DOD Bass30 User manual

I
These symbols are internationally accepted symbols that warn of potential
hazards with electrical products.The lightning flash means that there are
dangerous voltages present within the unit.The exclamation point indicates
that it is necessary for the user to refer to the owners manual.
These symbols warn that there are no user serviceable parts inside the unit.
Do not open the unit. Do not attempt to service the unit yourself. Refer all
servicing to qualified personnel. Opening the chassis for any reason will void
the manufacturer’s warranty. Do not get the unit wet. If liquid is spilled on
the unit, shut it off immediately and take it to a dealer for service.
Disconnect the unit during storms to prevent damage.
Warning
For your protection, please read the following:
Water and Moisture: Appliances should not be used near water
(e.g. near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.) Care should be taken so
that objects do not fall and liquids are not spilled into the enclosure
through openings.
Power Sources: The appliance should be connected to a power
supply only of the type described in the operating instructions or as
marked on the appliance.
Grounding or Polarization: Precautions should be taken so that
the grounding or polarization means of an appliance is not defeated.
Power Cord Protection: Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
appliance.
Servicing: To reduce the risk of fire or electrical shock, the user
should not attempt to service the appliance beyond that described in
the operating instructions.All other servicing should be referred to
qualified service personnel.
For units equipped with externally accessible fuse recepta-
cle: Replace fuse with same type and rating only.
Electromagnetic Compatibility
Operation is subject to the following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received, including interfer-
ence that may cause undesired operation.
•Use only shielded interconnecting cables.
•Operation of this unit within significant electromagnetic fields should
be avoided.

DECLARATION OFCONFORMITY
Manufacturer’s Name: DOD Electronics
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070
declares that the product:
Product Name: Bass30
Product Options: All (requires a Class II power adapter that conforms to the requirements of EN60065, EN60742, or equivalent).
conforms to the following product specifications:
Safety: EN 60065 (1993)
IEC65(1985) with Amendments 1, 2, 3
EMC: EN 55013 (1990)
EN 55020 (1991)
Supplementary Information:
The product herewith complies with the requirements of the Low voltage directive 73/23/EEC and the EMC Directive 89/336/EEC as amended by directive
93/68/EEC. DOD Electronics
Vice President of Engineering
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Effective (8/17/99)
European Contact: Your local DOD Sales and Service or
Harman Music Group
8760 S. Sandy Parkway
Sandy, Utah, USA
Tel: [phone]
Fax: [phone]
II

Table of Contents
Safety Information................ I
Declaration of Conformity.... II
Table of Contents................. III
Introduction
Congratulations................... 1
Included Items................... 1
Features.............................. 1
Section One
A Guided Tour..................... 2
Front Panel......................... 2
Rear Panel.......................... 5
Getting Started.................... 6
Making Connections........... 6
Section Two
Performance Mode.............. 8
Selecting a Preset................. 8
Data Wheel.......................... 8
Footswitches........................ 9
Accessing the Tuner............. 10
Jam-A-Long.......................... 11
Section Three
Editing a Preset................... 12
User Interface..................... 12
Expression Pedal................ 15
Storing/Copying.................. 17
Section Four
Effect Definitions................ 18
Compressor/Limiter.......... 18
Wah/AutoWah................... 18
Modeling.......................... 18
Fretless........................... 19
Bass Synth...................... 19
Noise Gate........................ 20
Mod/Pitch........................ 20
Delay................................ 21
Phrase Sampler.............. 22
Reverb.............................. 23
Parameter Definitions........ 23
Section Five
Creating a Preset................. 26
Section Six
Resetting the Bass30........... 30
Pedal Calibration................ 31
Maintenance....................... 31
Section Seven
Warranty............................ 32
Specifications.................... 33
III

Introduction
Congratulations!
You are now the proud owner of the Bass30 complete Bass Guitar system. The Bass30 is an extremely powerful tool capable of
producing virtually any sound that you can imagine. It offers Amp/Guitar Modeling, Bass Synthesis, and a host of great sounding
effects including: Frequency Selective Compression, Distortion, Equalization, Noise Gate, Chorus, Flanger, Phaser, Vibrato, Pitch
Shifter, Pitch Bending, Bass Enhancer, Detuner, Enveloped Effects, Wah, Auto Wah, Delay, Pong Delay, Phrase Sampler, Reverb,
and a Crossover for bi-amp applications. The Bass30 also includes a chromatic tuner, the Jam-A-Long™ function and a built-in
expression pedal capable of controlling effects in real time. This Owner’s manual is your guide to getting the most out of your
Bass30. Please read it carefully, to get familiar with the controls of the Bass30. This will ensure years of musical satisfaction.
Included Items
Your Bass30 was carefully assembled and packaged at the factory. Before proceeding any further please make sure the following
items are included.
• 1 Bass30 Bass Guitar System
• 1 PS750 External Power Supply
• 1 Owner’s Manual
• 1 Warranty Registration Card
• 1 Preset Card
Please save all packing materials, and take a moment to fill out the warranty registration card. It is your safeguard in the unlikely
event that your Bass30 needs servicing. Please use the packing materials to return the unit if necessary.
Features
1
• Authentic Amp/Guitar Modeling
• Built-in Expression Pedal
• 30 User/30 Factory Presets
• Up to 9 Effects at Once
• Stereo Outputs
• Chromatic Tuner
• Phrase Sampler
• Jam-A-Long™
• Headphone Output
• Bi-Amp Capabilities
