direct 4x4 7300-TROOP3-A Assembly instructions

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
Volkswagen T5/T6 SWB Roof Rack Fitting Guide

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
1: Parts List
Part Name Quantity
Roof Rack 1
Brackets 8
Roof Channel Brackets 8
6mm Bolts 8
8mm Bolts 32
10mm Bolts 8
Nuts 32
Large Washers 8
Small Washers 40
Large Spring Washers 8
Small Spring Washers 40
Allen Key 1
Please ensure that you have received all of the components listed above before fitting. If you believe there is anything
missing, contact us for assistance.

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
2: Fitting the Brackets to the Roof Rack
When fixing the brackets to the roof rack, place the bracket on the roof
rack with the flanges facing to the outside. Fix in place with the 8mm
bolts, keep it loose as you will need to adjust when putting it on the top
of the vehicle.
Place the 8mm bolts through the top of the roof rack and fix the brackets
in place using the bolts provided.

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
3: Fitting the Brackets (on the Vehicle)
First remove the pre-existing bolts along the channel on the top of the
vehicle. Place the brackets along at the given points with the upright
part of the brackets facing the outside of the vehicle as seen below. You
can re-use the rubber washer, however new ones are provided.
Remove the existing bolt and replace with the new fittings from the kit
with the upright part of the bracket facing out, you must use the rubber
seal as this will prevent water getting in the vehicle.

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
4: Fitting the Roof Rack
Place the roof rack on the top of the vehicle, be careful not to scratch the
top. Line up the bracket on the roof rack over the bracket on the vehicle.
You may need to adjust the bracket width and position (page 2). Fix in
place using the 6mm bolts, tighten the brackets on the vehicle with the
allen key provided.
When you have securely bolted the rack to the brackets on the roof you
can then tighten the rest of the bolts to keep the rack attached to the
brackets.

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
5: Fitting the Brackets (EXTRA)
When fitted in place the sturdy Steel or Aluminium Roof Rack will be
ready to carry any load safely.

Volkswagen T5/T6 SWB Roof Rack Fitting Guide
General Care & Maintenance
!IMPORTANT!
We strongly advise you check the car at several intervals after the initial fitting to ensure safety. After 7 days, check and
tighten any bolts and we recommend inspecting the bolts, brackets at least once every 6 months.
Cleaning Information
You can use most cleaning products on this roof rack. However, we strongly advise against using petrol based solutions or
corrosive cleaning solutions which include TFR (Traffic Film Remover) or similar chemicals (brake strippers etc.) These will
tarnish and possibly even corrode the metal.
