Dodge 2009 Dakota User manual

2009
QUICK REFERENCE GUIDE
DAKOTA
175476_09a_Dakota_102408.indd 6 4/24/09 1:45:03 PM

MANUAL CLIMATE CONTROLS
AIR RECIRCULATION
 Use recirculation for maximum A/C operation.
 For window defogging, turn recirculation off.
 Recirculation is not allowed in defrost or defrost/floor
(mix) modes.
uconnect™phone
 uconnect™phone is a voice-activated, hands-free, in-vehicle,
communications system. uconnect™phone allows you to
dial a phone number with your cellular phone using
voice commands.
uconnect™phone requires a cellular phone equipped with
the Bluetooth®Hands-Free Profile, Version 0.96 or higher.
See the www.dodge.com/uconnect website for supported
phones. Refer to your Owner’s Manual for further information.
REAR CARGO AREA UTILITY RAILS
 There are four adjustable cleats in the pick-up bed that can be
used to assist in securing cargo. Each cleat must be located
and tightened down in one of the detents along either rail, in
order to keep cargo properly secure.
 Refer to Owner’s Manual for further details.
Rotate
Blower
Control
Rotate
Temperature
Control
Rotate
Mode
Control
Push
A/C
Button
Air
Recirc.
Push Rear
Window
Defroster
Button
175476_09a_Dakota_102408.indd 2 4/24/09 1:44:37 PM

DRIVER’S SEAT ADJUSTMENT
SEAT ADJUSTMENT
 On manual seats, the adjusting lever controls forward
and rearward seat adjustment.
The recline lever controls the seatback adjustment.
Rotate the dial located on the outboard side of the seatback
to adjust lumbar “lower back” support.
 Up, down, forward, rearward, and tilt adjustment are power
seat adjustments.
REAR “CRATE ‘N GO” STORAGE
 The rear “Crate ‘n Go” storage, located under the rear
seat lower cushion, consists of two removable, collapsible
storage crates.
 To open the crates, lift upwards on the crate handles, and
engage the crate end flaps.
 To remove the crate, press on the release lever, located on the
ends of the base, and lift up on the crate.
 To install the crate into the base, insert the crate into the
inboard slot and push down on the outboard side of the crate,
then snap into place.
 To collapse the crate, push the crate end flaps inward to
disengage. Push the sides inward and snap into the base.
 Refer to Owner’s Manual for further details.
Recline
Up, Down, Forward,
and Rearward Lumbar Dial
175476_09a_Dakota_102408.indd 3 4/24/09 1:44:42 PM

VEHICLE FEATURES
Fuel cap
LOOSE GAS CAP MESSAGE

tighten the gas cap until a “clicking” sound is heard.
 
  
tightening the gas cap, see your dealer.
Tire pressure MoniToring sysTeM (TpMs)

Monitoring Light will illuminate and an audible chime will sound.
  Check the inflation pressure of each road tire on your vehicle and
inflate to the recommended cold pressure value, shown on the placard
located in the driver’s door opening. The TPMS display should not be
used as a tire pressure gauge when adjusting your tire pressure.
   
recognized. The vehicle may need to be driven for up to 10 minutes
above 15 mph (25 km/h) before the light will turn off.
  Temperature changes can affect tire pressures, causing the TPMS light
to turn on. Colder temperatures will decrease tire pressure and
warmer temperatures will increase tire pressure.
   
Refer to your Owner’s Manual.
oil change indicaTor
MESSAGE
 
single chime sounds, it is time for your next required oil change.
RESETTING LIGHT AFTER SERVICING
 
 
 
175476_09a_Dakota_102408.indd 4 4/24/09 1:44:44 PM

VEHICLE FEATURES
clock seTTing
NON-TOUCH-SCREEN RADIOS
 
SCROLL control knob to set the hours.
 
turn the TUNE/SCROLL control knob to set the minutes.
 
TOUCH-SCREEN RADIOS
  
  
 
Radio Only).
 
backward button.
 
minute backward button.
 
is displayed.
SPARE TIRE REMOVAL
 The scissor jack and tire changing tools on Extended Cab models are
located behind a panel on the outboard side of the right rear passenger
seat. On Crew®Cab models, the scissor jack and tire changing tools
are located below the right rear seat.
 Remove the jack from the stowage compartment.
 Assemble jacking tools.
 Locate the tire carrier access hole on the rear bumper.
 Place assembled jack tool extension rod into the access hole in the
direction of the arrow on the bumper trim.
 Rotate the tool counterclockwise to release and lower the spare tire to
the ground so that it can be pulled out from under the vehicle.
 Refer to Owner’s Manual for proper jacking and tire change procedures.
175476_09a_Dakota_102408.indd 5 4/24/09 1:44:45 PM

Headlight Switch
(Behind Steering Wheel)
Turn Signals/Wiper/
Washer/High Beams Lever
(Behind Steering Wheel)
Speed Control
Switches
Instrument
Cluster
INSTRUMENT PANEL
175476_09a_Dakota_102408.indd 7 4/24/09 1:45:08 PM

Instrument
Cluster
Column
Shift Lever
Audio System
(Non-Touch-Screen
Radio Shown)
Power Outlet
Climate
Controls
INSTRUMENT PANEL
175476_09a_Dakota_102408.indd 8 4/24/09 1:45:13 PM

Power Outlet
key Fob


 
twice within five seconds to unlock all the doors.
  
  
 
PANIC ALARM

 
time to turn the panic alarm off.
REMOTE START

Pressing the button a third time will shut the engine off.
 
ignition and turn to the ON/RUN position.
 
unless the ignition key is placed in the ON/RUN position.
 
consecutive timeouts.
VEHICLE FEATURES
Remote
Start
Lock
Unlock
175476_09a_Dakota_102408.indd 9 4/24/09 1:45:23 PM

headlighT swiTch


the second detent for headlights.
 
 
on or off based on ambient light levels.
DIMMER CONTROL
 
dim the instrument panel lights and prevent the interior lights from
illuminating when a door is opened.
  
instrument panel lights when the parking lights or headlights are on.
  
brighten the odometer and radio displays when the parking lights or
headlights are on. Refer to your multimedia or navigation user
manual for display dimming.
 
interior lighting.
FOG LIGHTS
 
once to turn the fog lights on. Push the switch a second time to turn the
fog lights off. Fog lights will not operate when the high beams are on.
 
fog lights are on.
VEHICLE FEATURES
Rotate
Headlight
Switch
AUTO
Push Fog
Lights
Rotate
Dimmer
Push
Cargo Light
175476_09a_Dakota_102408.indd 10 4/24/09 1:45:30 PM

speed conTrol
CRUISE ON/OFF
 
 
Speed Control is on.
 
SET

desired speed.
ACCEL/DECEL

hold the Decel switch to decelerate the vehicle, release the switch to
save the new set speed.
 
switch once will increase or decrease the set speed approximately
1 mph (2 km/h).
CANCEL

the set speed and maintain the set speed memory.
 
speed memory.
RESUME
 
Resume/Accel switch and release.
Push
ON/OFF Push
Resume - Accel
Push
Cancel
Push
Decel
Push
Set
175476_09a_Dakota_102408.indd 11 4/24/09 1:45:37 PM

Wipers
Pull Lever for
High Beams
Push Washer
Turn signals/wiper/washer/high beaMs leVer
TURN SIGNALS/LANE CHANGE ASSIST

flash three times then automatically turn off.
WIPERS
Intermittent, Low and High Operaton
 
intermittent settings, the second detent for low wiper operation and
the third detent for high wiper operation.
Washer Operation
 
long as spray is desired.
HIGH BEAMS
 
 
high beam lights are on.
WIND BUFFETING
 Wind buffeting can be described as a helicopter-type percussion
sound. If buffeting occurs with the rear windows open, adjust the
front and rear windows together.
175476_09a_Dakota_102408.indd 12 4/24/09 1:45:43 PM

Dakota
First Printing
Quick Reference Guide
81-316-0997
Dodge is a registered trademark of Chrysler LLC.
www.DODGE.com
This guide has been prepared to help you get quickly acquainted
with your new Dodge and to provide a convenient reference source
for common questions. However, it is not a substitute for your
Owner’s Manual.
For complete operational instructions, maintenance procedures and
important safety messages, please consult your Owner’s Manual,
Navigation Radio User Manual, Multimedia User Manual and other
Warning Labels in your vehicle.
Not all features shown in this guide may apply to your vehicle.
For additional information on accessories to help personalize your
vehicle, visit www.mopar.com or your local Dodge dealer.
