Directed Electronics 671XV User manual

© 2004 Directed Electronics, Inc. Vista, CA
N437V 05-04
MMooddeell667711XXVV
IInnssttaallllaattiioonnGGuuiiddee
NOTE: This product is intended for installation by a professional installer only!
Any attempt to install this product by any person other than a trained professional
may result in severe damage to a vehicle’s electrical system and components.

Bitwriter™, Code Hopping™, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn
Routine™, Nite-Lite®, Nuisance Prevention®Circuitry, NPC®, Revenger®, Silent Mode™, Soft
Chirp®, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away®are all Trademarks or
Registered Trademarks of Directed Electronics, Inc.
The Bitwriter®(p/n 998T)
requires chip version 1.4 or
newer to program this unit.
wwwwww..ddiirreecctteecchhss..ccoomm
DDiirreeccttFFaaxx880000--999999--11332299TTeecchhnniiccaallSSuuppppoorrtt880000--775533--00880000
These resources are for authorized Directed Dealer use only.

©2004
Directed Electronics, Inc.
3
Table of Contents
PPrriimmaarryyHHaarrnneessss((HH11))WWiirreeCCoonnnneeccttiioonnGGuuiiddee........................................................................................................................................................44
Primary Harness Wiring Diagram.............................................................................................4
Primary Harness Wiring Instructions........................................................................................4
DDoooorrLLoocckkHHaarrnneessss((HH22)),,33--PPIINNCCoonnnneeccttoorr................................................................................................................................................................99
PPeerriipphheerraallPPlluugg--IInnHHaarrnneesssseess..............................................................................................................................................................................................................1100
Super Bright LED, 2-Pin WHITE Plug..................................................................................10
Valet/Program Switch, 2-Pin BLUE Plug................................................................................10
Programmer Interface, 3-Pin BLACK Plug .............................................................................11
Mounting the Transceiver/Antenna .........................................................................................11
Shock Sensor Harness, 4-Pin White Plug................................................................................11
PPrrooggrraammmmiinnggJJuummppeerr..................................................................................................................................................................................................................................1133
Light Flash Jumper..................................................................................................................13
BByyppaassssiinnggSSeennssoorrIInnppuuttss............................................................................................................................................................................................................................1144
SSyysstteemmFFeeaattuurreessLLeeaarrnnRRoouuttiinnee......................................................................................................................................................................................................1144
SSyysstteemmFFeeaattuurreessMMeennuuss..............................................................................................................................................................................................................................1177
Menu #1 - Basic Features........................................................................................................17
Menu #2 - Advanced Features.................................................................................................17
FFeeaattuurreeDDeessccrriippttiioonnss......................................................................................................................................................................................................................................1188
Menu #1 - Basic Features........................................................................................................18
Menu #2 - Advanced Features.................................................................................................19
TTrraannssmmiitttteerr//RReecceeiivveerrLLeeaarrnnRRoouuttiinnee......................................................................................................................................................................................2211
TTrraannssmmiitttteerrCCoonnffiigguurraattiioonnss..................................................................................................................................................................................................................2233
Standard Configuration...........................................................................................................23
Single Button Arm/Disarm Configuration ..............................................................................23
DDiiaaggnnoossttiiccss..................................................................................................................................................................................................................................................................2244
Arm/Disarm Diagnostics.........................................................................................................24
System Status Chirps...............................................................................................................24
Table of Zones ........................................................................................................................24
LLoonnggTTeerrmmEEvveennttHHiissttoorryy......................................................................................................................................................................................................................2255
MMuullttii--LLeevveellSSeeccuurriittyyAArrmmiinngg..............................................................................................................................................................................................................2255
OOppttiioonnaallVVeehhiicclleeRReeccoovveerryySSyysstteemm((VVRRSS))......................................................................................................................................................................2255
NNuuiissaanncceePPrreevveennttiioonn®®CCiirrccuuiittrryy....................................................................................................................................................................................................2266
RRaappiiddRReessuummeeLLooggiicc......................................................................................................................................................................................................................................2266
TTrroouubblleesshhoooottiinngg....................................................................................................................................................................................................................................................2266
WWiirriinnggQQuuiicckkRReeffeerreenncceeGGuuiiddee......................................................................................................................................................................................................2288

4©2004 Directed Electronics, Inc.
Primary Harness (H1)Wire Connection Guide
Primary Harness Wiring Diagram
___
___
___
___
___
___
___
___
___
___
___
___
Primary Harness Wiring Instructions
This guide describes in detail the connection of each wire. Also included are possible applications
of each wire. This system was designed with the ultimate in flexibility and security in mind. Many
of the wires have more than one possible function. Please read carefully to ensure a thorough under-
standing of this unit.
H1/1 ORANGE (-) ground-when-armed output
This wire supplies a (-) ground as long as the system is armed. This output ceases as soon as the
system is disarmed. The ORANGE wire is pre-wired to control the 8618 starter kill relay. It can
supply up to 500 mA of current.
NOTE: If using the H1/1 ORANGE wire to activate an add-on accessory such as window
automation, pager or voice module a 1Amp diode must be installed to ensure proper operation.
Insert the diode as shown in the following diagram.
IMPORTANT! Never interrupt any wire other than the starter wire.
RED/WHITE (-) 200 mA Channel 2 Output
RED (+) Constant Power Input
BROWN (+) Siren Output
YELLOW (+) Switched Ignition Input, Zone 5
BLACK (-) Chassis Ground Input
VIOLET (+) Door Trigger Input, Zone 3
BLUE (-) Instant Trigger Input, Zone 1
GREEN (-) Door Trigger Input, Zone 3
BLACK/WHITE (-) 200 mA Domelight Supervision Output
WHITE/BLUE (-) 200 mA Channel 3 Programmable Output
WHITE (+)/(-) Selectable Light Flash Output
ORANGE (-) 500 mA Armed Output
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
H1/10
H1/11
H1/12

©2004
Directed Electronics, Inc.
5
H1/2 WHITE (+/-) light flash output
As shipped, the H1/2 WHITE wire should be connected to the (+) parking light wire. If the light flash
polarity jumper is moved to the (-) position (see the
Programming Jumper section of this installation
guide), this wire supplies a (-) 200 mA output. This is suitable for driving (-) light control wires in
Toyota, Lexus, BMW, some Mitsubishi, some Mazda, and other models.
NOTE: For parking light systems that draw 10 amps or more, the jumper must be switched to a
(-) light flash output (see the
Programming Jumpers section of this guide). P/N 8617 or a standard
automotive SPDT relay must be used on the H1/2 light flash output wire.
H1/3 WHITE/BLUE 200 mA (-) channel 3 output
This wire provides a (-) 200 mA output whenever the transmitter button(s) controlling Channel 3
IMPORTANT! DO NOT connect this wire to a negative vehicle light flash wire before
changing the programming jumper to the negative polarity position or damage to
vehicle light circuit may occur.

6©2004 Directed Electronics, Inc.
is pressed. This output can be programmed to provide the following types of output (see System
Features Learn Routine
section of this guide):
➤➤A vvaalliiddiittyyoutput will send a signal as long as the transmission is received.
➤➤A llaattcchheeddoutput will send a signal continuously when the Channel 3 button(s) is pressed and
released. The signal will continue until channel three is pressed again.
➤➤A llaattcchheedd//rreesseettwwiitthhiiggnniittiioonnoutput works similar to the latched output, but will also reset
(output will stop) when the ignition is turned on and then off.
➤➤A 3300sseeccoonnddttiimmeeddoutput will send a signal for 30 seconds when channel three is pressed. This
output can be shut off during the 30-second period by pressing Channel 3 again.
➤➤This output can also be programmed to provide a sseeccoonndduunnlloocckkppuullsseewhen the unlock button
is pressed a second time after disarming the system. This can be used to unlock the passenger
doors when installing progressive door locks.
H1/4 BLACK/WHITE (-) 200 mA domelight supervision output
Connect the H1/4 wire to the optional domelight supervision relay as shown in the following
diagram:
IMPORTANT! This output is only intended to drive a relay. It cannot be connected
directly to the domelight circuit, as the output cannot support the current draw of one
or more bulbs.
IMPORTANT! Never use this wire to drive anything but a relay or a low-current input!
This transistorized output can only supply 200 mA, and connecting directly to a
solenoid, motor, or other high-current device will cause the module to fail.

©2004
Directed Electronics, Inc.
7
H1/5 GREEN (-) door trigger input
Most vehicles use negative door trigger circuits. Connect the GREEN wire to a wire showing
ground when any door is opened. When connecting to newer model vehicles there is generally a
need to use individual door triggers. See DirectFax document 1076 for wiring instructions. This
wire will report Zone 3.
NOTE: If using a door trigger wire that has a delay, Advanced Menu 2, feature 6, or the 998T
Bitwriter can be used to turn Bypass Notification off.
H1/6 BLUE (-) instant trigger input
This input will respond to a negative input with an instant trigger. It is ideal for hood and trunk pins
and will report on Zone 1. It can also be used with Directed single-stage sensors. The H1/6 BLUE
instant trigger wire can also be used to shunt sensors during operation of auxiliary channels or remote
start. (See
Bypassing Sensor Inputs section of this guide.)
H1/7 VIOLET (+) door trigger input
This type of dome circuit is used in many Ford products. Connect the VIOLET wire to a wire that
shows (+)12V when any door is opened. This wire will report Zone 3.
NOTE: If using a door trigger wire that has a delay, Advanced Menu 2, feature 6, or the 998T
Bitwriter can be used to turn Bypass Notification off.

8©2004 Directed Electronics, Inc.
H1/8 BLACK (-) chassis ground connection
Connect this wire to a clean, paint-free sheet metal location (driver kick panel) using a factory bolt
that DOES NOT have any vehicle component grounds attached to it. A screw should only be used
when in conjunction with a two-sided lock washer. Under dash brackets and door sheet metal are
not acceptable ground points. It is recommended that all security components be grounded at the
same location.
H1/9 YELLOW (+) ignition input
Connect this wire to the (+) 12 volts ignition wire. This wire is pre-wired to the starter kill relay and
must show (+) 12 volts with the key in RUN position and during cranking. Take great care that this
wire cannot be shorted to the chassis at any point.
H1/10 BROWN (+) siren output
Connect this to the RED wire of the Revenger® siren. Connect the BLACK wire of the siren to (-)
chassis ground, preferably at the same point you connect the control module’s BLACK ground wire.

©2004
Directed Electronics, Inc.
9
H1/11 RED (+)12V constant power input
Before connecting this wire, remove the supplied fuse. Connect to the battery positive terminal or
the constant 12V supply to the ignition switch.
NOTE: Always use a fuse within 12 inches of the point you obtain (+)12V. Do not use the 15 fuse
in the harness for this purpose. This fuse protects the module itself.
H1/12 RED/WHITE 200 mA (-) channel 2 output
When the system receives the code controlling channel 2 for longer than 1.5 seconds, the
RED/WHITE will supply an output as long as the transmission continues. This is often used to
operate a trunk/hatch release or other relay/driven function.
Door Lock Harness (H2), 3-PIN Connector
___
___
___
For detailed instructions about connecting to the vehicle’s power door lock systems, refer to the
Door Lock Wiring guide (Document No. 1041) available to authorized dealers only from the
technical resources listed at the front of this guide.
IMPORTANT! The door lock outputs are low current and should not be attached
directly to any high current device; they are only to be used to activate relays.
Blue (-) Unlock, (+) Lock Output
Empty Unless Using 451M
Green (-) Lock, (+) Unlock Output
H2/A
H2/B
H2/C
IMPORTANT! Never use this wire to drive anything but a relay or a low-current input!
The transistorized output can only supply 200 mA of current. Connecting directly to a
solenoid, motor, or other high-current device will cause it to fail.

10 ©2004 Directed Electronics, Inc.
Peripheral Plug-In Harnesses
Super Bright LED, 2-Pin WHITE Plug
The super bright LED operates at (+) 2 volt DC and plugs into the two-pin WHITE port. Make
sure the LED wires are not shorted to ground as the LED will be damaged. Multiple LED’s can be
used, but they must be wired in series. The LED fits into a 9/32-inch mounting hole. Be sure to
check for clearance prior to drilling the mounting hole.
Valet/Program Switch, 2-Pin BLUE Plug
The Valet/Program button should be accessible from the driver’s seat. It plugs into the BLUE port
on the side of the unit. Since the system features Valet® by using the remote transmitter, the button
can be well hidden. Consider how the button will be used before choosing a mounting location.
Check for rear clearance before drilling a 9/32-inch hole and mounting the button.The GRAY wire
in the two-pin plug may also be used as a (+) ghost switch input and can be connected to any (+)
switch in the vehicle. (See
Feature Descriptions section of this guide.)
DIA-41
NOTE: Never use a BLUE LED in combination with a RED LED.

©2004
Directed Electronics, Inc.
11
Programmer Interface, 3-Pin BLACK Plug
The BLACK three-pin port is provided for programming of the unit. When using the 998T
Bitwriter, it is possible to configure any and all of the programmable functions. For more infor-
mation please refer to the guide packaged with the programmer. This port can also be used to interface
with Directed Video components for on-screen security system programming and trigger information.
Mounting the Transceiver/Antenna
Transceiver/antenna position should be discussed with the vehicle’s owner prior to installation, since
the antenna may be visible to the vehicle’s operator.
The best location for the transceiver/antenna is centered high on either the front or rear windshield.
For optimal range, the antenna should be mounted horizontally. It can be mounted vertically in
relation to the windshield or under the dashboard away from metal, but range will be diminished.
Metallic window tint can also affect range, so this should be a consideration when determining the
mounting location.
After determining the best mounting location, follow these steps:
1. Clean the mounting area with a quality glass cleaner or alcohol to remove any dirt or residue.
2. Plug the transceiver/antenna cable into the transceiver/antenna.
3. Mount the transceiver/antenna using the supplied double-sided tape.
4. Route the transceiver/antenna cable to the control module and plug it into the four-pin antenna
connector.
Shock Sensor Harness, 4-Pin White Plug
GREEN (-) Multiplex Input
Inputs shorter than 0.8 seconds will trigger the Warn Away® response, while inputs longer than 0.8
seconds will trigger full alarm sequence and report Zone 4.
NOTE: If installing an optional Directed dual-stage sensor, connect to the GREEN wire. The
following diagram eliminates the need for diodes to isolate the sensors, as well as providing a
separate zone for each sensor.
IMPORTANT! To achieve the best possible range, DO NOT leave the antenna cable
bundled under the dash. Always extend the cable full length during installation,
regardless of the antenna mounting location.

12 ©2004 Directed Electronics, Inc.
Diagram for adding optional Directed dual stage sensor to GREEN wire (zone 4).
BLUE (-) Multiplex Input
Inputs shorter than 0.8 seconds will trigger the Warn Away® response, while inputs longer than 0.8
seconds will trigger full alarm sequence and report Zone 2.
RED (+) 12V Constant and BLACK (-) Ground
Do not use these for anything besides the plug-in shock sensor.
NOTE: If adding additonal sensor(s), connect the power and ground of the additional
sensor(s) to the power and ground at the 12-pin harness.
504D 508D
BLUE
GREEN
GREEN
BLUE
Shock Sensor Field Disturbance Sensor
Plug to Control Module

©2004
Directed Electronics, Inc.
13
Programming Jumper
Light Flash Jumper
This jumper is used to determine the light flash output. In the (+) position, the on-board relay is
enabled and the unit will output (+)12V on the WHITE wire, H1/2. In the (-) position, the on-
board relay is disabled. The WHITE wire, H1/2, will supply a 200 mA (-) output suitable for
driving factory parking light relays.
NOTE: For parking light circuits that draw 10 amps or more, the jumper must be switched to a (-)
light flash output. P/N 8617 or a standard automotive SPDT relay must be used on the H1/2 light
flash output harness wire.
IMPORTANT! DO NOT connect the H1/2 light flash wire to a negative vehicle light
flash wire before changing the programming jumper to the negative polarity position or
damage to vehicle light circuit may occur.

14 ©2004 Directed Electronics, Inc.
Bypassing Sensor Inputs
There are times when you need to temporarily bypass all sensor inputs to the unit, such as when
remote starting the vehicle. Anytime an auxiliary channel output is used, all inputs are bypassed for
five seconds. During the five second bypass period, ground can be supplied to the H1/6 BLUE wire
without triggering the unit. When the five second bypass period ends, if the unit sees ground on
the H1/6 BLUE wire, all trigger inputs except the door trigger input will remain bypassed until five
seconds after ground is removed from the BLUE wire. This can be done using the status output of
a Directed Electronics remote engine starting unit as shown in the following diagram:
System Features Learn Routine
The System Features Learn Routine dictates how the unit operates. Due to the number of steps,
they have been broken up into two menus. It is possible to access and change any of the feature
settings using the Valet/Program switch. However, this process can be greatly simplified by using the
998T Bitwriter. Any of the settings can be changed and then assigned to a particular transmitter, up
to four, a feature called Owner Recognition. Each time that particular transmitter is used to disarm
the system, the assigned feature settings will be recalled. Owner Recognition is only possible when
programming the unit via the 998T Bitwriter.
If the system was previously programmed using the 998T Bitwriter, the learn routine may be
locked. If the siren generates one long chirp when attempting to program the unit, the learn routine
is locked and must be unlocked using the 998T Bitwriter.
1. OOppeennaaddoooorr..(The H1/5 GREEN wire or the H1/7 VIOLET wire must be
connected.)

©2004
Directed Electronics, Inc.
15
2. IIggnniittiioonn..Turn the ignition on, then back off: (The H1/9 YELLOW wire must
be connected.)
3. SSeelleeccttaaMMeennuu..Press and HOLD the Valet/Program switch: (The
Valet/Program switch must be plugged into the blue port.) After three seconds
the siren will chirp once indicating entry to the Basic Features Menu #1. If this
is the menu you wish to access, release the button and go on to Step 4. If the
button is not released, you will jump to the Advanced Features Menu #2 and
the siren will chirp twice. Once you have selected the desired menu, release the
Valet/Program button and then proceed to Step 4.
4. SSeelleeccttaaFFeeaattuurree..Press and release the Valet/Program switch the number of
times corresponding to the feature you wish to change. For example, to access
the third feature, press and release the switch three times. Then press the switch
once more and HOLD it. The siren will chirp the number of times equal to
the step you have accessed.
5. PPrrooggrraammtthheeFFeeaattuurree..While HOLDING the Valet/Program switch, you can
toggle the feature on and off using the remote transmitter. Pressing will
select the one chirp setting. Pressing will select the two chirp
setting. (See
System Features Menus section of this guide.)
NOTE: The Valet pulse count feature (2-5) and the Channel three timed
output (2-9) have five possible settings each. Pressing will toggle through
all the two-chirp settings.
6. RReelleeaasseetthheeVVaalleett//PPrrooggrraammSSwwiittcchh..
Once a feature is programmed:
➤➤Other features can be programmed within the same menu.
➤➤Another menu can be selected.
➤➤The learn routine can be exited if programming is complete.

16 ©2004 Directed Electronics, Inc.
To access another feature in the same menu:
1. Press and release the Valet/Program switch the number of times necessary to advance from the
feature you just programmed to the next one you want to program.
2. Then press the Valet/Program switch once more and HOLD it.
For example, if you just programmed the third feature in the menu and you would like to program
the seventh feature in the menu, you would press and release the Valet/Program switch four times
and then press it once more and hold it. The siren would chirp seven times to confirm access to the
seventh feature.
To select another menu:
1. Press and HOLD the Valet/Program switch.
2. After three seconds, the unit will advance to the next menu and the siren will chirp, indicating
which menu has been accessed.
For instance, if you just programmed some features in Menu #1 (Basic Features) and you wish to
program a feature in Menu #2, you press and hold the Valet/Program button. After three seconds,
the siren chirps twice indicating access to Menu #2.
To exit the learn routine do one of the following:
➤➤Close the open door.
➤➤Turn the ignition on.
➤➤No activity for longer than 15 seconds.
➤➤Press the Valet/Program switch too many times.

©2004
Directed Electronics, Inc.
17
System Features Menus
Menu #1 - Basic Features
Items in bold text have been programmed to the default setting at the factory.
Menu #2 - Advanced Features
Feature One Chirp Two-Chirp
Number Setting Setting
2-1 Siren Horn honk
2-2 30-second siren duration 60-second siren duration
2-3 Nuisance Prevention®Circuitry on Nuisance Prevention®Circuitry off
2-4 Progressive door trigger Instant door trigger
2-5 Valet switch input: 1 pulse Valet switch input: 2-5 pulses
2-6 Bypass Notification ON Bypass Notification OFF
2-7 Ignition-controlled domelight ON Ignition-controlled domelight OFF
2-8 Single unlock pulse Double unlock pulse
2-9 Channel 3:Validity Channel 3: latched/latched, reset
with ignition/30-second timed/
second unlock output*
*Second unlock is only available if Feature 2-8 is programmed to single pulse.
Feature One Chirp Two-Chirp
Number Setting Setting
1-1 Active arming Passive arming
1-2 Chirps ON Chirps OFF
1-3 Ignition controlled door locks ON Ignition controlled door locks OFF
1-4 Active locking only Passive locking
1-5 Panic with ignition on No panic with ignition on
1-6 0.8 second door lock pulses 3.5 second door lock pulses
1-7 Forced passive arming ON Forced passive arming OFF
1-8 Automatic Engine Disable ON Automatic Engine Disable OFF
1-9 Armed When Driving (AWD) Vehicle Recovery System (VRS)
1-10 Code Hopping™on Code Hopping™off

18 ©2004 Directed Electronics, Inc.
Feature Descriptions
The features of the system are described below. Features that have additional settings that can be
selected only when programming with the 998T Bitwriter are indicated by the following
icon:
Menu #1 - Basic Features
1-1 ACTIVE/PASSIVE ARMING: When active arming is selected, the system will only arm when
the transmitter is used. When set to passive, the system will arm automatically 30 seconds after the
last door is closed. To alert the consumer of passive arming, the siren will chirp 20 seconds after the
door is closed. This provides the consumer with an audible indication prior to the system actually
arming. At the 30 second mark, the system will arm but the siren will not chirp.
1-2 CHIRPS ON/OFF: This feature controls the chirps that confirm the arming and disarming of
the system.
1-3 IGNITION CONTROLLED DOOR LOCKS ON/OFF: When turned on, the doors
will lock three seconds after the ignition is turned on and unlock when the ignition is turned
off. The 998T Bitwriter will display separate steps for ignition lock and ignition unlock. They can
be programmed on or off independently.
1-4 ACTIVE/PASSIVE LOCKING: If passive arming is selected in step 1-1, then the system can
be programmed to either lock the doors when passive arming occurs, or only lock the doors when
the system is armed via the transmitter. Active locking means the system will not lock the doors
when it passively arms. Passive locking means that the system will lock the doors when it passively
arms.
NOTE: Remember, when passive arming is selected, the unit will chirp 20 seconds after the last
door is closed. The system does not actually arm or lock the doors until 30 seconds after the door
has been closed.
1-5 PANIC WITH IGNITION ON: This step controls whether or not the Panic Mode is available
with the ignition on. In some states, there are laws prohibiting a siren from sounding in a moving
vehicle. This feature makes the system compliant with these regulations.
1-6 DOOR LOCK PULSE DURATION: Some European vehicles, such as Mercedes-Benz and
Audi, require longer lock and unlock pulses to operate the vacuum pump. Programming the system
to provide 3.5 second pulses, will accommodate the door lock interface in these vehicles. The default
setting is 0.8 second door lock pulses.

©2004
Directed Electronics, Inc.
19
1-7 FORCED PASSIVE ARMING ON/OFF: To use this feature, passive arming must be selected
in step 1-1. When turned on, forced passive arming will ensure that the system will passively arm,
even if a zone is left open or invalid. Forced passive arming occurs one hour after the ignition is
turned off.
1-8 AUTOMATIC ENGINE DISABLE (AED) ON/OFF: AED is a full-time, passive starter
disable that works independently of the security system. When turned on, the orange, ground-
when-armed output (H1/1) will go active 30 seconds after the ignition is turned off. The LED will
flash at half its normal rate when the ignition is turned off to indicate that AED is active and will
interrupt the starter in 30 seconds. AED does not occur in Valet mode and can be bypassed using
the emergency override procedure. The transmitter can also be used to disarm AED.
1-9 ARMED WHILE DRIVING/VEHICLE RECOVERY SYSTEM: In the default setting
(Armed While Driving), the system can be armed with the ignition on. When armed, the ground-
when-armed is not active and the sensors are bypassed. The door triggers will remain active. If
programmed to the Vehicle Recovery System (VRS®®) setting, VRS®®will be activated.
1-10 CODE-HOPPING™ ON/OFF: The system uses a mathematical formula to change its code
each time the transmitter and transceiver communicate. This makes the group of bits or “word”
from the transmitter very long. The longer the word is, the easier it is to block its transmission to
the unit. Disabling the Code-Hopping™ feature lets the transceiver ignore the Code-Hopping™
part of the transmitted word. As a result, the unit may have better range with Code-Hopping™ off.
Menu #2 - Advanced Features
2-1 SIREN/HORN HONK: The system can be programmed to output pulses instead of a
continuous output when the system is triggered. This is useful to honk the factory horn in applica-
tions where a siren is undesirable. Remember that the unit is only capable of supplying 1 amp of
current. A relay will be required to interface with most factory horn systems.
2-2 SIREN DURATION 30/60 SECONDS: It is possible to program the unit to sound for
30 or 60 seconds during the triggered sequence. Some states have laws regulating how long a
security system can sound. When using the 998T Bitwriter, the siren can be programmed to sound for
any length of time ranging from 1 to 180 seconds. Using the SELECT button of the 998T Bitwriter
will adjust the siren duration in one second increments.
2-3 NUISANCE PREVENTION
®
CIRCUITRY (NPC
®
) ON/OFF: NPC®®stops repeated
triggering of the same zone. If one zone is triggered three times in one hour, that zone is bypassed
for one hour, starting from the time of the third trigger. During that hour, if the system detects a

20 ©2004 Directed Electronics, Inc.
trigger on that zone again, the system resets the one hour timer. If one hour passes and the zone has
not triggered again, the zone is activated and can trigger the system again. NPC®®monitors sensor
inputs and the door trigger, but does not bypass the ignition trigger at any time. If NPC®®is turned
off, the system will respond to repeated triggers on the sensor inputs and will do so indefinitely.
Some states have laws regulating how many times a security system can trigger before it is considered
a nuisance and the vehicle is towed away.
2-4 PROGRESSIVE DOOR TRIGGER ON/OFF: The system responds to a door trigger input
with a progressive response. When the door is opened with the system armed, the siren will chirp
10 times prior to the full triggered sequence. The door trigger is still treated as an instant trigger and
closing the door quickly will not prevent a full triggered sequence from occurring. If the progressive
door trigger is programmed off, the full siren output will occur the moment the door is opened.
2-5 VALET PULSE COUNT ONE TO FIVE PULSES: The system can be programmed to count
the number presses of the valet button before disarming the security system or VRS®®. The factory
default setting is one pulse. The unit can be set for two to five pulses using the two-chirp setting to
select the pulse count.
Ghost Switch Option: For added security, the GRAY wire on the two-pin Valet/Program can be
connected to any switch in the vehicle that provides a positive (+) momentary pulse.
2-6 BYPASS NOTIFICATION ON/OFF: when programmed on, any active zone input to the
system during arming will generate a bypass notification chirp. When programmed OFF, no bypass
notification chirps will be generated if any zone is active during arming.
2-7 IGNITION-CONTROLLED DOMELIGHT SUPERVISION ON/OFF: If turned on, the
system will turn on the domelight for 30 seconds when the ignition is turned off. The optional
domelight supervision feature must be installed.
2-8 DOUBLE PULSE UNLOCK ON/OFF: Some vehicles require two pulses on a single wire to
unlock the doors. When the double pulse unlock feature is turned on, the BLUE H2/C wire will
supply two negative pulses instead of a single pulse. At the same time, the GREEN H2/A wire will
supply two positive pulses instead of a single pulse. This makes it possible to directly interface with
double pulse vehicles without any extra parts.
2-9 CHANNEL 3 VALIDITY/LATCHED/LATCHED RESET WITH IGNITION/30
SECOND TIMED/SECOND UNLOCK OUTPUT:
Channel 3 can be programmed for these
output configurations. The unit is set to the default validity output. To change the configuration,
use the two-chirp setting to toggle to the different configurations.
