Installation Instructions
Model: Polaris Ranger
Description: Stage 2 Install
Part Number: MBQRG-STG2-RAD-1 & MBQRG-STG2-RC-1
Assembly Time: 90 Min (1.5-Hours)
Parts List
No. Component Name Qty
1 GMR-LED w/Housing (MBQRG-RAD-1) (MBQRG-STG2-RAD-1 Only) 1
2 6.5” Dash Speakers (MBQRG-FPOD-1) 2
3 Speaker Harness 2
1Bojo Tool
2 Panel Clip Pliers
3 1/8” Drill Bit
4 Drill
5T25 Torx Bit
7 10mm Socket
8 Rachet
Parts List
Tools Required
Before you begin, read through these instructions and check that
all parts are present. Always disconnect negative battery terminal
prior to installation. Please note that MB Quart cannot assume any
responsibility for damage resulting from incorrect installation.

Page 2 of 10
Dash Disassembly
● Remove hood by turning
two latches
● Remove two push pins from
center cup holder
● Remove two push pins from
instrument cluster. Remove and
disconnect connector on back

Page 3 of 10
Dash Disassembly
● Open upper glove box and
remove four T20 torx screw and
then lift assembly out of vehicle
● Remove three push pins on the
passenger side dash
● Remove three push pins on the
driver side dash

Page 4 of 10
Dash Disassembly
● Remove six push pins from the
front of the dash
● Lift up on the dash and remove
from vehicle

Page 5 of 10
Harness Installation
● Install front speaker wires placing
the four pin connector in the
middle of the dash and extending
the white wires to the driver side
of the dash and the gray wires to
the passenger side of the dash
● Reaching from the top of the
driver side of the dash, pass the
white wires through the top of the
pocket and insert the grommet
● Reaching from the top of the
passenger side of the dash,
pass the gray wires through the
top of the pocket and insert the
grommet

Page 6 of 10
Harness Installation
● On the radio harness pass the
power connection through the
grommet toward the front of the
vehicle and plug into an open port
on the pulse junction block
● Drill a 1” hole on the top of the
glove box to install the USB/AUX
Port (PSAP-18)
1”

Assembly & Dash Radio Install
Page 7 of 10
● Place top of dash in vehicle
● Install three push pins on driver
side of dash
● Connect harness and place the
instrument panel in location and
then insert two push pins

Assembly & Dash Radio Install
Page 8 of 10
● Install three push pins on
passenger side dash
● Install upper glove box with four
T20 Torx screws
● Install six push pins on the front
side of the dash

● Connect the radio harness and
USB/AUX (PSAP-18) harness to
the radio
● Install the radio assembly and
attach with two push pins
Page 9 of 10
Assembly & Dash Radio Install
● Turn vehicle and radio on and
enjoy the music

Page 10 of 10
MBQRG-STG2-RAD-1/MBQRG-STG2-RC-1 REV 01
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a mobile installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
WARNING: Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This equipment complied with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
