Discount Car Stereo A2DIY-C5CD User manual

Courtesy of: DiscountCarStereo.com
Serving the internet community since 1995
A2DIY-C5CD
QUICK START BLUETOOTH HANDS-FREE INSTALLATION GUIDE FOR SELECT 1997-04 CORVETTE WITH 12-DISC CD CHANGER
Created January 16, 2013
Revised September 9, 2020

Introduction:
If looking to add Bluetooth features to your American classic with trunk/hatch
mounted 12-disc changer should consider the A2DIY-C5CD Kit. This revised
easy to install kit is essential to adding Bluetooth features to the C5 radio.
This module sounds great for mobile conversations, streaming Pandora, Sirius
radio, Apple music, audiobook, podcast and more. The included wireless remote
control can be mounted on the dash or steering wheel to adjust volume, track
and more. In addition, an optional USB charging port is available to keep devices
charged while on the road. Thanks to the A2DIY-C5CD kit users keep the radio
and CD changer while enjoying Bluetooth features only available on newer cars.
Trunk/hatch mounted 12-disc changer is required. If
vehicle does not have one or if malfunctions; purchase our
A2DIY-C5 instead.
See Frequently Asked question at the end of this guide for more details.
Installation: (To radio)
Remove radio from dash to gain access to connectors. Click link below
https://www.youtube.com/watch?v=WTbWYNJTSDs
1. Locate and disconnect factory 20-pin plug from radio as seen in Fig. 1
Fig. 1
radio connector
2. Connect factory 20-pin plug to installation harness 20-pin connector
(white) See Fig. 2
Fig. 2
Fig. 3
installation harness
3. Connect installation harness 20-pin plug (black/gray) (See Fig. 3) to
radio 20-pin connector (See Fig. 1)
Trunk/hatch mounted 12-disc changer

Playback options explained
These options are available at checkout:
1. Retain changer playback (default)
2. Auxiliary input (instead of changer playback)
3. Auxiliary input + changer playback (both)
Retain Changer playback:
Default option that allows users to retain use of their 12-disc changer.
Proceed to installation step 4.
AUX input (instead of changer playback):
This option allows users to connect and play a portable audio device (e.g.
sat radio, Alexa, iPod, Mp3 etc.) instead of 12-disc changer)
WARNING: The required CD changer remains connected but will no
longer play. (At least one disc must be loaded to magazine)
1. Connect included 3.5mm audio cable (See Fig. 4) to module “AUX” jack
2. Route audio cable plug to where audio device will reside (within 3 ft.)
3. Proceed to installation step 4.
AUX Jack+ changer playback
With this option, AUX plus 12-disc changer playback are possible.
1. Route installation harness aux jack (See Fig. 5) to glove box, dash area
etc. (cable is 3 ft. long)
2. Drill a ¼” hole in dash or panel and secure jack with included nut or
leave freestanding.
3. To listen to audio device (e.g. Mp3 player) simply connects to jack. To
listen to the CD changer, disconnect audio device from jack (jack
must be empty during changer playback).
Proceed to installation step 4
Module
Fig. 4
3.5male to male audio cable
Fig. 5
4. Connect push-to talk button 1/8” plug to Module “CTR” jack, route
button to front of the dash, remove tape backing and stick to dash
(cable is 6ft. long). (See Fig. 6)
Fig. 6
push-to-talk button

5. Use visor clip to install microphone on headliner, route cable down
pillar, under dashboard toward module location and connect to module
“MIC” input.
The microphone incorporates noise filtering; however wind noise
(Convertibles) will negatively affect phone calls. Instead of sun
visor, convertible users are advised to locate alternate location
for microphone. Also ensure no ventilation duct is pointed
towards microphone.
Microphone
Revision (4.6.20)
what’s new:
1. Bluetooth playback is now possible up and until radio turns off.
(Previous revision would turn on/off with ignition switch).
2. No longer requires routing accessory wire to fuse panel.
Special circuit added to harness which powers module when radio is turned
on/off.Skip to “Optional USB” page 5
Modules purchased prior revision (4.6.20); proceed to step 6 below.
6. Connect (Tap) installation harness red wire to an ACC (Accessory or
switched) 12V supply power source in vehicle.
7. Connect red wire to accessory supply in your vehicle.
Optional push button with built-in microphone:
This option replaces standard visor microphone and separate push button
shown in Fig. 6, and combines both in a single button. (See images below)
which means button can be placed on dashboard within driver reach or
custom installed nearby.
To install simply connect 1/8” plug to module “MIC/CTR” jack, route to
dash area (cable is 6ft. long); clean surface, remove tape backing and
secure to dash. (To add to cart, simply tap option on order page)

Where to get 12 Acc. supply:
1997-03: Many have a 3-pin plug under passenger toe board near BCM (may be
covered in black duct tape) -- See Fig.8 Yellow wire is ACC. If vehicle does not
have 3-pin plug; go to Alternate 12V Acc. supply below.
Fig. 8
Note: 3-pin plug may not be present in all vehicles.
Alternate 12V Acc. supply:
Fuse #22 or #11 of interior fuse box which is located under
passenger toe board (See Fig. 9).
The add-a-fuse mini-tap circuit seen in Fig. 9a is included for this purpose.
Fig. 9
How to use Add-a-fuse circuit
a. Strip 1/4- 3/8” insolation from end of accessory wire.
b. Look inside blue connector where metal ends. (useful in step d)
c. Insert stripped wire to blue connector
d. Hold wire in place and crimp down (crimping tool or plyers). After
crimp, pull wire to verify crimp integrity.
e. Remove fuse #22 or #11 (if present) from vehicle fuse box otherwise
skip to step g.
f. Insert factory fuse to empty slot on add-a fuse circuit (See Fig. 9a)
g. Insert add-a-fuse circuit to fuse box slot #22 or# 11
Noteworthy: If there is no fuse in slots #22 or #11, the fuse slot on add-a-fuse
tap remains empty. (See Fig. 9a) Turn ignition “ON” to verify module LED is
flashing, otherwise test fuse slot for power and/or check crimp integrity,
Fig. 9a
Add a circuit

Optional Smart charging port (not for thumb drives etc.)
An optional USB charging port can be added to your module. Should you decide
on this add-on, we suggest one of 2 connecting options:
A. Flush to dash/panel requires drilling a ¾” hole
B. Flush with Support bracket (Mount USB terminal wherever your installation
demands without drilling)
A. Flush to Dash or Panel (drilling required)
Note: Alternately, user may modify cigar lighter opening
1. Drill a ¾” hole in the dash or panel using a step drill bit or equivalent
(See Fig. 10)
Fig. 10
Step drill bit
2. Insert male terminal from supplied 3ft. cable (See Fig. 11) through hole
created in step 1 and connect to installation harness charging port
(See Fig. 12)
Fig. 11
Flush mount 3 ft. USB cable
Fig. 12
USB port
3. Snap USB cable head (See Fig. 13) to hole created in step until flush
with mounting surface (See Fig. 14)
Fig. 13
USB head
Fig. 14
Flush mounted to dash
4. Tuck and secure any extra wire from moving parts and test operation

B. Bracket Mount (No drilling)
1. Locate a flat surface at location of choice within 3.2 ft. of module to
mount USB support bracket (See Fig. 15) using adhesive/tape or
screws (included).
Fig. 15
USB mounting bracket
2. Insert USB cable male terminal through hole in bracket (See Fig. 16)
and connect to installation charging port (See Fig. 12)
Fig. 16
3. Snap USB cable head (See Fig. 16) to bracket until flush (See Fig. 17)
Fig. 17
4. Tuck and secure any extra wire away from moving parts and test
operation ( See Bluetooth Pairing and Connection )
Smart remote
pairing smart remote: Pair to Smartphone for media control functions
(does not operate C5 radio). The remote pairs with multiple devices but can only
operate one at a time. Follow 3-step pairing process below:
Installing smart remote:
Install smart remote to dashboard or panel with provided holder or double side
tape.
Custom install

Smart Remote operation:
With smart remote paired to smartphone, users may perform the following
functions on devices with iOS7.0 and higher and Android 4.4 and higher.
In addition to above:
To answer/end call press Play/Stop button (Android only) or
press push-to-talk button (Apple and/or Android)
To switch from streaming to AUX press, Play/Stop button (Android only) or
press push-to-talk button (Apple and/or Android)
Noteworthy: Push-to-talk button must be used to answer/end calls on
Apple devices; however both the push-to-talk button and wireless remote
Play/Stop button can be used for this purpose. If your application is
exclusive to Android, the push-to-talk button may not be required.
Bluetooth Pairing:
This process is done upon initial install and will not have to be repeated.
1. Turn ignition and radio “ON”
Blue LED through module peephole will flash (pairing mode)
2. On A2DP device: go to Bluetooth Settings , Tap to Scan
3. Wait for Bluetooth device name (See below) to appear and tap it.
Once paired confirmation tone is heard on car speakers
Test Operation:
1. Turn ignition and radio “ON”
2. Press “TAPE/AUX” or “CD/AUX” button on radio
3. Launch smartphone music streaming application
4. Use smart remote to change tracks, adjust device volume, pause etc.
5. Place phone call or ask someone to call. Use push button to
accept/end call (iPhone and Android) or press pause/play button on
remote (Android only)
Note: Push button can be used to accept/end calls on both Apple and
Android devices, however smart remote pause/play button only works
on Android devices to accept/end calls and to switch between optional
CD Changer playback and Bluetooth.
6. If correct operation is confirmed go ahead and reinstall radio.
Playlist and Track selection is *NOT* possible from C5 radio
button. Use audio device built-in controls or optional wireless
remote to access and control audio files and applications.

Feature comparison:
The following chart illustrates the requirements and features offered by our
exclusive C5 Bluetooth modules.
FYI: Our Bluetooth kits are defined as music streaming and/or hands-free.
Bluetooth music streaming modules do not support hands-free calls, but our
hands-free calling modules support music streaming.
Features/Requirements
A2D-C5
A2DIY-C5
BLU-C5
A2DIY-C5CD
C5CD-HF
C5-HF
Retains changer playback
YES
NO
NO
YES*
YES*
NO
Requires CD changer
YES
NO
NO
YES
YES
NO
Audio input jack (Aux in)
NO
YES
NO
*
*
YES
USB charging port
optional
optional
optional
Optional
YES
YES
Supports Hands-free calls
NO
YES
NO
YES
YES
YES
Connect to radio
YES
YES
YES
YES
YES
YES
Connects to changer
YES
NO
YES
NO
NO
NO
Supports voice activation
**
**
**
**
YES
YES
Wireless remote control
optional
YES
optional
YES
NO
NO
Push-to-talk button
NO
YES
NO
YES
YES
YES
Controls from radio
NO
NO
NO
NO
NO
NO
*Optional:Aux input and/or CD changer playback retention
** Voice Activation possible with optional remote control (Android only)
Frequent asked questions
1. What is the difference between the C5CD-HF and A2DIY-C5CD?
The A2DIY-C5CD includes a push-to-talk button and separate visor mic and
a wireless remote. The C5CD-HF push-to-talk button has a built-in mic. See
feature comparison table for more details,
2. What is the difference between the A2D-C5 and A2DIY-C5CD?
The A2DiY-C5 both music streaming and Hand-free calls. The A2D-C5 does
not support hands-free calls.
3. Does the A2DIY-C5CD work on all C5 radios?
Works in 1997-04 C5 with Theftlock AM/FM/CD or AM/FM/Cassette with
functioning 12-disc changer in trunk/hatch. (will not work if changer
malfunctions). See our A2DIY-C5
4. Will radio display call number or song name?
NO. These features are not possible on this generation C5 radio.
5. Is it possible to control smartphone music from radio buttons?
NO; Use smartphone or audio device built-in controls or remote
control or voice commands. Use radio volume button to set playback level.
6. I selected the option to retain CD changer playback but how do I listen
to CD’s?
Press CD AUX or TAPE AUX button on radio to enter Bluetooth mode (if
not already), then press control button once (Android and Apple) or
smart remote play/stop (Android only).
7. I selected option to retain changer playback plus AUX input; but how
do I listen to AUX device?
Press CD AUX or TAPE AUX button on radio to enter Bluetooth Mode (if not
already), Connect aux device to 3.5mm jack, press push button once
(Android and Apple) or smart remote play/stop (Android only). To
stream music, repeat aforementioned steps.
8. I selected option to retain changer playback plus AUX input; but how
do I listen to CD changer?
Press CD AUX or TAPE AUX button on radio to enter Bluetooth Mode (if not
already), ensure aux jack is empty, then press push button once
(Android and Apple) or remote control play/stop (Android only)

9. Will radio mute when call is made and/or received?
Muting is only possible when radio is in “AUX/Bluetooth mode. If in AM/FM
mode; radio will not mute. Radio must be switched to “AUX” to hear callers
voice on car speakers.
10. My second phone does not pair or find Bluetooth module. What gives?
Ensure no other phone is paired. Allow module to enter “discovery” mode
at which point it will be ready for pairing.
11. Will I be able to connect a flash drive to optional USB port?
NO; Optional USB port does not support thumb/flash drives. Charge only.
12. How do I remove radio from dashboard to install module?
The ADIY-C5CD connects to the radio. Click link for video instructions:
https://www.youtube.com/watch?v=WTbWYNJTSDs
13. Will the radio CD player or Tape player work after installing this
module?
YES! The CD player or Tape player built-into AM/FM radio or remote 12-disc
changer operation are not affected by this module.
14. Callers not able to hear my voice with top down (convertible).
Can you offer some guidance?
In convertibles, microphone mounted to visor is exposed to wind noise.
Notable, callers will have no issue while vehicle is standing. Our microphone
includes noise cancellation features, which is different than wind noise and
our recommendation is to install microphone in an area less susceptible to
wind noise (e.g. pillar, mirror etc.). This may not be an issue with optional
push button with built-in mic.
Disclaimer
• This product has no affiliation with GM or Apple
• When possible, professional installation is recommended
Email [e-mail]
© 1995-Sep-20 Discount Car Stereo, Inc. All rights reserved. Information in this document is
subject to change without notice. Other products and companies referred to herein are
trademarks or registered trademarks of their respective companies or mark holders.
