Directed XPRESSKIT GM9 User manual

Installation Guide
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Vehicle Application Guide...................................................................................................................................................
Installation (Wiring Diagram & Vehicle Wiring Reference Chart)........................................................................................
SmartStart/XL202 Installation Notes..................................................................................................................................
Programming
Module Programming.........................................................................................................................................................
Module Reset.....................................................................................................................................................................
Hard Reset.........................................................................................................................................................................
Feature & Option List..........................................................................................................................................................
Feature Programming.........................................................................................................................................................
LED Diagnostics & Troubleshooting...................................................................................................................................
Limited One-Year Consumer Warranty..............................................................................................................................
Quick Reference Guide......................................................................................................................................................
2
3
6
7
8
8
9
10
11
13
14
Index
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Range
Extender Ready (RXT) mode without the use of a remote starter. See the Module Programming section for
more information.
Important!
▪This product is ONLY compatible with vehicles equipped with a factory-installed remote starter.
▪This guide is compatible with the GM9 firmware version 2.05 and later.
Range Extender Ready (RXT) is used to dramatically increase the factory remote start activation range
compared to the factory transmitter. Refer to the Quick Reference Guide for more information.
® Buick, Cadillac, and Chevrolet are registered trademarks and property of their respective companies.
The GM9 firmware for DBALL2 is an all-in-one door lock and override module compatible with
specific Buick, Cadillac,Chevrolet and GMC vehicles. This guide supports the installation of a
DBALL2 in Range Extender Ready (RXT) mode with an RF System or a SmartStart (both sold
separately).
This module can only be flashed and configured using XpressVIP at www.directechs.com or
using the Directechs Mobile application for smartphones. Refer to the Module Programming
section on page 7 for more information.
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Vehicle Application Guide Page 2
The table below lists the vehicles and features which are compatible with this product. Refer to the following pages for
more information on installation wiring, programming and troubleshooting for these vehicles.
Vehicles
2016 2015 2014 2013 2012 2011 2010 DL-Arm Factory Security DL-Disarm Factory Security DL-Door Lock Control DL-Door Unlock DL-Driver Priority Unlock DL-Trunk / Hatch Release RS-OEM Remote Start Activation using XL-202 or RF kit RS-SmartStart ST-Brake Status (foot brake)
Buick
LaCrosse (Smart Key) • • • • • • • • • • • • • • • •
Regal (Smart Key) • • • • • • • • • • • • •
Verano (Smart Key) • • • • • • • • • • • • • •
Cadillac
ATS (Smart Key) • • • • • • • • • • • • •
CTS Sedan (Smart Key) • • • • • • • • • • • •
Escalade (Smart Key) • • • • • • • • • • •
SRX (Smart Key) • • • • • • • • • • • • • • • •
XTS (Smart Key) • • • • • • • • • • • • •
Chevrolet
Cruze (Smart Key) • • • • • • • • • • • • • •
Impala (Smart Key) • • • • • • • • • • • •
Malibu (Smart Key) • • • • • • • • • • • • •
Suburban (Smart Key) • • • • • • • • • •
Tahoe (Smart Key) • • • • • • • • • • •
GMC
Yukon (Smart Key) • • • • • • • • • • •
Legend:
DL: OE Door Lock & Alarm Controls
RS: Engine Start & Status
ST: Function/Feature Status
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Single Wire CAN: Light Green: 1
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
(-) Ground: Black: 14
(+) 12V: Red: 13
SW CAN: Pin 1
(-) Ground: Black, pin 4
(+) 12V: Pin 16
1 8
169
HS CAN High: Pin 6
HS CAN Low: Pin 14
OBDII
Diagnostic Connector
Refer to "Vehicle Wiring Reference Chart" for more information on vehicle-specific connections.
Page 3
Wiring Diagram
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
10
RF
Prog. Button
LED
4
14 12 2
DBALL2
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.
Vehicle Wiring Reference Chart
Wire colors should only be used as a reference. You should always test a wire's function before connecting to it.
Page 4
Function Color Pin Polarity Location Color Pins
SW CAN Dk.Green 1 Data
HS CAN High Tan/Black 6 Data
CAN Low Tan 14 Data
12V Red/White 16 (+)
Ground Black 4 (-)
SW CAN Lt.Green 1 Data
HS CAN High Dk.Blue 6 Data
CAN Low Tan or White 14 Data
12V Red/Dk.Green 16 (+)
Ground Black 4 (-)
SW CAN Lt.Green 1 Data
CAN High Dk.Blue 6 Data
CAN Low White 14 Data
12V Blue/Green 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
CAN High Blue 6 Data
CAN Low White 14 Data
12V Red/White or Red/Violet 16 (+)
Ground Black 4 (+)
SW CAN Green 1 Data
HS CAN High Blue 6 Data
CAN Low White 1 Data
12V Red/White or Red/Violet 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
CAN High Blue 6 Data
CAN Low White 14 Data
12V Red 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
CAN High Blue 6 Data
CAN Low White 14 Data
12V Red/White 16 (+)
Ground Black 4 (-)
SW CAN Dk.Green 1 Data
CAN High Tan/Black 6 Data
CAN Low Tan 14 Data
12V Red/White 16 (+)
Ground Black 4 (-)
SW CAN Lt.Green 1 Data
CAN High Lt.Blue 6 Data
CAN Low White 14 Data
12V Red/Lt.Green 16 (+)
Ground Black 4 (-)
BlackOBDII Diagnostic Connector. 16
Cadillac SRX (Smart Key) 2010-2012
OBDII Diagnostic Connector. Black 16
Buick LaCrosse (Smart Key) 2013-2016
OBDII Diagnostic Connector. Black 16
OBDII Diagnostic Connector. Black 16
Buick Regal (Smart Key) 2011-2014
Cadillac CTS (Smart Key) 2014-2016
Wire Information Connector Information
Buick LaCrosse (Smart Key) 2010
Buick LaCrosse (Smart Key) 2011-2012
Black 16OBDII Diagnostic Connector.
Buick Verano (Smart Key) 2012-2016
OBDII Diagnostic Connector. Black 16
OBDII Diagnostic Connector. Black 16
Cadillac ATS (Smart Key) 2013-2016
Cadillac XTS (Smart Key) 2013-2016
OBDII Diagnostic Connector. Black 16
OBDII Diagnostic Connector. Black 16

Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.
Vehicle Wiring Reference Chart
Wire colors should only be used as a reference. You should always test a wire's function before connecting to it.
Page 5
Function Color Pin Polarity Location Color Pins
SW CAN Lt.Green 1 Data
HS CAN High Dk.Blue 6 Data
CAN Low White 14 Data
12V Red/Lt.Green 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
HS CAN High Blue 6 Data
CAN Low White 14 Data
12V Red/Blue 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
CAN High Blue 6 Data
CAN Low White 14 Data
12V Red/Green 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
CAN High Blue 6 Data
CAN Low White 14 Data
12V Red/Green 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
CAN High Blue 6 Data
CAN Low White 14 Data
12V Red/Brown 16 (+)
Ground Black 4 (-)
SW CAN Green 1 Data
HS CAN High Blue 6 Data
CAN Low White 1 Data
12V Red/Violet 16 (+)
Ground Black 4 (-)
Black 16
OBDII Diagnostic Connector. Black 16
Chevrolet Malibu (Smart Key) 2016
Chevrolet Malibu (Smart Key) 2013-2015
OBDII Diagnostic Connector. Black 16
Cadillac Escalade/Chevrolet Tahoe, Chevrolet Suburban/ GMC Yukon (Smart Key) 2015-2016
OBDII Diagnostic Connector. Black 16
Wire Information Connector Information
Cadillac SRX (Smart Key) 2013-2016
Chevrolet Cruze (Smart Key) 2012-2016
Black 16OBDII Diagnostic Connector.
BlackOBDII Diagnostic Connector. 16
Chevrolet Impala (Smart Key) 2014-2016
OBDII Diagnostic Connector.

Page 6
SmartStart/XL202 Installation Notes
The DBALL Range Extender Ready (RXT) solution offers two (2) configuration options to control your system: RF Kit or
SmartStart (both sold separately). This section provides specific installation information for SmartStart and XL202.
The optional XL202 and antenna are not included and MUST be purchased separately.
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information.
4
4
XL202
Antenna
XOVER
SmartStart is optional and not included. It MUST be purchased separately.
SmartStart is optional and not included. It MUST be purchased separately.
Configuration Wires (Gray & White)
Connect Gray wire to (-) Ground
5 pins
D2D (4 pins, white)
4 pins
2 pins,
not used
CABLE
CABLE
The modules must be connected in a specific order. Refer to the Module Programming section for more information.
1. Use the D2D Crossover (XOVER) cable that is provided with XL202, and NOT the one in the DBALL package.
2. The modules must be connected in a specific order. Refer to the Module Programming section for more information.
The modules must be connected in a specific order. Refer to the Module Programming section for more information.
SmartStart Revision B
RF Kit
RF Kit & PKE Combination
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information.
RF Kit, PKE & SmartStart BT Combination
SmartStart Revision A
DBALL2
DBALL2
DBALL2 LED
Prog.
Button
D2D (4 pins, white)
4 pins
2 pins,
not used
OR
SmartStart
Configuration Wires (White & Brown or Blue)
Cut Brown or Blue Loop
LED
THIS SIDE UP
LED
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Module Programming
Page 7
Refer to the LED Diagnostics section on pages 11-12 for more information and for troubleshooting purposes.
1
10-pin
D2D
st
1
12-pin
14-pin
nd
2
rd
3
&
Solid
Connect the 10-pin, 12-pin and 14-pin harnesses to
DBALL, then wait until the LED turns ON solid red.
2Enter the vehicle, while making sure the factory remote is inside with you.
Press 5 times on the programming button. The LED turns on solid orange. &
Press X5
Important
10-pin
D2D
XL202
10-pin
D2D
SmartStart
OR
The DBALL module must be disconnected from any power source before SmartStart can
be connected to it. Failing to do so could damage DBALL.
a. To ensure that the D2D communication between SmartStart and DBALL works properly, the
Gray wire must be connected to a ground source (Rev B SmartStart), and the Brown or Blue
loop must be cut (Rev A SmartStart).
b. Do NOT connect the 2-pin harness (on SmartStart). Power and ground will be provided by
the DBALL D2D connector.
Connect SmartStart to DBALL using the D2D port.
SmartStart Installation
Connect XL202 to DBALL using the D2D port.
XL202 Installation
Make all the required connections to the vehicle, as described in the wiring diagram(s) found in this guide, and double check to
ensure everything is correct prior to moving onto the next step.
Note: Before connecting either the XL202 or SmartStart module to DBALL, it is important to ensure that the proper feature and
function programming is selected using XpressVIP (version 4.5 or higher). Visit www.directechs.com to download the latest
version of the application.
Warning! To take advantage of advanced features, you must use XpressVIP 4.5 (and higher) or the Directechs Mobile app.
When the flashing operation is successful, you can proceed with the programming instructions below.
Flashing a module using your computer:
1. Connect the interface module to your computer using the
XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and
select the Config for RXT button.
3. Follow the instructions to select your vehicle, installation
type, and configure your options.
4. Once you have configured the firmware options, click on the
FLASH button.
Flashing a module using your smartphone or tablet
1. Connect the interface module to your XKLoader3.
2. Launch the Directechs Mobile app on your smartphone or
tablet.
3. Select FLASH YOUR MODULE and follow the on screen
instructions.
Solid Orange
3Press once and hold the Push-to-Start button to
turn the ignition ON. The LED flashes green. Flashes
Green
&
ENGINE
START
STOP
HOLD
&
1X ENGINE
START
STOP
PUSH
Go to the next page to complete the module programming.
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Module Reset
Page 8
1If required for your installation, connect the 10-pin & 12-pin
harnesses to the module. Press and hold the programming
button, then connect the 14-pin harness to the module.
10-pin
D2D
st
1
12-pin
14-pin
nd
2
th
4
rd
3
Warning Against Executing a Hard Reset!
A hard reset will revert the flashed firmware back to its default settings. Depending on the installation, some settings (such
as RFTD and D2D options) may have to be reconfigured. See the Feature & Option List section of this guide.
2
Solid
&
Release
3 Release the programming button. The LED turns ON solid red.
Hard Reset
2& &
1
Wait 3 seconds until the LED turns ON solid orange then release the
programming button. The LED turns ON solid red.
If required for your installation, connect the 10-pin & 12-pin
harnesses to the module. Press and hold the programming
button, then connect the 14-pin harness to the module.
10-pin
D2D
st
1
12-pin
14-pin
nd
2
th
4
rd
3
A module reset will only erase programming performed in the previous steps. All settings (firmware) and settings flashed
to the module using the web config tool will not be affected.
Solid Release Solid
Solid Flashes
&
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds
until the LED starts to flash orange and red.
Press the PTS (Push-to-Start) button once to turn the Ignition OFF.1X ENGINE
START
STOP
PUSH
4
5The LED turns ON solid orange for 3 seconds, then shuts OFF. &
Solid x3 Secs Off
You have successfully completed the module programming sequence.
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Page 9
Feature & Option ListFeature & Option List
It is recommended to configure all the features and options listed below using the configuration tool found on the module
flashing page on www.directechs.com. The web offers more options such as RXT; however, manual configuration of the
features is possible using the information on this page.
* Default Option
Feat. Operation Flashes/Options Description
1. No RF Output* Module is connected to a remote starter using a standard installation.
2. RFTD Output Module is connected to an XL202 using an RSR or RXT installation (w hen available).
3. SmartStart Module is connected to SmartStart using an RSR or RXT installation (w hen available).
1. Driver Priority * Unlocks only the driver door on first press and unlocks all doors on a second press w ithin 5 seconds.
2. All Unlocks all doors on first press.
1. Trunk* Will pop the trunk if available.
2. Electric Rear Hatch When available, w ill operate the electric rear hatch.
1. Trunk Will pop the trunk if available.
2. Electric Rear
Hatch* When available, w ill operate the electric rear hatch.
1. Disabled The OEM alarm w ill not be controlled by DBALL upon remote start. No disarm or arm command w ill be
executed at the beginning or end of the sequence; it must be controlled by the Remote Starter.
2. Safelock Smart OEM Alarm Control w ill behave like a standard Saf elock feature on a remote starter. It w ill unlock at the
beginning of the sequence, and relock after start and shutdow n.
3. Enabled*
Smart OEM Alarm Control w ill synchronize w ith the OEM alarm so that it w ill disarm and rearm the vehicle in
the remote start sequence, only w hen required. The reason for this is, factory alarm control must often be
done by lock or unlock operation. This could create unnecessary actions on door lock modules, such as the
horn to honk. When possible, Smart OEM Alarm Control w ill monitor the alarm and door lock status to detect if
the disarm or rearm is required. If the vehicle is unlocked or is not equipped w ith factory alarm, the
disarm/rearm w ill not be executed. Smart OEM Alarm Control w ill also monitor the remote starter actions so
that the factory alarm control is not done tw ice. A remote starter, for w hich the Safelock feature is active,
w ill w ork perfectly w ith this option and w ill make it invisible to the user.
RFTD Output
Type
1
5Smart OEM Alarm
Control
2Unlock Driver
Priority
3 Trunk
4 AUX 1
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.
To enter feature programming routine
-Turn the ignition ON, then OFF.
-Within 5 seconds, press and HOLD the programming button until the LED turns ON orange (after 3 seconds). Release the
Programming button.
-The LED will flash green once slowly to indicate the feature number is 1. After a short delay, the LED flashes red rapidly to indicate
the current option of feature 1 (i.e. 1x green followed by 1x red indicates feature 1 is set to option 1). The flashing sequence will repeat
until a new command is entered.
Changing feature options
-Press the lock/arm or unlock/disarm button on aftermarket transmitter to change the option of the selected feature.
-The LED flashes red rapidly the number of times equal to the current option number. After a short delay, the LED flashes green slowly
the number of times to indicate the current feature. The flashing sequence will repeat until a new command is entered.
Accessing another feature
-Press and release the programming button a number of times to advance from the current feature to the next desired feature.
-The LED flashes green slowly the number of times equal to the feature number. After a short delay, the LED flashes red rapidly to
indicate the current option of the current feature. The flashing sequence will repeat until a new command is entered.
When the maximum number of features or options is reached, the LED will start flashing again from the first feature or option.
Once a feature is programmed
-Other features can be programmed.
-The feature programming can be exited.
Exiting feature programming
-No activity for 30 seconds; after 30 seconds, the LED will turn ON orange for 2 seconds to confirm the end of the programming
sequence.
OR
-Press and HOLD the programming button for 3 seconds. After 3 seconds, the LED will turn ON orange for 2 seconds to confirm the
end of the programming sequence.
Feature Programming Programming
Button
Page 10

Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.
Page 11
LED Diagnostics & Troubleshooting
LED
Description Troubleshooting
Module Programming
Module has no power. Check the power connections.
Module is powered. Waiting to receive the first
part of the information from the key. Check your connections (see wiring diagram).
Information received from the key.
Check your bypass connections (Yellow/Black wire) and make sure the
battery is removed from the key fob. Make also sure the key is in key port
(or key reader.)
Waiting to receive the second part of the
information from the key. Normal operation.
Bypass was skipped. Normal operation.
All information received from the key. A 5 seconds delay can be necessary to receive all information from the key.
OBD CAN is detected, the device is ready for
Key2GO programming. Check OBD CAN connections (see wiring diagram).
Module was successfully programmed. Normal operation.
Module was successfully programmed without
transponder. Normal operation.
Module Programming - Error codes
SW CAN not detected. Check the LT green wire connections. Wake up the data bus by turning the
ignition on and try again.
OBD CAN not detected. Check the Tan - Tan/Black wire connections. Wake up the data bus by
turning the ignition on and try again.
Bypass data not detected.
Check the bypass line connection. If more than one wire is used, make sure
they are not inverted. Start vehicle using the key to confirm the OEM
equipment is still operational.
External Module Synchronisation
OBDII feature not supported.
Diagnostic data bus not detected. Some features are not supported by
SmartStart. This can be caused by missing wire connections or module
hardware limitation. Refer to the wiring installation section to check the
connections.
Active Ground While Running
GROUND OUT ON (GWR) command received. Otherwise, the Ground While Running (status) signal was lost or was never
received by the module. Commands can come from RF, D2D or W2W.
IGNITION ON command received. Otherwise, the ignition signal was not received by the module. In a W2W
install, it will show only if the ignition input wire is used.
START ON command received. Otherwise, the start signal was not received by the module. In a W2W
install, it will show only if the ignition input wire is used.
Solid
Red
Solid
Green
Solid
orange
Solid
orange
x3 sec
Solid
green
x3 sec
Flashes
orange
Flashes
green
Off
Flashes
red x 1
Flashes
red x 2
Flashes
red x 3
Flashes green
& orange
Flashes
green
Flashes
green
quickly
Flashes
red, red,
orange
Flashes red
& orange
Go to the next page to see the rest of the LED Diagnostics & Troubleshooting.

Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.
Page 12
LED Diagnostics & Troubleshooting
D2D and W2W Commands
LOCK command received.
Normal operation. If the LED do not flash, it means the
module did not receive the signal. Commands can come
from RF, D2D or W2W.
UNLOCK command received.
TRUNK command received.
AUX1 command received.
Remote Start Shutdown Code
Run safe shutdown.
Brake shutdown.
No key detected shutdown.
Speed detected.
Used to check the installation and for troubleshooting
purposes. Used to check for internal safety operation.
Does not represent an error.
Normal operation.
Flashes
orange
x2
Flashes
red x2
Flashes
orange
x3
Flashes
red x3
Flashes
orange
x4
Flashes
red x4
Flashes
orange
x1
Flashes
red x1
RXT Code
OEM Remote Start Activation was attempted
when RFTD feature is disabled.
Activated from Web automatically when using RXT flash
tool or can be done manually. Refer to Feature
Programming section for more information.
RXT start not possible when OEM system is
disabled. Refer to the owner documentation to activate it.
RXT start command not executed. Module received the command, but the car did not
perform the action.
If the bypass module fails to flash, it means the
module did not receive the signal.
If using XL202, make sure that the proper cable is
connected. When using SmartStart make sure that
SmartStart is configured in D2D.
Flashes
green
x7
Flashes
green
x8
Flashes
red x5
Flashes
red x6
Flashes
x7
Flashes
red x8

Limited One Year Consumer Warranty Page 13
For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed
Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the
security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material
under normal use, provided the following conditions are met: the Part was purchased from an authorized DIRECTED dealer;
and the Part is returned to DIRECTED, postage prepaid, along with a clear, legible copy of the receipt or bill of sale bearing the
following information: consumer’s name, address, telephone number, the authorized licensed dealer’s name and complete
product and Part description.
This warranty is nontransferable and is automatically void if the Part has been modified or used in a manner contrary to its
intended purpose or the Part has been damaged by accident, unreasonable use, neglect, improper service, installation or
other causes not arising out of defect in materials or construction.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, EXCEPT AS STATED ABOVE, ALL WARRANTIES, INCLUDING
BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY,
FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NONINFRINGEMENT OF INTELLECTUAL
PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY
PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS
PRODUCTS. DIRECTED HEREBY DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF
THIRD PARTIES INCLUDING DEALERS OR INSTALLERS. DIRECTED IS NOT OFFERING A GUARANTEE OR
INSURANCE AGAINST VANDALISM, DAMAGE, OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS,
AND DIRECTED HEREBY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITHOUT LIMITATION,
LIABILITY FOR THEFT, DAMAGE, OR VANDALISM. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING
DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF
CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE
DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED
TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE OF THE PART. DIRECTED SHALL NOT BE
RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL
DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL
LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE
MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR AT DIRECTED’S OPTION THE
PART AS DESCRIBED ABOVE.
This warranty only covers Parts sold within the United States of America and Canada. Parts sold outside of the United States of
America or Canada are sold “AS-IS” and shall have NO WARRANTY, express or implied. Some states do not allow limitations
on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights and you may also have other rights that vary from State to State. DIRECTED does not and has
not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this Part.
For further details relating to warranty information of Directed products, please visit the support section of DIRECTED’s
website at: www.directed.com
920-10012-01 2013-07
This Interface kit / Data Bus Interface part has been tested on the listed vehicles. Other vehicles will be added to the select
vehicle list upon completion of compatibility testing. Visit website for latest vehicle application guide. DISCLAIMER: Under no
circumstances shall the manufacturer or the distributors of the bypass kit / data bus interface part(s) be held liable for any
consequential damages sustained in connection with the part(s) installation. The manufacturer and it’s distributors will not, nor
will they authorize any representative or any other individual to assume obligation or liability in relation to the interface kit / data
bus interface part(s) other than its replacement. N.B.: Under no circumstances shall the manufacturer and distributors of this
product be liable for consequential damages sustained in connection with this product and neither assumes nor authorizes
any representative or other person to assume for it any obligation or liability other than the replacement of this product only.
Protected by U.S. Patents: 5,719,551; 6,011,460 B1 *; 6,243,004 B1; 6,249,216 B1; 6,275,147 B1; 6,297,731 B1; 6,346,876
B1; 6,392,534 B1; 6,529,124 B2; 6,696,927 B2; 6,756,885 B1; 6,756,886 B2; 6,771,167 B1; 6,812,829 B1; 6,924,750 B1;
7,010,402 B1; 7,015,830 B1; 7,031,826 B1; 7,046,126 B1; 7,061,137 B1; 7,068,153 B1; 7,205,679 B1; Cdn. Patent:
2,320,248; 2,414,991; 2,415,011; 2,415,023; 2,415,027; 2,415,038; 2,415,041; 2,420,947; 2,426,670; 2,454,089; European
Patent: 1,053,128; Pat. Pending: 2,291,306. Made in Canada.
Rev.: 20170407
Platform: DBALL2
Firmware: GM9 Range Extender Ready (RXT) Installation v.2.05+
© 2017 Directed. All rights reserved.

Quick Reference Guide
DBALL2-GM9 Range Extender Ready (RXT) Installation
© 2017 Directed. All rights reserved.
* Your factory or aftermarket remote may differ from the model shown in the
illustrations.
Pit Stop Mode
The Pit Stop Mode feature is practical when you need to stop and run an errand,
but wish to keep the engine running.
Vehicle Takeover with Get In and Go*
4
3
1Close the vehicle doors, hood and trunk, then press
the Remote Start button on the transmitter to start
the vehicle.**
2
Press the brake pedal, put the car
in gear and drive off.
Enter the vehicle, while making sure the
factory remote is inside with you.
Press the Unlock button on the factory
or aftermarket remote.**
Ready to
drive off
Press
remote start
button**
Press Unlock
button on
either remote** OR
** Your aftermarket remote may differ from the model shown in the illustrations.
GG
* Get In and Go connections required.
Get In and Go
Get In and Go is designed to provide users with easy takeover when
entering their Push-to-Start (PTS) equipped vehicle, once it has been
remote started.
Typically, users would have to remote start their vehicle, then get inside and press
the vehicle start button to perform a takeover. There is therefore a physical action
required to drive away. With Get In and Go technology, you simply remote start the
vehicle, unlock the doors, get in and go... Nothing to do but put the gear in drive and
enjoy your vehicle.
This unique feature monitors a variety of parameters such as the key fob, vehicle
speed sensor and door sensor, in order to perform takeover securily.
GG
Complete the following steps within 45 seconds
or the vehicle will shut down.
1
2
3
Stop the vehicle in a safe parking spot
and put the gear in Park (P).
Press
remote start
button*
Stop & put vehicle in Park (P)
P
&
Note: We recommend that you always lock the doors
of your vehicle when leaving it unattended.
It is now safe to leave the engine running and exit the
vehicle with the factory remote in hand.
Press the button to remote start the vehicle.*
Exit vehicle with
Smart Key
Enter vehicle with
factory remote*

Quick Reference Guide
DBALL2-GM9 Range Extender Ready (RXT) Installation
© 2017 Directed. All rights reserved.
Range Extender Ready (RXT) is used to amplify the distance covered
by factory remote starters. The interface connects to the vehicle and
uses the same code as the factory remote to remote start the vehicle.
The runtime and features are identical to the OEM remote starter.
Some of the advantages of RXT are greater remote range and 2-way
compatibility.
Range Extender Ready (RXT)
Command Engine Result
Start NOT running. The engine will be started.
Start Running. The engine will be stopped.
The following table describes the behavior of the vehicle in relation to the RXT
feature. The following commands are performed on the aftermarket remote.
Runtime
The runtime is equivalent to the amount set for the OEM remote starter, which can
be modified in some vehicles (refer to your vehicle owner’s manual for more
information). A maximum of 2 remote starts can be performed between ignition
cycles.
Runtime Reset
The Runtime Reset feature allows the user to return the runtime to its predefined
value. This can only performed ONCE per remote start.
RXT Operations
Button(s)
Actions
Press & hold for 1 second to lock.
Press & hold for 1 second to unlock.
Press & hold for 1 second to remote
start.
Press & hold for 5 seconds to activate
the trunk release (optional).
Press once, then to activate the
rear hatch/tail glass release (optional).*
Press 3 times, then to activate
the panic mode.
Press once, then to reset the
remote starter runtime.
List of Available Commands
x1 +
x3 +
x1 +
* This output is configurable. see your authorized installation center for more
information.
Note that the information below is for Viper, Clifford and Python models. Icons and
commands may differ depending on the remote brand and model purchased. Refer
to your authorized installation center for more information.

Quick Reference Guide
DBALL2-GM9 Range Extender Ready (RXT) Installation
© 2017 Directed. All rights reserved.
SmartStart Compatible
This system is compatible with Directed SmartStart 3.0. For
a complete list of supported features, please visit
www.mysmartstart.com.
What is SmartStart?
Now you can remote start, lock and unlock your car just by pushing a button on
your smartphone; using the SmartStart App from Directed, the leader in vehicle
security and remote start. The simple graphical interface gives you control over the
following features of your installed remote start or security with remote start system:
ŸLock/Arm
ŸUnlock/Disarm
ŸRemote Car Starter
ŸTrunk Release
ŸPanic
ŸAux Channels
You can also control multiple vehicles – great for families – and assign more than
one user to control a vehicle. It's easy with SmartStart!
But, this is only the beginning! SmartStart is loaded with additional features
including GPS tracking, SmartSchedule, vehicle status, roadside assistance, home
control, parked car finder and more.
3.0 enables a "Cloud-Connected Car" like never before, providing an entirely new
level of 2-way interaction with your vehicle. Connectivity is managed through the
Directed Cloud Services (DCS) network linking car, app, end user, and the Internet.
For more information, visit www.mysmartstart.com.
Notes
