time, making coffee has been an art. Precise rules have to be followed
in order to succeed. The formula to get a perfect cup of express coffee depends largely
on the quality of the coffee grinding machine. In order to achieve an indisputable quality
and a breathtaking taste it is mandatory to follow three rules:
1. A precise mixture
2. The correct use of equipment.
3. A thoroughly trained person.
To enjoy a good cup of coffee, unlike what you believe, it is not enough just to choose
a particular coffee mixture. A skilled operator, who follows the proper preparation
procedures and uses the machinery in an appropriated manner, contributes decisively
at the creation of a masterpiece.
This is why professionals give so much importance to their espresso and grinder
machines. Being familiar with his machines, keeping them in perfect working conditions
and using them to the best of their
ability, are the skills that belong to a
true coffee master.
The quality of a good espresso coffee
is the result of a series of operations,
grinding having an important role. The
grinder, therefore, is for the operator
one of the most important tool,
whose structure must meet certain
characteristics such as: strength,
durability and functionality.
Dimensions DKS-65

- 5 -
Components Description
Hopper cover
Hopper locking slide
On/Off button
Two cup button
On/Off switch
Bottom plate
Hopper
Indexing mechanism
Coffee grinding adjustement disk
Function button
One cup button
Control panel
Display
Start microswitch
Filter holder
Tray
Figure. 1

- 6 -
Unpacking the DKS-65 On demand Grinder:
When open the package, carefully check the equipment for any possible damage. If
you have any doubt, do not use it and contact a qualified technician. If you have to ship
back the equipment, this must be done in the original package otherwise the warranty
is void.
Warning: packing materials can be hazardous to children.
Packaging Disposal:
Dispose the packaging materials according to local laws and regulations. If you decide
not to use the appliance any more, disconnect it from the mains, cut the power cable at
the point where it comes out of the appliance. Contact a specialized recycling company.
Proper Use:
This appliance has been designed solely for grinding coffee beans. Any other use is
considered to be improper, and consequently hazardous. The manufacturer cannot be
held responsible for any damage as a result of improper or incorrect use.
Do not use the appliance for grinding other types of food, or anything else.
ALL COFFEE GRINDERS MANUFACTURED BY OUR COMPANY ARE DESIGNED TO BE USED
BY SKILLED PERSONNEL, ONLY FOR PROFESSIONAL USE AND NOT FOR HOUSE-HOLD USE.
The user must be an adult. Do not allow children or people with handicap to use the
appliance.
Installation and wiring:
The appliance must be installed by authorized personnel only. Incorrect installation
may result in personal injury or property damage, for which the manufacturer cannot
be held responsible.
• The appliance must be placed on a stable and flat surface.
• Do not install the appliance in rooms where water jets are used for cleaning.
• Before plugging in the appliance, make sure that the voltage and frequency
values of the supply mains correspond to the rating plate.
• It is essential to ensure that the socket power supply is suitable for the
appliance’s power consumption, as is indicated on the rating plate, and the
wall socket is current fluctuation protected.
• The wall socket must be fitted with an efficient earth contact (grounded). If in
doubt, have it checked by an licensed technician.
• Do not use extension cables, plug adapters, multiple sockets or makeshift
connections.

- 7 -
Operating instructions:
Preliminary operations
Check that the hopper is positioned correctly on the appliance and secured to the Coffee
grinding Adjustment disk with the relevant screw (fig.1). Close the Hopper locking slide
(fig. 1) and fill the hopper with coffee beans. Open the slide to allow the coffee beans to
fall in the grinding chamber.
Adjusting the grind
Your new DKS-65 is delivered from the factory at a preset grinding of minimum fineness.
Use the Adjustment disk located under the hopper (fig. 1), for obtaining a finer or
coarser grinding result.
The Adjustment disk is functional only when the Indexing mechanism (fig. 1) is hold
down.
For coarser grinding turn the Adjustment disk anti-clockwise, to finer grinding turn the
disk clockwise.
The Adjustment disk is blocked at the chosen position by releasing the Indexing
mechanism.
Grind small amounts of coffee in order to determine the optimal degree of fineness.
A simple method to verify the grinding setting, is at the espresso machine. If the coffee
comes out of the espresso coffee machine very quickly, it means that the coffee is
grounded to coarse. If it comes out too slowly, it means that the coffee is grounded to
fine. ADJUSTING GRINDING
Figure. 2

- 8 -
Safety protection:
THERMAL OVERLOAD PROTECTION
The appliance’s motor is protected against overheating by a thermal protection which,
when tripped, cuts off the motor’s power supply. If the protection trips as a result of
anomalous operation, such as jamming the grinding blades, the appliance must be
turned off using the ON/OFF switch (fig.1), DISCONNECTED FROM THE MAINS, AND
CONTACT A LICENSED TECHNICIAN.
Noise level:
The maximum noise emission of this coffee grinder is measured in UNI EN ISO 3741
reverberating chamber in compliance with the EN 60704-1 regulations and complies
with the EN 60704-1:1998 and EN 607043:1996 regulations.
The daily noise exposure of a worker, due only to an appliance’s limited operation of
240 minutes per 8 hours, is 78 dB (A), according to ED 89/188/ECC and ED 200311/EEC.
Therefore, during the daily operation, measures must be taken in order to prevent any
injury from noise exposure (article 3-8 of ED 2003/10/EEC).
Maintenance:
It is essential to check the status of the cable and plug periodically.
IN THE EVENT OF DAMAGED SUPPLY CABLE OR PLUG, CALL IN A LICENSED TECHNICIAN
TO REPLACE THEM. THIS WILL PREVENT ANY FUTURE DAMAGE OF THE APPLIANCE.
It is recommended to use original replacement parts to assure the proper working
conditions of the appliance. A licensed technician must perform periodic maintenance,
including detailed inspection of those components subject to wear.
The status of the grinding blades must be checked periodically. Keeping them in an
excellent condition, assures better productivity and cooler coffee outcome.
Cleaning the appliance:
THE APPLIANCE CANNOT BE CLEANED USING WATER JETS.
THOROUGHCLEANINGMUSTBEPERFORMEDPERIODICALLYBYALICENSEDTECHNICIAN.
Use perfectly clean, disinfected cloths or brushes for cleaning.
Do not use abrasive products for cleaning in order to prevent damaging the shiny parts.
NEVER PERFORM ANY MAINTENACE OR CLEANING OF THE APPLIANCE WHILE IT IS
CONNECTED TO THE MAINS

- 9 -
Hopper:
Wash the hopper once it has been removed from the appliance, using neutral soap and
water, rinse abundantly with warm water and dry thoroughly. It is recommend to clean
the hopper periodically.
Grinding Disk Replacement:
In order to change the grinding disks of the DKS-65 please follow the steps found below:
• Close the Hopper locking slide (fig.1).
• Start the machine until you stop hearing the sound of coffee beans grinded.
¢Unplug the machine.
• Remove the hoper and check that no coffee leftovers are found in the grinding
chamber.
• By keeping the Indexing mechanism pressed at all times, turn the Coffee
grinding adjustment disk (fig.1) anti-clockwise until it is fully released.
• Unscrew the lower disk found in the grinding chamber and the upper disk
found on the Coffee grinding adjustment disk.
• Clean thoroughly the surface where both disks were rested.
• Place the new grinding disks in their former position and fasten them tightly
with their screws.
• By keeping the Indexing mechanism pressed at all times, turn the Coffee
grinding adjustment disk (fig.1) clockwise until it is tightly fastened.
• Check that the Coffee grinding adjustment disk indicator (fig.1) is close to O.
• By keeping the Indexing mechanism pressed, turn the Coffee grinding
adjustment disk (fig.1) anti-clock wise, until its indicator is indexed to 1.
¢Connect the machine to the mains.
¢Set the working mode to Manual (page 13).
• Start the machine by pressing the start micro switch (fig. 1), JUST ONCE. If you
hear the sound of metal scraping turn the Coffee grinding adjustment disk
(fig.1) anti-clock wise until its indicator is indexed to 2.
• Start the machine again by pressing the start micro switch (fig.1), JUST ONCE
to make sure that you do not hear any sound of metal scraping.
• Set the working mode to your preference. Auto, Auto Plus or Manual (page 13).
• Adjust the grinding fineness at the optimal setting (page 7).

- 10 -
Display and functions
1. Starting the machine:
Flick the main switch:
The company’s logo appears
Few seconds after: The Single cup menu appears.
Auto grinding mode as default.
To shift between grinding modes see Chapter 6
00000 = Partial doses counter, can be reset periodically (see Chapter 7)
4.5 = Nr of seconds per dose
Auto = Grinding mode, to change (see Chapter 8)

- 11 -
2. Choosing between Single or Double Dose
a. Single shot (Default)
Press To choose for single
The pictogram appears
b. Double shot
Press To choose for double
The pictogram appears
3. Setting the grinding time
a. When single
When machine is set for single doze, press:
or To increase or decrease the grinding time
The Grinding time increments with 0.1 sec. ex 4.5, 4.6, 4.7, 4.8.

- 12 -
b. When double
When machine is set for Double doze, press:
or To increase or decrease the grinding time
The Grinding time increments with 0.1 sec. ex 8.5, 8.6, 8.7, 8.8
4. Grinding
a. When single
When the dose switch is hit shortly the machine starts grinding,
Auto/Auto+ disappears and:
A. A bar appears under the time index, i.e. 4.5, which is filled, during
grinding time.
B. Nr. of seconds decreases from 4.5 to 0
When the grinding finishes the bar disappears, Auto/Auto+ appears
ThePartial doses counter, 0000,increments with 1

- 13 -
b. When Double
When the dose switch is hit shortly the machine starts grinding,
Auto/Auto+ disappears and:
A. A bar appears under the time index, i.e. 8.5, which is filled, during
grinding time.
B. Nr. of seconds decreases from 8.5 to 0
When grinding finishes the bar disappears, Auto/Auto+ appears
The Partial doses counter, 0000, increments with 1
5. Grinding Modes:
Auto:
When the grinding switch is struck shortly, the machine grinds for
the preset time.
Ex: 4.5 sec for single / 8.5 sec for double
After each cycle the Partial doses counter increments with 1.

- 14 -
Auto plus:
When the grinding switch is struck shortly:
The machine grinds for the preset time. When the cycle ends, for 5 seconds the
word Manual appears.
During these 5 seconds:
The grinding switch activates grinding for as long as it is kept pressed.
Every time the switch is pressed those 5 seconds are reset.
After 5 sec of not touching the grinding switch the display turns to
Auto+ After each cycle the counter increments with 1.
Manual:
When the grinding switch is struck the machine runs for as long as
the switch is kept pressed, the seconds counter starts with 0.0:
During grinding the number of seconds of motor functioning increment with
0.1
Ex.: 0.1, 0.2, 0.3, etc, 3.1, 3.2, 3.3, 3.4 etc.

- 15 -
In this mode the Partial doses counter does not increment.
6. Locking Grinding time
In order to avoid the change of grinding time during daily operation the
grinding time has to be locked.
A. To lock the grinding time press for 5 seconds simultaneously:
and
The following pictogram appears:
or
During lock, if the operator presses
or the following pictogram appears
B. To unlock the grinding time press for 5 seconds simultaneously:
and
The following pictogram appears
or
Now the operator can change the grinding time

- 16 -
7. Resetting Partial Doses
To reset the partial doses counter press for 5 seconds simultaneously:
and
To prevent from changing the selected grinding time, lock before.
(see Chapter 6)
The following pictogram appears
For the next 10 seconds the partial dozes counters can be reset
Press simultaneously and for 7 more seconds. Both
counters are reset.
After releasing the and the machine turns to single or
double dose from where it was left:
or
The number of partial doses shifts to 00000.

- 17 -
8. Setting Grinding mode
Switch OFF the machine from the main switch
With both and pressed, flick the main switch
Keep both and pressed until the following pictogram
appears
You have 5 seconds to shift between modes by Pressing or
Every time you press or these 5 secs are refreshed
After 5 secs of no action, the grinding mode is saved to your selection:

- 18 -
9. Viewing the total doses
When machine is in normal operation
single or double :
Pres the single or double for 5 seconds:
The following pictogram appears
Working Hours represents the total Nr. of hours that motor run since
fabrication
Total doses represent, the total number of shots grinded since fabrication.
Att: The number of sigle doses is multiplied with 1
The number of double doses is multiplied by 2
Then, they are added together
3 secs after releasing, the machine turns to prior working mode:

- 20 -
ESPRESSO GRINDERS
DKS-65 On Demand grinder is an innovative machine. With devotion
to the needs of Coffee shops, Hotels and Baristas, DKS-65 delivers
each coffee portion, freshly grounded on demand
• Constant and cool grinding which assures crema and coffee aroma
• Fresh on demand coffee grinding for every dose delivered
• No coffee decay due to pre-grinding
• Precise dosing level by electronic control, to assure constant shots
• Single and double dose selector, individually adjustable
• Simple and precise grinding adjustment
• Daily Track counter for both single and double doses grounded
• Easy slide stop lid
• 2-Step cleaning 4-Step maintaining system
Technical information DKS-65
Voltage / Frequency 220-230V/50-60Hz
110-120V/60Hz
Motor power 0.65 kW
Average grinding capacity*3.2 g/sec
Hopper capacity 1300 g
Grinding disc diameter Ø 64 mm
Net weight 9 kg
Dimensions (w x d x h), mm 160 x 300 x 570
Standard colour Black
*The output can vary according to coffee beans type and roasting method
Additional electrical specications are available upon request
Special colours can be ordered, please consult with
our commercial dept.
HEAD OFFICE:
287 Theodor Pallady Blvd. 032258, Bucharest Romania
Phone: [phone] • Fax: [phone]
www.dipgrinders.ro • [email protected]
OMM.DKS65.2017.1
