Directed Electronics Python 1401 User manual

Remote Start Keyless Entry
Model 1401
Owner’s Guide
© 2008 Directed Electronics, Vista, CA
G4102P 2008-09

Contents
Government regulations .....................................................................................5
Warning! Safety first .........................................................................................7
What’s included................................................................................................9
Important information ........................................................................................9
Your warranty...........................................................................................9
Replacement remote controls ......................................................................9
System maintenance................................................................................10
Low battery indicator ..............................................................................10
Battery replacement ................................................................................10
Two car operation...................................................................................11
1-way remote .................................................................................................12
Transmitter configuration..........................................................................13
Feature list .............................................................................................14
Using the system .............................................................................................17
Locking the vehicle..................................................................................17
Unlocking the vehicle ..............................................................................17
Valet mode ...........................................................................................18
Panic Mode ...........................................................................................18
Remote feature programming ...................................................................19
Overriding the optional starter kill.............................................................20
Using the remote start ......................................................................................21
Manual transmission vehicles ...................................................................22
Timer mode............................................................................................23
Turbo timer mode....................................................................................24
Smart start activation...............................................................................25
Turning on the rear defogger....................................................................27
Valet take-over .......................................................................................27
Safety features................................................................................................28
Optional starter anti-grind circuitry............................................................28
Disabling the remote start system ..............................................................28
Diagnostics ....................................................................................................29
Locking..................................................................................................29
Unlocking ..............................................................................................29
Remote start ...........................................................................................29
Owner recognition ..........................................................................................30
Rapid resume logic..........................................................................................30
Power saver mode...........................................................................................30
Programming options.......................................................................................31
Convenience expansions..................................................................................32
Glossary of terms............................................................................................33
Quick reference guide .....................................................................................35
Limited lifetime consumer warranty ....................................................................37

5
© 2008 Directed Electronics. All rights reserved.
Government regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television,
which can be determined by turning the equipment Off and ON, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to•
which
the receiver is connected.
Consult the dealer or an experienced radio / TV technician for help.•
To satisfy FCC RF exposure compliance requirements, this device should be used
in hand-held, hand operated configurations only. The device and its antenna
must maintain a separation distance of 20 cm or more from the person’s body,
except for the hand and wrists, to satisfy RF exposure compliance. This device
is designed to be used in a person’s hands and its operating configurations do
not support normal transmissions while it is carried in pockets or holsters next to
a persons’ body.

6© 2008 Directed Electronics. All rights reserved.
This device complies with the Industry Canada Radio Standards Specification
RSS 210. Its use is authorized only on a no-interference, no-protection basis;
in other words, this device must not be used if it is determined that it causes
harmful interference to services authorized by IC. In addition, the user of this
device must accept any radio interference that may be received, even if this
interference could affect the operation of the device.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this device.

7
© 2008 Directed Electronics. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
Due to the complexity of this system, installation of this product must only be
performed by an authorized Directed dealer.
When properly installed, this system can start the vehicle via a command
signal from the remote control transmitter. Therefore, never operate the system
in an enclosed area or partially enclosed area without ventilation (such as a
garage). When parking in an enclosed or partially enclosed area or when
having the vehicle serviced, the remote start system must be disabled using the
installed toggle switch. It is the user’s sole responsibility to properly handle and
keep out of reach from children all remote control transmitters to assure that the
system does not unintentionally remote start the vehicle. THE USER MUST IN-
STALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA
ADJACENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT
LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions
are the sole responsibility of the user.
Remote starters on manual transmission vehicles operate differently than those
with automatic transmission because you must leave your car in neutral. You
must read this Owner’s Guide to familiarize yourself with the proper proce-
dures regarding manual transmission remote starters. If you have any questions,
ask your installer or contact Directed at 1-800-753-0600.
Before remote starting a manual transmission vehicle, be sure to:
Leave the vehicle in neutral and be sure no one is standing in front or•
behind the vehicle.
Only remote start on a flat surface•
Have the parking brake fully engaged•
Warning! It is the responsibility of the owner to ensure the parking/emergency
brake properly functions. Failure to do so can result in personal injury or prop-
erty damage. We recommend the owner have the parking/emergency brake
system inspected and adjusted by a qualified automotive shop biannually.

8© 2008 Directed Electronics. All rights reserved.
Use of this product in a manner contrary to its intended mode of operation
may result in property damage, personal injury, or death. (1) Never remotely
start the vehicle with the vehicle in gear, and (2) Never remotely start the
vehicle with the keys in the ignition. The user must also have the neutral safety
feature of the vehicle periodically checked, wherein the vehicle must not
remotely start while the car is in gear. This testing should be performed by an
authorized Directed dealer in accordance with the Safety Check outlined in
the product installation guide. If the vehicle starts in gear, cease remote start
operation immediately and consult with the authorized Directed dealer to fix
the problem.
After the remote start module has been installed, contact your authorized
dealer to have him or her test the remote start module by performing the Safety
Check outlined in the product installation guide. If the vehicle starts when
performing the Neutral Safety Shutdown Circuit test, the remote start unit has
not been properly installed. The remote start module must be removed or the
installer must properly reinstall the remote start system so that the vehicle does
not start in gear. All installations must be performed by an authorized Directed
dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT-
ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY
RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDI-
ATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN
AUTHORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED
REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR
PAY FOR INSTALLATION OR REINSTALLATION COSTS.
This product is designed for fuel injected vehicles only. Use of this product in a
standard transmission vehicle must be in strict accordance with this guide.
This product should not be installed in any convertible vehicles, soft, or hard
top with a manual transmission. Installation in such vehicles may pose certain
risk.

9
© 2008 Directed Electronics. All rights reserved.
What’s included
Two five-button/1-way Supercode remotes•
The control module (installed out-of-sight)•
Control center with integrated status LED and Valet override switch•
A remote start defeat toggle switch•
Window decals•
Your warranty registration•
Important information
Congratulations on the purchase of your state-of-the-art remote start and keyless
entry system. Due to the complexity of this system, it must be installed by an
authorized dealer only. Installation of this product by anyone other than an au-
thorized dealer voids the warranty. All dealers are provided with a preprinted
dealer certificate to verify authorization.
By carefully reading this Owner’s Guide prior to using your system, you will
maximize the use of this system and its features. You can print additional or
replacement copies of this manual by accessing our web site at
www.directed.com.
➤Your warranty
Your warranty registration must be completely filled out and returned within 10
days of purchase. Your product warranty will not be validated if your warranty
registration is not returned. Make sure you receive the warranty registration
from your dealer. It is also necessary to keep your proof of purchase, which
reflects that the product was installed by an authorized dealer.
➤Replacement remote controls
Your system comes with two, remote controls (P/N 7153P). If additional
remotes are desired, please see your authorized dealer or visit
www.directedstore.com to order.

10 © 2008 Directed Electronics. All rights reserved.
➤System maintenance
The system requires no specific maintenance. Your remotes are powered by
small coin cell lightweight 3-volt lithium batteries that last approximately one
year under normal use. The remote uses one CR2032 cell battery. When the
battery begins to weaken, the operating range is reduced.
➤Low battery indicator
When the batteries are low on the remote the vehicle system emits an addi-
tional honk when unlocking to let you know its time to change the battery.
Note: The optional horn honk should be installed, for the system to emit any
additional honks during unlocking. Ask your authorized dealer if you have any
questions.
➤Battery replacement
Using a small slot-1.
ted screwdriver, insert
into slot located as
shown and carefully
pry the front of the unit
open until front is com-
pletely separated from
housing.
+
+
Detail
+
+
Detail

11
© 2008 Directed Electronics. All rights reserved.
+
+
Detail
Turn both the unit front and circuit board over, remove battery from2.
clip and replace.
Note: Verify that the battery polarity is correct when replacing.
Reposition all parts and snap together.3.
➤Two car operation
You can use the remote control system for two cars, with full command capabil-
ity for both vehicles.
To change the car selection:
Press and hold the•
A U X
button for 3 seconds until the amber LED blinks
once or twice indicating the current vehicle:
One blink: Car 1
Two blinks: Car 2
To scroll from one car to the other, press the•
A U X
button again. After select-
ing the car, operation resumes. The selected car remains selected until the
setting is changed.
+
+

12 © 2008 Directed Electronics. All rights reserved.
1-way remote

5313
,&$
)&&,'(=6'(,
%$77(5<&5
8
1
2
3
4
5
6
7
6
7
9
1
2
3
4
5
6

5313
,&$
)&&,'(=6'(,
%$77(5<&5
Feature Description
1 Transmit indicator
2 Lock button Press for one second to lock.
3 Unlock
button
Press for one second to unlock.
4 Remote start
button
Press for one second to activate remote
start.
5 Auxiliary
button
Press and hold for 1.5 second to activate
optional trunk release.
6 Function button Allows access to programming and modi-
fies operation of the other buttons.
Note: If Keypad Lock is On, press and then press
1
3
4
5
6
2
A U X
8
7
1
2
3
4
5
6
1-800-274-0200
RPN 7152X
IC: 1513A-7152
FCC ID:EZSDEI7152
BATTERY: CR2032
7
8
7
8
1
2
3
4
5
6
to exit.

13
© 2008 Directed Electronics. All rights reserved.
➤Transmitter configuration
Button
Level Direct Access
A U X
x 1
A U X
x 2
A U X
x 3
A U X
x 4
A U X
Lock Silent Lock
A U X
Unlock Silent Unlock Valet Mode Car Finder
A U X
Remote Start Reset
Runtime
Timer Mode Smart Start Rear
Defogger
A U X
Trunk Release AUX 1 AUX 2 AUX 3
A U X
Function Shift

14 © 2008 Directed Electronics. All rights reserved.
➤ Feature list
A U X
Unlock
Command : Press one time to Lock
Notes : Press/hold for 1.5 seconds to lock the system and then
activate the Panic output*
A U X
Unlock
Command : Press one time to Unlock
A U X
Remote Start
Command : Press one time to activate Remote Start
A U X
Aux (trunk)
Command : Press and hold for 1.5 seconds to open trunk.
A U X
Function shift
Command :Press 1 to 4 times. ( See Function shift table)
Notes :Each Press then release, shifts the function of the com-
mand button.
Silent lock
Command : Press
A U X
one- time and then press
A U X
Notes : Locks the system without horn honks*
Silent unlock
Command : Press
A U X
one- time and then press
A U X
.
Notes : Unlocks the system without horn honks*
* Horn honk is an optional feature. The panic and horn honk feature is avail-
able when this option is installed.

15
© 2008 Directed Electronics. All rights reserved.
Runtime reset
Command : Press
A U X
one-time and then
A U X
.
Notes : Re-starts the remote start runtime counter if remote start is active.
.
Aux 1
Command : Press
A U X
one time and then press
A U X
.
Notes : This is an optional feature. See your sales rep/installer for
details.
Valet mode
Command : Press
A U X
two-times and then
A U X
.
Notes: Prevents the system from automatically activating the Failsafe
Starter Kill and locking the door passively.
Timer mode
Command : Press
A U X
two-times and then

ALL
.
Notes : Enables or disables the remote start timer mode.
Aux 2
Command : Press
A U X
two times and then press
A U X
.
Notes : This is an optional feature. See your sales rep/installer for de-
tails.
Car finder
Command : Press
A U X
three-times and then
A U X
.
Notes : The vehicle emits 1 long horn honk and the parking lights flash
10 times. Lock/Unlock cancels the parking light flashes.

16 © 2008 Directed Electronics. All rights reserved.
Smart start
Command : Press
A U X
three-times and then press
A U X
.
Notes : Enables or disables the Smart Start feature. The parking lights
flash fast 5 times when turning the feature on, and flash slowly
5 times when turning the feature off.
Aux 3
Command : Press
A U X
three times and then press
A U X
.
Notes : This is an optional feature. See your sales rep/installer for de-
tails.
Rear defogger
Command : Press
A U X
four times, and then
A U
X
. (after remote start is on.)
Notes : Manually turns on the defogger when remote start is on.
Panic
Command : Press and hold for 1.5 seconds.
Notes : Panic is available when the optional horn honk feature is in-
stalled.

17
© 2008 Directed Electronics. All rights reserved.
Using the system
➤Locking the vehicle
To lock the vehicle, press the button on the remote control.
The horn in the vehicle “honks” one-time, and the parking lights flash one-time.
If the power door locks have been connected, the doors lock.
The system automatically checks for errors when it locks.
If errors are found when locking:
If the door is open when you lock the vehicle, the horn honks once and the
parking lights flash. The horn then honks a second time to indicate that the
door is open and the LED on the control center flashes in groups of three
Note: The optional horn honk and door input has to be installed for this func-
tion.
Locking without the honk (Silent Lock)
Press the button on the remote one-time, and then press the button. The
vehicle locks without the confirmation honk. The parking lights flash one-time.
➤ Unlocking the vehicle
Lock the vehicle normally. Press the button one time. The vehicle horn honks
two-times and the parking lights flash.
UnLocking without the honk (Silent Unlock)
Lock the vehicle normally. Press the button on the remote one-time, and then
press the
1
3
4
5
6
2
A U X
button. The vehicle unlocks without the confirmation honk. The
parking lights flash two-times.

18 © 2008 Directed Electronics. All rights reserved.
➤ Valet mode
You can prevent your system from automatically activating the Failsafe® Starter
Kill. When the system is in Valet mode, the feature is disabled. The doors
do not automatically lock. This is useful when washing or having the vehicle
serviced.
To enter or exit valet mode with the valet/program switch:
1. Turn the ignition key on and then off.
2. At anytime during the next 10 seconds, press and
release the Valet switch on the control center. The
LED lights constantly if you have entered Valet®
Mode, and goes out if you have exited Valet
Mode.
To enter or exit Valet mode with the remote control:
Press two times, and then to set the system in or out of Valet Mode.
Repeating the process takes the system out of Valet Mode.
The control center LED come on solid when in Valet Mode and shuts off when
exiting Valet Mode.
➤Panic Mode
If you are threatened in or near your vehicle, you can attract attention by trig-
gering the system with your remote. This feature is only available if the optional
horn honk is connected.
Press• for 2 seconds, to enter Panic Mode. The horn honks and the
parking lights flash for the programmed horn honk duration.
To stop Panic Mode at any time:•
Press on the remote again.

19
© 2008 Directed Electronics. All rights reserved.
➤ Remote feature programming
The remote control has a menu for programming user features. Before you start
make sure the keypad is unlocked. (See page 12)
To program the remote user features:
Press and hold the1.
A U X
button on the remote for 12 seconds. (ignore the
car indicator at 3 seconds). The remote transmit LED turns on solid to
indicate the Main Menu.
Press and hold the2. button for 1.5 seconds: The remote LED blinks
two-times. You are now in the Remote Configuration menu. From this
menu you can now configure the remote's keypad lock features, as
described in the following steps.
To configure the remote keypad lock features:
Press the button to change the Auto keypad lock feature. Every press of the
button will cycle the setting from On to Off.
When the remote LED blinks once the keypad automatically locks 6o•
seconds after the last button operation to avoid accidental command op-
erations. When the keypad is locked, if any command button is pressed
the remote will not transmit and the LED will not blink.
When the remote LED blinks twice, the keypad lock feature is Off. The•
remote will transmit every time a command button is pressed.
If the keypad lock is On, press , and then press
1
3
4
5
6
2
A U X
to unlock the keypad.

20 © 2008 Directed Electronics. All rights reserved.
➤Overriding the optional starter kill
To bypass the optional starter kill without a remote control:
Use your override switch located on the control center (see diagram below) to
bypass the system. This switch bypasses the system only if you have the vehicle
key.
To check proper operation:
While the vehicle is locked, open the door. Immediately insert the key1.
into the ignition and turn it to the Run or On position. (all the indicators in
the dash turn on)
Press and release the Override Switch one time. The LED on the control2.
center will stop flashing and the optional starter kill is bypassed. You can
now start the vehicle with the key.
Note: The override switch feature allows you to select a specific number of
presses needed to disable the system. If the override switch has been pro-
grammed to a new number of presses by your authorized dealer, that number
should be indicated below.
Override Switch number of presses ________
