Direct Healthcare Services Dyna-Form Air User manual

Power Switch Alarm Reset
The power switch simply switches the mains power to the pump on and off.
When the pump detects an alarm LED condition, this can be cancelled by switching the pump off and then back on again.
CPR
Please ensure that the CPR tag is always positioned fi rmly into the mattress (Closed), prior to infl ating the mattress.
The mattress will NOT infl ate should the CPR tag not be closed. The CPR tag is only to be used in the event of a clinical
emergency for priority use. However the function can also be used to defl ate air rapidly from the mattress in readiness
for transport.
Settings
When the system is initially switched on using the power switch as above,simply select the valve from soft to fi rm as
clinically required. Patients who are up to the maximum user weight (24 stone) should be placed on a much fi rmer
setting than a frail or light weigh patient Please be patient and wait until the system fully infl ates from initial installation.
This may take up to 15 minutes from the initial set up.
Normal Pressure
When the system is operating at a normal functioning pressure, then the LED should always be shown as
highlighted left.
Low Pressure
If the mattress is operating at too low a pressure setting, there is a mattress “leak” or indeed if the CPR has not been
closed fully, then a low pressure light will be indicated as shown.
Quick Release Connector
The connectors (male & female coupling) as indicated left can also be used to create a “static mode”. This is achieved by
pressing home the male & female section together until locked tight To release the connectors, simply press the metal
release catch.
Filter
The fi lter is situated at the rear of the pump. This can be removed and cleaned whilst on site to improve infection
control measures. Please DO NOT insert the fi lter back into the unit when still wet Electricity and water is a dangerous
combination.
Dyna-Form Air System
DIRECTHEALTHCARESERVICES.CO.UK
QUICK REFERENCE GUIDE
This is a quick reference guide for the Dyna-Form Air System
(refer to user manual for additional information).
Product Code MAT/AIR/200/85/10
Controls
NB: Please ensure that all securing straps on the base of the mattress are secured onto the NON MOVING PARTS of the bed frame.
Product Code MAT/AIR/200/85/10
Product Code MAT/AIR/200/85/10

Dyna-Form Air System
TROUBLESHOOTING
Symptoms Problems / Cause
Low Pressure The mattress is set to a mode that is
too SOFT.
Change the mode button to standard (from Lo to High(+) a fi rmer pressure setting)
as required. If the mattress is still too soft after a short period of 5 to 10 minutes,
then please call an engineer.
The CPR connector is not fully home. Check all tubing is not kinked within the mattress.
There may be a leak in the system. Ensure that the tubing within the mattress are fully connected.
High Pressure The mattress is excessively fi rm on a
constant basis.
Set mattress to a softer setting as clinically required.
Evaluate that the mattress to be of a “less fi rm” state after a short period of 5 to
10 minutes.
If this is not achieved, then please follow the task as below before calling an
engineer for assistance.
NB: Check all tubing is not kinked within the mattress.
Points to check
Service Solutions
Direct Healthcare’s service solutions provide total
peace of mind when you need it most – 24 hours a day.
With centres throughout the UK, we have the ability to
get to you fast. Whether it’s a bed or mattress rental,
decontamination procedure or a more complex
service requirement towards your entire hospital or
homecare needs.
Our units are equipped to cope with the most complex
engineering tasks quickly and effi ciently.
Direct Healthcare Services Ltd
Unit 8-10 Withey Court, Western Industrial Estate
Caerphilly, CF83 1BF
Sales Offi ce [phone] F [phone] E [e-mail]
www.directhealthcareservices.co.uk
Although Direct Healthcare Services Ltd will endeavour to provide the exact specifi cation as printed,
we reserve the right to change specifi cation without prior notice. All equipment & information within this brochure,
should be used in conjunction with appropriate clinical judgement & nursing procedures.
All products manufactured to standards:
