olympia electronics BS-655/A User manual

921655004, 921657002, 921660004_08_006 921655004, 921657002, 921660004_08_006
45
1mA for 2 sec
90μA
12mA (with activated on board LED)
0.107 dB/m0.107 dB/m
-
-
-Α1RΑ1R
EN 54-7 EN 54-7, EN 54-5EN 54-5
Up to 95%
ABS/PC
158 gr.158 gr. 143 gr.
2 years
103 x 48mm 103 x 48mm103 x 55mm
ο
-40 to 70 C
ο
57 Cο 57 C
IP42
17-30V DC
Place the detector carefully so that the side marks are aligned and rotate the detector
clockwise until it locks. Provide power to the device and after 3-5 seconds it is ready for
operation.
4
Mounting Base
Connection
with external
LED
55
R
+
-R
U
T
/O
N
I
+
N
- I
T
U
- O
-R
U
T
/O
N
I
+
N
- I
T
U
- O
From the zone
of the panel
terminal
resistor
-R
U
T
/O
N
I
+
N
- I
T
U
- O
CONNECTION
Connect the power cables (minding the correct polarity) according to the requirements of
the installation.
1. + IN/OUT : It is connected to the zone of the panel or to the (+ IN/OUT) contact of
the previous detector.
2. - IN : It is connected to the zone of the panel or to the (- OUT) contact of the
previous detector.
3. - OUT : It is connected to the next detector (- IN) or if it is the last one to the terminal
resistor.
4. - R : It is connected with BS-572.
5. : Connected to the cable’s shield (when shield is used).
Connection
If the power of the detectors is turned off, wait for 3-5 seconds before you turn the power on
again.
3
4
Warranty
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical
leaflet, which accompanies each product. This warranty ceases to exist if the buyer does not
follow the technical instructions included in official documents given by Olympia Electronics or if
the buyer modifies the goods provided or has any repairs or re-setting done by a third party,
unless Olympia Electronics has fully agreed to them in writing. Products that have been damaged
can be returned to the premises of our company for repair or replacement, as long as the
warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not
charge the buyer depending on the reason of defection. Olympia Electronics reserves the right to
charge or not the buyer the transportation cost.
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.com
inf[email protected]
OPERATION VOLTAGE
START UP POWER CONSUMPTION
STANDBY CONSUMPTION
ALARM CONSUMPTION
SMOKE CONCENTRATION SENSITIVITY
CLASS
OUTPUT
INDICATORS
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATING TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
TEMPERATURE SENSITIVITY
EXTERNAL DIMENSIONS( x height)
Alarm LED
To panel / to external LED (BS-572)
Olympia Electronics - European manufacturer
Thank you for your trust in our products
European
manufacturers
SMOKE DETECTORS &
RATE OR RISE HEAT DETECTORS
1293
21
BS-655/A
Optical smoke detector
EN 54-7:2018
DoP: 921655004_59_002
1922
23
BS-660/A
Rate-of-rise heat detector
ΕΝ 54-5:2017+Α1:2018
DoP: 921660004_59_004
1293
21
BS-657/A
Optical smoke & rate-of-rise heat detector
ΕΝ 54-5:2017+Α1:2018 , ΕΝ 54-7:2018
DoP: 921657002_59_002 EGINIO
PIERIAS
60300
GREECE
Technical Characteristics
CONSTRUCTION COLOR WHITE ANTHRACITE (/C)
TYPE Optical
smoke detector
Optical
smoke & rate-of-rise
heat detector
Rate-of-rise
heat detector
BS-655/A
BS-655/A/C
BS-657/A
BS-657/A/C
BS-660/A
BS-660/A/C

In every device there is a double sticker with the UID (Unique Identifier) number. This number is
unique for each device.
CAUTION !!
•After installation the device must not be covered with dust or be painted or anything else happen
that will block the smoke to get to the sensor. Special attention must be given during the
installation and the use of the device, since the user assumes full responsibility for proper
operation afterwards.
- 360
ooptically visible LED.
(Only for BS-655/A & BS-657/A)
- Automatic fault diagnosis.
- Compensation of smoke measurements based on ambient temperature which ensures high
precision measurements even under extreme environmental conditions.
• Caution! Do not disassembly the detector for cleaning or for any other action.
-Dust compensation and automatic indication when cleaning is required. Stable level of detection
regardless of detector’s working hours.
- Integration of dynamic algorithms for noise and false alarm rejection.
UID:
Additional features of the device :
(Only for BS-655/A & BS-657/A)
1
1
1
1
During site works place the plastic cover to the detector (only for BS-655/A & BS-657/A) as shown in
the picture above to protect the device from dust. Remove the plastic cover when all the site works
have finished.
Accessories
1
2
Installation
Dimensional drawing (mm)
123921655004, 921657002, 921660004_08_006 921655004, 921657002, 921660004_08_006 921655004, 921657002, 921660004_08_006
927600001
927600003
921196000
Note:
BASE-6012/A Base 12V with relay
BASE-6024 Base 24V with relay
BASE-196/N Waterproof base
103
103 103
103
48 55
17
52
Detector
Package Contents
Mounting Accessories
General
Manual
Detector Base
The BS-657/A is a conventional smoke detector which integrates functions of optical smoke
and heat detection. It can detect smoke and heat. The detector transitions to alarm state
when the concentration of smoke reaches 0.107dB/m or when the temperature reaches
o
57 C. Also, the detector transitions to alarm state when the temperature rises suddenly by
o
32 C regardless of the initial temperature at the beginning of the sudden rise event.
For spacings, heights and all mounting points consult the local/national regulation or the
standard EN 54-14/2018. The detectors must be placed at least 50 cm away from fluorescent
2
lamps. Cable cross-section should be from 0.5 to 2.5mm .
The user have to read carefully the following instructions, in order to be properly informed
and keep them for future use.
The BS-655/A is a conventional smoke detector which integrates function of optical smoke
detection. The detector transitions to alarm state when the concentration of smoke reaches
0.107dB/m.
They are composed by two parts. A plastic base which is placed on the ceiling and the main
body of the detector which fits on the plastic base with a simple rotation to the right. The
o
detectors have a 360 visible led and a remote led driver which are light up constantly in case
of detection of fire, till cancelled from the panel. They are turned off only when a reset
command is given from the panel. The indicator led blinks every 7 sec indicating the normal
function.
The BS-660/A is a conventional heat detector which integrates the function of rate-of-rise
o
heat detection. The detector transitions to alarm state when the temperature reaches 57 C.
o
Also, the detector transitions to alarm state when the temperature rises suddenly by 32 C
regardless of the initial temperature at the beginning of the sudden rise event.
INSTALLATION
MAINTENANCE & FUNCTIONAL TESTING
The detector has fault diagnosis and dust compensation functions, which automatically
informs you through the onboard LED when replacement or cleaning actions are required.
The indication LED blinks every 7 seconds. In normal operation it blinks 1 time, if cleaning
action is required it blinks 2 times and if there is a failure it blinks 3 times. After cleaning
procedure it will take about 10 minutes for detector’s working indication to return to normal.
These functions combined with periodic manual testing ensure maximum security level. The
manual testing procedure is carried out by spraying a small amount of smoke into the
detector with an testing spray or a counterpart product. It is suggested to carry out a test
every 6 months or after a change in the position of the sensor. A key element of its proper
function is the air to be able to freely circulate inside it. So be careful not to block the
openings of the outer cover. You can clean the detector by blowing clean pressurised air from
the outer side of the mesh.
Description
Indications LED Status
(Red LED)
Cleaning Action (2 times)
Normal Operation (1 time)
Detector Failure (3 times)
BlinkingPermanently ON
Alarm
Remove the detector from its base by rotating counter-clockwise till the side marks are
aligned.
Fasten the base with the supplied mounting accessories.
