DMR DM-1260 User manual

CE DM-1260
DM R
Digital wireless interphone
RoHs
CQC
USER'S MANUAL

Do not disassemble the device without permission, which may cause device failure, and will
Please do not use device on the following occasions:
reduce the waterproof performance of device.
waterproof performance of the device.
Please do not damage the device and the label on the back of the battery, otherwise it will reduce the
In the launch, the device is not too close to or contact with the exposed parts of the body (especially
Before installing options, be sure to turn off the device power supply.
Device and battery do not charge when wet.
Notice of using device:
Please keep this manual.
IMPORTANT ITEMS
Ƹ
!
z
z
z
z
Ƹ
!
z
z
z
z
z
z
z
z
Precautions for battery use:
Please do not disassemble or refit batteries.
There is a protective circuit inside the battery, disassembly or modification of the battery will lead to damage
to the protection circuit, the battery may produce smoke, rupture or fire.
Do not short-circuit the battery.
Do not use any metal to connect the battery "+" pole and "-" pole, do not use metal object
container to store and store battery. If the battery is short circuited, it will produce too
large current, the battery will heat, smoke, break or fire.
Please do not place the battery near the fire, stove or other heater. Please don't burn or heat the battery.
Batteries can produce heat, fireworks, breaks, or fires.
Do not expose the battery to rain, snow, sea water or any other liquid.
Do not charge or use wet batteries. If the battery gets wet, it must be dried before use.
Precautions for charger:
Please do not plug the vent of the charger, otherwise it may cause internal parts damage and cause electric shock or fire.
Please don't let the charger close to the radiator or heat source; please don't pad the paper under the charger.
Please do not put the charger in a closed container and on the bed, sofa or carpet.
Please do not use the charger in the bathtub, the pool, the swimming pool or the wet basement.
Please do not place the metal sheet in a holder, otherwise the conductive material may damage the machine.
Please don't press the power supply to bend or twist the pins.
Please do not allow the charger to have stains, dust, water traces or food.
Please do not put the charger in high temperature or exposure to the sun.
Please read the instructions carefully before using.
The direct mode, transfer mode, a cluster mode of operation, please consult your dealer.
Ƹ
!
z
z
z
z
z
z
z
z
z
z
z
Ƹ
!
z
z
z
Please do not place the interphone on the unstable surface.
Please don't press the PTT key when you don't want to talk.
the face and eyes), please keep the antenna more than 2.5 centimeters away from the body.
When launching, the distance between the mouth and the microphone is 5 to 10 centimeters, which makes
the sound clearer and reduces the electromagnetic radiation.
Headset headset connected to intercom, please reduce the volume of interphone.
Please do not use the option which is not made by our company.
Do not place the radio at places where the ambient temperature is below -30 or above +60 centigrade or
in direct sunlight.
Near explosive sites.
On the plane.
Near the gas station.
+40

1 Button description...........................................................................................................................................1
2 Basic operations..............................................................................................................................................3
Powering on........................................................................................................................................................3
Channel selection...............................................................................................................................................3
Volume adjusting................................................................................................................................................3
Reception and emission.....................................................................................................................................3
Parameter configuration.....................................................................................................................................4
Work mode.........................................................................................................................................................9
3Device assembly.............................................................................................................................................10
Battery installation and disassembly..................................................................................................................10
Installation and disassembly of antenna............................................................................................................10
Installation and disassembly of belt clip.............................................................................................................11
Equipment fittings...............................................................................................................................................11
Clean..................................................................................................................................................................11
Technical index ..................................................................................................................................................12
&217(176
12
10
7
8
5
6
4
1
2
39
11
%87721'(6&5,37,21
-1-

12
13
Serial number Part name Serial number Part name
1
2
3
4
5
6
7
8
9
10
11
12
SK2 bottom key
Microphone
Speaker
Earphone Headset
Channel switch
Volume / power switch
Battery
Antenna
Belt clamp
Indicator light
PTT Key
SK1 Upper key
%87721'(6&5,37,21
-2-
POWERING ON
¾Start up:
¾Shutdown:
CHANNEL SWITCHING
¾
VOLUME ADJUSTING
¾
¾
RECEPTION AND EMISSION
¾Receive：
¾Emission:
Turn on the intercom and switch to the corresponding
channel. Press PTT, the red light of the indicator
lights up, which means that the transmitter enters
the transmitter, and the microphone is 5-10
centimeters in order to speak. Loosen the PTT,
and the device returns to standby mode.
Turn on the intercom, switch to the corresponding
channel, that is to enter the channel standby state.
When the signal is received, the green light is
switched on and the volume of the loudspeaker is
adjusted to the proper value.
When the interphone turns on the power supply, the
loudspeaker rotates clockwise and the sound becomes larger.
Turn the speaker counterclockwise and make the
sound smaller.
Rotating the channel knob, the white screen printing
on the knob cap aligned to the number printed on the
shell, that is, switch to the corresponding channel.
During switching, the indicator light orange, switch to
complete the channel prompt tone, and indicate the
lights out.
Turn the volume switch counterclockwise, until the
"bang" sound is heard, the intercom power switch is
switched off, and the interphone is turned off.
Clockwise turn the volume switch knob, hear "bang"
sound, the top of the indicator light orange, the speaker
has the starting prompt sound. When the orange indicator
lights out and the channel prompt tone is issued, it shows
that the interphone is started normally. The boot time
is about 8 seconds.
%$6,&23(5$7,216
-3-

PARAMETER CONFIGURATION
¾Write frequency interface:
¾Select communication port:
As shown in Figure 2, after opening the write frequency
software, first click the "communication port" option,
select the corresponding COM port.
Fig. 2 port of communication
¾Set up：
Figure 3 settings
The parameters of the DM-1260 interphone need to be
configured by the write frequency software of the host
computer. Before entering the write frequency software,
the write frequency line USB end is connected with the
computer, and the other end is inserted into the earphone
socket of the interphone.
Figure 1 write frequency software interface
-4-
%$6,&23(5$7,216
¾
¾Key：
¾Cue tone:
The function buttons of interphone SK1 and SK2 can
be configured by "button 3" and "button 4". As shown
in figure 4.
Figure 4 key configuration confidence
Under the "prompt tone" item, you can set up some
beep sounds of the interphone, such as the known
indicator lamp and the low electric alarm function.
As shown in figure 5.
Region:
A walkie talkie can be configured with multiple "zones",
where 16 channels can be set at most. As shown in
figure 6:
Figure 5 prompt tone item
%$6,&23(5$7,216
-5-

Figure 7 adding a digital channelFigure 6 region
The channel in the available channel list refers to the
channel configured in the "digital channel" and "analog
channel" selection. The channel member is the channel
that the user chooses to use, and the number on the
right side of the alias corresponds to the channel number
on the channel switch.
The digital channel and analog channel in the available
channel list should be configured in the "digital channel"
and "analog channel" options.
Digital channel:
Click on the "digital channel" tab to enter. Click the right
button in the blank and add the option. Click to add a
new digital channel. As shown in figure 7.
Click on the corresponding digital channel, the right
window can enter the parameter settings of the
channel. As shown in figure 8.
Among them, the "emission color code for receiving
and transmitting to set"; "launch contact" refers to
people call ID, "receiving list" refers to this as the
transmitter receiver ID number, you can set up a
number of.
-6-
%$6,&23(5$7,216
¾
¾
Figure 8 digital channel parameter setting
Analog channel:
Click on the "analog channel" tab to enter. Click the
right in the blank, add options, click to add a new
analog channel. Similarly, click on the corresponding
analog channel, you can enter the analog channel
parameter settings, as shown in figure 9.
Figure 9 analog channel parameter setting
Hybrid channel:
The mixed channel parameter configuration
interface is shown in figure 10.
Figure 10 mixed channel parameter setting
-7-
%$6,&23(5$7,216

¾
Figure 12 contact setting table
¾List of receive groups:
The list of receiving groups, as its name implies, is the
list set by the receiver for group call, and the call and
full call are not in this list. Multiple or one group can be
integrated into a receiving group. As shown in figure 13.
Figure 13 list setting of receive group
Digital service:
There are two sets of basic parameters and contacts
in the digital service project. "Basic parameters" mainly
refers to some parameters settings of the machine, in
which the "native ID" number is the only identification
code of the customer in the communication group, and
must ensure that the other members of the communication
group ID is different, otherwise the same ID number
members can not realize interoperability. As shown in
figure 11.
Figure 11 configuration of basic parameters
The "contact" configuration is shown in figure 12. Call
alias, call type, call ID and so on. There are more than
one call and group call at the same time. "Full call" can
only be set one, and the number of ID is 16777215. -8-
%$6,&23(5$7,216
¾Scan list:
Figure 14 settings of scan list
"Scan list" sets the channel needed to scan in the scan mode.
The group members are added to the scan channel, "move up"
and "move down" to adjust the scan order.
WORK MODE
The handheld supports conventional mode and cluster mode.
The working mode needs to be configured by the upper computer.
Cluster mode: in this mode, the interphone registers in the system.
Realize voice and data group call, call, cross regional call, scheduling
calls and other functions.
Conventional mode: in this mode, the mode of work is digital
communication and analog communication. Digital communication:
support call, group call, short message and other functions.
Analog communication: has the conventional function of analog
walkie talkie, can communicate with other analog walkie talkie.
%$6,&23(5$7,216
-9-

Battery installation and disassembly Installation and disassembly of antenna
¾
¾
Insert the battery according to the diagram.
According to the direction of the battery
icon into, until I heard a clatter.
¾
¾
The battery button is pushed out in the direction
of the arrow.
Then push the battery in the direction of the arrow.
¾
¾
Clockwise will tighten to the size of antenna antenna.
Turn the antenna out counterclockwise.
-10-
'(9,&($66(0%/<
¾
NUMBER
1Host 1
2Battery 1
3Antenna 1
4Charger 1
5Belt clamp 1
6Instructions 1
The elastic clips of the belt
clip are lifted outwards and
pushed upwards, so that the
belt clip can be dismounted.
¾
The belt clip card in accordance with the slot
position and push down until you hear a "click"
sound installation is complete.
Equipment fittings
Clean
The key, control knob and cabinet of this product are
very dirty. Clean with neutral detergent and non-woven
fabric. Don't use chemical agents such as detergent,
alcohol, spray or petroleum preparation to avoid damage
to the surface and shell. After cleaning, make sure that
the product is completely dry, otherwise don't use it.
z
z
Installation and disassembly of belt clip
SERIAL NUMBER PROJECT
Please regularly use clean dry lint free or brush to wipe
the dust on the surface of the product and the charging
pole.
-11-

12.5KHz(data+voice):7K60F1E
12.5KHz(data only):7K60F1D
High:5W
12.5KHz
Technical index
ＳＰＥＣＩＦＩＣＡＴＩＯＮ
ＲＥＣＥＩＶＥＲ
ＴＲＡＮＳＣＥＩＶＥＲ
400-470MHz 62 X 44 X 147mm
316g
Rubber Rod Antenna
The same frequency of simpiex
or simpiex
50
No Screen16 Screen256
DC 7.4V
-25°C~+60°C
-40°C~+85°C
400-470MHz
12.5KHz
±1.0ppm
0.35uV/-116dBm(20dB SINAD)
0.22uV/-120dBm(Typical)
0.35V/-117dBm(BER 5W)
0.7uV/-110dBm(BER 1%)
TIA 603C: 65dB
ETSI: 65dB
<-57dBm@1GHz
>-47dBm@1GHz
TIA 603C:70dB
84dB
1W
+1dB ~ -3dB
≤3%
ETSI:70dB
TIA 603C: [email protected]
ETSI: [email protected]
400-470MHz
12.5KHz
±1.5ppm
Low: 1W
[email protected]
<-36dBm@1GHz
>-30dBm@1GHz
[email protected]
+1dB~ -3dB
12.5KHz F3E
≤3%
ETSITS102361-1,-2,-3
AMBE+2TM
TIA 603C:[email protected]
ETSI:[email protected]
Analog sensibility
Digital sensibility
Spurious response
Adjacent channel selectivity
Frequency stability
Channel spacing
Frequency Range Spurious response suppression
Receiving spurious emissions
Blocking
Rated audio power
Audio response
Rated audio distortion
TX power
FM noise
Spurious emission
Adjacent channel selectivity
Frequency stability
Channel spacing
Frequency Range Spurious response suppression
RM modulation mode
4FSK digital modulation mode
Modulation limit
Rated audio distortion
Digital protocol
Vocoder type
Channel Vapacity
Channel Spacing
Operating Voltage
Operating Temperature
Storage Temperature
Frequency Range Size
Weight
Antenna Configuration
Antenna Impedance
Working
-12-

FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.

RDELL
include the appropriate bracketed item(s) in the manual.)
REDELL
REDELL
REDELL
RF Exposure Compliance and Control Guidelines and Operating Instructions
To control your exposure and ensure compliance with the occupational/controlled environment
exposure limits always adhere to the following procedures.
Guidelines:
•Do not remove the RF Exposure Label from the device.
• User awareness instructions should accompany device when transferred to other users.
• Do not use this device if the operational requirements described herein are not met.
Operating Instructions:
• Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the
Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting 50 % of the
time, or less, is important because this radio generates measurable RF energy exposure only when
transmitting (in terms of measuring for standards compliance).
• Hold the radio in a vertical position in front of face with the microphone (and the other parts of
the radio, including the antenna) at least one inch (2.5 cm) away from the nose. Keeping the
radio at the proper distance is important because RF exposures decrease with distance from the
antenna. Antenna should be kept away from eyes.
• When worn on the body, always place the radio in a ’s approved clip, holder, holster, case, or
body harness for this product. Using approved body-worn accessories is important because the use
of ’s or other manufacturer’s non-approved accessories may result in exposure levels, which
exceed the FCC’s occupational/controlled environment RF exposure limits.
• Use only manufacturer’s name approved supplied or replacement antennas, batteries, and
accessories. Use of non-manufacturer-name approved antennas, batteries, and accessories may
exceed the FCC RF exposure guidelines.
•For a list of ’s approved accessories (see the user manual), or(The manufacturer should
• For a list of ’s approved accessories (see the user manual)
