Rev. 1.7 (May 2018) 1 © DLP Design, Inc.
D
DL LP P- -R RF FI ID D- -
L
LP P8 8C C
LEAD-FREE
8
8- -C Ch ha an nn ne el l R Re ea ad de er r/ /W Wr ri it te er r
FEATURES:
• ISO15693, ISO14443A, ISO14443B Compatible
• Can read the UID/SID of up to 15 Tags Simultaneously
• 13.56MHz Reader/Writer
• 8 Channels for External Antenna Connections
• FCC/IC Modular Approvals in Place
• USB Port Powered from Windows, CE or Linux PC
• Both USB and RS232 Interfaces Provided
• USB Interface; No Driver Development Required for Windows, CE or Linux PC
• Operating Temperatures: 0°C to 70°C
• Dimensions: (L x W x H) 4.36” x 3.32” x 0.6”
APPLICATIONS INCLUDE:
• Real-Time Security
• Personal Identification
• Pharmaceutical Tracking
• Inventory/Asset Management & Tracking
• Library/Book Management & Tracking
• Baggage Tagging
• Sports Event Timing
1.0 INTRODUCTION
The DLP-RFID-LP8C is a low-cost, USB-powered module for reading from and writing to ISO15693,
ISO14443A and ISO14443B intelligent RFID transponder tags via up to eight external antennas. It has
the ability to both read and write tag user data in addition to reading the unique identifier (UID). All of the
DLP-RFID-LP8C’s electronics reside on a single, compact PCB; and all operational power is taken from
the host Windows/Windows CE/Linux PC via the USB interface. Up to eight external antennas can be
connected via reverse-polarity SMA connectors.

Rev. 1.7 (May 2018) 2 © DLP Design, Inc.
2.0 HARDWARE SETUP
The four jumpers provided on the DLP-RFID-LP8C module are used to select between the USB and
Rs232 interfaces. For RS232 interface operation, move the three jumpers to the RS and RS232
positions and remove JP3. For USB operation, move the three jumpers to the USB position and add
jumper JP3.
If using the RS232 interface, connect the J3 wiring terminals to ±8V to ±12V serial signals typically found
in the DB9, RS232 port connectors on a host PC. An external, regulated 5 volt power source must also
be connected to J2.
If using USB, simply connect the DLP-RFID-LP8C to a host PC using the 5-pin mini-B USB connector
CN1 and a compatible USB cable. All power and data are provided via the USB cable.
3.0 APPLICATION DEVELOPMENT
The serial interface for the DLP-RFID-LP8C operates at 115,200 baud, no parity, 8 data bits and
1 stop bit.
A demonstration GUI is provided with the purchase of a DLP-RFID-LP8C module that demonstrates the
communications protocols. Using the Virtual COM Port USB drivers, the DLP-RFID-LP8C appears to the
host PC (Windows, Linux, Mac) as an RS232 port. The GUI presents the actual control packets sent,
and the reply data coming back from the DLP-RFID-LP8C as an aid to the software developer.
3.1 DEMONSTRATION GUI
The demonstration GUI is available as a free download from the DLP Design website. The URL for the
download page is printed on the outer packaging of the DLP-RFID-LP8C.

Rev. 1.7 (May 2018) 3 © DLP Design, Inc.
3.2 LP8C SPECIFIC COMMANDS
To select one of the 8 external antennas on the DLP-RFID-LP8C you must send the correct command
packet (Ex: 010900030422F00000). To send this packet using the TI GUI, first make the connection to
the DLP-RFID-LP8C, and then click on the Test tab. Enter a command packet as shown below and click
on Send Raw. The LED associated with the antenna channel selected will light and successive tag reads
will use that channel.
LP8C Specific commands:
Commands to activate 1 of the 8 Antenna Channels:
1. 010900030422F00000
2. 010900030423F00000
3. 010900030424F00000
4. 010900030425F00000
5. 010900030426F00000
6. 010900030427F00000
7. 010900030428F00000
8. 010900030429F00000
Read Opto-isolated inputs:
010900030435F00000
Write opto-isolated output 1 high:
010900030430F00000
Write opto-isolated output 1 low:
010900030431F00000
Write opto-isolated output 2 high:
010900030432F00000
Write opto-isolated output 2 low:
010900030433F00000
Issue Pass beep
010900030477F00000
Issue Fail Beep
010900030479F00000

Rev. 1.7 (May 2018) 4 © DLP Design, Inc.
3.3 LP8C OPERATING FIRMWARE
The source code for the firmware running in the DLP-RFID-LP8C reader (developed using Code
Composer Studio) is available for download upon purchase of the DLP-RFID-LP8C from the DLP Design
website.
4.0 MECHANICAL DIMENSIONS IN INCHES (MM)
0.45 typ
(11.4typ)
2.08 typ
(53.0 typ)
0.12 typ
(3.1 typ)
0.60 typ
(15.1 typ)
0.37 typ
(9.3 typ)
3.84 typ
(97.6typ)
3.0 typ
(76.2typ)
2.70 typ
(68.6typ)
1.55 typ
(39.4typ)
4.36 typ
(111 typ)
2.85 typ
(72.3typ)
3.32 typ
(84typ)
2.75 typ
(68.9 typ)

Rev. 1.7 (May 2018) 5 © DLP Design, Inc.
5.0 REGULATORY AGENCY CONSIDERATIONS
5.1 AGENCY IDENTIFICATION NUMBERS
Compliance with the appropriate regulatory agencies is essential in the deployment of all intentional
radiators. DLP Design has obtained modular approval for this RF product such that an OEM need only
meet a few basic requirements in order to utilize their end product under this approval. Corresponding
agency identification numbers are listed below:
P
PA AR RT T N NU UM MB BE ER R U US S/ /F FC CC C C CA AN N/ /I IC C
DLP-RFID-LP8C SX90LP8C 5675A-0LP8C
5.2 EXTERNAL ANTENNAS
The DLP-RFID1-LP8C is approved for use with external 50 Ohm loop/ferrite antennas that are resonant
at 13.56MHz. Connection is made via reverse-polarity SMA connectors.
Two different antennas are available from DLP Design: the DLP-FANT and the DLP-RFID-ANT.
D
DL LP P- -F FA AN NT T D DL LP P- -R RF FI ID D- -A AN NT T
The DLP-FANT ferrite-based antenna provides a compact footprint for space-constrained applications
and provides up to a 1.25-inch read range.
The DLP-FANT requires a coax cable with a reverse-polarity SMA connector at one end for connection
to the DLP-RFID-LP8C reader. This coax cable is available in a 3-foot length from DLP Design under
part number DLP-COAX1.
The DLP-RFID-ANT ships with an attached 15-foot coax cable with a reverse-polarity SMA connector
and provides up to 4 inches of read range with larger (credit card size) tags.

Rev. 1.7 (May 2018) 6 © DLP Design, Inc.
5.3 FCC/IC REQUIREMENTS FOR MODULAR APPROVAL
Any changes or modifications to the DLP-RFID-LP8C’s printed circuit board could void the user’s
authority to operate the equipment. Operation of an unapproved antenna could void the user’s authority
to operate the equipment.
5.4 WARNINGS
Operation is subject to the following two conditions: (1) This device may not cause harmful interference;
and (2) this device must accept any interference received, including interference that may cause
undesirable operation.
To reduce potential radio interference with other users, the antenna type and its gain should be so
chosen that the equivalent isotropically-radiated power (e.i.r.p.) is not more than that permitted for
successful communication.
This device is intended for use under the following conditions:
1. The transmitter module may not be co-located with any other transmitter or antenna; and,
2. The module is approved using the FCC “unlicensed modular transmitter approval” method.
As long as these two conditions are met, further transmitter testing will not be required. However, the
OEM integrator is still responsible for testing their end product for any additional compliance measures
necessitated by the installation of this module (i.e. digital device emissions, PC peripheral requirements,
etc.).
Note: In the event that these conditions cannot be met (i.e. co-location with another transmitter), then
the FCC authorization is no longer valid, and the corresponding FCC ID may not be used on the final
product. Under these circumstances, the OEM integrator will be responsible for re-evaluating the end
product (including the transmitter) and obtaining a separate FCC authorization.
5.5 OEM PRODUCT LABELING
The final end product must be labeled in a visible area with the following text:
“Contains TX FCC ID: SX90LP8C”
5.6 RF EXPOSURE
In order to comply with FCC RF exposure-compliance requirements, the antenna used for this transmitter
must not be co-located or operating in conjunction with any other antenna or transmitter.

Rev. 1.7 (May 2018) 7 © DLP Design, Inc.
5.7 ADDITIONAL INFORMATION FOR OEM INTEGRATORS
The end user should NOT be provided with any instructions on how to remove or install the DLP-RFID-
LP8C. This device has been pre-certified to operate with the antenna models listed below, or any other
50 Ohm, magnetic loop antenna that resonates at 13.56MHz.
 DLP Design Large Loop Antenna
 DLP Design Small Loop Antenna
 DLP Design Ferrite Antenna
6.0 DISCLAMER
Neither the whole nor any part of the information contained herein nor the product described in this
datasheet may be adapted or reproduced in any material or electronic form without the prior written
consent of the copyright holder.
This product and its documentation are supplied on an as-is basis, and no warranty as to their suitability
for any particular purpose is either made or implied. DLP Design will not accept any claim for damages
whatsoever arising as a result of use or failure of this product. Your statutory rights are not affected.
This product or any variant of it is not intended for use in any medical appliance, device or system in
which the failure of the product might reasonably be expected to result in personal injury.
This document provides preliminary information that may be subject to change without notice.
7.0 CONTACT INFORMATION
DLP Design, Inc.
1605 Roma Lane
Allen, TX 75013
Phone: [phone]
Fax: [phone]
Email: [email protected]
Internet: http://www.dlpdesign.com

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
CH1
CH3
CH5
CH7
FT232R
3.3V
TX -->
RX <--
DTR -->
TX -->
RX <--
5V IN
RX <--
TX -->
CH2
CH8
CH6
CH4
SWVCC
SWVCC
SWVCC
USBVCC
RESET
TOHOST
FROMHOST
USBVCC
SWVCC
SWVCC
ANTENNA
SWVCC
SWVCC
UCVCC
UCVCC
ANT_SEL_B
ANT_SEL_C
ANT_SEL_A
UCVCC
R4
360
C3
0.1uF
C10
10/10 Tant
RL8
RELAY SPST
1
4
2
3
R21
30K
RL5
RELAY SPST
1
4
2
3
D2
LED
Q5
MMBT3904
RP-SMA3
901-144-8RFX
U3
ULN2003A/TSSOP
1
2
3
4
5
6
7
16
15
14
13
12
11
10
9
8
1B
2B
3B
4B
5B
6B
7B
1C
2C
3C
4C
5C
6C
7C
COM
GND
C18
0.1uF
C20
.01uF
C1
0.1uF
R1
360
C9
.1uF
J2
5VDC IN
1
2
C16
.1uF
C8
1uF/10V/0603
C14
.1uF
D8
LED
R3
360
C21
0.1uF/0603
C4
0.1uF
R28
360
U5
74HC238/TSSOP
1
2
3
816
15
14
13
12
11
10
9
7
6
4
5
A
B
C
GND VCC
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
G1
G2A
G2B
RP-SMA8
901-144-8RFX
RL6
RELAY SPST
1
4
2
3
C6
10/10 Tant
RL4
RELAY SPST
1
4
2
3
RP-SMA7
901-144-8RFX
RP-SMA2
901-144-8RFX
U8
FT232R
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25 26
27
28
TXD
DTR#
RTS#
VCCIO
RXD
RI#
GND
VCCIN/NC
DSR#
DCD#
CTS#
CBUS4
CBUS2
CBUS3
USBDP
USBDM
3V3OUT
GND
RESET#
VCC5 IN
GND
CBUS1
CBUS0
AVCC/NC
AGND TEST
OSCI
OSCO
D3
LED
C22
.47uF
C13
47pF
D1
LED
R8
360
D7
LED
C2
0.1uF
RL7
RELAY SPST
1
4
2
3
D9
LED
Q4
MMBT3904
R23
47K
J3
RS232 Header
1
2
3
4
R6
360
C12
47pF
R30
10K
FB1
240-1018-1
1 2
RL2
RELAY SPST
1
4
2
3
CN1
Mini-B USB Connector
1
2
3
4
5
R5
360
FB2
240-1018-1
1 2
R2
360
RL1
RELAY SPST
1
4
2
3
1
TX SELECT
1
5V SELECT
C15
.1uF
D4
LED
C11
.01
R7
360
Q3
IRLML6402CT P
RP-SMA4
901-144-8RFX
C5
0.1uF
RL3
RELAY SPST
1
4
2
3
U6
MAX3238/SO
2
26
16
15
28
25
1
3
27
4
13
14
24
23
22
19
17
8
9
11
21
20
18
5
6
7
10
12
GND
VCC
R1OUTB
INVALID
C1+
C1-
C2+
C2-
V+
V-
FORCEON
FORCEOFF
T1IN
T2IN
T3IN
T4IN
T5IN
R1IN
R2IN
R3IN
R1OUT
R2OUT
R3OUT
T1OUT
T2OUT
T3OUT
T4OUT
T5OUT
C7
.01uF/0603
RP-SMA1
901-144-8RFX
D6
LED
RP-SMA5
901-144-8RFX
D5
LED
RP-SMA6
901-144-8RFX
C19
10/10 Tant
U7
PQ1L303M2SP
4
2
3 1
5
IN
GND
CIN COUT
OUT
1
RX Select
U4
ULN2003A/TSSOP
1
2
3
4
5
6
7
16
15
14
13
12
11
10
9
8
1B
2B
3B
4B
5B
6B
7B
1C
2C
3C
4C
5C
6C
7C
COM
GND

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
DLP-RFID-LP8C
IN1
IN2
COM
OUT1
OUT2
Not used
Simplified
Schematic
Matching
network &
filtration
SPKR
SWVCC
SIMO
3VCC
SOMI DATA_CLK
SWVCC
SIMO
RESET
3VCC
3VCC
TOHOST
3VCC
SLAVE_SELECT
SLAVE_SELECT
SOMI
DATA_CLK
FROMHOST
LED
LED
ANT_SEL_C
ANT_SEL_B
ANT_SEL_A
EXT_IN1
EXT_IN2
EXT_OUT1
EXT_OUT2 SPKR
EXT_OUT1
EXT_IN2
EXT_OUT2
3VCC EXT_IN1
3VCC
ANTENNA
UCVCC
SWVCC
J5
PROGRAMMING HEADER
1
2
3
4
5
6
7
8
R33
470
ISO1
LTV846
2
1
5
4
3
6
7
8
12
11
10
9
16
15
14
13
C25
0.01uF
R32
470
U2
MSP430F2370
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 21
22
23
24
25
26
27
28
29
30
31
32
33
34 35 36 37
38
39
40
DVCC
XIN/P2.6/CA6
XOUT/P2.7/CA7
P1.0/TACLK
P1.1/TA0
P1.2/TA1
P1.3/TA2
P1.4/SMCLK
P1.5/TA0
P1.6/TA1
P1.7/TA2
P2.0/ACLK/CA2
P2.1/TAINCLK/CA3
P2.2/CAOUT/TA0/CA4
P2.3/CA0/TA1
P2.4/CA1/TA2
P2.5/Rosc/CA5
P3.0/UCB0STE/UCA0CLK
P3.1/UCB0SIMO/UCB0SDA
P3.2/UCB0SOMI/UCB0SCL P3.3/UCB0CLK/UCA0STE
P3.4/UCA0TXD/UCA-SIMO
P3.5/UCA0RXD/UCA0SOMI
P3.6
P3.7
P4.0/TB0
P4.1/TB1
P4.2/TB2
P4.3/TB0
P4.4/TB1
P4.5/TB2
P4.6/TBOUTH/ACLK
P4.7/TBCLK
TDO/TDI
TDI/TCLK
TMS
TCK
RST/NMI
D/AVSS
AVCC
C47 22pF
R20
47K
Q1
MMBT3904
J1
1
2
R36
1.8K
R31
10K
R29 470
J4
1
2
3
R34
1.8K
C24
2.2uF
Q2
MMBT3904
R19
100
TG
Mode Sel
1
2
R37
47K
Y1
13.56MHz
C46 22pF
D10
GR TAG LED
R35
10K
U1
TRF7970A
5
14
15
4
16
17
18
1
2
3
6
7
8
9
10
11 12
13
19
20
21
22
23
24
25
26
27
28
29
30
31
32
TX_OUT
MOD
VSS_A
VDD_PA
VDD_IO
IO0
IO1
VDD_A
VIN
VDD_RF
VSS_PA
VSS_RX
RX1_AM
RX2_PM
VSS
BG ASK/OOK
IRQ
IO2
IO3
IO4
IO5
IO6
IO7
EN2
DATA_CLK
SYS_CLK
EN
VSS_D
XTAL_OUT
XTAL_IN
VDD_X
C34
0.01uF
C33
2.2uF
BZ1
Buzzer
R22
470
