Safety Precautions
Product
Do not disassemble, repair, modify your camera or power related accessories. For warranty service,
please contact DOD Tech Support.
Do not adjust camera while driving.
Avoid exposing your camera to extended periods of humidity and/or heat.
Prolonged exposure may reduce the product’s lifespan.
Do not spray water or cleaning agents directly onto the camera.
Fluids may cause fire, electric shocks, or malfunctions.
Avoid installing camera where it may obstruct the driver’s view or airbag deployment.
Car Charger
Use only the power adapter supplied with your unit.
Other power adapters may create a safety hazard or damage the unit.
Do not use damaged power adapters or cords. If damaged, please disconnect the power adapter
and contact DOD Tech Support for assistance.
Do not pull, insert, or bend the power cable using excessive force.
Do not operate or handle power cable with wet hands.
Battery
Keep the device away from heaters or other hot objects.
Store the camera at lower temperatures to reduce the rate of self-discharge and preserves the initial
energy stored in the battery. The battery in the device self discharges over a period of time naturally
whether the battery is used or not.
Charge the dash camera for 5 minutes if you are unable to turn on the camera.
3

Package Contents
1 2
3
DOD LS370W+ Dash Camera User Manual CPL Filter*
4 5 6
Suction Mount Car Charger Adhesive Tape Mount
*CPL filter will reduce reflections from windshield.
Note: Supplied accessories may vary by region.
4

Camera Controls
5

Camera Controls
●
1Record/Shutter/Confirm [ ]
Video Recording- Starts/Stops recording.
Photo- Takes a photo.
Video Playback-Plays/Pauses video.
Settings- Selects highlighted item.
●
2Power [ ]
Turn on/off the unit.
●
3A/V Video Out Port
●
4USB Port
●
5Speaker
●
6Operation Status LED:
Indicates the device operating status.
Steady Blue-Powered off and charging.
Steady Pink-Powering up while charging or is in
Playback Mode.
Steady Red-In Standby Mode but not charging.
Flashing Red-Recording video, not charging.
Flashing Blue & Pink-Recording video and
Charging.
●
7Arrow Key[]/[]
Used to navigate through menus.
Select videos for playback.
●
8
Menu [ ]
Access the setting menu
While recording the video
Press [ ] to stop recording.
Enter the Standby Mode, and
 Press [ ] once to access the Camera Menu.
 Press [ ]twice to access the System Menu.
Note: Cannot access menu while recording
In the Photo Mode
Switch between the two menu settings by
pressing [ ]:
 Camera Menus Settings
 System Menu Settings
In the Video Playback Mode
Press [ ] to enter the menu settings.
Delete file /protect file/create a slideshow.
●
9Mutes Microphone[ ]
To turn off the audio recording, press [ ] and hold
it until the icon appears.
6

Camera Controls
●
10 Mode[ ]
Press [ ] to stop recording.
Enter the Standby Mode.
Switch between 3 Modes by pressing [ ]:
 Video Recording-Starts/Stops recording.
 Photo-Takes a photo.
 Video Playback-Plays/Pauses video.
●
11 3”LCD Screen
●
12 SOS Emergency File Lock [ ]
Press[ ] while recording videos to lock the
current file from being overwritten.
●
13 Micro SD Slot
A Micro SDHC card rated at class 10 or above is
required.
Supports up to 32GB.
●
14 HDMI Out Port
Outputs either live or previously recorded video
over the HDMI connection.
The camera is unable to record while HDMI
output is enabled.
●
15 Reset Button / Microphone
Press to force the device to reboot.
If camera freezes, use a small pin to press button.
7

Getting Started
Setting Up Your Camera
Set up your camera inside your vehicle to ensure easy access to power.
1. Insert the Micro SD Memory Card.
Format the Micro SD card when using the unit for the first time.
To save recorded videos stably, DOD Tech recommends
formatting your SD card every two weeks.
Note:
Please purchase a micro SD card for use with this unit.
After formatting the SD card, all of your data will be lost. Be sure that you have
backed up the important files.
2. Connect the Power Adapter.
Plug the DOD power adapter into your vehicle’s power outlet.
Insert the USB plug into the USB port.
8

GettingStarted
3. Turn on Your Vehicle.
Power from your vehicle through the outlet will automatically turn on your camera and when power
is turned off your camera will shut off automatically. The camera automatically begins recording
every time it is turned on and stops recording when it is turned off.
Note: In some vehicles, the power outlet is continuously providing power, even when the vehicle is turned off.
4. Turn on/off Your Camera.
Press[ ]to turn on or turn off the unit.
5. Select Language→Set the Date and Time
Upon powering up the camera for the first time or after upgrading the firmware on the device, you
will need to go through the Settings below.
Select Language
Select the language of your choice by pressing[] / [].
Press [ ] found on the top of your unit to confirm your selection.
Set the Date and Time Format
Select your Year, Month, Day, Time and press [ ] to confirm.
9

Installing Your Camera
1. Clean Windshield
Wipe down both the interior and exterior glass for the best image quality.
Keep the mount secured to the windshield.
Please insert Micro SD card to the unit.
2. Attach the Mount to Your Camera
3. Prepare the Camera for Installation
Peel off the protective mount cover.
Find a location which does not obstruct your view when driving.
DOD Tech recommends placing the camera behind the rear view mirror without obstructing either
lenses or camera functions.
10

Installing Your Camera
4. Adjust the Angle
Set your camera to the best angle, which do not be blocked by the rearview mirror. The mount has an
adjustable ball joint, which can be loosened using the plastic locking nut. Angle your camera slightly
below the horizon line to minimize glare.
5. Connect the Cigarette Lighter Adapter
If you have not done so previously plug the cigarette adapter into your vehicle’s power port. Insert
the USB plug (opposite end of the power adapter) into the USB port on the camera. The wiring can be
hidden in the headliner and the various seams and rubber strips around the perimeter of the
windshield.
6. Remove the Protective Lens Cover
Congratulations! Your camera is now installed and ready for daily use.
Tips:
Remove any grease, fingerprints, or dirt and dust from the external or internal side of your
windshield to ensure the best recording.
Do not turn on Motion Detection unless your vehicle is parked. If Motion Detection is enabled while
driving, the camera may not continuously record.
DOD Tech recommends setting the G-Sensor to low.
11

BasicCameraOperation
Everyday Operation
Your dash camera will automatically turn on and start recording when it starts receiving power. By
default, the camera will record over the oldest videos when the memory card is full (loop recording).
Continuously Powered Electrical Outlet
If your camera is continuously powered, the camera will not automatically shut down when your
vehicle is turned off. To turn off your camera, the USB cable can be pulled out or the power button
can be pressed (see the below section).
The camera may be left on while parked to capture video while you are away.
“Continuously-Powered-Electrical-Outlet” operation will slowly drain your vehicle’s
battery and may eventually prevent your car from starting.
Manually Turning On / Off Your Camera
Press [ ]to turn on /off your camera.
Press [ ]to begin recording.
12

Camera Modes
When the camera is not recording video, you can switch between three modes by pressing the [ ]:
1. Video Recording
2. Photo
3. Video Playback
1. Video Recording Mode
The camera defaults to video recording when the camera is first turned on.
Recording Mode: Press[ ]to stop recording.
Standby Mode: Press[ ] to access two Modes: Photo Mode and Playback Mode.
Microphone (
on)
White Balance (Auto)
Date/Time
Exposure Value(Auto)
Loop Recording (3 Minutes)
WDR Enabled
Recording
Status
Video Recording Mode
Video Resolution
Motion Detection
(Enable in parking mode)
Memory Card Inserted
Power Status
Time Elapsed
SOS Emergency File Lock
ISO sensitivity
Parking mode
13

Camera Modes
2. Photo Mode
 Press [ ] once to enter the Photo Mode during the Standby Mode.
 Press [ ] to take a photo.
Note: Photo Mode is only accessible during the Standby Mode.
Memory Card Inserted
Image Quality
White Balance
(
Auto
)
Power Connected
ISO Sensitivity
(
A
uto
)
Exposure Value
(
Auto
)
Shake Reduction
(
on
)
WDR Enabled
Camera Mode
Image Resolution
S
elf
-
Timer
(
2s)
14

Camera Modes
3. Playback Mode
You can watch previously recorded videos in Playback Mode.
Press [ ] twice to enter the Playback Mode during the Standby Mode.
 Play the Video
 Press [ ] to play and pause.
 Press [] / []to move or back forwards and press [ ] to enter the Playback Mode.
 Delete Files from the card(This cannot be undone).
 Press [ ] to enter Playback Menu during Playback Mode.
 Press [] / []to delete the file and press [ ] to confirm.
 Protect the current file from being overwritten or erased
 Press [ ] to enter Playback Menu during Playback Mode.
 Press [] / []to lock the file.
 Press [ ] to confirm. If protected, a blue padlock icon will appear at the top of the screen.
 Press [ ] to exit.
Note: The “Format” setting will erase all files including locked files.
 Slideshow
 Press the menu button and navigate to slideshow.
 Photos and the first frame of each video will be shown in order.
Video File Name
Video Resolution
Power Connected
Play/Pause Indicator
Playback Mode
15

Camera Settings
Each mode has a unique set of settings. See the description below.
Video Recording: First Settings Page
Accessed by pressing[ ] once.
WDR (Wide Dynamic Range)
Cannot be changed.
Shows WDR processing is enabled.
Resolution
Changes the video resolution. Lower the resolution for
smaller file sizes but this reduces video quality.
Recommended
s
etting: 1080P FHD.
Exposure
Value
Sets the brightness /darkness of the video.
Video too bright? Set between -1 to -3.
Video too dark? +1 to +3.
Recommended
s
etting: 0.
White Balance
Sets the white balance.
Recommended setting: Auto.
Record Audio
Switches the microphone on/off.
Can be used during recording by pressing button [
].
Date Stamp
Imprints the time and date on the recorded video.
Loop Recording
Can be set to 2, 3 or 5 minutes. Video recordings of
the selected length will be recorded onto the memory
card. When the memory card is full, the oldest files
will be overwritten, excluding locked clips. Turing off
loop recording will prevent the camera from writing
new files when the memory card is filled.
G
–
Sensor
Measures shock forces. The settings from “low to
high” determine the amount of force needed to lock
the file from being overwritten.
Recommended setting: Low.
Two Camera
Settings pages are accessible:
Video Recording Settings
System Settings
The menu settings can be switched by pressing [ ].
If you move the cursor before pressing [ ], you must exit and try again.
Note: Press [ ]to enter the camera settings when recording.
16

Camera Settings
Video Recording: First Settings Page
Accessed by pressing [ ] once.
Parking mode (Default: off)
When function is enabled, dashboard camera will automatically switch to parking mode if vehicle is stationary for
over 10 minutes.
1. Automatically records a 15-second video when motion detected within view range of camera.
2. Automatically records and locks a 1-minute video when excessive force of impact is detected by G-sensor.
3. Unit will return to normal recording mode if vehicle moves continuously for 3 seconds or longer.
Note:
 Parking Mode requires consistent power supply via vehicle battery. (Power cord with low-voltage protection is
recommended to prevent battery drainage.)
 Please ensure to enable G-sensor function in setting menu before switch to Parking Mode. (G-sensor
sensitivity Default: Medium)
Plate Stamp
Imprints a customized set of 8 digits to the recorded
video. Add license plates or other identifying features
to watermark your video.
Password Settings
Set a password lock which will prevent files from being
deleted or the settings changed on the device.
Note: This does not prevent other users from
extracting the memory card or changing the files. This
feature should be turned off during regular driving.
Speed Units
Select Metric or Imperial units.
Image Rotation
Rotates the recorded image 180o. Used if the camera is
mounted o
n the dashboard.
Time-Lapse
The time-lapse function is used to create a sped-up
video. When set, the camera will record one frame
every 200ms (milliseconds)/500 ms/1 second/5
seconds.
ISO Stamp
On/ Off
Default: On.
17

Camera Settings
System Settings: Second Setting Page
Accessed by pressing [ ] twice.
Format
Completely deletes all files including locked footage on
the Memory Card and optimizes the card for
recording. 64GB cards should use DOD's formatting
program for proper functionality. See the support
section online.
Language
Sets the language.
Date/Time
Sets Year/Date/Time format.
Frequency
Adjusts the camera's frequency setting to minimize
flickering and banding in the recorded video.
Beep Sound
Turns
on
/
off
notification sounds.
Screen Saver
Turns
off
the screen after the set time.
TV Mode
Switches between the NTSC and PAL video output
standard.
Version
Shows the model name and current firmware version.
Default Settings
Sets all settings back to the original settings.
18
