Intelliguard 750
OOwwnneerr’’ssGGuuiiddee

i
© 2003 directed electronics, inc.
limited lifetime consumer warranty
Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace
with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding
without limitation the siren, the remote transmitters, the associated sensors and accessories,
which proves to be defective in workmanship or material under reasonable use during the life-
time of the vehicle provided the following conditions are met: the unit was professionally
installed and serviced by an authorized Directed dealer; the unit will be professionally rein-
stalled in the vehicle in which it was originally installed by an authorized Directed dealer; and
the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other
dated proof of purchase bearing the following information: consumer's name, telephone num-
ber and address; the authorized dealers name, telephone number and address; complete prod-
uct description, including accessories; the year, make and model of the vehicle; vehicle license
number and vehicle identification number. All components other than the unit, including with-
out limitation the siren, the remote transmitters and the associated sensors and accessories,
carry a one-year warranty from the date of purchase of the same. This warranty is non-trans-
ferable and is automatically void if: the original purchaser has not completed the warranty card
and mailed it within ten (10) days of the date of purchase to the address listed on the card; the
unit's date code or serial number is defaced, missing or altered; the unit has been modified or
used in a manner contrary to its intended purpose; the unit has been damaged by accident,
unreasonable use, neglect, improper service, installation or other causes not arising out of
defects in materials or construction. The warranty does not cover damage to the unit caused
by installation or removal of the unit. Directed, in its sole discretion, will determine what con-
stitutes excessive damage and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED
TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS
FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL
PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES
ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CON-
NECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY
FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR
INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS
AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE
AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;
AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITHOUT LIM-
ITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT
COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR
ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE
INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUN-
TY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS
SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM
AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER'S
PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCI-
DENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL

ii
LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE,
THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an
implied warranty will last or the exclusion or limitation of incidental or consequential damages.
This warranty gives you specific legal rights and you may also have other rights that vary from
State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your authorized
Directed dealer for details of the plan or call Directed Customer Service at 1-800-876-0800.
Directed security systems, including this unit, are deterrents against possible theft. Directed is
not offering a guarantee or insurance against vandalism, damage or theft of the automobile,
its parts or contents; and hereby expressly disclaims any liability whatsoever, including without
limitation, liability for theft, damage and/or vandalism. Directed does not and has not autho-
rized any person or entity to create for it any other obligation, promise, duty or obligation in
connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
zDate of purchase
zYour full name and address
zAuthorized dealer's company name and address
zType of alarm installed
zYear, make, model and color of the automobile
zAutomobile license number
zVehicle identification number
zAll security options installed on automobile
zInstallation receipts
trademarks and copyrights
Bitwriter™, Clifford®, Code-Hopping™, DEI®, Directed®, Doubleguard®, ESP™, FailSafe®, Ghost
Switch™, Learn Routine™, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®, Revenger®, Silent
Mode™, Soft Chirp®, Stealth Coding™, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and
Warn Away®are all Trademarks or Registered Trademarks of Directed Electronics, Inc.
iimmppoorrttaanntt!!Please note that this manual was intended for US consumers
and therefore includes American phrases or words.

1
© 2003 directed electronics, inc.
what is included . . . . . . . . . . . .2
important information . . . . . . .2
system maintenance . . . . . . .3
your warranty . . . . . . . . . . . .3
fcc/id notice . . . . . . . . . . . . .3
transmitter configurations . . . .4
transmitter functions . . . . . . . . .5
standard configuration . . . . .5
using your system . . . . . . . . . . .7
arming . . . . . . . . . . . . . . . . .7
disarming . . . . . . . . . . . . . . .8
disarming without a transmitter 9
remote siren silencing . . . . . .9
transmitter chirp muting . . . .9
transmitter sensor disable . . .10
intellistart and smartwindows
sensor bypass . . . . . . . . . . . .10
auxiliary channel bypass . . . .11
panic mode with smart door
locking . . . . . . . . . . . . . . . . .11
disarm/valet mode . . . . . . . .11
transmitter valet mode . . . . .12
one-time auto-arming bypass 12
low battery warning . . . . . . .13
multiple event total recall . . .13
false alarm control technology
(FACT II) . . . . . . . . . . . . . . . .14
select siren sounds . . . . . . . . . . .15
diagnostics . . . . . . . . . . . . . . . . .15
arming diagnostics . . . . . . . .15
disarming diagnostics . . . . . .16
arm/disarm diagnostic chart .16
table of zones . . . . . . . . . . . .17
anti-code grabbing (ACG) . . . . .17
high frequency . . . . . . . . . . . . . .18
smart power up II . . . . . . . . . . .18
power saver mode . . . . . . . . . . .18
programming options . . . . . . . .19
cliffnet wizard installation
software programming . . . . .21
manual programming
instructions . . . . . . . . . . . . . .21
user selectable features . . . . .23
user selectable features
descriptions - column one . . .24
user selectable features
descriptions - column two . . .26
user selectable features
descriptions - column three . .28
pin programming . . . . . . . . . . .30
auto-immobilization feature . .31
auto-immobilization sequence 31
one-time valet feature . . . . .32
blackjax feature . . . . . . . . . . . . .33
blackjax activation sequence .33
blackjax deactivation sequence34
bypass blackjax temporarily . .35
blackjax off warning indicator36
audio sensor . . . . . . . . . . . . .36
adjusting the omnisensor . . .36
glossary of terms . . . . . . . . . . . .38
security & convenience
expansions . . . . . . . . . . . . . . . . .40
health check . . . . . . . . . . . . . . . .41
contents

what is included
zIntelliguard control module and harness
zTwo five-button transmitters
zPresentation envelope and quick reference card
zTwo window decals
zXHF antenna/receiver with harness
zPre-wired blue status LED
zPlainView 2 Valet switch
z518C neo-siren
z506T audio sensor
zDigital dual-zone omnisensor
important information
Congratulations on the purchase of your state-of-the-art vehicle
security system. It has been designed to provide years of trouble-free
operation. This system must be installed by an authorized dealer.
Installation of this product by anyone other than an authorized dealer
voids the warranty. As verification of authorization, all authorized deal-
ers are provided with preprinted dealer certificates.
In order to maximize the use of this system, please review this owner's
guide carefully prior to using your system. You can print additional or
replacement copies of this owner’s guide by accessing the Clifford web-
site at www.clifford.com.
2

3
© 2003 directed electronics, inc.
system maintenance
The system requires no specific maintenance. Your transmitter is pow-
ered by a miniature 3V lithium battery that will last approximately one
year under normal use. When the battery weakens, operating range will
be reduced and the system will provide a low battery warning chirp indi-
cation when disarming.
your warranty
Your warranty registration must be completely filled out and returned
within 10 days of purchase. Your product warranty will not be validat-
ed if your warranty registration is not returned. Make sure you receive
the warranty registration from your dealer. It is also necessary to keep
your proof of purchase, which reflects that the product was installed by
an authorized dealer.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user's authority to operate this device.
Directed Electronics, Inc.
Tested to Comply
with FCC Standards

4
transmitter configurations
.
Arm/Disarm and
Panic Button
Silent Arm/Disarm
or Accessory
Output Button
Trunk Release or
Optional Accessory
Channel Button
Remote Start or
Accessory Output
Button
Shift Button
nnoottee::This manual describes the features and accessories that are
included with your system along with information about compatible
Clifford accessories that are not included. For a list of included acces-
sories, please refer to the
What Is Included section of this manual.

5
© 2003 directed electronics, inc.
transmitter functions
This system uses computer-based code learning to learn the transmit-
ter buttons. This makes it possible to assign any transmitter button to
any system function. The transmitter initially comes programmed with
standard configuration, but may also be customized using the CliffNet
Wizard PC program. The buttons in all of the instructions in this man-
ual correspond to a standard configuration transmitter.
standard configuration
Button
The arming, disarming, and panic function are controlled by this but-
ton.
Button
The trunk release or accessory output A is controlled by this button.
Button
Silent arm and disarm is controlled by this button.
Button
Remote start is controlled by this button.
Button, then Button
Accessory B output is controlled by these buttons.
Button, then Button
These buttons activate SmartWindows.

6
Button, then Button
Accessory C output is controlled by these buttons.
Button twice, then Button
These buttons active remote valet.
Button twice, then Button
These buttons disable the sensors.
Button twice, then Button
These buttons enter safe start mode for manual transmission vehicles
and activate Autostart mode.
Button three times, then Button
These buttons adjust the dual-zone omnisensor.
Button three times, then Button
These buttons adjust the dual-zone radar sensor.

7
© 2003 directed electronics, inc.
using your system
The buttons used in the instructions in this manual correspond to the
standard transmitter configuration. If your transmitter has been custom
configured, the icons on your transmitter buttons may not correspond
to the indicated functions.
arming
You can activate, or arm, the system by pressing on your trans-
mitter for one second. When the system arms, you will hear two short
siren sounds, or chirps, and see the parking lights flash twice. The LED
will begin to flash steadily. If the vehicle’s power door locks have been
connected to the system, the doors will lock.
While the system is armed, the LED status indicator will flash approxi-
mately once per second showing that the system is actively protecting
your vehicle. If you hear more than two chirps when arming, refer to
the Diagnostics section of this guide. These extra chirps confirm a mal-
function autobypass.
The security system also can be programmed to arm itself
automatically (called passive arming). If the system is programmed for
passive arming, it will automatically arm 30 seconds after the ignition
is turned off and the system sees you leave the vehicle by opening and
closing a door. Whenever the system is in its 30-second passive-arming
countdown. The siren will chirp twice and the lights will flash twice five
seconds after the last door has been closed. The system is not actually
armed at that point. The system arms and the doors lock (if connected

8
and programmed for passive locking) at 30 seconds, but the siren will
not chirp. The early chirps provide you with a 25-second warning prior
to arming.
When armed, your vehicle is protected as follows:
zThe LED will flash as a visible theft deterrent.
zLight impacts will trigger the Warning Zone signal. When
triggered, the siren will sound for a few seconds.
zHeavy impacts will trigger the system. The triggered
sequence is 30, 60, or 90 seconds of constant siren sounding
and flashing parking lights.
zIf a protected entry (door, hood, or trunk) is opened, the sys-
tem will immediately trigger the siren and flash the parking
lights. If any vehicle glass is broken the system will immedi-
ately trigger the siren and flash the lights.
disarming
To disarm the system, press . You will hear a chirp and the park-
ing lights will flash once. If the power locks are connected to the sys-
tem, the doors will unlock. If the siren chirps three times when disarm-
ing, refer to the Diagnostics section of this guide. This is called Tamper
Alert. If the siren is active when the system is disarmed you will hear two
chirps but the system is not disarmed. (Refer to the Remote Siren
Silencing section of this guide.) However, if the alarm completes the full
trigger cycle when disarmed you will hear three chirps.
nnoottee::If any protected entry point (a door or a switch-protected trunk or
hood) is open, the system will not passively arm. Additionally, each
time a protected entry is triggered during the arming countdown, the
30-second countdown starts over.

9
© 2003 directed electronics, inc.
disarming without a transmitter
This feature allows you to disarm the system without the transmitter
should it be lost, damaged, or disabled. In order to disarm without a
transmitter, you must have the vehicle’s ignition key, know where the
PlainView 2 Valet switch is located, and have the PIN code. Be sure to
check with the installer for the location of the PlainView 2 Valet switch.
Please refer to the Disarm/Valet Mode section of this guide for instruc-
tions to enter the pin code.
remote siren silencing
This system offers remote siren silencing. Remote siren silencing is a fea-
ture that makes it possible to silence and reset the system when it is
triggering without disarming the system. If the system is triggered and
the siren has been sounding, press on the transmitter to stop the
trigger and return the unit to the armed state. The system will not dis-
arm, but rather reset. This prevents you from disabling the system
should you wish to silence it without visually checking the vehicle. After
resetting the system, press again to disarm the system.
transmitter chirp muting
To temporarily turn off the arm or disarm chirps, use transmitter chirp
muting. Simply press on the transmitter, and the confirmation
chirp(s) will be eliminated for that one operation only. The parking
lights will flash to confirm the arm/disarm command. If you want the
arm/disarm chirps turned off permanently, please refer to the User-
Selectable Features section of this guide.

10
transmitter sensor disable
To temporarily disable a sensor input, arm the system, press
twice and then . The lights will flash four times and
all warn away trigger zones one, two, three, and eight are bypassed.
Press the buttons again; the lights flash four times and both warn away
and full trigger zones one, two, three, and eight are bypassed until the
system is disarmed. This can be performed anytime the system is
armed.
1. Arm the system.
2. Press twice and then .
3. The lights will flash four times; all warn away zones are now
bypassed.
4. Transmit the sensor bypass channel again.
5. The lights will flash four more times; the sensor warn away
and full trigger zones are now bypassed.
6. The sensor zones will reset when disarmed.
intellistart and smartwindows sensor bypass
When the system sees a command to start the vehicle via the
Intellistart, it bypasses sensor zones and will continue to bypass these
zones until the remote start shuts down.
When the system sees a SmartWindows command for up or down
operation, the unit will automatically bypass sensor zones one, two,
three, and eight until the windows complete their operation.

11
© 2003 directed electronics, inc.
auxiliary channel bypass
Alarm sensor input zones one, two, three, and eight will be bypassed
while a pulsed or timed auxiliary Output is active.
panic mode with smart door locking
If you are threatened in or near your vehicle, you can attract attention
by triggering the system with your transmitter! Just press for
two seconds to enter Panic Mode. The siren will sound and the park-
ing lights will flash for the programmed duration. If the ignition is on,
the doors will lock; if the ignition is off, the doors will unlock. To stop
Panic Mode at any time press on the transmitter again.
disarm/valet mode
Entering your pin code using the PlainView 2 Valet switch allows you
to disarm the system or enter valet mode without using the transmit-
ter. In valet mode, the security system will not arm, even with the trans-
mitter, but all convenience functions (door locks, trunk release, etc.)
will continue to work normally.
To disarm or enter Valet Mode:
1. Turn the ignition on.
2. Enter PIN code (factory setting is 2).
3. After the last digit of the pin code is entered:
a. To disarm the system: press and release .

12
b. To enter valet mode: Press and hold for
three seconds.
The LED status indicator will light steadily if you are entering Valet
Mode and will turn off if you are exiting Valet Mode.
To exit Valet Mode:
1. Turn the ignition on.
2. Enter PIN code.
3. After the last digit press for one second.
The LED will turn off.
transmitter valet mode
The operations described in this section refer to transmitter buttons.
Remember, the buttons used in all the instructions in this guide corre-
spond to a Standard Configuration transmitter. This may not be how
your transmitter is set up.
To enter Valet Mode, press twice and then . The
LED status indicator will light solid if you are entering Valet Mode, or
will turn off if you are exiting Valet Mode.
one-time auto-arming bypass
This will bypass the auto arm feature once only.
1. With the key, turn the ignition on, then off within two seconds.
2. The siren will chirp once to confirm auto arming bypass.

13
© 2003 directed electronics, inc.
3. The system will not auto arm.
During auto arming bypass the system will not roll up the windows if
SmartWindows is connected, and the accessory output will not auto-
activate when using the remote to arm the system.
low battery warning
When the transmitter battery is low, the system will generate a low-
pitched tone when disarmed.
multiple event total recall
This will report the last eight system triggers.
1. Press and hold of the PlainView 2 Valet switch.
2. While still holding , arm and disarm the system, then
release the button.
3. The LED will start to blink to indicate the most recent trigger
and proceed down to the eighth trigger. If fewer than eight
triggers are stored in memory, the LED will blink continuous-
ly until the system is armed/disarmed using the transmitter
or the ignition is turned on. For more information, please
refer to the Table of Zones section of this guide.
nnoottee::The system will revert to normal auto arming when the system
sees the ignition on for at least three seconds.

14
false alarm control technology (FACT II)
Your system offers FACT II, a feature that prevents annoying
repetitive trigger sequences due to a faulty sensor or environmental
conditions such as thunder, jackhammers, airport noise, etc.
Here’s how it works: The alarm triggers three times. If the same sensor
is triggering the alarm and the first and the third triggers are within 60
minutes of each other, FACT II will interpret this pattern of triggers as
false alarms. After the third trigger, FACT II ignores, or bypasses, that
sensor (along with any other sensors sharing the same zone) for 60
minutes.
If the bypassed sensor tries to trigger the system while it is being
bypassed, the 60-minute bypass period will start over. This ensures that
a sensor that continually triggers will remain bypassed.
Doors are covered by FACT II differently; if the alarm is triggered by an
open door for three full cycles, the doors will be bypassed until the trig-
ger ceases. FACT II is programmable. See the Programming Options
section of this guide.
nnoottee::Arming and disarming the system does not reset this function! The
only way to reset a bypassed zone is for 60 minutes or to turn on the
ignition. If testing your system, it is important to remember that the FACT
II programming can cause zones to be bypassed and appear to stop
working. If you wish to clear the FACT II memory, turn the ignition key on.

15
© 2003 directed electronics, inc.
select siren sounds
To customize siren sounds, please refer to the selectable siren sounds
feature in the User Selectable Features grid. Once in programming
mode, press on the transmitter to begin playback of the avail-
able sounds.
Press on the PlainView 2 Valet switch while playing the desired
sound to add that sound; press while playing the desired sound to
delete that sound.
diagnostics
The microprocessor at the heart of your security system is constantly
monitoring all of the switches and sensors that are connected to it. It
detects any faulty switches and sensors and prevents them from dis-
abling the entire system. The microprocessor will also record and report
any triggers that occurred during your absence.
arming diagnostics
If the system is armed while an input is active (door open, sensor trig-
gering, etc.) the unit will chirp twice when arming and then four more
times five seconds later. This is called Bypass Notification.
The security system will ignore the input that was active when the sys-
tem was armed, until the input goes away. Three seconds later the sys-

16
tem will monitor that input normally. For example, if your vehicle has
interior light exit delay, and you arm the system before the interior light
goes out, you may hear Bypass Notification chirps. Once the light shuts
off, however, the doors are monitored normally.
disarming diagnostics
Extra disarm chirps are the Tamper Alert. If three chirps are heard when
disarming, the system was triggered in your absence. If three chirps are
heard, the LED status indicator will indicate which zone was involved
when you turn the ignition on (see the Table of Zones section). The sys-
tem will retain this information in its memory. Refer to the Multiple
Event Total Recall section of this guide.
arm/disarm diagnostic chart
Action Chirps Light Flashes Description
Arm 2 2 System armed
Arm 4 4 System armed with hood/
trunk active and bypassed
(zones 5 and 6)
Arm 2 (5 sec.) 4 2 (5 sec.) 4 System armed with door
active and bypassed (zone 4)
Arm 2 (10 sec.) 4 2 (10 sec.) 4 System armed with sensor
active and bypassed zones
1, 2, 3, and 8
Disarm 1 1 System disarmed
Disarm 3 3 System disarmed with
tamper alert

17
© 2003 directed electronics, inc.
table of zones
The zone number is the number of LED flashes used by the system to
identify a specific input. The standard input assignments are listed
below, along with spaces to write in any optional sensors or switches
you have had installed. If the Warning Zone response is triggered, the
LED will not report it.
anti-code grabbing (ACG)
This unit features Anti-Code Grabbing (ACG) with Random Code
Encryption. This means the receiver and transmitters each use a math-
ematical formula called an algorithm to change their code each time
the transmitter is used. This technology has been developed to increase
the security of the unit. The control unit knows what the next codes
should be.
Zone - Number Dealer-Installed
of LED Flashes Description Options
1 Proximity sensor
2 Omnisensor
3 Mux 1 trigger - for optional
sensors
4 Door switch trigger
5 Instant trigger - trunk
6 Instant trigger - hood
7 Ignition trigger
8 Mux 2 trigger - for optional
sensors
9 BlackJax activation
10 Power interrupt
