PERFORMANCE SERIES
CAR AUDIO SPEAKERS
WELCOME
Thank you for buying a DLS Performance series speaker.
These speakers are mainly design for installation in factory pre-
made mounting holes.
Install the speakers yourself if you feel confident with our
instructions and if you have the proper tools. However if you
feel unsure, turn over the installation job to someone better
suited to it.
You can use this speaker to a normal Car stereo high power
head unit, but avoid connecting this speaker kit to an external
amplifier.
INSTALLATION
Mount the speakers in the door or in the dashboard of your
car. Normally they will fit in the facory pre-made mounting
holes. If you want an improved sound reinforce with a baffle of
MDF-board or similar. An installation high up on the door side
is to be prefered.
In many vehicles there are factory made places for tweeters
that you can use for installation. If this is impossible, try to
Install the tweeter close to the bass/mid driver. The tweeter
can also be installed on the dash-board, or recessed in the
door with the accessories in the tweeter box.
It is important to fasten the speakers properly in order to avoid
bad sound or rattling.
The tweeters are equipped with an integrated filter in the
tweeter cabling.
K4
K5
K6


 Technical Assistance
For technical assistance ask the shop where the product was
sold or the distributor in your very country.You can always phone
the DLS Helpdesk in Sweden + 46 31 840060 or send an e-
mail to [email protected]
Information can also be found on our WEB-site www.dls.se
WARRANTY SERVICE
This speaker is covered by warranty, depending on the
conditions in the country where it is sold. If the speaker is retur-
ned for service, please include the original dated receipt with
the product.
TWEETER INSTALLATION T13
T13 can be installed on the
dashboard with the angled
cup (1), or recessed in a
doorside.
SURFACE MOUNTING:
Angled mounting:Put the cable through the hole in the rear
end of the angled cup. The tweeter is attached to the cup by
pressing them together. Attach the cup to the surface with the
double adhesive tape.
RECESSED MOUNTING:
You need a hole with a diame-
ter of 43 mm/ 1,7”. Put the two
metal wings through the two
tracks in the center of the cup,
just as the picture shows, and
attach them with the M4 screw
and nut through the center
hole. The cup is attached to
the door side when the metal
wings is pressed to the back
side of the door.
Put the tweeter element into
the cup with the cable going
out through the bottom hole.
Then attach the element by
putting it into the cup.
3
4
Size 13 mm / 0,63"
Nom. power (RMS) 50 Watts, 80 Watts max
Freq. range 2 kHz-20 kHz
Sensitivity 91 dB
Mounting depth 20 mm / 0,8" (recessed mounting)
Mounting hole 43 mm / 1,7" (recessed mounting)
Cone material Silk
FACTS ABOUT DLS T13 TWEETER
DLS Svenska AB
P.O. Box 13029
SE-40251 Göteborg, Sweden
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.dls.se
CONNECTION
OF SPEAKERS
For speakers with
integrated filters,
connect like this.
Make sure the
polarity is same for
both left and right
side.
Allow the speakers
to play for at least
15-20 hours. After
this time the
performance is
correct.
Car stereo or
amplifier
+-
+
+
-
-
TECHNICAL DATA
K4 K5 K6
Impedance 4 ohm 4 ohm 4 ohm
Nomial power 50 W 50 W 50 W
Max power 80 w 80 w 80 W
Cone material Paper* Paper* Paper*
* Dual cone EFR-technology for improved sound quality
Woofer size 4” (10 cm) 5,25” (13 cm) 6,5”(16,5 cm)
Magnet size 70 mm/2,76” 70 mm/2,76” 80 mm/3,15”
Sensitivity 91 dB 91 dB 92 dB
Inst depth 45 mm/1,77” 50 mm/2” 60 mm/2,36”
Mounting hole 102 mm /4” 115 mm /4,53” 145 mm / 5,7”
Tweeter
crossover
Black
Red/Black
