Displays2go CHRFLMAXCP User manual

1
Rev 22.12
User Manual
Description: Charging Station with
Double-sided 21.5” Digital LCD Screens
SKU: CHRFLMAXCP,CHRFLMACPS
Scan QR code to visit
the product page:
Operating Instructions for Digital Signage
Note: Before using the product, please read the instructions carefully!
Do not attempt to disassemble this product. If the product does not work properly, please call our Customer
Service Department at 1-844-221-3393.

2
Contents
Features ................................................................................................................................ 3
Safety Warnings and Precautions ........................................................................................... 3
Assembly and Connection ...................................................................................................... 6
Packing List....................................................................................................................................6
Installation Instructions ................................................................................................................7
Replace Charging Cables ...............................................................................................................8
Install Graphics..............................................................................................................................9
Remote Control of LCD Screen .............................................................................................. 10
Description of Basic Operation ............................................................................................. 11
Power on/Standby ......................................................................................................................11
Connect to Wi-Fi .........................................................................................................................11
Upload Content …….………………………………………………………………………………………………………………13
Description of Wallpaper Switch.................................................................................................15
File Manager ...............................................................................................................................15
Local Settings ..............................................................................................................................16
StatusofMenu Bar .....................................................................................................................17
Factory Reset...............................................................................................................................17
Choose System Language............................................................................................................18
Technical Specifications…………………………………………………………………………………………………………19
Troubleshooting……………………………………………………………….……………………………………………………21
Cleaning and Maintenance……………………………………………….……………………………………………………23
Names and Contents of Toxic and Hazardous Substances or Elements in the Product…….………24
FCC Statement….……….……….……….……….……….……….……….……….……….……….……….……….………25

3
Features
1. The Mighty Max Floor Charging Kiosk is made for charging upto10 mobile devices simultaneously.
2. Features double-sided 21.5-inch Digital Screens for advertising with Advertising content management
program.
3. The digital signage is embedded with Android 10 smart operating system and unique UIdesign, bringing
you a more convenient operation and better visual experience.
4. Supports a USB mouse, realizing easy manipulation like a computer. Using a mouse for set
up is recommended.
5. High-quality LCD screen asthe display,noflicker,low radiation, greatly reducing eye fatigue,
eye protection, high brightness, high contrast, and wide viewing angle; ultra-fast response time
greatly reduces ghosting of fast-moving images.
6. Progressive image processing and industry-leading motion compensation technology improves
the flickering and blurring in the edges of motion pictures.
7. Dynamic contrast technology can significantly improve the clarity andcontrast of various screens.
Safety Warnings and Precautions
Thank you for purchasing the Digital Charging Station with Double Sided Screens from Displays2go.
We have considered the factors toensure personal safety in product design and have done rigorous
testing atthe factory. However,improper installation anduse may result in electric shock and fire.
In order to safely use, maximize performance ofthe unit and extend the life ofthe product, please read
and follow all instructions carefully before using the product.
Keep theinstructions for future reference.
We strongly recommend using a surge protector,or apower strip with internal circuit breaker to prevent
damages tothe digital signage.
Symbol Legends:
Warning: May cause personal injury or death
The operation is prohibited
Caution: May cause damage or property loss
The operation must be executed
If any of the following occurs:
Power outage orinstable voltage.
Abnormal sound or smell from the unit.
AC power cord isdamaged.
Digital Signage is damaged due todrop, knock or impact.
Any liquid or foreign matters fall into the enclosure.
Turn off the Digital Signage immediately,pullout the plug from the power outlet, and ask the
authorized personnel for immediate maintenance.
If coal gas or other flammable gas leaks, do not pull out the plug of the LCD Digital Signage or other
electrical appliances; instead, turn off the gas valve immediately, and open the doors and windows quickly.

4
Do not use power supply other than AC110V, 60Hz.
Cut off the power supply before connecting ordisconnecting any cables.
Do notplacethe Digital Signage on/in an unstable position, orelse it may be damaged orcause
fire.
Do not place the Digital Signage inthepositions such as:
1. The environment subject todirect strong sunlight, moisture, extreme temperature or too much
dust;
2. The environment with flammable orexplosive materials;
3. The environment with flammable orcorrosive gases;
Do not use damaged orinappropriate power outlets, and ensure that the plugs and outlets contact
properly.
Do not let dust ormetal deposits adhere to theplugs and outlets.
Do not damage thepower cords:
1. Do not modify thepower cords;
2. Do not place heavy objects on the power cords;
3. Keep thepower cords away from heat source;
4. Do not pull the cord to remove theplug.
Do not connect toomany plugs to one outlet in parallel, orelse it may cause fire due toexcessive
power consumption.
Do notapproach the Digital Signage with open flame (e.g. a lighted candle), orelse it may cause
electric shock orfire.
Do not put any sharp objects, metal orliquid into the vents or let them touch the signal terminals
to avoid short circuit, product damage, and electric shock.
Do not touch the plugs with wet fingers, or else it will cause electric shock.
Do not use the Digital Signage in stormy weather, especially when there is lightning; instead, please
disconnect the power and antenna plugs to avoid lightning strike.
Do not disassemble the Digital Signage without permission, or else it may cause electric shock or fire.
Please ask qualified technician for repair.
WARNING

5
This charging station is for indoor use only ina dry area. Do not position inany location near water.
Positioning this product outside, orinside ina location near water may cause damage to property
or injury to persons. Please read and abide bythe 'Safety Warning'carefully.
Ensure the charging station isassembled and installed inaway that prevents a person tripping
over the power cable orthe unit falling from its location.
Please ensure the packing materials are disposed ofcompletely to prevent injury to children.
Do not install inanarea with high temperature, high humidity, or areas where thecharging station
may come into contact with water.
Do not install near air conditioners, orinareas with excessive dust, smoke, or vibration. The charging
station should beinstalled on a horizontal, flat surface to ensure it does notfall.
Do not modify oralter theproduct inany way.
Do not use theproduct, orany parts, ifthey are damaged.
All cables and adapters should beconnected and disconnected slowly and carefully. Ensure
suitable packaging for transport ofthe product based onits 'Specifications'.
Do not lean on the charging station.
Keep thesmall parts away from children to prevent them from swallowing.
If the charging station won’t beused for a long time, please turn it off and pull out the power plug.
To adjust theposition ofthe charging station,please disconnect all power cords and move slowly to
prevent unit from tipping over.
Do not scratch orknock theLCD with hard object, ortwist and squeeze the LCD.
Do not turn onthe unit immediately when itismoved from a place with low temperature to high
temperature, orelse itwill cause condensation and malfunction.
Before cleaning the charging station, please pull out the power plug; wipe with soft cloth; donot
use industrial chemicals; prevent foreign matters from entering the machine. Improper cleaning
(such as cleaning solution, water) may damage theproduct, erase theprinted information, and even
cause damage ofthe components iffluid flows in, resulting inmachine failure.
The power of the charging station can becutoff bypulling out the plug.
If the LCD screen ruptures and the liquid splashes onthe skin, please rinse for 15minutes with clean
water immediately, and consult your doctor.
Use the charging station properly: Use inproper lighting conditions; insufficient lighting or extended
viewing may impair your eyesight.
When the plug orcoupler isused asdisconnection device, itshould beeasy tooperate the device.
Insert theplug into theoutlet properly, orelse it may cause sparks and fire.
The technical specifications printed herein and onthe packaging are subject tochange without prior
notice. The manual may beslightly different from actual operation.
CAUTION: Disconnect the power plug before assembling or disassembling the unit!
CAUTION

6
Assembly and Connection
Packing List
Accessory
Qty
Digital Charging Station 1
AC Power Cord 1
AC Power Cord Extension 1
Remote Control
for LCD Screen 1
Antenna 1
Expansion Anchor
(Concrete Floor ONLY) 2
User Manual 1

7
Installation Instructions
Step 1: Drill holes for expansion bolts.
Step 2: Remove front panel, insert expansion bolts.
Step 3: Tighten the nuts on expansion blots with adjustable wrench (Detail C).
Step 4: Attach antenna on the top of the unit.
Step 5: AC power can be connected in two ways:
5.1. On the side of the unit: please switch to I (Detail A).
5.2. Underneath the unit: please switch to II (Detail B).
Step 6: Replace the front panel with all the screws.

8
Charging Cable Replacement
WARNING: Disconnect the power supply before servicing.
1. Remove 10x screws from the front.
2. Take off thefront panel.
3. Identify the cable to bereplaced and unscrew the holding plate from the
bottom.
4. Remove 2xscrews on both sides of the cable clip.
5. Remove the old cable and install a new cable.
6. Secure the new cable with holding plate and hardware.

9
Install Graphics
1. Remove 10 screws from the front panel.
2. Take the front panel off.
3. Remove protective film attached to the front panel.
4. Place graphic behind the front panel.
5. Replace 10 screws to re-attach the front panel.
6. Replace steps 1-4 for the back panel.

10
Remote Control of the LCD Screen
Installing batteries for the remote control:
Remove the battery cover and insert two AAA batteries (not included). Ensure that the battery polarity
matches the “+”/“-” marks in the battery compartment of the remote control.
Precautions for using the remote control:
•Aim the remote control at the receiver window. Do not place any object between the remote control and
the receiver window to avoid interference with the normal operation.
•Keep the remote control away from violent vibration. To prevent heat damage, do not set or place the
remote control in direct sunlight.
•The remote control may be invalid when the receiver window of the unit is in direct sunlight or strong lighting.
Inthis case, please adjust the angle of the lighting or the unit or approach the receiver window to use it.
•The range of the remote control will be diminished if the battery voltage is insufficient; in this case,
please replace with new batteries; if the remote control won’t be used for a long time or the batteries are
depleted, please take out the batteries to avoid corrosion due to battery leakage, which will damage the
remote control.
•Do not use batteries of different types or mix new batteries with old ones. Always replace the batteries
in pairs.
•Do not charge or disassemble,short circuit, heat or burn used batteries. Please dispose of depleted
batteries in accordance with local environmental regulations. Do not expose the batteries in overheated
environments such as sunlight and fire.
Description of remote control buttons:
Sleep Mode
Mouse Mode
Directional Pad
(Up/Down/Left/Right)
Volume Control
Battery
Compartment
Go Back
Home
Select
Menu

11
Description of Basic Operation
Power on/Standby
Insert the power plug into the outlet. In power on state, press the “” button on the remote control, and the
Digital Signage enters sleep mode.
Connect to Wi-Fi
It’s recommended to use directional pad button on remote control to navigate on screen contents.
1. Plug unit into electrical outlet.
2. Turn power button at the bottom side of unit to ON.
3. Once the Home screen pops up, select app drawer icon at the bottom (circle with six dots).
4. Select Settings.

12
5. Select Network & Internet.
6. Select Wi-Fi.
7. Select “Add Network” and enter your Wi-Fi network and password.

13
Upload Content:
NOTE: Use remote control for file transferring between USB device and internal storage.
1. Insert your USB flash drive (not included) containing files into USB port under the digital screen.
2. Select app drawer icon. (circle with six dots logo), then select “Settings”.
3.Select “Storage” then select your flash drive attached to the USB port.
4. Select file to upload.: Click icon in lower left corner of file to turn it into a blue checkmark.
5. Select “Copy to” from the “More Options” drop-down menu in the upper right corner.

14
7. Choose the desired destination tostore your files and select “Copy” in the lower right corner.
8. Push “Home” button (circle with a house logo) onthe remote control and select app drawer icon.
Select “VLC Player”.
9. Select video and then select “Play” button (circle with a triangle pointing right) in bottom right corner
of screen.
10. Push “Options” button (circle with three stacked lines) on remote control. Select “Loop” (double
arrow icon) on the screen for continuous play.

15
Changing Wallpaper
We suggest using a mouse to change the wallpaper.
Connect a mouse with the digital panel through USB port, then follow the steps below:
1. Click “Setting”.
2. At the setting menu, click “Display”.
3. At the Display setting menu, click “Wallpaper”,then choose a
folder.
4. Then select animage you would like to set up as background.
5. Confirm the selection by clicking “Set wallpaper”.
File Manager
1. Click the Main Apps button “ ” in the Home screen to enter the “APPS” menu interface (Fig. 1);
2. Click the “Explorer” icon in the “APPS” menu interface (Fig. 2) and enter “Explorer” menu (Fig. 3);
3. Choose storage in the “Explorer” menu to read the files from different devices.

16
Local Settings
1. Click the App Drawer icon “ ” in the Home page to enter the “APPS” menu interface (Fig. 1);
2. Click the “Settings” icon (Fig. 1) and enter “Settings” menu (Fig. 2);
3. Click “Wi-Fi” and choose options then set up the WIFI connection (Fig. 3).
Description of Settings Interface (shown on the right)
Icon Function
WIFI switch
Bluetooth
Data usage
Display
Notifications
Sound
Apps
Screenshot Setting
Storage
Battery
Memory
Users
Location
Security
Accounts
Google
Languages & input
Backup & reset

17
Status of Menu Bar
1. Click the setting (Fig. 1);
2. At the setting menu click the display menu (Fig. 2);
3. At the display setting menu unselect the display navigation check box (Fig. 3);
Factory Reset:
1. Get into Settings, then click “Backup &reset” (Fig. 1);
2. Click “Factory data reset” (Fig. 2);
3. Choose “Erase Tablet”,then click “ERASE EVERYTHING” to get the unit to Factory Reset (Fig. 3).

18
Choose System Language:
1. Get into Settings, then click “Language & input” (Fig. 1);
2. Click “Languages”,then click “Add a language” (Fig. 2);
3. You can add the required system language (Fig. 3);
4. Drag the system language you just added upto thefront (Fig. 4)-Please use a mouse tooperate.

19
Technical Specifications
ITEM SPECIFICATION
Panel
LCD Size 21.5”
Panel A-SITFT-LCD
Light Source LED
Resolution 1920(H)× 1080(V)
Brightness (typ.)/(min) 250 nits (typ.)
Contrast (typ.) 3000:1 (typ.)
Response Time 8ms (typ.)
Pixel Pitch 248.25 ㎛(H)X248.25 ㎛(V)
Refresh Rate 60Hz
Viewing Angle 89° /89°
Display Area 486.64mm x 268.11mm
Display Color 16.7M
Color Temperature 6517K
Aspect Ratio 16:9
Touch N/A
Power
Input 100V~240V, 50-60Hz, 10A
Power Consumption 1000W
Output DC: 10X 5V/2.1A
AC: 2X 100~240V / 3A
Environment
Operating Temperature 32~104 °F (0~40 °C)
Storage Temperature 14~104 °F (-10~40 °C)
Functions
Operating System Android 10
RAM 1G
Internal Storage 8G
Compatible Network Wi-Fi, Bluetooth
Supported Video Files MP4
Supported Photo Files JPEG

20
Functions
Supported Audio files MP3
Player MX Player / VLC Player
Speaker 2X 5W
Remove Control Input/Output IR/2.4G
App Installation Support download and installation
I/O interfaces
Ethernet (RJ45) N/A
HDMI N/A
VGA N/A
Speaker 2
USB 1
SIM N/A
