dj power V-3 User manual

CONTENTS
1BEFORE YOU BEGIN........................................................................................................................................1
1.1 WHAT IS INCLUDED ................................................................................................................................................... 1
1.2 UNPACKING INSTRUCTIONS....................................................................................................................................... 1
1.3 SYMBOLS .................................................................................................................................................................... 1
1.4 DISCLAIMER ................................................................................................................................................................ 2
1.5 SAFETY NOTES............................................................................................................................................................ 2
1.5.1 Personal Safety.............................................................................................................................................. 2
1.5.2 Mounting and Rigging................................................................................................................................ 2
1.5.3 Power and Wiring......................................................................................................................................... 2
1.5.4 Operation........................................................................................................................................................ 3
2INTRODUCTION ..............................................................................................................................................3
2.1 DESCRIPTION.............................................................................................................................................................. 3
2.2 FEATURES.................................................................................................................................................................... 3
2.3 PRODUCT OVERVIEW ................................................................................................................................................. 4
2.4 PRODUCT DIMENSIONS ............................................................................................................................................. 4
3TECHNICAL SPECIFICATIONS.......................................................................................................................5
4SETUP .................................................................................................................................................................6
4.1 AC POWER ................................................................................................................................................................. 6
4.2 AC PLUG .................................................................................................................................................................... 6
4.4 DMX LINKING ............................................................................................................................................................ 7
4.4MOUNTING................................................................................................................................................................. 7
4.4.1 Orientation ..................................................................................................................................................... 7
4.4.2 Rigging ............................................................................................................................................................ 7
5OPERATION ......................................................................................................................................................7
5.1 PREPARING FOR OPERATION ..................................................................................................................................... 7
5.2 ON-DEVICE CONTROL PANEL ................................................................................................................................... 7
5.3 ON-DEVICE CONTROL MODE &OPERATION .......................................................................................................... 8
5.3.1 Programming................................................................................................................................................. 8
5.3.2 Menu Map ...................................................................................................................................................... 8
5.5DMX MODE &OPERATION....................................................................................................................................10
5.5.1 Starting Address..........................................................................................................................................10
5.5.2 DMX Mode Menu Map .............................................................................................................................11
5.5.3 DMX Channel Assignments and Values ...............................................................................................11
5.4CORRESPONDENCE OF SPARK HEIGHT &SPARK DENSITY.....................................................................................12
5.5ADVANCED SETTINGS INTERFACE............................................................................................................................12
5.5.1 Enter And Exit Advanced Settings Interface........................................................................................12
5.5.2 Menu Map of Advanced Settings Interface.........................................................................................12
5.4 Wireless Remote-Control Mode & Operation .....................................................................................................9

6SPARK SEED................................................................................................................................................... 13
6.1FILL IN SPARK SEED ..................................................................................................................................................13
6.2PRECAUTION FOR USE ..............................................................................................................................................13
7TECHNICAL INFORMATION ...................................................................................................................... 14
7.1 MAINTENANCE .........................................................................................................................................................14
7.2 STORAGE ..................................................................................................................................................................14
7.2.1 Machine Storage.........................................................................................................................................14
7.2.2 Spark Seed Storage & Recycling ............................................................................................................15
7.3 GENERAL TROUBLESHOOTING .................................................................................................................................15
7.3.1 Device Error Description ...........................................................................................................................15
7.3.2 Device Error Menu Map............................................................................................................................15

DJPOWER
1
1BEFORE YOU BEGIN
1.1 What Is Included
1.2 Unpacking Instructions
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from shipping, or
show signs of mishandling, notify the carrier or dealer/seller immediately. In addition, keep the box and
contents for inspection.
1.3 Symbols
Symbol
Meaning
Caution
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important
Important installation or configuration information. Failure to comply with this
information may keep the product from working correctly.
Information
Useful information.
V-3Spark Machine ×1
Power Cord ×1
User Manual ×1 Warranty Card ×1
Spark Seed Filling
Funnel ×1
Spark Seed Recycling
Tube ×1
W-2 Wireless Remote Kit ×1

DJPOWER
2
1.4 Disclaimer
The information and specifications contained in this User Manual are subject to change without notice.
DJPOWER assumes no responsibility or liability for any errors or omissions and reserves the right to revise
or to create this manual at any time.
Copyright ©2018 DJPOWER. All rights reserved.
1.5 Safety Notes
Please read the following Safety Notes carefully before working with the product. The notes include
important safety information about installation, usage, and maintenance.
1.5.1 Personal Safety
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•During heating up and operation, the housing will be scalding hot. Do not touch.
•The product is very hot during operation and it remains hot for a long time after operation has
stopped. Do not touch the product’s nozzle.
•Keep a minimum distance of 6.6 ft. (2 m) from the machine to the nearest human or flammable
material. The output spark from the nozzle must be in the air but not reaching any object. And mind
the falling residue after the spark.
•Make sure that children, unauthorised people and animals do not obtain access to the machine.
•The operation noise is lower than 80 dB without harm to ear. No need to wear ear protection when
close to the working machine.
•Eye protection is always required when operate the machine closely.
1.5.2 Mounting and Rigging
•For safety reasons, we do not recommend mounting the product in any capacity. Operate the
product while it is on the ground only.
•The product is for indoor use! To prevent risk of fire or shock, do not expose the product to rain or
moisture. Optional waterproof case is available for operating in rain.
•CAUTION: When transferring product from extreme temperature environments, (e.g. cold truck to
warm humid ballroom) condensation may form on the internal electronics of the product. To avoid
causing a failure, allow product to fully acclimate to the surrounding environment before connecting
it to power.
•Do not mount the product on a flammable surface (linoleum, carpet, wood, paper, carton, plastic,
etc.).
•Do not use in a confined space. Always install the product in a location with adequate ventilation, at
least 20 in (50 cm) from adjacent surfaces.
• Be sure that no ventilation slots on the product’s housing are blocked.
1.5.3 Power and Wiring
•Always make sure that the voltage of the outlet to which you are connecting the product is within the
range stated on the decal or rear panel of the product.

DJPOWER
3
•Make sure the power cord is not crimped or damaged.
•Never connect this product to a dimmer pack or rheostat.
•Never disconnect the product from power cord by pulling or tugging on the cord.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it
1.5.4 Operation
•Do not operate this product if you see damage to the housing or cables. Have the damaged parts
replaced by an authorized technician at once.
•Make sure there are no flammable materials close to this product while it is operating.
•Do not cover or plug the output nozzle during operation.
•Do not use the product as a space heater.
•Never carry the product by the power cord or any moving part. Always use the handles.
•Empty the storage bin before transporting the product.
•The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate the product at higher
temperatures.
•Always disconnect the product from the power source before cleaning.
•This product contains no user-serviceable parts. Any reference to servicing in this User Manual will
only apply to properly trained, certified technicians. Do not open the housing or attempt any repairs
which can lead to damage or malfunction.
•In the event of a serious operating problem, stop using the product immediately.
•Use only DJPOWER Spark Seed PRO-K.
Keep this User Manual for future use. If you sell the product, be sure that the purchaser
receives this document.
2INTRODUCTION
2.1 Description
The Spark machine produces a fantastic, non-hazardous effect that looks like traditional fireworks
or pyrotechnics, adopting brand-new control system and standard DMX Control to realize multiple
stage special effects.It thoroughly changed the drawbacks on traditional cold fireworks such as
danger caused by gunpowder, environmental pollution, restricted for use etc.
Based on V-1, V-3 has a more compact design. It uses a belt drive for less noise and better results.
The product is very safe and easy to operate. Spark is bright, environmental friendly, creating less
smoke. It can strongly enhance the rendering atmosphere of the scene, favored by the stage
designer and event planner.
2.2 Features
•Unique design: the storage bin flip cover warning function makes the machine safer to use.

DJPOWER
4
•Compact size, with belt drive, less noise.
•Higher and denser spark, quicker eruption speed, amazing effect.
2.3 Product Overview
2.4 Product Dimensions
205 mm 200 mm
255 mm

DJPOWER
5
3TECHNICAL SPECIFICATIONS
Identification
Category
Spark Machine
Model
V-3
Software Version
1.0
AC Power
Input Voltage & Rate
220-240 V, 50/60 Hz
Current Limiter Specifications
F 5 A, 250 V
Typical Current
2.6 A
Current Limiter Type
FUSE
Nominal Total Power Consumption
600 W
Power Input Connector
Lockable PowerCon
Power Output Connector (Daisy Chained)
Lockable PowerCon
Heating
Heat Up Time
<3 min
Re-heat Up Time
0 min
Capacity
Powder Tank Capacity
200 g
Output
Adjustable Output
√
Adjustment Level/Range
Level 1-10
Max Output Height
Approx. 5.0 m
Powder Consumption (100% Output)
Approx. 11 g/min
Maximum Continuous Duration (100% Output)
30s
Continuous Output
×
Consumable Type for Standard Output Test
PRO-K
Accessory
Power Cord
√
Wireless Controller (Controller Model)
×
Wired Controller (Controller Model)
√
Placement &
Mounting
Horizontal
√
Inclined
√
Vertical
×
Hang Upside Down
×
Rigging & Trussing
×
Rotating Nozzle
×
Deflector
×
Features
Operation Noise
1 m, 80 dB
Control
On-device Manual Control
LCD control board
Wireless Control
Wired Control
×
Control Protocol
DMX-512
DMX Channel Range
2
RFID Card
√
Certification
CE
√
RoHS
√
Weight &
Dimensions
Net Weight
7.5 kg
Gross Weight
9 kg
Machine Dimensions - Length
205 mm
Machine Dimensions - Width
200 mm
Machine Dimensions - Height
255 mm
Packing Dimensions - Length
270 mm
Packing Dimensions - Width
245mm
Packing Dimensions - Height
320 mm
Consumable
Consumable
Spark Seed PRO-K
√

DJPOWER
6
4SETUP
4.1 AC Power
The machine has a fixed voltage power supply and can work with an input voltage of AC 220 V-240 V,
50/60 Hz, depending on the specific model.
To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the
current value listed on the label affixed to the product’s back panel, or refer to the product’s
specifications chart. The listed current rating indicates the product’s average current draw under normal
conditions.
Always connect the product to a protected circuit (circuit breaker or fuse). Make sure the
product has an appropriate electrical ground to avoid the risk of electrocution or fire.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the
rheostat or dimmer channel serves only as a 0 to 100% switch.
4.2 AC Plug
The Spark Machine V-3comes with a power input cord terminated with a Seetronic Powerkon connector
on one end and an EU plug on the other end (EU & China market). If the power input cord that came with
your product has no plug, or if you need the change the plug, use the table below to wire the new plug:
Connection Wire (U.S.) Wire (Europe)
AC Live Black Brown
AC Neutral White Blue
AC Ground Green/Yellow Green/Yellow
4.3DMX Linking
You can link the V-3to a DMX controller using a 3- or 5-pin DMX connection. If using other DMX-
compatible products with this product, you can control each individually with a single DMX controller.
Instructions for connecting and configuring this product for DMX operation are in the User Manual.

DJPOWER
7
4.4Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
4.4.1 Orientation
For safety reasons, we do not recommend mounting the product in any capacity. Operate the product
while it is on the ground only, and make sure there is adequate room for ventilation, configuration, and
maintenance.
4.4.2 Rigging
DJPOWER recommends using the following general guidelines when mounting this product.
•Before deciding on a location for the product, make sure there is easy access to the product for
maintenance and programming purposes.
•Make sure that the structure or surface onto which you are mounting the product can support the
product’s weight (see the Technical Specifications).
•When mounting the product on the floor, make sure that the product and cables are away from
people and vehicles.
5OPERATION
5.1 Preparing for Operation
•After checking that all the parts are intact and complete, position the machine on flat.
•Fill the consumable into feed port when power off.
•Always connect the product to a grounded circuit. Before power on, make sure it is connected with
the rated voltage.
•Turn on the machine, it will immediately start heating up.
5.2 On-device Control Panel
To access the control panel functions, use the four buttons located underneath the LCD display.
Button
Function
<MENU>
Switch menu pages to select a function

DJPOWER
8
Button
Function
▲
Increases the numeric value of current function
▼
Decreases the numeric value of current function
<ENTER>
Switch between current menu page and Standby Page
5.3 On-device Control Mode & Operation
5.3.1 Programming
•Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
•To go to the desired main level, press <MENU> repeatedly until the option shows on the display. This
will take you to the first programming level for that option.
•To select an option or value within the current programming level, press ▲or ▼until the option
shows on the display. If there is another programming level, you will see that first option, or you will
see the selected value.
•Press <MENU> repeatedly to switch menu pages.
•Press <ENTER> to switch between current menu page and Standby Page at any time
5.3.2 Menu Map
Display
Description
Parameter
Range
Preparing
Page
>>>>>>
The machine is heating up.
The machine could only start working
when reach the pre-set target
temperature.
530 - 600℃
Standby Page
>>>>>>
Finished heating up, ready to work.
Displays current heating system
temperature.
Press <ENTER> to get back to this
page at any time (not DMX mode).
Manual Mode
Pages
Press ▲or ▼to switch ON/OFF
Auto Heat-up function.
ON/OFF
The default setting of Auto Heat-up is ON. The Heat-up starts when the
machine is powered on. LCD will keep showing “Heating Up” until the
heating system reaches pre-set target temperature. When the LCD reads
“Ready to Spark”, the machine is available for spark effect at the moment.
Press ▲or ▼to trigger spark output
manually
ON/OFF

DJPOWER
9
Display
Description
Parameter
Range
Manual Mode
Pages
>>>>>>
The machine is outputting spark.
The LCD will automatically switch to
this page after Manual Spark is on for
5 seconds.
Press any button, the LCD will go
back to previous page “Manual Spark
ON”, and press ▲or ▼again to
switch OFF Manual Spark.
The longest duration of single time of Manual Spark output is 30
seconds when machine works properly. The machine will automatically
stop after 30 seconds continuous output with LCD showing “Manual
Spark OFF”. For longer output, just turn on Manual Spark again.
Press ▲or ▼to set the Spark height
of Manual Spark from level 1
(minimum) to 10 (maximum).
1 - 10
DMX
Configuration
Page
Press ▲and ▼to set the DMX
starting address
1-512
5.4 Wireless Remote-Control Mode & Operation
This mode will allow you to control the Spark Machine V-3 using the wireless controller W-2. This consists of the transmitter and the
receiver. Any one (or more) W-2 transmitter can work with any one (or more) W-2 receiver, no paring procedure needed.
You may control up to 4 independent Spark Machines V-3or many more if you run them simultaneously. See the below instructions on
setting up your Spark Machine V-3to operate with the W-2.
•Plug the wires receiver into the fog machine 5-pin port labeled “Wireless Controller”. The red LED indicator will be on when the transmitter
is successfully connected. There is no any reaction in the green LED indicator
>>>>>>
Dipswitche
LED indicator light
Wireless Receiver Wireless Transmitter

DJPOWER
10
5.5DMX Mode & Operation
The Spark Machine V-3works with a DMX controller.
•Connect the product to a suitable power outlet.
•Turn the product on.
•There are 4 buttons on the wireless remote transmitter which act as triggers. Each button can be assigned to a different Spark Machine
V-3. You may only choose 1 dipswitch on each receiver. See the below configuration options for setting the receivers to operate with
the transmitter remote.
Mode Dipswitches
CH1 1 = On, 2-4 = Off
CH1, CH2 1, 2 = On, 3,4 = Off
CH1, CH2, CH3 1, 2, 3 = On, 4 = Off
CH1, CH2, CH3, CH4 1, 2, 3, 4 = On
……
•Press the button, and the Spark Machine V-3will output spark momentarily for as long as you hold down the button (no more than 30
seconds). The screen display as below:
•Release the button, Spark stops. The screen display as below:
•Connect a DMX cable from the DMX output of the DMX controller to the DMX input socket on the
product.
5.5.1 Starting Address
When selecting a starting DMX address, always consider the number of DMX channels. If you choose a
starting address that is too high, you could restrict the access to some of the product’s channels.
DJPOWER® V-3DMX uses 2 DMX channels, which defines the highest
configurable address to 511 to have all channels controllable.
Set the Spark Machine V-3starting address in the 001 - 512 DMX range. This enables control of up
to 256 products in the 2-channel personality.
Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product, or press repeatedly “MENU” button until the LCD shows “DMX
Address”. Press “▲” or “▼” to set desired DMX starting address.

DJPOWER
11
5.5.2 DMX Mode Menu Map
Display Description Adjustable
Range
Preparing
Page
The selected DMX starting address
is 1.
The machine is heating up.
1 - 512
Standby Page
The selected DMX starting address
is 1.
Finished heating up, ready to work.
1 –512
Operation
Page
The selected DMX starting address
is 1.
The machine is outputting spark.
1 –512
The longest duration of single time of spark output is 30 seconds
when machine works properly. The machine will automatically stop
after 30 seconds continuous output with LCD showing “Spark OFF”.
For longer output, just turn on spark again via DMX controller.
Status Pages
The selected DMX starting address
is 1.
The machine is having error. Error
code is E0.
1 –512
Refer to “General Troubleshooting” chapter to for a brief
description of each error code.
5.5.3 DMX Channel Assignments and Values
Channel Function Value Description
1 Spark Height
000 - 009 Spark OFF
010 - 035 Spark height level 1
036 - 060 Spark height level 2
061 - 085 Spark height level 3
086 - 110 Spark height level 4
111 - 135 Spark height level 5
136 - 160 Spark height level 6
161 - 185 Spark height level 7
186 - 210 Spark height level 8
211 - 235 Spark height level 9
236 - 255 Spark height level 10

DJPOWER
12
2 Safety Channel
0 - 9 Device enabled
10 - 60 Consumable cleaning up
61 - 120 Emergency stop / Device disabled
121 - 182 Auto Heat-up OFF, spark output (channel 1)
disabled
183 - 255 Auto Heat-up ON, spark output (channel 1)
disabled
5.4Correspondence of Spark Height & Spark Density
Spark Height Spark Density
Height level 1 (Minimum) Density level 1 (Minimum)
Height level 2
Height level 3
Height level 4
Density level 2
Density level 3
Density level 4
Height level 5
Height level 6
Height level 7
Height level 8
Height level 9
Density level 5
Density level 6
Density level 7
Density level 8
Density level 9
Height level 10 (Maximum) Density level 10 (Maximum)
The internal temperature increases dramatically after continuous high-level output, which
might cause clogging and failure.
5.5Advanced Settings Interface
5.5.1 Enter And Exit Advanced Settings Interface
Press <ENTER> for 3s to enter Advanced Settings Interface. Press <MENU> repeatedly until the option
shows on the display. To select an option or value, press ▲or ▼until the option shows on the display.

DJPOWER
13
6.1Fill in Spark Seed
Tear open the vacuum resealable foil pouch, and fill in the Spark Seed through the feed port on the top
of the fixture depending on the dosage needed.
Consumable Feed Port & Storage Bin
(Filling & Refilling Procedures)
•Open the magnetic hinged lid.
•Fill the consumable into the feed port, NOT into the output nozzle when power off.
•Close the lid securely after filling.
•The capacity of storage bin is 200g.
•Only use DJPOWER consumable.
6.2Precaution for use
•The Spark Seed could be only filled in and used for the DJPOWER Spark Machine after successfully
identified by swiping Consumable ID card.
6SPARK SEED
Spark Seed is the consumable specially designed for DJPOWER Spark Machine, to create light golden
color cold firework for stage effect.
•Make sure to fill the Spark Seed through the feed port on the top of the fixture and when power
supply is off.
•Use Dry Chemical Extinguishers once lighting a fire. DO NOT use Water-Type Extinguishers, Foam
Extinguishers or Carbon Dioxide Extinguishers.
Detect The Magnetic
Hinged Lid When the function of "detect the magnetic hinged lid" is on, the
lid must be closed to make the machine work normally, otherwise
the display interface will prompt "Close magnetic hinged lid!"

DJPOWER
14
7TECHNICAL INFORMATION
7.1 Maintenance
The V-3 requires minimal upkeep in order to maintain optimum performance. However, some steps are
needed in order to clean and maintain the product for maximum usage. The recommended procedure is
as follows:
•After a period of using, check if there is any consumable tuberculation inside the nozzle. Do
necessary cleaning up if there has some, or it may affect spark performance, even damage the
machine.
Test-run your DJPOWER® V-3 on a monthly basis to achieve the best performance.
7.2 Storage
7.2.1 Machine Storage
Before storing the machine, empty the storage bin，clean it as described in the “Maintenance”section.
And keep the machine in dry cool place.
Empty the storage bin:
•Remove the power cord from mains power, and allow unit to cool down. Empty the storage bin
through feed port by inverting the machine.
•Run the machine to generate Spark till out of Spark Seed, or run Consumable Cleaning Up procedure
(Safety channel, channel 2) to completely clear remaining Spark Seed inside the nozzle.
Refer to “DMX Channel Assignments and Values” chapter to for more information.

DJPOWER
15
Spark Seed would easily get damp in the open air and deliver poor spark effect. Storing
damp Spark Seed in the machine storage bin will do harm to machine and cause clogging.
Please empty the storage bin after each use.
7.2.2 Spark Seed Storage & Recycling
7.2.2.1 Sealed Spark Seed Storage
Spark Seed should be stored in a cool, dry place, vacuum packed in resealable foil bags, and protected
from moisture, heat, hot surface, open fire and other ignition sources.
7.2.2.2 Spark Seed Recycling
Store the unfinished Spark Seed in the Recycling Tube with the Funnel. Keep it sealed and away from
moisture.
7.3 General Troubleshooting
7.3.1 Device Error Description
When error happens, device will stop working and heating system shuts off automatically. LCD shows
corresponding error code.
7.3.2 Device Error Menu Map
Errors
Display
Possible Cause
Over heat
shutdown
The heating system temperature is higher than
700 ℃over 30 seconds.
Heating up
failed
Heating system cannot reach pre-set target
temperature after 10-min heat-up
Over current
protection for
motor
Consumable feeding motor failed
Thermocouple
failed
Short circuit or wrong connection of
thermocouple

DJPOWER
16
Errors
Display
Possible Cause
Thermocouple
tripped off
Open circuit or no connection of thermocouple
Internal
temperature too
high
The internal temperature is higher than 60°
Motor error Stepper motor cannot be reset.
Power line
frequency
abnormal
Power input frequency is abnormal.
