Baratza SETTE 30 Installation and user guide

How to: Motor/Gearbox Assembly Replacement
Sette 30, Sette 270, Sette 270W, Sette 270Wi
Time: 10 min
Difculty: Easy
Tools/supplies: Torx 10 Driver (2mm hex key can be used)
Parts: Sette Motor/Gearbox Assembly (SKU S056 [110v] - S057 [220v])
Additional Resources: Case Removal
*** Unplug the grinder from power supply ***
www.baratza.com [e-mail] rev. 5/23/2019
ver. 1.0
Remove the case using our Case Removal guide
Remove the hopper and adjustment ring from the unit.
Torx 102mm Hex Pliers Sette Motor Gearbox Assembly
110v SKU: S056
220v SKU: S057

www.baratza.com [e-mail] rev. 5/23/2019
Pg. 2
Possible High Voltage
CAUTION: The capacitor
is normally discharged
however it may retain
a charge. Do not touch
the exposed metal at the
rear of the component.
Unplug the wires from
the back of the motor
Note how the wires are
routed before removing
the gearbox/motor
assembly for easiest
reassembly.
Remove the (4) screws
that fasten the motor/
gearbox assembly to the
chassis.
These insulated
connectors are
safe to touch by
hand or with pliers
ADVISORY
ADVISORY

www.baratza.com [e-mail] rev. 5/23/2019
Pg. 3
Lift to remove the
gearbox / motor
assembly.
Insert the new gearbox/
motor assembly and
install the (4) screws. Be
careful not to pinch any
wires.
Plug in the motor wires,
taking care to match
the red wire with the red
terminal.
Re-install the case,
hopper, and adjustment
ring to return the unit to
operation.
Match red to red

www.baratza.com [e-mail] rev. 5/23/2019
Pg. 4
With a new gearbox installed, the grind calibration may change.
Add or remove shims as needed to adjust overall grind range.
See Shim Installation guide for reference. To avoid potentially
clogging the unit, we advise grinding at a coarser setting at rst.
If you encounter any issues,
or have any questions about
this guide, reach out to
suppor[email protected]
