dj power V-1 User manual

V-1
USER’S MANUAL

V-1 SPARK MACHINE Art.No.: 118428
2 / 16
Table of content
1. Safety instructions............................................................................................... 3
1.1. For safe and efficient operation................................................................... 3
2. Intended use of the device.............................................................................. 4
2.1. Overhead installation..................................................................................... 5
2.2. Connections .................................................................................................... 6
2.2.1. Electrical connections............................................................................. 6
2.2.2. DMX connections..................................................................................... 7
2.3. DMX connection with terminator................................................................. 7
3. Introduction......................................................................................................... 8
3.1. Product description ........................................................................................ 8
4. Before using......................................................................................................... 9
5. Control buttons................................................................................................... 9
6. User Interface.................................................................................................... 10
6.1. Status interface ............................................................................................. 10
6.2. Menu............................................................................................................... 11
6.3. DMX Interface ............................................................................................... 11
7. Error..................................................................................................................... 12
8. Operation .......................................................................................................... 13
8.1. Manual Operation........................................................................................ 13
8.2. Operation via DMX....................................................................................... 13
9. Settings............................................................................................................... 14
9.1. DMX address.................................................................................................. 14
9.2. Fan speed setting ......................................................................................... 14
9.3. Manual operation......................................................................................... 14
10. RFID card ........................................................................................................... 14
10.1. How to use the card ................................................................................. 14
10.2. How to check the remaining time.......................................................... 14
11. Technical dato ................................................................................................. 15

V-1 SPARK MACHINE Art.No.: 118428
3 / 16
1. Safety instructions
This device is suitable for indoor use (not outdoors) only.
Unauthorized modifications will invalidate the warranty.
Repairs are to carry out by skilled workers only.
Use only fuses of the same type and original parts as spare parts.
To avoid fire and electric shocks protect the unit from rain and humidity.
1.1.For safe and efficient operation
Be careful with heat and extreme temperatures!
Do not place the device in a location where it is exposed to extreme
temperatures.
Operate the device only in an ambient temperature between 0°C (32°F) -
40°C (104°F). Do not expose the device to direct sunlight or heat sources.
Keep away from humidity, water and dust!
Avoid placing the device in a location with high humidity or excessive
dust. Place no liquids on or near the system.
Place the device on a firm ground!
To avoid vibrations always place the device on a firm ground.
Do not use chemicals for cleaning!
Use a clean and dry cleaning rag to remove dust. Metal parts can be
cleaned with a damped cleaning rag. Before cleaning always unplug the
device from the power supply.
If the device is not working properly!
If problems occur unplug the device from the power supply. The user should
not try to service the device independently. All repairs and service must be
performed by a qualified technician.
Take proper care with the power cord!
Never pull the power cord to disconnect the device from the power
supply, but remove the plug with plug housing in the hand. If you do not
use the device for an extended period, unplug the device from the power
supply.
ATTENTION!
Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any consequent secondary
failures. Only skilled workers are allowed to carry out the electrical
connections. All electrical and mechanical connections have to be carried
out according to the European safety standards.

V-1 SPARK MACHINE Art.No.: 118428
4 / 16
2. Intended use of the device
This device was developed for professional use on stages, in discos, theatres
etc. The device is only approved for a connection up to 230 V 50/60 Hz
alternating current and only for indoor use.
Regular breaks during operation increase the lifetime of your device.
Avoid convulsions or any form of forceful impact during the installation or the
startup of the device.
Take care that no cables are lying around. You would endanger your own
safety and also the safety of a third party.
It is not allowed to operate or store the device in an environment in which
spray water or rain is expected. Humidity or very high atmospheric humidity
could reduce the isolation of the device and could cause deathly electric
shocks.
If using fog machine you have to ensure that the fog saturation of the room
must allow a good visibility of at least 10m.
Operate the device not during thunderstorms. Surge voltages could destroy
the device. Unplug the power supply during thunderstorms.
Surrounding objects or surfaces should not be in contact with the device.
Make sure that during the installation and removal of the device the area
below the place of installation is basically cordoned off. This also applies to
implementation of service.
Make familiar yourself with the functions of the device before start-up. People
without the experience should not handle with the device. The most cause of
functional disorder is inappropriate handling.
Keep the device away from children and never operate it unattended.
Never aim the nozzle on people a keep a distance from 50 cm to the nozzle.
ATTENTION. The ejected fog is very hot!
Keep a minimum distance of 50 cm to other objects.
Use only the recommended, high quality granule from your dealer. Other
fluids may cause damages.
Never aim the nozzle on open fire or flammable objects.
Operate the unit only in a horizontal position.
Never use solvents or aggressive detergents for cleaning. Use instead of this a
damped cleaning rag.
To prevent damages during transport use for transport the original packing or
provided accessories.
For reasons of safety unauthorized changes are forbidden!

V-1 SPARK MACHINE Art.No.: 118428
5 / 16
A usage of the device which differs from usages which are described in this
manual can cause damages of the device. In this case the warranty expires.
Additional you should notice that every different usage is related with
dangers and can cause e.g. an electrical short, fire, electric shock or crash.
2.1. Overhead installation
Danger of life!
You have to observe the regulations of BGV C1 (formerly VBG
70) and EN60598-2-17 Installations are to carry out by skilled
personnel only.
The suspension devices have to be build and measured so they can
withstand for an hour the tenfold of the payload without suffering a
permanent detrimental deformation.
Basically installation has to be made by using a second separate suspension.
This can be e.g. a suitable net. The second suspension must be designed and
attached so no part of the installation can fall down in case of failure.
During construction, reconstruction and deconstruction unnecessary stay in
the range of moving areas, on lightning bridges, under elevated work stations
or any other danger zones is forbidden.
The operator is obliged to following safety-related and mechanical facilities:
Before the first start-up or after critical changes before restarting it has
to be checked by an expert.
Review in the frame of the inspection test at least all four years by an
expert. .
Review by a qualified person at least once a year.
How to carry out the overhead installation:
Ideally the device should be installed outside lounge areas of people.
IMPORTANT! Overhead installation requires a high level of experience. This
includes knowledge of calculating the payload, used installation material
and safety inspections of the used material and the projector whereas the
required experience is not limited to this. Do not try to carry out installation
yourself under any circumstances if you are not qualified. Contact a
professional installer. An inappropriate installation can lead to injuries and/or
damaged properties.
It is not allowed to install the device in the grip area of people.
If the device may hang from the ceiling or from high beams, the use of truss
systems is mandatory. The device may not be installed so it can swing freely in
the room.
Please note: Crashing down items can cause serious injuries! Do not install the
projector, if you doubt the safety of a possible installation form!

V-1 SPARK MACHINE Art.No.: 118428
6 / 16
Before installation make sure that the mounting surface has the ability to carry
the tenfold point load of the own weight of the device.
Mount the device with the mounting-bracket to your trussing system using an
appropriate clamp.
During overhead installation the device must be always secured by a safety
rope which is designed to hold the twelvefold weight of device. Only safety
ropes with quick-release safety fastener elements may be used. Hang up the
safety rope in the hole of the mounting bracket. Direct the rope over the truss
or an appropriate fastening point. Hang up the end in the fastening element
and tie up the locking nut. A safety rope once exposed to failing load or
damaged may not be used furthermore.
The maximum drop exceed must not exceed 20cm.
A safety rope once exposed to failing load or damaged may not be used
furthermore. Adjust the desired inclination angle via the mounting bracket
and tighten the screw.
2.2.Connections
2.2.1. Electrical connections
Connect the fixture to the mains with the enclosed power cable and plug.
The earth has to be connected.
Cable (EU) Cable (US) Pin International
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth

V-1 SPARK MACHINE Art.No.: 118428
7 / 16
2.2.2. DMX connections
Make sure that you use shielded cable. 3pol or 5pol XLR cables are suitable.
2.3. DMX connection with terminator
Where the DMX cable has to run a long distance or the equipment is
operated in an electrically noisy environment like a disco for installations, we
recommend using a DMX terminator. This prevents corruption of the digital
control signal by electrical noise. The DMX terminator is simply an XLR
connector with a 120 Ωresistor between pins 2 and 3, which is then plugged
into the XLR output socket of the last device in the series. Please look to the
bottom drawings.

V-1 SPARK MACHINE Art.No.: 118428
8 / 16
3. Introduction
Thank you for choosing the DJPOWER V-1.
We recommend that you carefully read these operating instructions before
commissioning the unit. Please follow the instructions in this manual. This is the
only way to ensure safe operation, proper use and long service life.
3.1.Product description
1. Nozzle
2. Feed port
3. Storage bin cover
4. Air Outlet
5. Control panel
6. XLR 3pol INPUT/OUTPUT
7. XLR 5pol INPUT/OUTPUT
8. Fuse
9. Power OUTPUT
10.Power ‚INPUT
11.On/Off switch
12.Air Inlet
13.Handle

V-1 SPARK MACHINE Art.No.: 118428
9 / 16
4. Before using
Remove before start-up every packing material.
1. After verifying that the unit is intact and complete, please place it on a
level surface.
2. Connect the device to the power supply.
3. The device starts to heat up. This process needs 4 min, meanwhile the
display shows „Heating“.
4. The heating process is finished. The display shows „Ready To Work“.
5. Now you have to fill in the granules. More information for this you can
read on the packing of the granules. You are only allowed to use the
granules of DJ Power.
5. Control buttons
Button Function
MENU Navigation through the menu.
▲Increase a value or make a setting.
▼Decrease a value or make a setting.
ENTER Back to the root menu.

V-1 SPARK MACHINE Art.No.: 118428
10 / 16
6. User Interface
6.1.Status interface
Advice Meaning
Ready To Work
》》》》》》》580
The unit finishes pre-heating. Current
temperature is 580°C.
Working
》》》》》》》580
The unit is working. Current temperature is
580°C.
Heating
》》》》》》》580
The unit is heating. Current temperature is
200°C.
Device Fault E0 The unit stops to over temperature.
Device Fault E1 The unit failed to heat.
Device Fault E2 Feeding motor is protected.
Device Fault E3 Temperature sensor failed.
Device Fault E4 Temperature sensor tripped off.
NO Time E5 The granules are run out soon.
Device Fault E6 Temperature inside the unit is too high.
Device Fault E7 Step motor is not able to reset.
Device Fault E8 The input power frequency is abnormal.

V-1 SPARK MACHINE Art.No.: 118428
11 / 16
6.2.Menu
Menu Function
Manual Heat ON/OFF (De-)Activates the manual operation.
Manual Fountain ON/OFF Start the manual operation.
Fountain Height 1-10 Setting the fountain height.
DMX Address Set 1-512 Setting the DMX address.
Surplus Time XX Min
XX Sec Check out the remaining time of using.
6.3.DMX Interface
Display Meaning
DMX Address Set
Ready 1
The unit is ready to work. Current DMX
address is 1.
DMX Address Set 1
Heating
The unit is heating. Current DMX address is 1.
DMX Address Set
Device Fault 1
The unit failed. Current DMX address is 1.
DMX Address Set
No Time 1
Materials are to run out soon. Current DMX
address is 1.
DMX Address Set
Working 1
The unit is working. Current DMX address is 1.

V-1 SPARK MACHINE Art.No.: 118428
12 / 16
7. Error
When Error Protections are activated, the unit stops working and heating system shuts off
automatically. LCD screen displays Error code.
Error Cause
E0 Over temperature The temperature is since more
than 30s more than 700°C.
E1 Heating failed The device did not reach the
working temperature after 10 min.
E2 Over current protection of the
motor
Error of the motor.
E3 Thermocouple failed Short circuit or wrong connection.
E4 Thermocouple tripped
off Open circuit or no connection.
E5 No enough time Granules run out soon.
E6 Over temperature
inside the unit
The temperature inside the unit is
higher than 60°C.
E7 Step motor problem The step motor is not able to reset.
E8 The working frequency is
abnormal.
Electrical network frequency is
abnormal.

V-1 SPARK MACHINE Art.No.: 118428
13 / 16
8. Operation
When the unit is in good condition, it can start fountain for 30s continuously,
then stops automatically. To prolong the working duration, user needs to re-
start the fountain.
8.1.Manual Operation
If the displays shows “Ready To Work” press "Menu" until the display shows
“Menu Fountain”.With the buttons ▲and ▲buttons you can choose On/Off.
8.2.Operation via DMX
Channel Value from Value to Function
1
0 9 No Function
10 35 Height 1
36 60 Height 2
61 85 Height 3
86 110 Height 4
111 135 Height 5
135 160 Height 6
161 185 Height 7
186 210 Height 8
211 235 Height 9
236 255 Height 10
2
0 9 Normal operation
10 60 Clear material
61 120 EMERGENCY STOP
121 182 Pre-heat OFF
183 255 Pre-heat ON

V-1 SPARK MACHINE Art.No.: 118428
14 / 16
9. Settings
9.1.DMX address
Connected to DMX signal, the unit will display “DMX Address Set” in the LCD
screen. Or press “MENU” button till pages “DMX Address Set”. Through “▲”
and “▼”to set the address
9.2.Fan speed setting
Press “MENU” Button till page “Fountain Height”. Adjust the fan speed through
“▲” and “▼”. Maximum speed is 10.
9.3.Manual operation
Press “MENU” Button till page “Manual Heat”. Turn ON/OFF the heating system
through “▲”and “▼”
LCD screen displays” Ready to Work” after the unit finishes heating. Press
“MENU” button till page “Manual Fountain”. Turn on/OFF the Manual fountain
through “▲”and “▼”. When the temp is lower than 520℃or the unit failed,
this function will shut off automatically.
10.RFID card
10.1. How to use the card
Tap the IC Card in the card reader area to activate the unit. Each card
enables the unit to work 25 minutes. In the meantime, the IC card will be
invalid after being read.
10.2. How to check the remaining time
Press “Menu” buttons till the page “Surplus Time” to check the remaining time
of using. The LCD screen displays “No time” “E5” when there is no enough
materials and times up. Tap another new card to re-activate the unit.

V-1 SPARK MACHINE Art.No.: 118428
15 / 16
11.Technical dato
Voltage AC 220 V; 50 Hz
Power consumption max. 700 W
Heating-time 3 Minutes
Consumption 14 g/min
Height of the fountains 1-5 Meter
Stand-By Temperature 580°C
Max. Loudness 94 dB
Number of DMX channels 2
Strom in P-Con

V-1 SPARK MACHINE Art.No.: 118428
16 / 16
Importer:
B&K Braun GmbH
Im Stöckmädle 27
D-76307 Karlsbad
www.bkbraun.com
[email protected]
