DITTING 1203 Series User manual

www.dittingswiss.ch
1203 / 1403
ORIGINAL INSTRUCTIONS
KFA 1403 Industrial
KFA 1203 / 1403
KR 1203 / 1403

1203 / 1403 | ENSHOP GRINDER
2
Overview
KFA 1403 Industrial
9
KFA 1203 / 1403
9
10
KR 1203 / 1403
1
4
5
3
6
82
7
A

3
1203 / 1403 | ENSHOP GRINDER
2
KR 1203 / 1403
12
14
11
13
KFA 1203 / 1403 | KFA 1403 Industrial
15 12
13
14
11
B
KR 1203 / 1403 KFA 1403 Industrial
KFA 1203 / 1403
2
C

1203 / 1403 | ENSHOP GRINDER
4
KR 1203 / 1403
8
7
16
3
D
E
KFA 1203 / 1403
KFA 1403 Industrial
9
16

5
1203 / 1403 | ENSHOP GRINDER
4
Scope of delivery
No. Designation
1Bean hopper (with lid)*
2Grind adjustment system
3Start/stop switch
4Cover
5Drip tray
6Bag shaking unit
7Spout
8Knocker
9Clamping lever (incl. function as a start/stop lever)
10 Sliding valve**
11 Ventilation slots
12 Power cable with power plug
13 Type plate
14 Release button (thermal overcurrent circuit-breaker)***
15 On/Off switch
16 Bag clamp
* The bean hopper of model KFA 1403 Industrial has no lid.
** The sliding valve is an optional component for the models KFA 1203, KFA 1403 and KFA 1403 Industrial.
The sliding valve enables the bean hopper to be closed off to the grinding mechanism, so that no beans
enter the grinding mechanism from the bean hopper.
*** The release button (thermal overcurrent circuit-breaker) can be found on the underside of the grinder.

7
1203 / 1403 | ENSHOP GRINDER
6
1203 / 1403 | ENSHOP GRINDER
6
Shop grinder
Contents
Overview ................................ 2
Scope of delivery .................... 5
General Informaon ............... 7
Reading and retaining
the original instrucons.....................7
Explanaon of symbols used .............7
Safety...................................... 8
Intended use ......................................8
Safety informaon .............................9
Operang principle /
Dierences between models .. 11
Before pung into service ... 11
Check the grinder
and scope of delivery.......................11
Seng up the grinder
and making it ready for operaon...12
Operaon ............................. 12
Seng the grinding degree .............12
Filling with coee beans ..................12
Preparing the receptacle for the
ground material and starng the
grinding process...............................13
KR 1203 / 1403...............................13
KFA 1203 / 1403 and KFA 1403 In-
dustrial ..........................................13
Changing the coee variety.............14
Cleaning................................ 14
Cleaning the
grinder installaon surface..............15
Cleaning the casing..........................15
Cleaning the bean hopper ...............15
Cleaning the grinding mechanism...16
Troubleshoong ................... 17
Technical data....................... 19
Disposal ................................ 21
Disposing of the packaging..............21
Disposing of the grinder ..................21
Maintenance and service ..... 21

7
1203 / 1403 | ENSHOP GRINDER
6
1203 / 1403 | ENSHOP GRINDER
6
General Informaon
Reading and retaining the original instrucons
Carefully read these original instructions and the safety information
before you put the described shop grinder of the 1203 or 1403
model series into service. This is the only way that you can operate
the shop grinder safely and use it without any risk.
These original instructions are based on the standards and regulations in force
in the European Union. Please also note the guidelines and laws of your specific
country if abroad.
For reasons of clarity, the shop grinder will be referred to only as "grinder" in
the following.
Keep these original instructions for future reference. Also pass these original
instructions on to subsequent owners and users of the grinder.
Explanaon of symbols used
The following symbols and signal words are in these original instructions, on
the grinder and on the packaging.
WARNING!
This signal word/symbol indicates a hazard with a medium degree
of risk which can lead to death or serious injury if not avoided.
CAUTION!
This signal word/symbol indicates a hazard with a low degree of
risk which can lead to minor or moderate injury if not avoided.
NOTE!
This signal word warns of possible material damage.
This symbol indicates important information concerning operation
or handling.

9
1203 / 1403 | ENSHOP GRINDER
8
Declaration of Conformity:
Products marked with this symbol fulfil all applicable community
provisions of the European Economic Area.
ETL Listed seal of approval:
Products marked with this symbol meet the requirements of
electrical product safety in the United States of America.
Products marked with this symbol meet the criteria required by
the NSF (National Sanitation Foundation) regarding cleanliness and
hygiene in the food industry.
Products marked with this symbol are only permitted for use
indoors.
This symbol indicates an electrical shock hazard.
This symbol indicates that the grinder conforms to protection class I.
Safety
Intended use
The grinder is only suitable for grinding whole roasted coffee beans. Do not
use the grinder for grinding other products or objects. It is intended for com-
mercial use and may only be serviced by trained personnel. However, it may be
operated by other persons in a place where its use is supervised.
Any other use is not considered to comply with the intended use and can
result in material damage or even personal injury. Do not make any changes to
the grinder. The manufacturer or supplier cannot be held liable for any injury
or damage resulting from the failure to comply with the safety instructions.

9
1203 / 1403 | ENSHOP GRINDER
8
Safety informaon
WARNING!
Danger of electric shock!
Improper use, incorrect electrical installaon or an excessively high
voltage can all lead to electric shock.
– Connect the grinder only if the mains voltage of the socket com-
plies with the informaon indicated on the type plate.
– Connect the grinder only to a socket with good accessibility, so
that you can disconnect it quickly from the power supply in the
event of a fault.
– Do not use the grinder if you noce any visible damage or if the
power cable or plug is faulty.
– If the grinder power cable is damaged, it must be replaced by the
manufacturer or by qualied personnel, in order to avoid hazards.
– Do not operate the grinder without an earth connecon.
– Only connect the grinder to a power supply with a 16 A slow fuse.
Have a 16 A slow fuse installed by a qualied electrician if the
power connecon at the place of installaon of the grinder is not
provided with such protecon.
– Only install the grinder at places where the handling of the
grinder can be supervised by trained personnel.
– Do not immerse the grinder or the power cable or power plug in
water or any other liquids.
– Do not clean the grinder with a water jet.
– Never touch the power plug with wet hands.
– Never unplug the power plug from the wall socket by pulling on
the power cable; always grip the plug itself.
– Never use the power cable as a handle to carry the grinder.
– Keep the grinder and power cable/power plug away from open
ames and hot surfaces.
– Posion the power cable in such a way that it does not become a
trip hazard.
– Do not bend the power cable and do not place it over sharp
edges.

11
1203 / 1403 | ENSHOP GRINDER
10
– Use the grinder in indoor areas only. Never operate the grinder in
damp rooms or in the rain.
– Keep children away from the grinder.
– Ensure that children do not insert any objects into the grinder.
– If you are not currently using the grinder, if you are cleaning it
or if a fault occurs, switch the grinder o and remove the power
plug from the socket.
– Do not open the grinder casing; leave repairs to the experts. If
repairs are required, please contact a specialist workshop. In the
event of unauthorised repairs, faulty connecon or incorrect oper-
aon, all liability and guarantee claims are excluded. Only parts
that comply with the original appliance specicaons may be used
for repairs. This grinder contains electrical and mechanical parts
that are essenal for protecon against potenal hazards.
WARNING!
Danger for children and persons with reduced physical, sensory or
mental capabilies (e.g. parally disabled persons, older persons with
limited physical and mental capabilies) or a lack of experience and
knowledge (e.g. older children).
– This grinder may be used by children older than eight years and
by persons with reduced physical, sensory or mental capabilies
or a lack of experience and knowledge if they are supervised
or have been instructed in the safe use of the grinder and have
understood the possible resulng dangers. Children may not play
with the grinder. Cleaning and user maintenance may not be car-
ried out by children without supervision.
– Do not leave the grinder unsupervised when in operaon.
– Do not let children play with the packaging lm.
Children can become entangled in it while playing and may suocate.
– Do not let children play with the small parts. These can be
life-threatening if swallowed.

11
1203 / 1403 | ENSHOP GRINDER
10
CAUTION!
Risk of pping and injury!
Incorrect handling of the grinder can result in injury.
– Posion the power cable so that nobody can become entangled
in it and cause the grinder to fall.
– Place the grinder on a level and stable surface to prevent it from
falling o.
Operang principle / Dierences between models
All the grinder models described in these original instructions are shop grinders
(see chapter on “Intended use").
The 1203 and 1403 model series differ in their grinding capacity and their type
of power supply (see chapter on "Technical data").
Bag clamping and grinding are carried out separately and started manually in
models with the prefix KR. These models are equipped with a bag shaking unit.
The bag is clamped and grinding started automatically in one process in models
with the prefix KFA. These models are not equipped with a bag shaking unit.
Before pung into service
Check the grinder and scope of delivery
NOTE!
Risk of damage!
Take care when opening the packaging with a sharp knife or other
pointed objects, otherwise the grinder may be damaged.
– Be very careful when opening the packaging.
1. Remove the grinder from the packaging.
2. Check that the delivery is complete (see Fig. A).
3. Check for damage to the grinder or the individual parts. If this is the case,
do not use the grinder. Contact your supplier (see chapter on “Maintenance
and service”).
Please note that the grinder is subjected to an extensive function
test before delivery and may still contain residues of coffee powder.

13
1203 / 1403 | ENSHOP GRINDER
12
Seng up the grinder and making it ready for operaon
1. Place the grinder on a level, stable and vibration-free surface.
2. Insert the power plug (12) in a properly installed socket.
The models KR 1203 / 1403 are ready for operation when connect-
ed to the power supply.
3. KFA 1203 / 1403 | KFA 1403 Industrial:
Tilt the on/off switch (15) to the Iposition to switch on the grinder and
make it ready for operation.
Operaon
The grinder has a thermal overcurrent circuit-breaker (see base of
the grinder) which interrupts the circuit of the grinder in the event
of an electrical overload.
To restart the grinder, first switch it off (on/off switch (15) in the
0position)* and remove the power plug from the socket. Then
press in the release button (14). You can now make the grinder
ready for operation again (see chapter on "Setting up the grinder
and making it ready for operation").
Seng the grinding degree
• The grinding degree scale of the grind adjustment system (2)
shows the desired grinding degree. The finest setting is “1”.
• Reduce the grinding degree only when the grinder is in operation.
1. Ensure that the grinder is ready for operation (see chapter on “Setting up
the grinder and making it ready for operation”).
2. Turn the grind adjustment system (2) in the direction of “1” for fine coffee
grinding and in the opposite direction for coarse coffee grinding (see Fig. C).
Filling with coee beans
1. Open the lid of the bean hopper (1).
2. Fill the bean hopper with whole roasted coffee beans from above.
The maximum filling quantity should be approx. 1 cm below the edge of
the bean hopper.
3. Close the lid of the bean hopper.
* Only the models KFA 1203 / 1403 and KFA 1403 Industrial have an on/off switch. You only need to dis-
connect the grinder from the power supply in the models KR 1203 / 1403.

13
1203 / 1403 | ENSHOP GRINDER
12
Preparing the receptacle for the ground material and
starng the grinding process
Prepare the receptacle to collect the ground material and, with the grinder
ready for operation, start grinding as described for your model.
KR 1203 / 1403
1. Hold the knocker (8) in the upper position (see Fig. D).
2. Put the coffee bag over the spout, so that the rear edge of the bag is located
in the bag clamp (16) between the bag shaking unit (6) and the spout (7).
3. Release the knocker.
The coffee bag is clamped between the knocker and the bag shaking unit.
4. Start the grinding process by pressing and holding down the start/stop
switch (3) (see Fig. A).
The grinding process has been completed as soon as the grinder is idling and
no grinding noises are audible.
5. After the grinding process has been completed, actuate the knocker (8)
several times in succession by lifting and releasing it.
Any adhering grind residues are removed from the grinding mechanism.
6. Stop the grinding process by releasing the start/stop switch (3).
The grinder stops grinding and the bag clamp (16) releases the coffee bag.
KFA 1203 / 1403 and KFA 1403 Industrial
1. If required, ensure that the grinder is ready for operation (on/off switch (15)
in the Iposition) (see chapter on “Setting up the grinder and making it ready
for operation”)
2. Put the coffee bag over the spout, so that the rear edge of the bag is locat-
ed in the bag clamp (16) behind the spout (7) (see Fig. E).
3. Push the clamping lever (9) all the way to the left.
The coffee bag is clamped in the bag clamp and the grinding process starts
automatically at the same time.
The grinding process has been completed as soon as the grinder is idling and
no grinding noises are audible.
4. Hold the clamped coffee bag with one hand and push the clamping lever (9)
all the way to the right.
The grinder stops grinding and the bag clamp (16) releases the coffee bag.
5. If required, switch off the grinder by tilting the on/off switch (15) to the
0 position.

1203 / 1403 | ENSHOP GRINDER
14
In the case of continuous use, the grinder can remain on standby
between individual grinding processes (on/off switch (15) in the
Iposition).
Changing the coee variety
1. If applicable, close off the bean hopper (1) to the grinding mechanism by
pushing the sliding valve* (10) all the way in.
2. Remove the remaining coffee beans from the bean hopper.
3. Grind any coffee beans left in the grinding mechanism until the grinder
runs empty.
4. Fill the bean hopper with the new coffee beans.
5. If applicable, open the bean hopper again by pulling out the sliding valve.
Cleaning
CAUTION!
Risk of injury!
The grinder can fall over and cause injury when moved.
– Always place the grinder on a stable and lt-proof surface.
– If necessary, ask another person for help if the grinder is too heavy.
NOTE!
Short-circuit hazard!
The ingress of water into the grinder can cause a short circuit.
– Never immerse the grinder in water or any other liquids.
– Never clean the grinder with a water jet.
– Ensure that no water or other liquids make their way into the casing.
NOTE!
Risk of damage!
Inappropriate handling can cause damage to the grinder.
– Do not use any harsh cleaning products or sharp or metallic
cleaning objects such as knives, metal scouring pads or similar.
These can scratch the surface.
* The sliding valve is an optional component for the models KFA 1203, KFA 1403 and KFA 1403 Industrial.

15
1203 / 1403 | ENSHOP GRINDER
14
– Do not clean the grinder with compressed air (e.g. with a com-
pressed air gun).
– Do not put the drip tray in the dishwasher.
– Do not li the grinder by the bean hopper; li only by the casing
and always with both hands.
Cleaning the grinder installaon surface
1. Switch off the grinder (on/off switch (15) in the 0position)* and remove
the power plug (12) from the socket.
2. Lift the grinder by the casing using both hands and place it on a clean surface.
3. Clean the installation surface and the underside of the grinder with a
damp cloth and dry the surfaces.
The surfaces must be dry and free of oil and grease.
4. Place the grinder back on the cleaned surface.
Cleaning the casing
1. Switch off the grinder (on/off switch (15) in the 0position)* and remove
the power plug (12) from the socket.
2. Carefully clean the spout (7) with a brush.
3. Use a damp cloth to wipe down the casing and the drip tray (5) as re-
quired, but at least once a week.
Cleaning the bean hopper
The bean hopper (1) must be cleaned every day to remove any
coffee oil residues, as these can have a detrimental effect on the
taste. In this respect, the manufacturer recommends the use of
bean hopper cleaner. You will find more information on the cleaner
at www.dittingswiss.ch.
1. Grind the remaining coffee beans from the bean hopper.
2. Sprinkle the inside and outside of the bean hopper with a few squirts of
bean hopper cleaner.
3. Use a cloth to clean the inside and outside of the bean hopper and allow
to dry.
* Only the models KFA 1203 / 1403 and KFA 1403 Industrial have an on/off switch. You only need to dis-
connect the grinder from the power supply in the models KR 1203 / 1403.

1203 / 1403 | ENSHOP GRINDER
16
Cleaning the grinding mechanism
• The manufacturer recommends the use of GRINDZTM grinder
cleaner. You will find more information on GRINDZTM at
www.dittingswiss.ch.
• The grinding mechanism should be cleaned every 2-5 days.
1. Grind any coffee beans left in the grinding mechanism until the grinder
runs empty and there are no more coffee beans in the bean hopper (1).
2. Use the grind adjustment system (2) to set the coarsest possible grinding
degree (see chapter on "Setting the grinding degree").
3. Fill the bean hopper with grinder cleaner.
Note the quantities specified by the manufacturer for the grinder cleaner
you are using.
4. Place a collecting container under the spout (7) to collect the grinder cleaner.
5. Start the grinding of the grinder cleaner as described for your model.
KR 1203 / 1403:Press and hold down the start/stop switch (3) to start the
grinding of the grinder cleaner.
KFA 1203 / 1403 & KFA 1403 Industrial: If required, switch on the grinder
(on/off switch (15) in the Iposition) and push the clamping lever (9) all the
way to the left to start the grinding of the grinder cleaner.
The grinding of the grinder cleaner has been completed as soon as the grinder
is idling.
6. Stop the grinding and switch off the grinder as described for your model
once the grinder cleaner has been ground completely.
KR 1203 / 1403: Stop the grinding by releasing the start/stop switch (3) and
then remove the power plug (12) from the socket.
KFA 1203 / 1403 & KFA 1403 Industrial: Push the clamping lever (9) all the
way to the right. Next, switch off the grinder (on/off switch (15) in the 0
position) and remove the power plug from the socket.
7. Wipe out the bean hopper with a dry, lint-free cloth.
8. Reconnect the power plug and switch on the grinder (on/off switch (15) in
the Iposition) to make the grinder ready for operation again (see chapter
on “Setting up the grinder and making it ready for operation”).
9. Grind approximately the same amount of coffee beans as you did grinder
cleaner, in order to remove leftover cleaning particles. Reset the grinding
degree to the desired setting during the grinding process.
10. Dispose of the ground grinder cleaner and the ground coffee beans in the
commercial/domestic waste.

17
1203 / 1403 | ENSHOP GRINDER
16
Troubleshoong
Fault Cause Remedy
The grinder is
making noise but
not grinding.
• The spout is clogged. tSet the grinding degree to the
"coarsest grind" and start the
grinding process.
The grinder will clear itself.
Then set the grinding degree
to the desired setting during
operation.
tActuate the knocker of the
grinder several times to clear
the blockage.
• The grinding degree
is too fine.
tSet the grinding degree to the
"coarsest grind" and start the
grinding process. The grinder
will clear itself.
Then set the grinding degree
to the desired setting during
operation.
Contact your supplier if the
problem persists
�see chapter on “Mainte-
nance and service”).
• A foreign object has
got into the grinding
mechanism.
tContact your supplier
(see chapter on “Mainte-
nance and service”).

1203 / 1403 | ENSHOP GRINDER
18
Fault Cause Remedy
The grinder is
not grinding and
making noise.
• The power plug is not
plugged into a socket.
tInsert the power plug into a
properly installed socket.
• The grinder is not
switched on/
ready for operation.
tSwitch on the grinder by tilt-
ing the on/off switch to the I
position (only applies to the
models KFA 1203 / 1403 and
KFA 1403 Industrial)
• The thermal overcur-
rent circuit-breaker
was triggered.
tCheck whether the release
button of the overcurrent cir-
cuit-breaker has popped out.
Push it back in if necessary.
Contact your supplier if the
overcurrent circuit breaker
pops out repeatedly (see
chapter on “Maintenance and
service”).
• The electrical fuse
has tripped.
tCheck the electrical fuse. If
required, restore the fuse to
its original state or replace it.
Check whether other loads are
connected to this fuse and if
so, pull out their plugs. Con-
tact your supplier if the fuse
repeatedly trips (see chapter on
“Maintenance and service”).
The grinder is
not grinding fine
enough.
• The grinding discs
are worn out.
tContact your supplier (see
chapter on “Maintenance and
service”).
• The grinding discs
are not correctly
aligned.
tContact your supplier (see
chapter on “Maintenance and
service”).

19
1203 / 1403 | ENSHOP GRINDER
18
Technical data
Models: KR 1203 | KFA 1203
Voltage / frequency: 120 V, 60 Hz 220 V, 60 Hz 220–240 V, 50 Hz
Nominal value: 1600 W
Protection type: IPX1
Protection class: I
Fuse: 16 A slow
Idle speed: 1400 rpm
Sound emission value
Idle: 55 dB
Grinding: 78 dB
Grinding capacity: 1400 g/min*
Dimensions (W × D × H): 260 × 340 × 640 mm
Weight (net): 38.0 kg
max. funnel filling quantity: 1.1 kg
Models: KR 1403 | KFA 1403
Voltage / frequency: 220/380 V, 60 Hz 230/400 V, 50 Hz
Nominal value: 2000 W
Protection type: IPX1
Protection class: I
Fuse: 16 A slow
Idle speed: 1400 rpm
Sound emission value
Idle: 55 dB
Grinding: 78 dB
Grinding capacity: 2200 g/min*
Dimensions (W × D × H): 260 × 340 × 640 mm
Weight (net): 38 kg
max. funnel filling quantity: 1.1 kg
* The grinding capacity depends on the coffee beans and the selected grinding degree.

1203 / 1403 | ENSHOP GRINDER
20
Model: KFA 1403 Industrial
Voltage / frequency: 220/380 V, 60 Hz 230/400 V, 50 Hz
Nominal value: 2000 W
Protection type: IPX1
Protection class: I
Fuse: 16 A slow
Idle speed: 1400 rpm
Sound emission value
Idle: 55 dB
Grinding: 78 dB
Grinding capacity: 2200 g/min*
Dimensions (W × D × H): 302 × 360 × 920 mm
Weight (net): 47 kg
max. funnel filling quantity: 10 kg
* The grinding capacity depends on the coffee beans and the selected grinding degree.
