Directed Audio 26152 Viper User manual

VIPER
26152
SEALED BOX ONE DRIVER
NORMA
L
LOADING
BOX SEALED 1 NORMAL 26152
SIZE Q FB F3 HUMP NOTE
1.500 1.221 52.60 38.51 16.85
1.625 1.184 51.01 37.68 16.29
1.750 1.152 49.60 36.96 15.77
1.875 1.123 48.35 36.33 15.29
2.000 1.097 47.23 35.78 14.84
2.125 1.073 46.22 35.30 14.41
2.250 1.052 45.30 34.86 14.01
2.375 1.032 44.46 34.48 13.63
2.500 1.015 43.70 34.13 13.27
2.625 0.998 42.99 33.82 12.93
2.750 0.983 42.34 33.55 12.61
2.875 0.969 41.73 33.29 12.30
3.000 0.956 41.17 33.06 12.00
3.125 0.944 40.65 32.86 11.71
3.250 0.932 40.16 32.67 11.44
3.375 0.922 39.70 32.49 11.17
3.500 0.912 39.27 32.33 10.92
3.625 0.902 38.87 32.19 10.67
3.750 0.894 38.48 32.05 10.44
3.875 0.885 38.12 31.93 10.21
4.000 0.877 37.78 31.82 9.98
4.125 0.870 37.46 31.72 9.77
4.250 0.863 37.15 31.62 9.56
4.375 0.856 36.86 31.53 9.36
4.500 0.849 36.58 31.45 9.16
4.625 0.843 36.32 31.37 8.97
4.750 0.837 36.06 31.30 8.78
4.875 0.832 35.82 31.24 8.60
5.000 0.826 35.59 31.18 8.42
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26152
SEALED BOX ONE DRIVER
NORMA
L
LOADING
BOX SEALED 1 NORMAL 26152
SIZE Q FB F3 HUMP NOTE
5.125 0.821 35.37 31.12 8.25
5.250 0.816 35.16 31.07 8.08
5.375 0.812 34.96 31.02 7.92
5.500 0.807 34.76 30.98 7.76
5.625 0.803 34.57 30.94 7.60
5.750 0.799 34.39 30.90 7.44
5.875 0.795 34.22 30.86 7.29
6.000 0.791 34.05 30.83 7.15
6.125 0.787 33.89 30.80 7.00
6.250 0.783 33.74 30.77 6.86
6.375 0.780 33.59 30.74 6.72
6.500 0.776 33.44 30.72 6.59
6.625 0.773 33.30 30.70 6.45
6.750 0.770 33.17 30.67 6.32
6.875 0.767 33.04 30.65 6.19
7.000 0.764 32.91 30.64 6.07
7.125 0.761 32.79 30.62 5.94
7.250 0.759 32.67 30.60 5.82
7.375 0.756 32.55 30.59 5.70
7.500 0.753 32.44 30.58 5.58
7.625 0.751 32.33 30.56 5.47
7.750 0.748 32.23 30.55 5.35
7.875 0.746 32.13 30.54 5.24
8.000 0.744 32.03 30.53 5.13
8.125 0.741 31.93 30.52 5.02
8.250 0.739 31.84 30.51 4.92
8.375 0.737 31.74 30.51 4.81
8.500 0.735 31.66 30.50 4.71
8.625 0.733 31.57 30.49 4.61
8.750 0.731 31.48 30.49 4.51
8.875 0.729 31.40 30.48 4.41
9.000 0.727 31.32 30.48 4.31
9.125 0.725 31.24 30.47 4.21
9.250 0.724 31.17 30.47 4.12
9.375 0.722 31.09 30.47 4.02
9.500 0.720 31.02 30.46 3.93
9.625 0.719 30.95 30.46 3.84
9.750 0.717 30.88 30.46 3.75
9.875 0.715 30.81 30.46 3.66
10.000 0.714 30.75 30.46 3.57
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26152
SEALED BOX TWO DRIVER
NORMAL
LOADING
BOX SEALED 2 NORMAL 26152
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375
0.500
0.625
0.750
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125 1.202 51.78 38.08 16.56
3.250 1.184 51.01 37.68 16.29
3.375 1.167 50.28 37.31 16.03
3.500 1.152 49.60 36.96 15.77
3.625 1.137 48.96 36.63 15.53
3.750 1.123 48.35 36.33 15.29
3.875 1.109 47.78 36.05 15.06
4.000 1.097 47.23 35.78 14.84
4.125 1.085 46.71 35.53 14.62
4.250 1.073 46.22 35.30 14.41
4.375 1.062 45.75 35.07 14.21
4.500 1.052 45.30 34.86 14.01
4.625 1.042 44.87 34.67 13.82
4.750 1.032 44.46 34.48 13.63
4.875 1.023 44.07 34.30 13.45
5.000 1.015 43.70 34.13 13.27
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26152
SEALED BOX TWO DRIVER
NORMAL
LOADING
BOX SEALED 2 NORMAL 26152
SIZE Q FB F3 HUMP NOTE
5.125 1.006 43.34 33.98 13.10
5.250 0.998 42.99 33.82 12.93
5.375 0.990 42.66 33.68 12.77
5.500 0.983 42.34 33.55 12.61
5.625 0.976 42.03 33.42 12.45
5.750 0.969 41.73 33.29 12.30
5.875 0.962 41.45 33.18 12.15
6.000 0.956 41.17 33.06 12.00
6.125 0.950 40.91 32.96 11.85
6.250 0.944 40.65 32.86 11.71
6.375 0.938 40.40 32.76 11.57
6.500 0.932 40.16 32.67 11.44
6.625 0.927 39.93 32.58 11.30
6.750 0.922 39.70 32.49 11.17
6.875 0.917 39.48 32.41 11.05
7.000 0.912 39.27 32.33 10.92
7.125 0.907 39.06 32.26 10.80
7.250 0.902 38.87 32.19 10.67
7.375 0.898 38.67 32.12 10.55
7.500 0.894 38.48 32.05 10.44
7.625 0.889 38.30 31.99 10.32
7.750 0.885 38.12 31.93 10.21
7.875 0.881 37.95 31.87 10.09
8.000 0.877 37.78 31.82 9.98
8.125 0.873 37.62 31.77 9.88
8.250 0.870 37.46 31.72 9.77
8.375 0.866 37.30 31.67 9.66
8.500 0.863 37.15 31.62 9.56
8.625 0.859 37.00 31.57 9.46
8.750 0.856 36.86 31.53 9.36
8.875 0.853 36.72 31.49 9.26
9.000 0.849 36.58 31.45 9.16
9.125 0.846 36.45 31.41 9.06
9.250 0.843 36.32 31.37 8.97
9.375 0.840 36.19 31.34 8.87
9.500 0.837 36.06 31.30 8.78
9.625 0.835 35.94 31.27 8.69
9.750 0.832 35.82 31.24 8.60
9.875 0.829 35.71 31.21 8.51
10.000 0.826 35.59 31.18 8.42
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26152
SEALED BOX TWO DRIVERS
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 26152
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375
0.500
0.625
0.750
0.875 1.152 49.60 36.96 15.77
1.000 1.097 47.23 35.78 14.84
1.125 1.052 45.30 34.86 14.01
1.250 1.015 43.70 34.13 13.27
1.375 0.983 42.34 33.55 12.61
1.500 0.956 41.17 33.06 12.00
1.625 0.932 40.16 32.67 11.44
1.750 0.912 39.27 32.33 10.92
1.875 0.894 38.48 32.05 10.44
2.000 0.877 37.78 31.82 9.98
2.125 0.863 37.15 31.62 9.56
2.250 0.849 36.58 31.45 9.16
2.375 0.837 36.06 31.30 8.78
2.500 0.826 35.59 31.18 8.42
2.625 0.816 35.16 31.07 8.08
2.750 0.807 34.76 30.98 7.76
2.875 0.799 34.39 30.90 7.44
3.000 0.791 34.05 30.83 7.15
3.125 0.783 33.74 30.77 6.86
3.250 0.776 33.44 30.72 6.59
3.375 0.770 33.17 30.67 6.32
3.500 0.764 32.91 30.64 6.07
3.625 0.759 32.67 30.60 5.82
3.750 0.753 32.44 30.58 5.58
3.875 0.748 32.23 30.55 5.35
4.000 0.744 32.03 30.53 5.13
4.125 0.739 31.84 30.51 4.92
4.250 0.735 31.66 30.50 4.71
4.375 0.731 31.48 30.49 4.51
4.500 0.727 31.32 30.48 4.31
4.625 0.724 31.17 30.47 4.12
4.750 0.720 31.02 30.46 3.93
4.875 0.717 30.88 30.46 3.75
5.000 0.714 30.75 30.46 3.57
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26152
SEALED BOX TWO DRIVERS
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 26152
SIZE Q FB F3 HUMP NOTE
5.125 0.711 30.62 30.46 3.40
5.250 0.708 30.50 30.45 3.23
5.375 0.705 30.38 30.45 3.06
5.500 0.703 30.27 30.46 2.90
5.625 0.700 30.16 30.46 2.75
5.750 0.698 30.06 30.46 2.59
5.875 0.696 29.96 30.46 2.44
6.000 0.693 29.86 30.47 2.29
6.125 0.691 29.77 30.47 2.15
6.250 0.689 29.68 30.47 2.01
6.375 0.687 29.60 30.48 1.87
6.500 0.685 29.52 30.48 1.73
6.625 0.683 29.44 30.49 1.60
6.750 0.682 29.36 30.50 1.47
6.875 0.680 29.29 30.50 1.34
7.000 0.678 29.22 30.51 1.22
7.125 0.677 29.15 30.51 1.09
7.250 0.675 29.08 30.52 0.97
7.375 0.674 29.02 30.53 0.85
7.500 0.672 28.95 30.53 0.73
7.625 0.671 28.89 30.54 0.62
7.750 0.669 28.83 30.55 0.50
7.875 0.668 28.78 30.55 0.39
8.000 0.667 28.72 30.56 0.28
8.125 0.666 28.67 30.57 0.17
8.250 0.664 28.61 30.57 0.07
8.375 0.663 28.56 30.58 -0.04
8.500 0.662 28.51 30.59 -0.14
8.625 0.661 28.47 30.59 -0.25
8.750 0.660 28.42 30.60 -0.35
8.875 0.659 28.37 30.61 -0.45
9.000 0.658 28.33 30.61 -0.54
9.125 0.657 28.29 30.62 -0.64
9.250 0.656 28.24 30.63 -0.74
9.375 0.655 28.20 30.63 -0.83
9.500 0.654 28.16 30.64 -0.92
9.625 0.653 28.12 30.65 -1.01
9.750 0.652 28.09 30.65 -1.10
9.875 0.651 28.05 30.66 -1.19
10.000 0.650 28.01 30.67 -1.28
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26122
SEALED BOX ONE DRIVER
NORMAL
LOADING
BOX SEALED 1 NORMAL 26122
SIZE Q FB F3 HUMP NOTE
0.500 1.139 63.75 47.66 15.52
0.625 1.049 58.71 45.23 13.96
0.750 0.985 55.10 43.62 12.69
0.875 0.936 52.37 42.51 11.61
1.000 0.898 50.23 41.72 10.67
1.125 0.867 48.49 41.15 9.85
1.250 0.841 47.06 40.72 9.11
1.375 0.820 45.85 40.41 8.44
1.500 0.801 44.82 40.17 7.83
1.625 0.785 43.93 39.99 7.27
1.750 0.771 43.15 39.86 6.75
1.875 0.759 42.47 39.76 6.27
2.000 0.748 41.86 39.69 5.82
2.125 0.738 41.31 39.63 5.39
2.250 0.730 40.82 39.60 4.99
2.375 0.722 40.38 39.58 4.62
2.500 0.715 39.97 39.56 4.26
2.625 0.708 39.61 39.56 3.92
2.750 0.702 39.27 39.56 3.59
2.875 0.696 38.96 39.57 3.28
3.000 0.691 38.67 39.58 2.98
3.125 0.686 38.40 39.59 2.70
3.250 0.682 38.15 39.61 2.42
3.375 0.678 37.92 39.63 2.16
3.500 0.674 37.71 39.65 1.90
3.625 0.670 37.51 39.67 1.66
3.750 0.667 37.32 39.69 1.42
3.875 0.664 37.14 39.72 1.19
4.000 0.661 36.97 39.74 0.97
4.125 0.658 36.81 39.76 0.75
4.250 0.655 36.66 39.79 0.54
4.375 0.653 36.52 39.81 0.34
4.500 0.650 36.39 39.83 0.14
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26122
SEALED BOX TWO DRIVER
NORMA
L
LOADING
BOX SEALED 2 NORMAL 26122
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375
0.500
0.625
0.750
0.875 1.200 67.11 49.39 16.46
1.000 1.139 63.75 47.66 15.52
1.125 1.090 61.00 46.31 14.70
1.250 1.049 58.71 45.23 13.96
1.375 1.015 56.77 44.35 13.29
1.500 0.985 55.10 43.62 12.69
1.625 0.959 53.65 43.02 12.12
1.750 0.936 52.37 42.51 11.61
1.875 0.916 51.24 42.08 11.12
2.000 0.898 50.23 41.72 10.67
2.125 0.881 49.32 41.41 10.25
2.250 0.867 48.49 41.15 9.85
2.375 0.853 47.74 40.92 9.47
2.500 0.841 47.06 40.72 9.11
2.625 0.830 46.43 40.55 8.77
2.750 0.820 45.85 40.41 8.44
2.875 0.810 45.32 40.28 8.13
3.000 0.801 44.82 40.17 7.83
3.125 0.793 44.36 40.07 7.55
3.250 0.785 43.93 39.99 7.27
3.375 0.778 43.53 39.92 7.01
3.500 0.771 43.15 39.86 6.75
3.625 0.765 42.80 39.80 6.51
3.750 0.759 42.47 39.76 6.27
3.875 0.753 42.15 39.72 6.04
4.000 0.748 41.86 39.69 5.82
4.125 0.743 41.58 39.66 5.60
4.250 0.738 41.31 39.63 5.39
4.375 0.734 41.06 39.61 5.19
4.500 0.730 40.82 39.60 4.99
4.625 0.726 40.60 39.59 4.80
4.750 0.722 40.38 39.58 4.62
4.875 0.718 40.17 39.57 4.43
5.000 0.715 39.97 39.56 4.26
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26122
SEALED BOX TWO DRIVER
NORMA
L
LOADING
BOX SEALED 2 NORMAL 26122
SIZE Q FB F3 HUMP NOTE
5.125 0.711 39.79 39.56 4.08
5.250 0.708 39.61 39.56 3.92
5.375 0.705 39.43 39.56 3.75
5.500 0.702 39.27 39.56 3.59
5.625 0.699 39.11 39.57 3.43
5.750 0.696 38.96 39.57 3.28
5.875 0.694 38.81 39.57 3.13
6.000 0.691 38.67 39.58 2.98
6.125 0.689 38.53 39.59 2.84
6.250 0.686 38.40 39.59 2.70
6.375 0.684 38.28 39.60 2.56
6.500 0.682 38.15 39.61 2.42
6.625 0.680 38.04 39.62 2.29
6.750 0.678 37.92 39.63 2.16
6.875 0.676 37.81 39.64 2.03
7.000 0.674 37.71 39.65 1.90
7.125 0.672 37.61 39.66 1.78
7.250 0.670 37.51 39.67 1.66
7.375 0.669 37.41 39.68 1.54
7.500 0.667 37.32 39.69 1.42
7.625 0.665 37.23 39.71 1.30
7.750 0.664 37.14 39.72 1.19
7.875 0.662 37.05 39.73 1.08
8.000 0.661 36.97 39.74 0.97
8.125 0.659 36.89 39.75 0.86
8.250 0.658 36.81 39.76 0.75
8.375 0.657 36.74 39.78 0.65
8.500 0.655 36.66 39.79 0.54
8.625 0.654 36.59 39.80 0.44
8.750 0.653 36.52 39.81 0.34
8.875 0.652 36.45 39.82 0.24
9.000 0.650 36.39 39.83 0.14
9.125 0.649 36.32 39.85 0.05
9.250 0.648 36.26 39.86 -0.05
9.375 0.647 36.20 39.87 -0.14
9.500 0.646 36.14 39.88 -0.24
9.625 0.645 36.08 39.89 -0.33
9.750 0.644 36.02 39.90 -0.42
9.875 0.643 35.97 39.91 -0.51
10.000 0.642 35.91 39.93 -0.59
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26122
SEALED BOX TWO DRIVERS
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 26122
SIZE Q FB F3 HUMP NOTE
0.125
0.250 1.139 63.75 47.66 15.52
0.375 0.985 55.10 43.62 12.69
0.500 0.898 50.23 41.72 10.67
0.625 0.841 47.06 40.72 9.11
0.750 0.801 44.82 40.17 7.83
0.875 0.771 43.15 39.86 6.75
1.000 0.748 41.86 39.69 5.82
1.125 0.730 40.82 39.60 4.99
1.250 0.715 39.97 39.56 4.26
1.375 0.702 39.27 39.56 3.59
1.500 0.691 38.67 39.58 2.98
1.625 0.682 38.15 39.61 2.42
1.750 0.674 37.71 39.65 1.90
1.875 0.667 37.32 39.69 1.42
2.000 0.661 36.97 39.74 0.97
2.125 0.655 36.66 39.79 0.54
2.250 0.650 36.39 39.83 0.14
2.375 0.646 36.14 39.88 -0.24
2.500 0.642 35.91 39.93 -0.59
2.625 0.638 35.71 39.97 -0.94
2.750 0.635 35.52 40.01 -1.26
2.875 0.632 35.35 40.05 -1.57
3.000 0.629 35.19 40.09 -1.87
3.125 0.626 35.04 40.13 -2.16
3.250 0.624 34.91 40.17 -2.43
3.375 0.622 34.78 40.20 -2.70
3.500 0.620 34.67 40.23 -2.95
3.625 0.618 34.56 40.26 -3.20
3.750 0.616 34.45 40.30 -3.43
3.875 0.614 34.36 40.32 -3.66
4.000 0.612 34.27 40.35 -3.88
4.125 0.611 34.18 40.38 -4.10
4.250 0.610 34.10 40.41 -4.31
4.375 0.608 34.02 40.43 -4.51
4.500 0.607 33.95 40.45 -4.71
4.625 0.606 33.88 40.48 -4.90
4.750 0.605 33.82 40.50 -5.09
4.875 0.603 33.76 40.52 -5.27
5.000 0.602 33.70 40.54 -5.45
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26122
SEALED BOX TWO DRIVERS
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 26122
SIZE Q FB F3 HUMP NOTE
5.125 0.601 33.64 40.56 -5.62
5.250 0.600 33.59 40.58 -5.79
5.375
5.500
5.625
5.750
5.875
6.000
6.125
6.250
6.375
6.500
6.625
6.750
6.875
7.000
7.125
7.250
7.375
7.500
7.625
7.750
7.875
8.000
8.125
8.250
8.375
8.500
8.625
8.750
8.875
9.000
9.125
9.250
9.375
9.500
9.625
9.750
9.875
10.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26102
SEALED BOX ONE DRIVER
NORMAL
LOADING
BOX SEALED 1 NORMAL 26102
SIZE Q FB F3 HUMP NOTE
0.125
0.250 1.022 68.08 53.01 13.12
0.375 0.874 58.22 49.14 10.28
0.500 0.790 52.60 47.66 8.27
0.625 0.734 48.92 47.16 6.70
0.750 0.695 46.30 47.11 5.43
0.875 0.666 44.34 47.26 4.35
1.000 0.643 42.81 47.52 3.41
1.125 0.624 41.58 47.81 2.59
1.250 0.609 40.56 48.11 1.85
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26102
SEALED BOX TWO DRIVER
NORMAL
LOADING
BOX SEALED 2 NORMAL 26102
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375 1.151 76.68 57.14 15.13
0.500 1.022 68.08 53.01 13.12
0.625 0.936 62.35 50.61 11.56
0.750 0.874 58.22 49.14 10.28
0.875 0.827 55.08 48.22 9.20
1.000 0.790 52.60 47.66 8.27
1.125 0.760 50.59 47.33 7.44
1.250 0.734 48.92 47.16 6.70
1.375 0.713 47.51 47.10 6.04
1.500 0.695 46.30 47.11 5.43
1.625 0.679 45.25 47.17 4.87
1.750 0.666 44.34 47.26 4.35
1.875 0.654 43.53 47.38 3.87
2.000 0.643 42.81 47.52 3.41
2.125 0.633 42.16 47.66 2.99
2.250 0.624 41.58 47.81 2.59
2.375 0.616 41.05 47.96 2.21
2.500 0.609 40.56 48.11 1.85
2.625 0.602 40.12 48.26 1.51
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

VIPER
26102
SEALED BOX TWO DRIVER
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 26102
SIZE Q FB F3 HUMP NOTE
0.125 1.022 68.08 53.01 13.12
0.250 0.790 52.60 47.66 8.27
0.375 0.695 46.30 47.11 5.43
0.500 0.643 42.81 47.52 3.41
0.625 0.609 40.56 48.11 1.85
0.750
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

STUDIO
23128
SEALED BOX ONE DRIVER
NORMAL
LOADING
BOX SEALED 1 NORMAL 23128
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375 1.088 69.77 53.00 13.23
0.500 0.959 61.45 49.29 11.22
0.625 0.871 55.88 47.25 9.65
0.750 0.808 51.82 46.13 8.38
0.875 0.760 48.72 45.57 7.30
1.000 0.722 46.26 45.35 6.36
1.125 0.690 44.25 45.36 5.54
1.250 0.664 42.58 45.51 4.80
1.375 0.642 41.16 45.75 4.14
1.500 0.623 39.93 46.05 3.53
1.625 0.606 38.87 46.37 2.97
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

STUDIO
23128
SEALED BOX TWO DRIVERS
NORMAL
LOADING
BOX SEALED 2 NORMAL 23128
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375
0.500
0.625 1.182 75.77 56.00 14.51
0.750 1.088 69.77 53.00 13.23
0.875 1.016 65.15 50.86 12.15
1.000 0.959 61.45 49.29 11.22
1.125 0.911 58.42 48.12 10.39
1.250 0.871 55.88 47.25 9.65
1.375 0.838 53.70 46.60 8.99
1.500 0.808 51.82 46.13 8.38
1.625 0.783 50.18 45.80 7.82
1.750 0.760 48.72 45.57 7.30
1.875 0.740 47.43 45.43 6.82
2.000 0.722 46.26 45.35 6.36
2.125 0.705 45.21 45.34 5.94
2.250 0.690 44.25 45.36 5.54
2.375 0.677 43.38 45.42 5.16
2.500 0.664 42.58 45.51 4.80
2.625 0.653 41.84 45.63 4.46
2.750 0.642 41.16 45.75 4.14
2.875 0.632 40.52 45.90 3.82
3.000 0.623 39.93 46.05 3.53
3.125 0.614 39.38 46.21 3.24
3.250 0.606 38.87 46.37 2.97
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

STUDIO
23128
SEALED BOX TWO DRIVERS
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 23128
SIZE Q FB F3 HUMP NOTE
0.125
0.250 0.959 61.45 49.29 11.22
0.375 0.808 51.82 46.13 8.38
0.500 0.722 46.26 45.35 6.36
0.625 0.664 42.58 45.51 4.80
0.750 0.623 39.93 46.05 3.53
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

STUDIO
23124
SEALED BOX ONE DRIVER
NORMAL
LOADING
BOX SEALED 1 NORMAL 23124
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375 1.097 70.00 53.03 13.71
0.500 0.969 61.83 49.33 11.69
0.625 0.883 56.35 47.27 10.13
0.750 0.821 52.39 46.11 8.85
0.875 0.773 49.36 45.48 7.77
1.000 0.736 46.96 45.20 6.84
1.125 0.705 45.01 45.12 6.02
1.250 0.680 43.38 45.19 5.28
1.375 0.658 42.00 45.36 4.61
1.500 0.640 40.82 45.57 4.00
1.625 0.624 39.79 45.82 3.44
1.750 0.609 38.89 46.09 2.92
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

STUDIO
23124
SEALED BOX TWO DRIVERS
NORMA
L
LOADING
BOX SEALED 2 NORMAL 23124
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375
0.500
0.625 1.190 75.91 56.00 14.98
0.750 1.097 70.00 53.03 13.71
0.875 1.026 65.46 50.89 12.63
1.000 0.969 61.83 49.33 11.69
1.125 0.922 58.85 48.15 10.87
1.250 0.883 56.35 47.27 10.13
1.375 0.850 54.22 46.61 9.46
1.500 0.821 52.39 46.11 8.85
1.625 0.796 50.78 45.75 8.29
1.750 0.773 49.36 45.48 7.77
1.875 0.754 48.09 45.31 7.29
2.000 0.736 46.96 45.20 6.84
2.125 0.720 45.94 45.14 6.42
2.250 0.705 45.01 45.12 6.02
2.375 0.692 44.16 45.15 5.64
2.500 0.680 43.38 45.19 5.28
2.625 0.669 42.66 45.27 4.94
2.750 0.658 42.00 45.36 4.61
2.875 0.649 41.39 45.46 4.30
3.000 0.640 40.82 45.57 4.00
3.125 0.631 40.29 45.69 3.72
3.250 0.624 39.79 45.82 3.44
3.375 0.616 39.32 45.96 3.18
3.500 0.609 38.89 46.09 2.92
3.625 0.603 38.47 46.23 2.68
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.

STUDIO
23124
SEALED BOX TWO DRIVERS
ISOBARIC
LOADING
BOX SEALED 2 ISOBARIC 23124
SIZE Q FB F3 HUMP NOTE
0.125
0.250 0.969 61.83 49.33 11.69
0.375 0.821 52.39 46.11 8.85
0.500 0.736 46.96 45.20 6.84
0.625 0.680 43.38 45.19 5.28
0.750 0.640 40.82 45.57 4.00
0.875 0.609 38.89 46.09 2.92
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET AND ALL FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2002 by Directed Electronics, Inc. All rights reserved
Directed Electronics Inc.
