Directed Electronics Clifford 12.2X User manual

MMooddeell1122..22XX
➤
OOwwnneerr’’ssGGuuiiddee

3
© 2006 directed electronics
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
Directed Electronics ("Directed") promises to the original purchaser to repair or replace
with a comparable reconditioned model any Directed unit (hereafter the "unit"), exclud-
ing without limitation the siren, the remote transmitters, the associated sensors and acces-
sories, which proves to be defective in workmanship or material under reasonable use dur-
ing the lifetime of the vehicle provided the following conditions are met: the unit was pro-
fessionally installed and serviced by an authorized Directed dealer; the unit will be pro-
fessionally reinstalled in the vehicle in which it was originally installed by an authorized
Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy
of the bill of sale or other dated proof of purchase bearing the following information: con-
sumer's name, telephone number and address; the authorized dealers name, telephone
number and address; complete product description, including accessories; the year, make
and model of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote trans-
mitters and the associated sensors and accessories, carry a one-year warranty from the date
of purchase of the same. This warranty is non-transferable and is automatically void if: the
original purchaser has not completed the warranty card and mailed it within ten (10) days
of the date of purchase to the address listed on the card; the unit's date code or serial num-
ber is defaced, missing or altered; the unit has been modified or used in a manner con-
trary to its intended purpose; the unit has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising out of defects in materi-
als or construction. The warranty does not cover damage to the unit caused by installa-
tion or removal of the unit. Directed, in its sole discretion, will determine what consti-
tutes excessive damage and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-
ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,
WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,
ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,
OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-
ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS
UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-
AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND
HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-
ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR
MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

4© 2006 directed electronics
CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM
OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER
VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY
AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY
CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.
DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-
ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con-
sequential damages. This warranty gives you specific legal rights and you may also have
other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-
rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-
876-0800. Directed security systems, including this unit, are deterrents against possible
theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability what-
soever, including without limitation, liability for theft, damage and/or vandalism.
Directed does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
➤Date of purchase
➤Your full name and address
➤Authorized dealer's company name and address
➤Type of alarm installed
➤Year, make, model and color of the automobile
➤Automobile license number
➤Vehicle identification number
➤All security options installed on automobile
➤Installation receipts

5
© 2006 directed electronics
ttaabblleeooffccoonntteennttss
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy..............................................................................33
22--wwaayyrreemmootteeccoonnttrroollddiiaaggrraamm...........................................................
...........................77
ssttaannddaarrddrreemmootteeccoonnffiigguurraattiioonnss....................................................................................88
wwhhaattiissiinncclluuddeedd.......................................
.....................................................................99
iimmppoorrttaannttiinnffoorrmmaattiioonn........
..........................................................................................99
system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
rreeppllaac
ceemmeennttrreemmootteeccoonnttrroollss......................................................................................1111
22--wwaayyrreemmootteeccoonnttrroollffuunnccttiioonnss..................................................................................1122
standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
rreemmootteeooppeerraattiioonn..........................................................
..............................................1155
system signal paging features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
out of range notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
pprrooggrraammmmiinngg22--wwaayyrreemmoottee........................................................................................1177
uussiinnggyyoouurrssyysstteemm......................................................................................................1188
active arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
passive arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
multi-level security arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
disarming without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
dome light control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
one-time bypass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
nuisance prevention® circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
aauuxxiilliiaarryy
oouuttppuuttss((ooppttiioonnss))...................................................................................
.......2299
sshhoocckksseennssoorraaddjjuussttmmeenntt............................................................................................3300
enter shock sensor adjustment mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
adjusting the shock sensor setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
exit shock sensor adjustment mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
reset shock sensor to default setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
ddiiaaggnnoossttiiccss...........................................................
.......................................................3322
arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6© 2006 directed electronics
interpreting zone diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
oowwnneerrrreeccooggnniittiioonn..................................................................................
....................3377
rraappiiddrreessuummeellooggiicc......................................................................................................3377
ppoowweerrssaavveerrmmooddee......................................................................................................3388
pprrooggrraammmmiinngg..............................................................................................................3399
iinnssttaallllaattiioonnooppttiioonnss....................................................................................................4422
vveehhiicclleerreeccoovveerryyssyysstteemm((vvrrss®®))....................................................................................4422
arming the vrs® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
vrs® triggered sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
disarming the vrs® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
pprrooggrraammmmiinnggooppttiioonnss................................................................................................4466
sseeccuurriittyy&&ccoonnvveenniieenncceeeexxppaannssiioonnss............................................................................4488
gglloossssaarryyoofftteerrmmss........................................................................................................5511
qquuiicckkrreeffeerreenncceegguuiiddee..................................................................................................5533

7
© 2006 directed electronics
22--wwaayyrreemmootteeccoonnttrroollddiiaaggrraamm
1. Arm/Disarm Indicator (Orange)
2. Receive/Transmit Indicator (Green)
3. Auxiliary Indicator (Yellow)
4. Siren Indicator (Red)
5. Arm Button
6. Disarm Button
7. Panic Button
8. Auxiliary Channel Button
9. Battery Door
1-800-274-0200
RPN 488V/P/X
2(66) CODES
FCC ID: EZSDEI487
1
5
8
2
3
4
6
7
9

8© 2006 directed electronics
ssttaannddaarrddrreemmootteeccoonnffiigguurraattiioonnss
controls the LLoocckk––AArrmm//PPaanniiccOOnn//PPaanniiccOOfffffunction.
controls the UUnnlloocckk––DDiissaarrmm//PPaanniiccOOfffffunction.
controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt((22)).
controls the PPaanniic
cOOnn//OOfffffunction (hold for 2-seconds).
and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((33)).
and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((44)).
and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((55)).
and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((66)).

9
© 2006 directed electronics
wwhhaattiissiinncclluuddeedd
➤One control module
➤One four-button LED 2-way transmitter, 488XD
➤One four-button transmitter, 7141X
➤Wire harnesses
➤Dual diode harness
➤The 514N six-tone programmable siren
➤The in-vehicle status LED indicator light
➤A push-button Valet switch
➤Your warranty registration
➤Failsafe®Starter Kill ready circuitry
(may require additional labor)
➤548T transceiver/antenna
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years
of trouble-free operation. Due to the complexity of this system,
it must be installed by an authorized dealer only. Installation of
this product by anyone other than an authorized dealer voids the
warranty. All dealers are provided with preprinted dealer certifi-
cates to verify that they are authorized.
This owner’s guide should help you to get the most out of your
system. Please take the time to read it prior to using the system.
note: On both remotes the panic button is the same color.

10 © 2006 directed electronics
system maintenance
This system needs no specific maintenance beyond 2-way
remote control battery replacement. The 2-way remote is
powered by a 1.5V AAA battery. The 1-way remote is powered
by a pair of 3V CR2016 batteries.
Low Battery Notification
If the battery is low (and this feature is programmed On) the 2-
way remote will emit 2 long beeps 5-seconds after a transmission
is completed. The 2 long beeps will repeat every 25 seconds up
to 3 times (or until a 2-way remote button is pressed).
Battery Replacement
Gently pull the end of the battery door away from the top of the
remote control then slide the door up to expose the battery and
remove the expired battery. Place the new battery into the
remote control observing the correct polarity. When power is
returned the remote control will light all icons and generate
melodies (representing all beeper tones).
your warranty
Your warranty registration must be returned and the bar code
serial number must not be removed. If the warranty registration
is not returned, you do not have a warranty. It is also necessary
to keep your proof of purchase, which reflects that the product
was installed by an authorized dealer. Make sure that you receive
the warranty registration from your dealer.
➜
➜

11
© 2006 directed electronics
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
rreeppllaacceemmeennttrreemmootteeccoonnttrroollss
You can purchase replacement remote controls from your
Authorized Dealer or on-line at the following web site:
www.directedstore.com
Once you receive your new remote control, please refer to
instructions included on the remote packaging.
3201 Series
➜
