DMP Electronics 1165 Assembly instructions

INSTALLATION SHEET
1165/1165H/1165HS Wireless Commercial Smoke Detectors
Description
The Model 1165 Smoke Detector, 1165H Smoke/Heat Detector, and 1165HS Smoke/Heat Detector with Sounder are
photo electric, wireless detectors used with the 1100X Series Wireless Receivers.
Features
• Tamper switch sends a trouble signal to the control
panel when the detector is removed from the
mounting base.
• Optional integrated xed 135°F temperature and
rate of rise heat detector trips an alarm based on
temperature detected.
Included Components
• One 1165 Smoke Detector with DMP wireless
transmitter installed
OR
• One 1165H Smoke/Heat Detector with DMP wireless
transmitter installed
OR
• One 1165HS Smoke/Heat Detector with Sounder
with DMP wireless transmitter installed
AND
• Two 3V lithium Panasonic CR123A (DMP part number CR123-FIRE) batteries
• Hardware pack
Programming the Transmitter in the Panel
Program the device as a zone in Zone Information during panel programming. At the Serial Number: prompt, enter
the eight-digit serial number. Set supervision time to 3. Continue to program the zone as directed in the panel
programming guide.
Note: When a receiver is installed, powered up, or the panel is reset, the supervision time for transmitters is reset.
If the receiver has been powered down for more than one hour, wireless transmitters may take up to an additional
hour to send a supervision message unless tripped, tampered, or powered up. This operation extends battery life for
transmitters. A missing message may display on the keypad until the transmitter sends a supervision message.
Transmitted Signal Outputs
The smoke detector provides the signals listed in the table:
Signal Keypad Display
Alarm ALARM
Alarm restore OK
Low battery LOBAT
Selecting the Proper Location (LED Survey Operation)
The 1165/1165H/1165HS Transmitter provides a survey capability to allow one person to conrm transmitter
communication with the receiver. The 1165/1165H/1165HS Transmitter PCB Red Survey LED turns on whenever data
is sent to the receiver then immediately turns off when the receiver acknowledgement is received. Pressing the test
button is a convenient way to send data to the receiver to conrm operation. The transmitter survey LED can be
seen around the test button location. When the transmitter does not receive an acknowledgement from the receiver
the LED remains on for about 8 seconds to let you know communication is not established. Communication is also
faulty when the LED blinks multiple times in quick succession. Relocate the transmitter or receiver until the LED
immediately turns off indicating the transmitter and receiver are communicating properly. Proper communication
between the transmitter and receiver is veried when for each press or release of the test button, the LED blinks
immediately on and immediately off. Repeat this test to conrm ve separate consecutive LED blinks. Any indication
otherwise means proper communication has not been established.
Figure 1: Smoke Detector Features
LED
Sounder Vent
Optional Heat Sensor
Optional Heat Sensor
Test Button

Digital Monitoring Products 1165/1165H/1165HS Detectors Installation Sheet
2
Selecting a suitable location is critical to the
operation of smoke detectors. This equipment
should be installed in accordance with the National
Fire Protection Association’s (NFPA) Standard 72.
Depending on the application, you may need to
reference NFPA 72 or NFPA 101.
Since regulations pertaining to smoke detector
installation vary from state to state, contact the
authority having jurisdiction (AHJ). Where public
safety is primary, the AHJ may be a federal, state,
local, or other regional department or individual such
as a re chief, re marshal, chief of a re prevention
bureau, labor or health department, building ofcial,
electrical inspector, or others having statutory
authority. For insurance purposes, an insurance
inspection department, rating bureau, or other
insurance company representative may be the AHJ. In
some cases, the property owner or their designated
agent assumes the role of the AHJ. At government
installations, the commanding ofcer or department
ofcial may be the AHJ.
Additional NFPA Guidelines, Smoke Detector
Limitations, and Fire Prevention information are listed
at the end of this document.
General Guidelines
In addition to NFPA 72, use the following location
guidelines to optimize performance and reduce the
chance of false alarms from the detector:
• Locate ceiling-mounted smoke detectors in the center of a room or hallway at least 4 inches from any walls or
partitions
• Locate wall-mounted smoke detectors so the top of the detector is 4 to 12 inches below the ceiling
• Mount smoke detectors on a rm permanent surface
• Locate the detector in environmentally controlled areas where the temperature range is between 40° and
100° F (4.4° and 37.8° C) and the humidity is between 0 and 90% non condensing
• In rooms with sloped, peaked, or gabled ceilings, locate detectors 3 feet (.9 meters) down or away from the
highest point of the ceiling
• When mounting to suspended ceiling tile, the tile must be secured with the appropriate fastener to prevent
tile removal
Locations to Avoid
Do not install smoke alarms/detectors:
• In or near areas where combustion particles are normally present such as in kitchens, garages, near furnaces,
hot water heaters, or gas space heaters
• On the ceiling in rooms next to kitchens where there is no transom between the kitchen and such rooms
• In damp or very humid areas or next to bathrooms with showers, locate detectors at least 5 feet (1.5 meters)
away from bathrooms.
• In very cold or very hot areas
• In dusty, dirty, or insect infested areas
• Away from air conditioners, heating registers, and any other ventilation source that may interfere with smoke
entering the detector.
• Near fresh air inlets or returns or excessively drafty areas — heating/air conditioning vents, fans, and fresh air
intakes can drive smoke away from smoke alarms/detectors
• In dead air spaces at the top of peaked ceilings or in corners where walls and ceiling meet — dead air may
prevent smoke from reaching a smoke alarm/detector.
• Near uorescent light xtures — locate smoke alarms/detectors at least 10 feet (3 meters) away from these
xtures.
In commercial buidings locate
a smoke detector in each room.
Locate a smoke detector
on each level.
In multifamily dwellings, locate smoke alarms/detectors
in hallways and stariwells of each level
Locate smoke alarms/detectors in the living area,
hallway, and in each bedroom of the apartment.
I
n mul
t
i
f
ami
f
f
ly dwell
ings, locate smok
e
alarms
/
detectors
k
k
i
n
h
a
l
lw
a
y
s an
d
stariwe
l
l
s o
f
each lev
el
Locate smok
e alarms/detectors in the l
k
k
i
v
i
ng a
r
e
a,
hl
l
d
i
hb
d
f
th
tt
Stairwell
Third Floor
Second Floor
First Floor
Stairwell
Apartment
ApartmentApartmentApartment
ApartmentApartment
Dining
Room
Living
Room
Kitchen
Bedroom
Bedroom
Bath
Room
Closet Closet Closet
Dining
Area
Living
Room
Kitchen
Bedroom
Bedroom
Bath
Room
Closet Closet Closet
Bedroom
Bath
Room
Closet
Office
Office
Office Office OfficeOffice
Office
Office
Stairwell
Stairwell
Hall
Closet
Office
Elevator
Hall
Conference Room
Lobby
Mens Ladies
Hall
H
H H
Hall
Figure 2: Smoke Detector Placement Locations

1165/1165H/1165HS Detectors Installation Sheet Digital Monitoring Products
3
Installing the Detector
Note: When setting up a wireless system, it is recommended
to program zones and connect the receiver before installing
batteries in the transmitters.
Use the following steps to install the detector.
1. Slide the battery compartment cover away from the
detector to unsnap it and lift it off. See Figure 3.
2. Observing proper polarity, insert two 3V lithium
batteries into the detector battery compartment. Flip
the ribbon over the top of the batteries and replace
the battery compartment cover.
3. Locate and record the detector serial number.
This number is required during programming. See
Programming the Transmitter in the Panel.
4. Remove the red plastic dust cover from the
detector. The detector is shipped with a dust cover
for protection on construction sites with dusty
environments.
5. Test the communication between the control panel
and the detector before permanently mounting the
detector as follows:
- Hold the detector up where you plan to install it.
- Press the Test button on the detector for 4 seconds.
The detector sends a signal to the control panel.
- At the control panel, verify the signal was received
and the RF signal strength is adequate. If no signal
is received or the RF signal is low, relocate the
detector and retest.
6. Using the two screws and anchors provided, mount
the base.
7. Line up the raised tab on the lip of the detector
with the slot on the lip of the mounting base. See
Figure 4.
Important: The control panel alarm and all auxiliary
functions should be veried for a complete test of the
system.
Smoke Testing the Smoke Detector
Smoke detectors should be tested in place annually using one of the following methods:
A. Use DMP Model 526, Smoke! in a can®, a canned aerosol simulated smoke and follow the directions on the can.
B. Use the following steps to test the detector with smoke:
1. Hold a smoldering punk or cotton wick close to the smoke entry openings.
2. Gently direct the smoke into the detector for 20 seconds or until an alarm is indicated.
Be sure to extinguish the smoke source after testing! The detector LED should stay on and an alarm should be
indicated at the control panel. Use the system reset switch to reset the detector.
Testing the Detector Sensitivity
The smoke detector provides a sensitivity level test mode that allows you to check the smoke detector sensitivity
using the Test/Silence button and the LED indicator on the detector as follows:
1. Press the Test/Silence button on the smoke detector for 2 seconds. Once the test starts, the detector LED
ashes one to nine times.
2. Count the number of times the LED ashes and use the following table to determine the status of the smoke
detector sensitivity and what action to take, if any.
Battery
Compartment
Figure 3: Battery Compartment
Alignment Tab
Alignment Arrow
Figure 4: Smoke Detector-to-Base Alignment

Digital Monitoring Products 1165/1165H/1165HS Detectors Installation Sheet
4
Flashes Indication Action
1 Unserviceable hardware fault Rest unit and rerun sensitivity test.
If the error persists, replace the unit.
2-3 Detector is becoming sensitive Clean the Unit. Reset the unit and rerun sensitivity test.
If the error persists, replace the unit.
4-7 Detector is within normal sensitivity range. N/A
8-9 Detector is becoming too sensitive Verify that the smoke chamber is snapped down securely.
Clean the unit and replace the smoke chamber.
After the ashes, if the sensitivity is within limits and all other tests pass, the detector goes into alarm and
resets after 7 seconds.
If the sensitivity is not within limits, or an unserviceable hardware fault has been detected, the smoke detector LED
extinguishes until the detector is serviced.
Understanding the LED
The LED on the detector indicates the status of the detector as follows:
FLASHING = Flashes every 8 seconds to indicate normal operation.
ON = Detects smoke.
OFF = Trouble or maintenance is required.
Understanding the Test/Silence Button
The Test/Silence button on the detector performs the following three functions:
Testing = Press the Test/Silence button for 4 seconds. The detector performs a sensitivity test then sends a test
signal to the control panel.
Silence alarm = Press to silence the sounder during an alarm. The sounder and alarm do not silence if smoke is still
present.
Silence trouble chirp = Press to silence a trouble chirp. The trouble chirp resumes after 24 hours if the trouble
condition is not corrected.
Attaching and Removing the Detector
Attach the smoke detector to its mounting base as follows:
1. Line up the raised alignment tab on the lip of the smoke
detector with arrow on the mounting base. See Figure 4.
2. Insert the smoke detector into the base and turn clockwise
approximately 15 degrees. It should snap rmly into place.
To remove the detector from the mounting base, grasp the detector
and turn it counterclockwise approximately 15 degrees. The detector
should snap off of the mounting base. See Figure 5.
Installing or Replacing the Batteries
Observe polarity when installing the battery. Use only Panasonic Model
CR123A or DMP Model CR123-FIRE 3.0V lithium batteries.
When the batteries are low, the detector extinguishes its LED and chirps every 30 seconds until the batteries are
replaced. The sounder can be silenced for 24 hours by pushing the Test/Silence button. See Figure 1.
Note: When setting up a wireless system, it is recommended to program zones and connect the receiver before
installing batteries in the transmitters.
1. Remove the detector from the mounting base. See Attaching and Removing the Detector.
2. Slide the battery compartment cover away from the detector to unsnap it and lift it off. See Figure 3.
3. If replacing the batteries, remove the old batteries and dispose of them properly.
4. Observing correct polarity, insert two new 3V lithium batteries into the battery compartment and replace the
cover. Use only new batteries when replacing old ones.
5. Reattach the detector to the mounting base. See Attaching and Removing the Detector.
6. Test the detector. See Smoke Testing the Detector.
Caution: Properly dispose of used batteries. Do not recharge, disassemble, heat above 212°F (100°C), or
incinerate. Risk of re, explosion, and burns.
Figure 5: Remove Detector from Base

1165/1165H/1165HS Detectors Installation Sheet Digital Monitoring Products
5
Sensor Reset to Clear LOBAT
When the battery needs to be replaced, a LOBAT message will display on the keypad. Once the battery is replaced, a
sensor reset is required at the system keypad to clear the LOBAT message.
1. On a 7000/9000 Series Keypad, press and hold “2” for two seconds. On a 7800/9800 Series Keypad press Reset
on the carousel menu.
2. Enter your user code if required.
3. The keypad displays SENSORS OFF followed by SENSORS ON.
Battery Life Expectancy
Typical battery life expectancy for DMP wireless smoke detectors is at least 1 year. DMP wireless equipment uses
two-way communication to extend battery life.
The following situations can reduce battery life expectancy:
• If a receiver is unplugged or not installed, transmitters send supervision messages until a receiver returns an
acknowledgement.
• Frequent transmissions, such as how often the detector is tested.
• When installed in extreme hot or cold environments.
The following situation can extend battery life expectancy:
• Extend transmitter supervision time in panel programming.
• Infrequent transmission trips, such as extending the detector test time schedule.
Cleaning the Detector
Clean the detector cover with a dry or damp (water) cloth as
needed to keep it free from dust and dirt. When necessary, clean
the detector interior and replace the smoke chamber as follows:
1. Remove the detector from its mounting base. See
Attaching and Removing the Detector.
2. Remove the batteries. See Replacing the Batteries.
3. Slide a at-blade screwdriver in the slot on the detector
cap and gently push the handle down to pry the cap up
and off. See Figure 6.
4. Press the sides of the smoke chamber in where indicated
by the alignment arrows. Pull the chamber up and away
from the detector and discard. See Figure 7.
Note: The part number of the smoke chamber is UTC211.
5. Blow out or use a soft-bristled brush to remove dust and
dirt from the smoke chamber base.
6. Line the new smoke chamber up with the smoke
chamber base by lining up the arrows on the
smoke chamber to the latches on the optical
base and snap down into place.
7. Replace the detector cap as follows:
— Line the cap up with the smoke detector.
— Insert the cap into the smoke detector and
turn clockwise approximately 15 degrees. It
should snap rmly into place
8. Observing correct polarity, insert two new 3V
lithium batteries into the battery compartment
and replace the cover.
9. Reattach the detector to its mounting base. See
Attaching and Removing the Detector.
10. Test the detector sensitivity. See Testing the
Detector Sensitivity.
Important: The control panel alarm and all auxiliary
functions should be veried for a complete test of the
system.
Figure 6: Remove Detector Cap
Figure 7: Detector Parts
Strobe Chamber Latch
Optical Base
Alignment Arrows
Smoke Chamber
Detector Cap

Digital Monitoring Products 1165/1165H/1165HS Detectors Installation Sheet
6
Maintaining the Detector
The 1165/1165H/1165HS detectors are designed for easy eld service and maintenance. When installed and used
properly, they require minimal maintenance. The smoke detector should be functionally tested per NFPA 72 2013 Table
14.4.3.2 for system type smoke detectors. See Testing the Detector Sensitivity and Smoke Testing the Smoke Detector.
When an 1165/1165H/1165HS detector requires maintenance, it extinguishes its LED.
WARNING
Smoke alarms CANNOT provide warnings for res resulting from explosions, smoking in bed or other furniture,
ignition of ammable liquids, vapors and gases, children playing with matches or lighters.
NFPA 72 Guidelines
Total (Complete) Coverage. If required, total coverage shall include all rooms, halls, storage areas, basements,
attics, lofts, spaces above suspended ceilings, and other subdivisions and accessible spaces; and the inside of all
closets, elevator shafts, enclosed stairways, dumbwaiter shafts, and chutes. Inaccessible areas shall not be required
to be protected by detectors. (For exceptions, refer to NFPA 72.)
Partial Coverage. If required, partial detection systems shall be provided in all common areas and work spaces, such
as corridors, lobbies, storage rooms, equipment rooms, and other tenantless spaces in those environments suitable
for proper detector operation in accordance with this code.
Selective Coverage. Where codes, standards, laws, or authorities having jurisdiction require the protection of
selected areas only, the specied areas shall be protected in accordance with this code.
Supplementary (Non required) Coverage. Where installed, detection that is not required by an applicable law, code,
or standard, whether total (complete), partial, or selective coverage, shall conform to the requirements of this
code. (For exceptions, refer to NFPA 72 Spacing Requirements.)
Where non required detection devices are installed for a specic hazard, additional non required detection devices
shall not be required to be installed throughout an entire room or building.
Heat-Sensing Fire Detectors. Heat-sensing re detectors shall be installed in all areas where required by the NFPA
codes and standards or by the authority having jurisdiction.
Detection in New Apartment Buildings. Approved, single-station smoke alarms shall be installed in accordance with
7-6.2.10 of NFPA 101 outside every sleeping area in the immediate vicinity of the bedrooms and on all levels of the
dwelling unit including basements. (For exceptions, refer to this section of NFPA 72.)
Detection in Existing Apartment Buildings. Approved, single-station smoke alarms shall be installed in accordance
with 7-6.2.10 of NFPA 101 outside every sleeping area in the immediate vicinity of the bedrooms and on all levels of
the dwelling unit including basements. (For exceptions, refer to this section of NFPA 72.)
WARNING! Limitations of Smoke Detectors
Wireless smoke alarms are very reliable, but may not work under all conditions. No re alarm provides total
protection of life or property. Smoke alarms are not a substitute for life insurance.
Smoke alarms require a source of power to work. This smoke alarm will not operate and the alarm will not sound
if batteries are dead or not installed properly.
Smoke alarms may not be heard. A sound sleeper or someone who has taken drugs or alcohol may not awaken if the
alarm is installed outside a bedroom. Closed or partially closed doors and distance can block sound. This alarm is not
designed for the hearing impaired.
Smoke alarms may not always activate and provide warning early enough. Smoke alarms only activate when
enough smoke reaches the alarm. If a re starts in a chimney, wall, roof, on the other side of closed doors, or on a
different level of the property enough smoke may not reach the alarm for it to alarm.
Smoke alarms are a signicant help in reducing loss, injury and even death. However, no matter how good a
detection device is, nothing works perfectly under every circumstance and we must warn you that you cannot
expect a smoke alarm to ensure that you will never suffer any damage or injury.
Fire Prevention and Escape
The purpose of an early warning smoke alarm is to detect the presence of re in its early stages and sound an alarm
giving the occupants time to exit the premises safely.

1165/1165H/1165HS Detectors Installation Sheet Digital Monitoring Products
7
Avoid Fire Hazards
No detection device can protect life in all situations. Therefore, safeguards should be taken to avoid potentially
dangerous situations as follows:
• Do not smoke in bed.
• Do not leave children home alone.
• Never clean with ammable liquids such as gasoline.
• Properly store materials. Use general good housekeeping techniques to keep your home neat and tidy. A
cluttered basement, attic, or other storage area is an open invitation to re.
• Use combustible materials and electrical appliances carefully and only for their intended uses. Do not
overload electrical outlets.
• Do not store explosive and/or fast burning materials in your home.
• Even after proper precautions have been taken, res can start. Be prepared.
In Case of Fire
In the event of a re, you should do the following:
• Leave immediately. Don’t stop to pack or search for valuables.
• In heavy smoke, hold your breath and stay low, crawl if necessary.
The clearest air is usually near the oor.
• If you have to go through a closed door, carefully feel the door and door knob to see if undue heat is present.
If they seem cool, brace your foot against the bottom of the door with your hip against the door and one hand
against the top edge. Open it slightly. If a rush of hot air is felt, slam the door quickly and latch it. Unvented
re tends to build up considerable pressure. Be sure all members of the household realizes and understands
this danger.
• Use your neighbor’s phone or a street re alarm box to call the re department. The job of extinguishing the
re should be left to the professionals.
Be Prepared
Practice the following steps to prepare you and your family in the event of a re:
• Perform re drills regularly. Use them to assure recognition of an alarm signal.
• Draw a oor plan and show two exits from each room. It is important that children be instructed carefully,
because they tend to hide in times of crisis.
• Establish one meeting place outside the home. Insist that everyone meet there during an alarm. This will
eliminate the tragedy of someone reentering the house for a missing member who is actually safe.
• If you have children and/or physically challenged people residing in your household, use window decals to
help emergency personnel identify the sleeping quarters of these individuals.

800-641-4282
INTRUSION • FIRE • ACCESS • NETWORKS
www.dmp.com 2500 North Partnership Boulevard
Designed, Engineered and
Assembled in U.S.A. Springeld, Missouri 65803-8877
LT-0698 1.02 © 2017 Digital Monitoring Products, Inc.
17035
Specications
Battery
Life Expectancy At least 1 year
(normal operation)
3.0V Lithium Panasonic CR123A or
DMP CR123-Fire
See Battery Life Expectancy for full details.
Low battery
Threshold signal 2.70V
Beep rate 1 every 30 sec. ± 2 sec.
Sounder pattern
Temporal 85dBa at 10’
Sensitivity 2.3% ±0.8%
Frequency Range 903 - 927 MHz
Dimensions
Detector 5.6” x 2.4”
(14.3cm x 6.1cm)
Base 5.4” x 0.46”
(13.7cm x 0.46cm)
Heat alarm specications:
Rate-of-rise 15°F/min > 105°F
(8.3°C/min > 40.6°C)
Fixed 135°F ± 5°F
(57.2°C ± 2.8°C)
Drift compensation
adjustment 0.5%/ft. max.
Color White
Compatibility
1100X Wireless Receiver
1100XH Wireless High Power Receiver
Patents
U. S. Patent No. 7,239,236
Certications
California State Fire Marshal (CSFM)
FCC Part 15 Registration CCKPC0088
Industry Canada Registration 5251A-PC0088
New York City (FDNY COA #6167)
ANSI/UL 268 Smoke-Automatic Fire Detectors
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modications made by the user and not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Information
This device complies with Industry Canada Licence-exempt RSS standard(s). Operation is subject to the following
two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
