Directed Python 1600XP User manual

© 2005 Directed Electronics, Vista, CA
N563P 07-05
NOTE: This product is intended for installation by a professional installer only!
Any attempt to install this product by any person other than a trained professional
may result in severe damage to a vehicle’s electrical system and components.
MMooddeell11660000XXPP
IInnssttaallllaattiioonnGGuuiiddee
All manuals and user guides at all-guides.com
all-guides.com

22© 2005 Directed Electronics—all rights reserved
Bitwriter®, Code Hopping™, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine™,
Nite-Lite®, Nuisance Prevention® Circuitry, Revenger®, Silent Mode™, Soft Chirp®, Stinger®,
Valet®, Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered
Trademarks of Directed Electronics.
NNeewwSSooffttwwaarreeCCoommppaattiibbiilliittyyffoorr110033TT
KKeeyyppaadd
This unit now has software that
allows arming with entry delay when
used in conjunction with the optional
110033TTKeypad. Refer to the 103T
Owner’s Guide for details.
The Bitwriter®(p/n 998T)
requires chip version 2.2 or
newer to program this unit.
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 33
ttaabblleeooffccoonntteennttss
wwaarrnniinngg!!ssaaffeettyyffiirrsstt..................................................44
iinnssttaallllaattiioonnppooiinnttssttoorreemmeem
mbbeerr..................................55
before beginning the installation . . . . . . . . . . . . . 5
after the installation. . . . . . . . . . . . . . . . . . . . . . 5
ddeecciiddiinnggoonnccoommppoonneennttllooccaattiioonnss............................
....66
locations for the control module . . . . . . . . . . . . . . 6
locations for the siren. . . . . . . . . . . . . . . . . . . . . 6
locations for stinger doubleguard shock sensor . . . . 7
mounting the antenna. . . . . . . . . . . . . . . . . . . . . 7
locations for the status LED . . . . . . . . . . . . . . . . . 8
locations for valet/program switch . . . . . . . . . . . . 8
locations for the optional starter kill relay . . . . . . . 9
locations for the relay satellite. . . . . . . . . . . . . . . 9
ffiinnddiinnggtthheewwiirreessyyoouunneeeedd........................................99
obtaining constant 12V . . . . . . . . . . . . . . . . . . . . 9
finding the 12V switched ignition wire. . . . . . . . . 10
finding the starter wire . . . . . . . . . . . . . . . . . . . 10
finding the accessory wire . . . . . . . . . . . . . . . . . 11
finding the tachometer wire . . . . . . . . . . . . . . . . 11
finding the wait-to-start bulb wire for diesels . . . 11
finding a (+) parking light wire. . . . . . . . . . . . . . 12
finding the door pin switch circuit . . . . . . . . . . . 12
mmaakkiinnggyyoouurrwwiirriinnggccoonnnneeccttiioonnss................................1133
pprriimmaarryyhhaarrnneessss((HH11)),,1122--ppiinnccoonnnneeccttoorr......................1144
aauuxxiilliiaarryyhhaarrnneessss((HH22)),,66--ppiinnccoonnnneeccttoorr......................1144
ddoooorrlloocckkhhaarrnneessss,,33--ppiinnccoonnnneeccttoorr............................1155
rreemmootteessttaarrttrriibbbboonnhhaarrnneessss,,wwiirriinnggddiiaaggrraamm................1155
hheeaavvyyggaauuggeerreellaayyssaatteelllliitteewwiirriinnggddiiaaggrraamm..................1166
rreemmootteessttaarrtthhaarrnneessss((HH33)),,55--ppiinnccoonnnneeccttoorr................1166
hhoorrnn,,cchhaannnneell66((HH44)),,22--ppiinnccoonnnneeccttoorr......................1166
pprriimmaarryyhhaarrnneessss((HH11))wwiirreeccoonnnneeccttiioonngguuiiddee................1177
sseeccoonnddaarryyhhaarrnneessss((HH22))wwiirreeccoonnnneeccttiioonngguuiiddee............2211
rreellaayyssaatteelllliitteewwiirreeccoonnnneeccttiioonngguuiiddee..........................2244
rreemmootteessttaarrttsseeccoonnddaarryyhhaarrnneessss
((HH33))wwiirree....................
ccoonnnneeccttiioonngguuiiddee....................................................2255
hhoorrnn,,cchhaannnneell66hhaarrnneessss((HH44))wwiirreeccoonnnneeccttiioonngguuiiddee....2266
nneeuuttrraallssaaffeettyysswwiittcchhiinntteerrffaaccee..........
........................2277
testing the neutral safety switch. . . . . . . . . . . . . 27
bbyyppaassssiinnggGGMMvveehhiicclleeaannttii--tthheeffttssyysstteemmss((VVAATTSS))..........3300
11999955aannddnneewweerrvveehhiicclleeaannttii--tthheeffttssyysstteemmss..................
((iimmmmoobbiilliizzeerrss))........................................................3311
passlock I and passlock II (PL-1 and PL-2). . . . . . 31
passkey III (PK-3), transponder-based systems . . . 31
pplluugg--iinnLLEEDDaannddvvaalleett//pprrooggrraammsswwiittcchh........................3322
pprrooggrraammmmeerriinntteerrffaaccee,,33--ppiinnbbllaacckkpplluugg......................3322
sshhoocckksseennssoorrhhaarrnneessss,,44--ppiinnccoonnnneeccttoorr........................3333
ttaacchhlleeaarrnniinngg..........................................................3344
pprrooggrraammmmiinnggjjuummppeerrss..............................................3344
ttrraannssmmiitttteerr//rreecceeiivveerrlleeaarrnnrroouuttiinnee™™............................3355
tach threshold on/off . . . . . . . . . . . . . . . . . . . . 35
light flash (+)/(-) . . . . . . . . . . . . . . . . . . . . . . . 35
ttrraannssmmiitttteerrccoonnffiigguurraattiioonnss........................................3377
standard configuration. . . . . . . . . . . . . . . . . . . . 37
mmuullttii--lleevveellsseeccuurriittyyaarrmmiinngg........................................3388
ssyysstteemmffeeaattuurreesslleeaarrnnrroouuttiinnee....................................3399
ffeeaattuurreemmeennuuss........................................................4411
menu #1 - basic features . . . . . . . . . . . . . . . . . . 41
menu #2 - advanced features . . . . . . . . . . . . . . . 42
menu #3 - remote start options . . . . . . . . . . . . . 43
ffeeaattuurreeddeessccrriippttiioonnss................................................4444
menu #1 - basic features . . . . . . . . . . . . . . . . . . 44
menu #2 - advanced features . . . . . . . . . . . . . . . 45
menu #3 - remote start options . . . . . . . . . . . . . 48
nnuuiissaanncceepprreevveennttiioonn®®cciirrccuuiittrryy..................................4499
vvaalleettmmooddee..............................................................5500
rreeaarrddeeffooggggeerrccoonnttrrooll................................................5500
ttiimmeerrmmooddee............................................................5511
ttaabblleeooffzzoonneess........................................................5522
sshhuuttddoowwnnddiiaaggnnoossttiiccss..............................................5522
to perform shutdown diagnostics . . . . . . . . . . . . 52
lloonnggtteerrmmeevveenntthhiissttoorryy............................................5533
ssaaffeettyycchheecckk............................................................5533
ttrroouubblleesshhoooottiinngg................................
......................5544
alarm troubleshooting . . . . . . . . . . . . . . . . . . . . 54
remote start troubleshooting . . . . . . . . . . . . . . . 55
wwiirriinnggqquuiicckkrreeffeerreenncceegguuiiddee....................................5577
rreellaayy
ssaatteelllliitteewwiirriinnggqquuiicckkrreeffeerreenncceegguuiiddee..................5588
All manuals and user guides at all-guides.com

44© 2005 Directed Electronics—all rights reserved
wwaarrnniinngg!!ssaaffeettyyffiirrsstt
The following safety warnings must be observed at all times:
■Due to the complexity of this system, installation of this product must only be performed by an authorized
Directed Electronics dealer.
■When properly installed, this system can start the vehicle via a command signal from the remote control
transmitter. Therefore, never operate the system in an area that does not have adequate ventilation. The fol-
lowing precautions are the sole responsibility of the user; however, authorized Directed Electronics dealers
should make the following recommendations to all users of this system:
1. Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
2. When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote
start system must be disabled using the installed toggle switch.
3. It is the user's sole responsibility to properly handle and keep out of reach from children all remote
control transmitters to assure that the system does not unintentionally remote start the vehicle.
4. TTHHEEUUSSEERRMMUUSSTTIINNSSTTAALLLLAACCAARRBBOONNMMOONNOOXXIIDDEEDDEETTEECCTTOORRIINNOORRAABBOOUUTTTTHHEELLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOO
T
THHEEVVEEHHIICCLLEE..AALLLLDDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTTLLIIVVIINNGGAARREEAASSTTOOTTHHEEEENNCCLLOOSSEEDDOORRPPAARRTTIIAALLLLYY
EENNCCLLOOSSEEDDVVEEHHIIC
CLLEESSTTOORRAAGGEEAARREEAAMMUUSSTTAATTAALLLLTTIIMMEESSRREEMMAAIINNCCLLOOSSEEDD..
■Use of this product in a manner contrary to its intended mode of operation may result in property damage,
personal injury, or death. Except when performing the Safety Check outlined in this installation guide, (1)
Never remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the
keys in the ignition. The user will be responsible for having the neutral safety feature of the vehicle period-
ically checked, wherein the vehicle must not remotely start while the car is in gear. This testing should be
performed by an authorized Directed Electronics dealer in accordance with the Safety Check outlined in this
product installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult
with the user to fix the problem immediately.
■After the remote start module has been installed, test the remote start module in accordance with the Safety
Check outlined in this installation guide. If the vehicle starts when performing the Neutral Safety Shutdown
Circuit test, the remote start unit has not been properly installed. The remote start module must be removed
or properly reinstalled so that the vehicle does not start in gear. All installations must be performed by an
authorized Directed Electronics dealer. OOPPEERRAATTIIOONNOOFFTTHHEERREEMMOOTTEESSTTAARRTTMMOODDUULLEEIIFFTTHHEEV
VEEHHIICCLLEESSTTAARRTTSSIINN
GGEEAARRIISSCCOONNTTRRAARRYYTTOOIITTSSIINNTTEENNDDEEDDMMOODDEEOOFFOOPPEERRAATTIIOONN..OOPPEERRAATTIINNGGTTHHEERREEMMOOTTEESSTTAARRTTSSYYSST
TEEMMUUNNDDEERR
TTHHEESSEECCOONNDDIITTIIOONNSSMMAAYYRREESSUULLTTIINNPPRROOPPEERRTTYYDDAAMMAAGGEEOORRPPEERRSSOONNAALLIINNJJUURRYY..IIMMMMEEDDIIAATTEELLYYCCEEAASSEETTHHEEUUS
SEE
OOFFTTHHEEUUNNIITTAANNDDRREEPPAAIIRROORRDDIISSCCOONNNNEECCTTTTHHEEIINNSSTTAALLLLEEDDRREEMMOOTTEESSTTAARRTTMMOODDUULLEE..DDIIRREECCTTEEDDEELLEECCTTRROONNIICCSS,,
IINNCC.
.WWIILLLLNNOOTTBBEEHHEELLDDRREESSPPOONNSSIIBBLLEEOORRPPAAYYFFOORRIINNSSTTAALLLLAATTIIOONNOORRRREEIINNSSTTAALLLLAATTIIOONNCCOOSSTTSS..
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 55
iinnssttaallllaattiioonnppooiinnttssttoorreemmeemmbbeerr
IIMMPPOORRTTAANNTT!!This product is designed for fuel-injected, automatic transmission vehicles only.
Installing it in a standard transmission vehicle is dangerous and is contrary to its intended use.
■Please read this entire installation guide before beginning the installation. The installation of this remote
start system requires interfacing with many of the vehicle’s systems. Many new vehicles use low-voltage or
multiplexed systems that can be damaged by low resistance testing devices, such as test lights and logic
probes (computer safe test lights). Test all circuits with a high quality digital multi-meter before making con-
nections.
■Do not disconnect the battery if the vehicle has an anti-theft-coded radio. If equipped with an air bag, avoid
disconnecting the battery if possible. Many airbag systems will display a diagnostic code through their
warning lights after they lose power. Disconnecting the battery requires this code to be erased, which can
require a trip to the dealer.
■Check with the customer on status LED location.
■Remove the domelight fuse. This prevents accidentally draining the battery.
■Roll down a window to avoid being locked out of the car.
■Test all functions. The “Using Your System” section of the Owner's Guide is very helpful when testing.
■When testing, don’t forget that this system is equipped with Nuisance Prevention® Circuitry (NPC). NPC can
bypass trigger zones, making them appear to stop working. See the
Nuisance Prevention® Circuitry section.
■Review and complete the
Safety Check section of this guide prior to the vehicle reassembly.
aafftteerrtthheeiinnssttaallllaattiioonn
bbeeffoorreebbeeggiinnnniinnggtthheeiinnssttaallllaattiioonn
All manuals and user guides at all-guides.com

66© 2005 Directed Electronics—all rights reserved
ddeecciiddiinnggoonnccoommppoonneennttllooccaattiioonnss
SSoommeetthhiinnggssttoorreemmeemmbbeerraabboouuttmmoouunnttiinnggtthheessiirreenn::
■Keep it away from heat sources, such as radiators, exhaust manifolds, turbochargers, and heat shields.
■Mount it where a thief cannot easily disconnect it, whether the hood is open or shut. Both the siren and its
wires should be difficult to find. This usually involves disguising the wire to look like a factory harness.
■We recommend against grounding the siren to its mounting screws. Instead, we recommend running both the
red and black wires into the passenger compartment and grounding to one common point for all devices. After
all, both wires are the same length and come already bonded together. Whenever possible, conceal your wires
in the factory harnesses or in the same style loom as the factory.
■When possible, place the siren on the same side of the vehicle as the control module, where its wires will
reach the control module’s wires without extending them. Always run the wires through the center of a
grommet, never through bare metal!
■Point the siren down so water does not collect in it.
SSoommeetthhiinnggssttoorreemmeemmbbeerraabboouuttwwhheerreetto
ommoouunntttthheeccoonnttrroollmmoodduullee::
■Never put the control module in the engine compartment!
■The first step in hot-wiring a vehicle is removing the driver's side under-dash panel to access the starter and
ignition wires. If the control module is placed just behind the driver's side dash it can easily be disconnected.
■When mounting the control module, try to find a secure location that will not require you to extend the har-
nesses’ wires (they are 1.5 meters long). Keep it away from the heater core (or any other heat sources) and
any obvious leaks.
llooccaattiioonnssffoorrtthheeccoonnttrroollmmoodduullee
llooccaattiioonnssffoorrtthheessiirreenn
All manuals and user guides at all-guides.com
all-guides.com

© 2005 Directed Electronics—all rights reserved 77
■Some good control module locations are: Above the glove box, inside the center console, above the under-
dash fuse box, or above the radio.
The antenna position should be discussed with the vehicle’s owner prior to installation, since the antenna may
be visible to the vehicle’s operator. The best location for the antenna is centered high on either the front or rear
windshield. For optimal range, the antenna should be mounted vertically. It can be mounted horizontally in rela-
tion to the windshield or under the dashboard away from metal, but range will be diminished. Metallic window
tint can also affect range, so this should be a consideration when determining the mounting location.
After determining the best mounting location, follow these steps:
1. Clean the mounting area with a quality glass cleaner or alcohol to remove any dirt or residue.
3. Mount the antenna using the supplied double-sided tape.
4. Route the antenna cable to the control module and plug it into the antenna connector.
IIMMPPOORRTTAANNTT!!To achieve the best possible range, DO NOT leave the antenna cable bundled under
the dash. Always extend the cable full length during installation, regardless of the antenna
mounting location.
SSoommeetthhiinnggssttoorreemmeemmbbeerraabboouuttwwhheerreettoommoouunntttthheesshhoocckksseennssoorr::
■Never put the Stinger®in the engine compartment!
■Find a spot close to the control module so that the wires do not need to be extended. Keep it away from the
heater core (or any other heat sources) and any obvious leaks.
HHoowwtthheeSSttiinnggeerr®®iissmmoouunntteeddiisstthheemmoossttiimmppoorrttaannttffaaccttoorriinniittssppeerrffoorrmmaannccee..WWeerreeccoommmmeennddttwwoommeetthhooddss::
■Using double-sided tape or hook-and-loop fastener to mount to a trim panel or an air duct, or
■Wire-tying to a wire harness.
If mounting the sensor where it cannot be easily reached for adjustment, hook-and-loop fastening tape (such as
Velcro) is recommended for ease of removal for future adjustments.
NNOOTTEE::In many vehicles, tying the sensor to a steering column or screwing it to metal will result
in poor sensitivity, especially at the rear of the vehicle.
llooccaattiioonnssffoorrssttiinnggeerrddoouubblleegguuaarrddsshhoocckksseennssoorr
mmoouunnttiinnggtthheeaanntteennnnaa
All manuals and user guides at all-guides.com

88© 2005 Directed Electronics—all rights reserved
IIMMPPOORRTTAANNTT!!When the vehicle is delivered, please show the user where this switch is located
and how to disarm the system with it.
Ensure that the location you pick for the switch has sufficient clearance to the rear. The switch should be well
hidden. It should be placed so passengers or stored items (such as in a glove box or center console) cannot acci-
dentally hit it. The switch fits into a 9/32-inch hole.
This system has Remote Valet. The user can enter and exit Valet Mode without having to reach the Valet/Program
switch. This feature was introduced so that switch location was less critical in day-to-day use. As long as the
Valet/Program switch can be reached to disarm without a transmitter, easy access is not important.
TThhiinnggssttoorreemmeemmbbeerrwwhheennppoossiittiioonniinnggtthheeSSttaattuussLLEEDD::
■It should be visible from both sides and the rear of the vehicle, if possible.
■It needs at least 1/2-inch clearance to the rear.
■It is easiest to remove a small panel, such as a switch blank or a dash bezel, before drilling a 9/32-inch hole.
■Use quick-disconnects near the LED wires if the panel is removable. This lets mechanics or other installers
remove the panel without cutting the wires.
llooccaattiioonnssffoorrtthheessttaattuussLLEEDD
llooccaattiioonnssffoorrvvaalleett//pprrooggrraammsswwiittcchh
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 99
If optional starter kill relay or its connections are immediately visible upon removal of the under-dash panel,
they can easily be bypassed. Always make the relay and its connections difficult to discern from the factory
wiring! Exposed yellow butt connectors do not look like factory parts, and will not fool anyone! For this reason,
routing the optional starter kill wires away from the steering column is recommended.
The relay satellite wiring carries large amounts of current. The wires should not be extended and should be cut
to the minimum length necessary. Since the relay satellite is functioning as the ignition switch in the vehicle,
it is often convenient to mount the relay satellite close to the main ignition switch harness.
ffiinnddiinnggtthheewwiirreessyyoouunneeeedd
Now that you have decided where each component will be located, you’re going to find the wires in the car that
the security system will be connected to.
IIMMPPOORRTTAANNTT!!Do not use a 12V test light or logic probe (computer safe test light) to find these
wires! Use a digital multimeter for all testing.
We recommend two possible sources for 12V constant: the (+) terminal of the battery, or the constant supply to
the ignition switch. Always install a fuse within 12 inches of this connection. If the fuse also will be powering
other circuits, such as door locks, a power window module, a Nite-Lite® headlight control system, etc., fuse
accordingly.
IIMMPPOORRTTAANNTT!!Do not remove the fuse holder on the red wire. It ensures that the control module
has its own fuse, of the proper value, regardless of how many accessories are added to the main
power feed.
oobbttaaiinniinnggccoonnssttaanntt1122VV
llooccaattiioonnssffoorrtthheerreellaayyssaatteelllliittee
llooccaattiioonnssffoorrtthheeooppttiioonnaallssttaarrtteerrkkiillllrreellaayy
All manuals and user guides at all-guides.com

1100© 2005 Directed Electronics—all rights reserved
The ignition wire is powered when the key is in the run or start position. This is because the ignition wire powers
the ignition system (spark plugs, coil) as well as the fuel delivery system (fuel pump, fuel injection computer).
Accessory wires lose power when the key is in the start position to make more current available to the starter motor.
HHoowwttooffiinndd((++))1122VViiggnniittiioonnwwiitthhyyoouurrmmuullttiimmeetteerr::
1. Set to DCV or DC voltage (12V or 20V is fine).
2. Attach the (-) probe of the meter to chassis ground.
3. Probe the wire you suspect of being the ignition wire. The
steering column harness or ignition switch harness is an excel-
lent place to find this wire.
4. Turn the ignition key switch to the run position. If your meter
reads (+)12V, go to the next step. If it doesn’t, probe another
wire.
5. Now turn the key to the start position. The meter display should stay steady, not dropping by more than a
few tenths of a volt. If it drops close to or all the way to zero, go back to Step 3. If it stays steady at (+)12V,
you have found an ignition wire.
The starter wire provides 12V directly to the starter or to a relay controlling the starter. In some vehicles, it is
necessary to power a cold start circuit. A cold start circuit will test exactly like a starter circuit, but it does not
control the starter. Instead, the cold start circuit is used to prime the fuel injection system for starting when the
vehicle is cold.
HHoowwttooffiinnddtthheessttaarrtteerrwwiirreewwiitthhyyoouurr
mmuullttiimmeetteerr::
1. Set to DCV or DC voltage (12V or 20V is fine).
2. Attach the (-) probe of the meter to chassis ground.
3. Probe the wire you suspect of being the starter wire. The steering
column is an excellent place to find this wire. Remember you do not
need to interrupt the starter at the same point you test it. Hiding
your optional starter kill relay and connections is always recommended.
4. Turn the ignition key switch to the start position. Make sure the car
is not in gear! If your meter reads (+)12V, go to the next step. If it doesn’t, probe another wire.
5. Cut the wire you suspect of being the starter wire.
6. Attempt to start the car. If the starter engages, reconnect it and go back to Step 3. If the starter does not
turn over, you have the right wire.
ffiinnddiinnggtthheessttaarrtteerrwwiirree
ffiinnddiinnggtthhee1122VVsswwiittcchheeddiiggnniittiioonnwwiirree
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 1111
An accessory wire will show +12V when the key is in the accessory and run positions. It will not show +12V during
the cranking cycle. There will often be more than one accessory wire in the ignition harness. The correct accessory
wire will power the vehicle's climate control system. Some vehicles may have separate wires for the blower motor and
the air conditioning compressor. In such cases, it will be necessary to add a relay to power the second accessory wire.
To test for a tachometer wire, a multimeter capable of testing AC voltage must be used. The tachometer wire will
show between 1V and 6V AC. In multi-coil ignition systems, the system can learn individual coil wires. Individual
coil wires in a multi-coil ignition system will register lower amounts of AC voltage. Also, if necessary, the system
can use a fuel injector control wire for engine speed sensing. Common locations for a tachometer wire are the
ignition coil itself, the back of the gauges, engine computers, and automatic transmission computers.
IIMMPPOORRTTAANNTT!!Do not test tachometer wires using a test light or logic probe (computer safe test light)!
This will damage the vehicle.
HHoowwttooffiinnddaattaacchhoommeetteerrwwiirreewwiitthhyyoouurrmmuullttiimmeetteerr::
1. Set to ACV or AC voltage (12V or 20V is fine).
2. Attach the (-) probe of the meter to chassis ground.
3. Start and run the vehicle.
4. Probe the wire you suspect of being the tachometer wire with the red probe of the meter.
5. If this is the correct wire the meter will read between 1V and 6V.
In diesel vehicles it is necessary to interface with the wire that turns on the WAIT TO START light in the dash-
board. This wire illuminates the bulb until the vehicle’s glow plugs are properly heated. When the light goes out
the vehicle can be started. This wire is always available at the connector leading to the bulb in the dashboard.
It can also be found at the Engine Control Module (ECM) in many vehicles.
TTootteessttaannddddeetteerrmmiinneetthheeppoollaarriittyyoofftthhiissw
wiirree::
1. Set your multimeter to DCV or DC voltage (12 or 20V is fine).
2. Attach the (+) probe of the meter to (+)12V.
3. Probe the wire that you suspect leads to the bulb with the (-) probe of the meter.
4. Turn the ignition switch to the ON position.
5. If the meter indicates 12 volts until the light goes out you have isolated the correct wire and the wire's polar-
ity is negative (ground while the bulb is on).
6. If the meter reads zero volts until the light goes out and then reads 12 volts, you have isolated the correct
wire and the wire's polarity is positive.
ffiinnddiinnggtthheewwaaiitt--ttoo--ssttaarrttbbuullbbwwiirreeffoorrddiieesseellss
ffiinnddiinnggtthheettaacchhoommeetteerrwwiirree
ffiinnddiinnggtthheeaacccceessssoorryywwiirree
All manuals and user guides at all-guides.com
all-guides.com

1122© 2005 Directed Electronics—all rights reserved
The (+) parking light wire is often found near the switch. Many cars have the switch built into the turn signal
lever, and in these cars the parking light wire can be found in the steering column. The same wire is often avail-
able in the kick panel or running board.
NNOOTTEE::Many Toyotas, as well as many other Asian vehicles, send a (-) signal from the switch to
a relay. The relay then sends (+)12V to the bulbs. Whenever you have difficulty finding a (+)
parking light wire near the switch, simply test the wires at any switch or control panel which is
lit by the instrument panel lighting. Remember, you need a (+) parking light wire that does not
vary with the dimmer setting.
HHoowwttooffiinnddaa((++))ppaarrkkiinngglliigghhttffllaasshhwwiirreewwiitthhyyoouurrmmuullttiimmeetteerr::
1. Set to DCV or DC voltage (12V or 20V is fine).
2. Attach the (-) probe of the meter to chassis ground.
3. Probe the wire you suspect of being the parking light wire. Usually, the area near the headlight/parking light
switch is an excellent area to start, as is the kick panel.
4. Turn on the parking lights. If your meter shows (+)12V, turn off the parking lights and make sure it goes back
to zero.
5. If it does return to zero, turn the parking lights back on and, using the dash light dimmer control, turn the
brightness of the dash lights up and down. If the meter changes more than a volt when using the dimmer,
look for another wire. If it stays relatively close to (+)12V, you have found your parking light wire.
TThheebbeessttppllaacceessttooffiinnddtthhee
ddoooorrsswwiittcchhwwiirreeaarree::
■At the pin switch: When testing at the pin switch, check the wire to ensure that it “sees” all the doors. Often,
the passenger switch will cover all the doors even if the driver’s switch will not.
■At the dome light: This may not be your best choice if the vehicle has delayed domelight supervision, but it
will work in many Hondas, or any vehicle with completely diode-isolated pin switches.
ffiinnddiinnggtthheeddoooorrppiinnsswwiittcchhcciirrccuuiitt
ffiinnddiinnggaa((++))ppaarrkkiinngglliigghhttwwiirree
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 1133
Once you have determined the wire color, the easiest place to connect to the wire is often at the kick panel, at
the windshield pillar, or in the running board. When an easy location is not available, running a wire to the dome-
light itself is often the best solution.
HHoowwttooffiinnddaaddoooorrppiinnsswwiittcchhttrriiggggeerrwwiirreewwiitthhyyoouurrmmuullttiimmeetteerr::
1. Set to DCV or DC voltage (12V or 20V is fine).
2. In most Fords, fasten the (-) probe of the meter to chassis ground. In most other cars, fasten the (+) probe
of your meter to (+)12V constant.
3. Probe the wire you suspect of being the door trigger wire. If the meter reads (+)12V when any door
is opened, you have found a trigger wire.
NNOOTTEE::Make sure the wire you use “sees” all the doors! Some newer GM vehicles lack standard-
type pin switches. The dome light in these vehicles is turned on when the door handle is lifted.
These usually have a blue/white or white wire coming out of the door into the kick panel which
will provide a (-) trigger for all doors. Some GM vehicles (some Cavaliers, Grand Ams, etc.) have
a yellow wire coming out of the door which provides a (+) door trigger.
mmaakkiinnggyyoouurrwwiirriinnggccoonnnneeccttiioonnss
Before making your connections, plan how your wires will be routed through the vehicle. For instance, the red
12V constant input and the orange ground-when-armed output (for the optional starter kill relay) will often be
routed together to the ignition switch harness. In order to keep the wiring neat and make it harder to find, you
may wish to wrap these wires together in electrical tape or conceal them in tubing similar to what the manu-
facturer used.
There are two acceptable ways of making a wire connection - solder connections and crimp connectors. When
properly performed, either type of connection is reliable and trouble-free. Regardless of whether you solder your
connections or you use mechanical-type crimp-on connections, ensure that all connections are mechanically
sound and that they are insulated.
Cheap electrical tape, especially when poorly applied, is not a reliable insulator. It often falls off in hot weather.
Use good-quality electrical tape or heat shrink.
■Never twist-and-tape the wires together without soldering.
■Never use “fuse taps”, as they can damage fuse box terminals.
If you use tapping connectors such as 3M T-Taps (not to be confused with Scotch-Locks), avoid using them in
higher-current applications (constant 12V, ground, etc.). Some tapping connectors are inferior in quality and
should be avoided.
All manuals and user guides at all-guides.com

1144© 2005 Directed Electronics—all rights reserved
pprriimmaarryyhhaarrnneessss((HH11)),,1122--ppiinnccoonnnneeccttoorr
______
______
______
______
______
______
______
______
______
______
______
______
aauuxxiilliiaarryyhhaarrnneessss((HH22)),,66--ppiinnccoonnnneeccttoorr
______
______
______
______
______
______ LLIIGGHHTTGGRREEEENN//BBLLAACCKK((--))FFAACCTTOORRYYAALLAARRMMDDIISSAARRMM
GGRRAAYY//BBLLAACCKK((--))WWAAIITTTTOOSSTTAARRTTIINNPPUUTT
GGRREEEENN//WWHHIITTEE((--))FFAACCTTOORRYYAALLAARRMMRREEAARRMM
VVIIOOLLEETT//BBLLAACCKK((--))CCHHAANNNNEELL44OOUUTTPPUUTT
WWHHIITTEE//BBLLAACCKK((--))CCHHAANNNNEELL55OOUUTTPPUUTT
LLIIGGHHTTBBLLUUEE((--))SSEECCOONNDDUUNNLLOOCCKKOOUUTTPPUUTT
HH22//11
HH22//22
HH22//33
HH22//44
HH22//55
HH22//66
OORRAANNGGEE((--))550000mmAAAARRMMEEDDOOUUTTPPUUTT
WWHHIITTEE((++))//((--))SSEELLEECCTTAABBLLEELLIIGGHHTTFFLLAASSHHOOUUTTPPUUTT
WWHHIITTEE//BBLLUUEE((--))RREEMMOOTTEESSTTAARRTTAACCTTIIVVAATTIIOONNIINNPPUUTT
BBLLAACCKK//WWHHIITTEE((--))220000mmAADDOOMMEELLIIGGHHTTSSUUPPEERRVVIISSIIOONNOOUUTTPPUUTT
GGRREEEENN((--))DDOOOORRTTRRIIGGGGEERRIINNPPUUTT,,ZZOONNEE33
BBLLUUEE((--))MMUULLTTIIPPLLEEXXEEDDIINNPPUUTT,,ZZOONNEE44
VVIIOOLLEETT((++))DDOOOORRTTRRIIGGGGEERRIINNPPUUTT,,ZZOONNEE33
BBLLAACCKK((--))CCHHAASSSSIISSGGRROOUUNNDDIINNPPUUTT
EEMMPPTTYYNNOOTTUUSSEEDD
BBRROOWWNN((++))SSIIRREENNOOUUTTPPUUTT
RREEDD((++))CCOONNSSTTAANNTTPPOOWWEERRIINNPPUUTT
RREEDD//WWHHIITTEE((--))220000mmAACCHHAANNNNEELL22VVAALLIIDDIITTYYOOUUTTPPUUTT
HH11//11
HH11//22
HH11//33
HH11//44
HH11//55
HH11//66
HH11//77
HH11//88
HH11//99
HH11//1100
HH11//1111
HH11//1122
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 1155
ddoooorrlloocckkhhaarrnneessss,,33--ppiinnccoonnnneeccttoorr
______
______
______
NNoottee::Refer to TechTip 1041 for wiring information.
rreemmootteessttaarrttrriibbbboonnhhaarrnneessss,,wwiirriinnggddiiaaggrraamm
______
______
______
______
______
______
______
This ribbon harness connects to the relay satellite.
BBLLUUEE((--))220000mmAASSTTAATTUUSSOOUUTTPPUUTT
OORRAANNGGEE//BBLLAACCKK((--))AANNTTIIGGRRIINNDD//GGRROOUUNNDDWWHHEENNAARRMMEEDDOOUUTTPPUUTT
PPUURRPPLLEE((--))220000mmAASSTTAARRTTEERRRREELLAAYYTTUURRNN--OONN
OORRAANNGGEE((--))220000mmAAAACCCCEESSSSOORRYYRREELLAAYYTTUURRNN--OONN
PPIINNKK((--))220000mmAAIIGGNNIITTIIOONNRREELLAAYYTTUURRNN--OONN
YYEELLLLOOWW((++))IIGGNNIITTIIOONNIINNPPUUTTTTOOAALLAARRMM
PPIINNKK//WWHHIITTEE220000mmAA((--))PPRROOGGRRAAMMMMAABBLLEEIIGGNN22//AACCCC22RREELLAAYYTTUURRNNOONN
11
22
33
44
55
66
77
GGRREEEENN((--))LLOOCCKK((++))UUNNLLOOCCKKOOUUTTPPUUTT
EEMMPPTTYYNNOOTTUUSSEEDD
LLIIGGHHTTBBLLUUEE((++))LLOOCCKK((--))UUNNLLOOCCKKOOUUTTPPUUTT
11
22
33
All manuals and user guides at all-guides.com

1166© 2005 Directed Electronics—all rights reserved
hheeaavvyyggaauuggeerreellaayyssaatteelllliitteewwiirriinnggddiiaaggrraamm
______
______
______
______
______
______
______
______
rreemmootteessttaarrtthhaarrnneessss((HH33)),,55--ppiinnccoonnnneeccttoorr
______
______
______
______
______
hhoorrnn,,cchhaannnneell66((HH44)),,22--ppiinnccoonnnneeccttoorr
______
______ BBRROOWWNN((--))220000mmAAHHOORRNN
OORRAANNGGEE//BBLLAACCKKCCHHAANNNNEELL66OOUUTTPPUUTT
HH44//11
HH44//22
BBLLUUEE//WWHHIITTEE((--))220000mmAA22NNDDSSTTAATTUUSS//RREEAARRDDEEFFOOGGGGEERR--LLAATTCCHHEEDD//PPUULLSSEEDD
GGRRAAYY((--))HHOOOODDPPIINNSSWWIITTCCHHIINNPPUUTT,,ZZOONNEE11
BBRROOWWNN((++))BBRRAAKKEESSHHUUTTDDOOWWNNWWIIRREE
VVIIOOLLEETT//WWHHIITTEETTAACCHHOOMMEETTEERRIINNPPUUTTWWIIRREE
BBLLAACCKK//WWHHIITTEE((--))NNEEUUTTRRAALLSSAAFFEETTYYSSWWIITTCCHHIINNPPUUTT
HH33//11
HH33//22
HH33//33
HH33//44
HH33//55
RREEDD//WWHHIITTEE((++))((3300AA))HHIIGGHHCCUURRRREENNTT1122VVIINNPPUUTT
PPIINNKK//WWHHIITTEE((++))OOUUTTPPUUTTTTOOSSEECCOONNDDIIGGNNIITTIIOONNCCIIRRCCUUIITT
RREEDD((++))((3300AA))HHIIGGHHCCUURRRREENNTT1122VVIINNPPUUTT
PPIINNKK((++))OOUUTTPPUUTTTTOOPPRRIIMMAARRYYIIGGNNIITTIIOONNCCIIRRCCUUIITT
OORRAANNGGEE((++))OOUUTTPPUUTTTTOOAACCCCEESSSSOORRYYCCIIRRCCUUIITT
RREEDD((++))HHIIGGHHCCUURRRREENNTT1122VVIINNPPUUTT
GGRREEEENNSSTTAARRTTEERRIINNPPUUTTFFRROOMMIIGGNNIITTIIOONN((KKEEYYSSIIDDEE))
PPUURRPPLLEE((++))SSTTAARRTTEERROOUUTTPPUUTTTTOOSSTTAARRTTEERR((SSTTAARRTTEERRSSIIDDEE))
11
22
33
44
55
66
77
88
All manuals and user guides at all-guides.com
all-guides.com

© 2005 Directed Electronics—all rights reserved 1177
pprriimmaarryyhhaarrnneessss((HH11))wwiirreeccoonnnneeccttiioonngguuiiddee
When the system receives the code controlling Channel 2, for longer than 1.5 seconds, the red/white wire will
supply an output as long as the transmission continues. This is often used to operate a trunk/hatch release or
other relay-driven function.
IIMMPPOORRTTAANNTT!!Never use this wire to drive anything but a relay or a low-current input! The tran-
sistorized output can only supply 200 mA of current. Connecting directly to a solenoid, motor,
or other high-current device will cause it to fail.
Before connecting this wire, remove the supplied fuse. Connect to the battery positive terminal or the constant
12V supply to the ignition switch.
NNOOTTEE::Always use a fuse within 12 inches of the point you obtain (+)12V. Do not use the 15A
fuse in the harness for this purpose. This fuse protects the module itself.
HH11//22RREEDD((++))1122VVccoonnssttaannttppoowweerriinnppuutt
HH11//11RREEDD//WWHHIITTEEcchhaannnneell22,,220000mmAA((--))oouuttppuutt
All manuals and user guides at all-guides.com

1188© 2005 Directed Electronics—all rights reserved
Connect this to the red wire of the siren. Connect the black wire of the siren to (-) chassis ground, preferably at
the same point you connected the control module’s black ground wire. See
Features Description section for horn
output.
Remove any paint and connect this wire to bare metal, preferably with a factory bolt rather than your own screw.
(Screws tend to either strip or loosen with time.) We recommend grounding all your components, including the
siren, to the same point in the vehicle.
This wire is used in vehicles that have a positive (+) switched dome light circuit. Connect the violet wire to a
wire that shows (+)12V when any door is opened, and ground when the door is closed. This wire will report Zone 3.
HH11//66VVIIOOLLEETT((++))ddoooorrttrriiggggeerriinnppuutt,,zzoonnee33
HH11//55BBLLAACCKK((--))cchhaassssiissggrroouunnddccoonnnneeccttiioonn
HH11//33BBRROOWWNN((++))ssiirreennoouuttppuutt
All manuals and user guides at all-guides.com

© 2005 Directed Electronics—all rights reserved 1199
Inputs shorter than 0.8 seconds will trigger the Warn Away response, while inputs longer than 0.8 seconds will
trigger the full alarm sequence. If installing an optional Directed Electronics dual stage sensor, connect both the
blue and the green wires of the optional sensor to this input. This wire will report Zone 4.
Most vehicles use negative door trigger circuits. Connect the green wire to a wire which shows ground when any
door is opened. In vehicles with factory delays on the domelight circuit, there is usually a wire that is unaffected
by the delay circuitry. This wire will report Zone 3.
Connect this wire to the optional domelight supervision relay as shown below:
IIMMPPOORRTTAANNTT!!This output is only intended to drive a relay. It cannot be connected directly to the
domelight circuit, as the output cannot support the current draw of one or more light bulbs.
HH11//99BBLLAACCKK//WWHHIITTEE((--))220000mmAAddoommeelliigghhttssuuppeerrvviissiioonnoouuttppuutt
HH11//88GGRREEEENN((--))ddoooorrttrriiggggeerriinnppuutt,,zzoonnee33
HH11//77BBLLUUEE((--))mmuullttiipplleexxiinnppuutt,,zzoonnee44
All manuals and user guides at all-guides.com

2200© 2005 Directed Electronics—all rights reserved
This input comes from the factory set to 2 activation pulses. This means that it is necessary to have 2 consec-
utive ground pulses on the white/blue wire for the remote start to activate or to deactivate. The same holds true
for the remote control activation when set to a two pulse setting it is necessary to press the button twice
for the remote start to activate or deactivate.
NNOOTTEE::When the activation pulse count can be programmed to 1, 2, or 3 pulses when changed
it will affect both activation inputs; the White/Blue wire and the remote control activation.
As shipped, this wire should be connected to the (+) parking light wire. If the light flash polarity jumper under
the sliding door is moved to the opposite position (see
Internal Programming Jumper section of this guide), this
wire supplies a (-) 200 mA output. This is suitable for driving (-) light control wires in Toyota, Lexus, BMW, some
Mitsubishi, some Mazda, and other model cars.
((++))PPoossiittiivveeLLiigghhttFFllaasshhOOuuttppuutt
HH11//1111WWHHIITTEE((++//--))sseelleeccttaabblleelliigghhttffllaasshhoouuttppuutt
HH11//1100WWHHIITTEE//BBLLUUEErreemmootteessttaarrtt((--))aaccttiivvaattiioonniinnppuutt
All manuals and user guides at all-guides.com
