DOD TEC8G User manual

Owner’s Guide
Introduction
Welcome to the world of the DOD TEC8G! You have purchased the finest
guitar signal processor and preamp of its kind; hardly a surprise when it
comes from DOD. The TEC8G gives you both functional flexibility and
tonal excellence, driven by our proven effects processing technology.
Specifications
Up to 8 effects at a time
Ergonomic look and feel
Built-in effect Expression Pedal
Analog IT™ and Grunge™ Distortions
3-band EQ
Effects include: Compressor, 8 Analog Distortions, Noise Gate, Chorus,
Flanger, Phaser, Tremolo, Ring Modulator, Pixellator, Pitch, Shift, Detune,
Mono and Tap Delays, Reverb
Easy-to-use interface
30 User, 30 Factory Presets
Jam-a-long™ Jack
A/D Resolution: 18 Bit
D/A Resolution: 16 Bit
DSP: 24 bit
Frequency Response: 20Hz to 16kHz
Signal to Noise Ratio: -87dB
Power Supply: DOD PS750, 9 VAC @ 750 ma

IMPORTANT!
FOR YOUR PROTECTION, PLEASE READ THE FOLLOWING:
WATER AND MOISTURE: Appliance should not be used near water (e.g. near a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so
that objects do not fall on and liquids are not spilled into the enclosure through openings.
POWER SOURCES: The appliance should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.
GROUNDING OR POLARIZATION: Precautions should be taken so that the grounding or polarization
means of an appliance is not defeated.
POWER CORD PROTECTION: Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from the appliance.
SERVICING: The user should not attempt to service the appliance beyond that described in the oper-
ating instructions. All other servicing should be referred to qualified service personnel.
FUSING: If your unit is equipped with a fuse receptacle, replace with only same type fuse. Refer to
replacement text on the unit for correct fuse type.
Warranty
1. The warranty registration card must be mailed within ten days after purchase date to
validate this warranty.
2. DOD warrants this product, when used solely within the U.S., to be free from defects in
materials and workmanship under normal use and service.
3. DOD liability under this warranty is limited to repairing or replacing defective materials
that show evidence of defect, provided the product is returned to DOD WITH RETURN
AUTHORIZATION, where all parts and labor will be covered up to a period of two (2)
years. A Return Authorization number may be obtained from DOD by telephone. The
company shall not be liable for any consequential damage as a result of the product’s
use in any circuit or assembly.
4. Proof-of-purchase is considered to be the burden of the consumer.
5. DOD reserves the right to make changes in design or make additions to or improve-
ments upon this product without incurring any obligation to install the same on prod-
ucts previously manufactured.
6. The foregoing is in lieu of all other warranties, expressed or implied, and DOD neither
assumes nor authorizes any person to assume for it any obligation or liability in con-
nection with the sale of this product. In no event shall DOD or its dealers be liable for
special or consequential damages or from any delay in the performance of this warran-
ty due to causes beyond their control.
DOD® and TEC8G™ are registered trademarks of DOD Electronics Corporation.
The information contained in this manual is subject to change at any time without notifica-
tion. Some information contained in this manual may also be inaccurate due to undocu-
mented changes in the product or operating system since this version of the manual was
completed. The information contained in this version of the owner's manual supersedes
all previous versions.

SECTION 1 - GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
PROGRAM AND BANK SELECTOR FOOTSWITCHES . . . . . . . . . . . . . . . .2
EFFECT SELECTOR BUTTONS (DIGITAL FX) . . . . . . . . . . . . . . . . . . . . . .2
EFFECT GROUPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
EFFECT SELECTOR BUTTONS (PREAMP) . . . . . . . . . . . . . . . . . . . . . . . .2
STORE BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
DATA WHEEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CLIP LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......
3OUTPUT KNOB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
INPUT KNOB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
EXPRESSION ASSIGN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Rear Panel Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
INSTRUMENT INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
JAM-A-LONG™ INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
HEADPHONE OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
LEFT / MONO OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
RIGHT OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
AC POWER INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
POWER CORD STRAIN RELIEF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Hooking Up and Supplying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
SECTION 2 - PROGRAMMING THE TEC8G . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Navigating The TEC8G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Selecting Programs in the TEC8G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
User LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Using The Footswitches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Selecting Programs using the footswitches . . . . . . . . . . . . . . . . . . . . . . . . . .5
Editing Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Expression Pedal Assign . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Storing Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Bypassing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
The TEC8G's Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
DISTORTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
EQUALIZER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CHORUSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
FLANGERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
PHASERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......
10 TREMOLO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
RING MODULATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
PIXELLATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
DELAYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Tuner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Accessing the Tuner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Changing the Tuning Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Factory Program Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Factory Program List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
1

SECTION 1 - GETTING STARTED
Front and Rear Panel Controls
1) PROGRAM and BANK SELECTOR FOOTSWITCHES - These
footswitches give you access to the User Programs in the TEC8G and
allow you to change User Banks.
2) EFFECT SELECTOR BUTTONS - This row of buttons lets you select
an effect group for editing, or to bypass the group completely. These
groups include Master Level, Reverb, Delay, Detune, Pitch Shift, Phase,
Tremolo, Ring Modulator, Pixellator, Chorus, Flange, Gate, EQ,
Distortion, and Compressor.
3) EFFECT GROUPS - The TEC8G's effects are divided into 14 groups
and labeled on the front panel. When lit, the LED in each group indi-
cates that an effect in the group is active.
4) TUNER LEDS - These LEDs become active when the tuner is selected
and a note is played. Used in conjunction with the Program Display,
they will show whether the input note is sharp or flat.
5) STORE BUTTON - Stores your custom Programs in the User memory
location you select.
6) DISPLAY - The LED display in Program mode, shows which Bank and
Program is currently selected. In Edit mode, it shows the number
and/or status of the selected effect. In Tuner mode, it displays the input
note.
7) DATA WHEEL - In Program mode, use the Data wheel to scroll through
Programs. In Edit mode, use it to change the setting of effect groups.
2
2
1
3456
789 10 11 12

8) CLIP LED - The red Clip LED lights when clipping occurs at the input of
the TEC8G or when the Master Level may be too high. To eliminate
clipping, reduce the setting of the Input Level control or the Master
Level parameter until it only blinks occasionally with peak signals.
9) OUTPUT KNOB - Controls the overall output level of both the Left and
Right outputs and the Headphone output.
10) INPUT KNOB - Controls the level of the signal at the TEC8G's input
stage.
11) EXPRESSION PEDAL - Controls the parameter selected by
Expression Assign Group. (See Expression Assign on page 8.)
12) EXPRESSION ASSIGN. - Expression Assign selects which effect para-
meter is controlled by the Expression Pedal.
1) INSTRUMENT INPUT - Plug your instrument in here.
2) HEADPHONE OUTPUT - This stereo mini phone plug is for your head-
phones. The overall headphone level is controlled by the Output level
knob.
3) JAM-A-LONG™ INPUT - This stereo mini jack lets you connect your
tape deck or CD player headphone output to the TEC8G for personal
jam sessions. The Jam-a-Long™ signal is mixed with your instrument
signal at both the main and headphone outputs so you can play along
with your favorite tunes.
4) LEFT / MONO OUT - For stereo applications, this is the Left main out-
put. Use this jack for mono applications.
5) RIGHT OUT - For stereo applications, this is the Right main output. For
mono applications, leave this jack unconnected.
6) AC POWER ADAPTER INPUT - Connect the supplied PS750 AC power
adapter to this jack. Use only the adapter supplied with the TEC8G.
Use of any other adapter may damage the unit.
7) POWER CORD STRAIN RELIEF - This clip prevents the AC power cord
from being accidentally pulled out.
3
