Dodge 2016 Dart User manual

16PFD41-926-AA
DART
FIRST EDITION
USER GUIDE
DOWNLOAD A FREE
ELECTRONIC COPY OF THE OWNER’S
MANUAL AND WARRANTY BOOKLET
BY VISITING:
WWW.DODGE.COM/EN/OWNERS/MANUALS
OR WWW.DODGE.COM/EN/WARRANTY ( U . S . ) ;
WWW.OWNERS.MOPAR.CA/EN (CANADA).
© 2015 FCA US LLC. ALL RIGHTS RESERVED.
DODGE AND DART ARE REGISTERED TRADEMARKS OF FCA US LLC.
2016
DART
USER
GUIDE
1888383_16a_Dart_UG_050615.indd 1 5/6/15 10:26 AM

The driver’s primary responsibility is
the safe operation of the vehicle.
Driving while distracted can result in
loss of vehicle control, resulting in a
collision and personal injury. FCA US
LLC strongly recommends that the
driver use extreme caution when
using any device or feature that may
take their attention off the road. Use
of any electrical devices, such as
cellular telephones, computers,
portable radios, vehicle navigation
or other devices, by the driver while
the vehicle is moving is dangerous
and could lead to a serious collision.
Texting while driving is also
dangerous and should never be done
while the vehicle is moving. If you
find yourself unable to devote your
full attention to vehicle operation,
pull off the road to a safe location
and stop your vehicle. Some states or
provinces prohibit the use of cellular
telephones or texting while driving. It
is always the driver’s responsibility
to comply with all local laws.
IMPORTANT
This User Guide is intended to familiarize you with the important features
of your vehicle. The DVD enclosed contains your Owner’s Manual,
Navigation/Uconnect Manuals, Warranty Booklets, Tire Warranty and
Roadside Assistance (new vehicles purchased in the U.S.) or Roadside
Assistance (new vehicles purchased in Canada) in electronic format.
We hope you find it useful. Replacement DVD kits may be purchased by
visiting www.techauthority.com.
DODGE.COM (U.S.)
DODGE.CA (CANADA)
This guide has been prepared to help you get quickly acquainted with your
new Dodge and to provide a convenient reference source for common
questions. However, it is not a substitute for your Owner’s Manual.
For complete operational instructions, maintenance procedures and
important safety messages, please consult your Owner’s Manual, Navigation/
Uconnect Manuals and other Warning Labels in your vehicle.
Not all features shown in this guide may apply to your vehicle. For additional
information on accessories to help personalize your vehicle, visit
www.mopar.com (U.S.), www.mopar.ca (Canada) or your local Dodge dealer.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes
of accidents. Your driving ability can be seriously impaired with
blood alcohol levels far below the legal minimum. If you are drinking,
don’t drive. Ride with a designated non-drinking driver, call a cab,
a friend, or use public transportation.
WARNING!
Driving after drinking can lead to an accident. Your perceptions are
less sharp, your reflexes are slower, and your judgment is impaired
when you have been drinking. Never drink and then drive.
If you are the rst registered retail owner of your vehicle, you may
obtain a complimentary printed copy of the Owner’s Manual,
Navigation/Uconnect Manuals or Warranty Booklet by calling
1-800-423-6343 (U.S.) or 1-800-387-1143 (Canada) or by
contacting your dealer.
1888383_16a_Dart_UG_050615.indd 2 5/6/15 10:26 AM

INTRODUCTION/WELCOME
WELCOME FROM FCA US LLC .......2
CONTROLS AT A GLANCE
DRIVER COCKPIT ...............4
INSTRUMENT CLUSTER ...........6
GETTING STARTED
KEYFOB ....................8
REMOTESTART ................9
KEYLESS ENTER-N-GO ...........10
VEHICLE SECURITY ALARM ........14
SEAT BELT SYSTEMS ............16
SUPPLEMENTAL RESTRAINT SYSTEM
(SRS) — AIR BAGS .............17
CHILD RESTRAINTS ............24
HEAD RESTRAINTS .............28
FRONT SEATS ................30
REAR SEAT ..................32
HEATEDSEATS ...............33
HEATED STEERING WHEEL —
IF EQUIPPED .................34
TILT/TELESCOPING STEERING
COLUMN ...................35
OPERATING YOUR VEHICLE
ENGINE BREAK-IN
RECOMMENDATIONS ............36
TURN SIGNAL/WIPER/WASHER/HIGH
BEAM LEVER .................37
HEADLIGHT SWITCH ............39
ELECTRONIC SPEED CONTROL —
IF EQUIPPED .................40
MANUAL CLIMATE CONTROLS .......44
UCONNECT 8.4 MANUAL CLIMATE
CONTROLS ..................45
UCONNECT 8.4 AUTOMATIC CLIMATE
CONTROLS ..................47
BLIND SPOT MONITORING .........49
PARKVIEW REAR BACK UP CAMERA —
IF EQUIPPED .................49
POWER SUNROOF — IF EQUIPPED . . . 51
MANUAL TRANSMISSION —
IF EQUIPPED .................53
SIX-SPEED AUTOMATIC TRANSMISSION . . . 54
ELECTRONICS
YOUR VEHICLE'S SOUND SYSTEM ....56
UCONNECT 200 ...............58
UCONNECT 8.4 & 8.4N ...........68
STEERING WHEEL AUDIO CONTROLS . . 96
ELECTRONIC VEHICLE INFORMATION
CENTER (EVIC) — STANDARD
(2 BUTTON) ..................97
DRIVER INFORMATION DISPLAY (DID) —
PREMIUM (4 BUTTON) ...........98
UCONNECT 8.4 CUSTOMER
PROGRAMMABLE FEATURES ......101
UNIVERSAL GARAGE DOOR OPENER
(HomeLink) .................102
POWER OUTLET ..............105
UTILITY
TRAILER TOWING WEIGHTS (MAXIMUM
TRAILER WEIGHT RATINGS) .......106
RECREATIONAL TOWING (BEHIND
MOTORHOME, ETC.) ............107
WHAT TO DO IN EMERGENCIES
ROADSIDE ASSISTANCE ..........108
INSTRUMENT CLUSTER WARNING
LIGHTS ...................108
INSTRUMENT CLUSTER INDICATOR
LIGHTS ...................114
IF YOUR ENGINE OVERHEATS ......115
JACKING AND TIRE CHANGING .....116
TIRE SERVICE KIT .............124
JUMP-STARTING PROCEDURES .....130
SHIFT LEVER OVERRIDE .........133
TOWING A DISABLED VEHICLE .....134
FREEING A STUCK VEHICLE .......134
ENHANCED ACCIDENT RESPONSE
SYSTEM (EARS) ...............136
EVENT DATA RECORDER (EDR) .....136
MAINTAINING YOUR VEHICLE
TO OPEN AND CLOSE THE HOOD ....137
ENGINE COMPARTMENT — 1.4L
TURBO ....................138
ENGINE COMPARTMENT — 2.0L ....140
ENGINE COMPARTMENT — 2.4L ....142
FLUID CAPACITIES .............144
FLUIDS, LUBRICANTS, AND
GENUINE PARTS ..............144
MAINTENANCE PROCEDURES ......146
MAINTENANCE SCHEDULE .......146
FUSES ....................151
TIRES — GENERAL INFORMATION . . . 154
REPLACEMENT BULBS ..........157
CONSUMER ASSISTANCE
FCA US LLC CUSTOMER CENTER ....158
FCA CANADA INC. CUSTOMER CENTER . . 158
ASSISTANCE FOR THE HEARING
IMPAIRED ..................158
PUBLICATIONS ORDERING ........158
REPORTING SAFETY DEFECTS IN THE
UNITED STATES ..............159
Uconnect CUSTOMER CENTER ......159
MOPAR® ACCESSORIES
AUTHENTIC ACCESSORIES BY MOPAR . . 160
FREQUENTLY ASKED QUESTIONS
FAQ’s .....................162
INDEX .....................164
TABLE OF CONTENTS

WELCOME FROM FCA US LLC
Congratulations on selecting your new FCA US LLC vehicle. Be assured that it represents
precision workmanship, distinctive styling, and high quality - all essentials that are
traditional to our vehicles.
Your new FCA US LLC vehicle has characteristics to enhance the driver's control under
some driving conditions. These are to assist the driver and are never a substitute for
attentive driving. They can never take the driver's place. Always drive carefully.
Your new vehicle has many features for the comfort and convenience of you and your
passengers. Some of these should not be used when driving because they take your eyes
from the road or your attention from driving. Never text while driving or take your eyes more
than momentarily off the road.
This guide illustrates and describes the operation of features and equipment that are
either standard or optional on this vehicle. This guide may also include a description of
features and equipment that are no longer available or were not ordered on this vehicle.
Please disregard any features and equipment described in this guide that are not available
on this vehicle. FCA US LLC reserves the right to make changes in design and specifica-
tions and/or make additions to or improvements to its products without imposing any
obligation upon itself to install them on products previously manufactured.
This User Guide has been prepared to help you quickly become acquainted with the
important features of your vehicle. It contains most things you will need to operate and
maintain the vehicle, including emergency information.
The DVD includes a computer application containing detailed owner's information which
can be viewed on a personal computer or Mac computer. The multimedia DVD also
includes videos which can be played on any standard DVD player (including the Uconnect
Touchscreen Radios if equipped with DVD player capabilities). Additional DVD opera-
tional information is located on the back of the DVD sleeve.
For complete owner information, refer to your Owner's Manual on the DVD in the owner’s
kit provided at the time of new vehicle purchase. For your convenience, the information
contained on the DVD may also be printed and saved for future reference.
FCA US LLC is committed to protecting our environment and natural resources. By
converting from paper to electronic delivery for the majority of the user information for
your vehicle, together we greatly reduce the demand for tree-based products and lessen
the stress on our environment.
INTRODUCTION/WELCOME
2

VEHICLES SOLD IN CANADA
With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be
deleted and the name FCA Canada Inc. used in substitution (excluding legal lines).
WARNING!
• Pedals that cannot move freely can cause loss of vehicle control and increase the
risk of serious personal injury.
• Always make sure that objects cannot fall into the driver foot well while the vehicle
is moving. Objects can become trapped under the brake pedal and accelerator
pedal causing a loss of vehicle control.
• Failure to properly follow floor mat installation or mounting can cause interference
with the brake pedal and accelerator pedal operation causing loss of control of the
vehicle.
• Never leave children alone in a vehicle, or with access to an unlocked vehicle.
Allowing children to be in a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or fatally injured. Children should be
warned not to touch the parking brake, brake pedal or the transmission gear
selector.
• Do not leave the Key Fob in or near the vehicle, or in a location accessible to
children, and do not leave the ignition of a vehicle equipped with Keyless
Enter-N-Go in the ACC or ON/RUN mode. A child could operate power windows,
other controls, or move the vehicle.
• Never use the “PARK” position as a substitute for the parking brake. Always apply
the parking brake fully when parked to guard against vehicle movement and
possible injury or damage.
• Refer to your Owner's Manual on the DVD for further details.
USE OF AFTERMARKET PRODUCTS (ELECTRONICS)
The use of aftermarket devices including cell phones, MP3 players, GPS systems, or
chargers may affect the performance of on-board wireless features including Keyless
Enter-N-Go and Remote Start range. If you are experiencing difficulties with any of your
wireless features, try disconnecting your aftermarket devices to see if the situation
improves. If your symptoms persist, please see an authorized dealer.
When it comes to service, remember that your authorized dealer knows your vehicle best,
has factory-trained technicians and genuine MOPAR parts, and cares about your satis-
faction.
INTRODUCTION/WELCOME
3

DRIVER COCKPIT
1. Headlight Switch pg. 39
2. Electronic Vehicle Information Center (EVIC) Control/Driver Information Display (DID)
pg. 6
3. Turn Signal/Wiper/Washer/High Beam Lever pg. 37
4. Instrument Cluster pg. 6
5. Electronic Vehicle Information Center (EVIC)/Driver Information Display (DID) pg. 6
6. Fuel Door Locator pg. 6
7. Speed Control pg. 40
8. Ignition Switch pg. 12
9. Audio System pg. 56
CONTROLS AT A GLANCE
4

10. Glove/Storage Compartment
11. Hazard Warning Light
12. Climate Control pg. 44
13. Shifter
14. Power Outlet pg. 105
15. Power Mirrors
16. Power Windows
17. Power Locks
CONTROLS AT A GLANCE
5

INSTRUMENT CLUSTER
1. Tachometer
2. Selectable Information Area — If Equipped
3. Electronic Vehicle Information Center (EVIC)/ Driver Information Display (DID)
4. Speedometer
(See page 108 for Instrument Cluster Warning Lights.)
CONTROLS AT A GLANCE
6

5. Gear Position Display
6. Fuel Gauge
7. Fuel Door Location
(See page 114 for Instrument Cluster Indicator Lights.)
CONTROLS AT A GLANCE
7

KEY FOB
Locking And Unlocking The Doors
Push and release the LOCK button on
the RKE transmitter to lock all doors. The
turn signal lights will flash, and the horn will
chirp to acknowledge the signal.
Push and release the UNLOCK button
on the RKE transmitter once to unlock the
driver's door or twice within five seconds to
unlock all doors. The turn signal lights will
flash to acknowledge the unlock signal. The
illuminated entry system will also turn on.
1st Press Of Key Fob Unlocks
This feature lets you program the system to
unlock either the driver's door or all doors on
the first push of the UNLOCK button on
the RKE transmitter. To change the current
setting, refer to your “Uconnect Settings” in
“Understanding Your Instrument Panel” in
your Owner's Manual on the DVD for further
information.
Opening The Trunk
Push the Trunk Release button on the trans-
mitter two times within five seconds to open
the trunk.
Panic Alarm
1. Push the PANIC button once to turn the
Panic Alarm on.
2. Wait approximately three seconds and
push the button a second time to turn
the Panic Alarm off.
Key Fob
1 — Decklid
2 — Unlock
3 — Lock
4 — Remote Start
5 — Panic
Key Fob
1 — Decklid
2 — Lock
3 — Unlock
4 — Remote Start
5 — Emergency Key
GETTING STARTED
8

Emergency Key
Should the battery in the vehicle or the Key Fob transmitter go dead, there is an
emergency key located in the Key Fob. To remove the emergency key, slide the button at
the back of the Key Fob sideways with your thumb and then pull the key out with your
other hand.
The emergency key is also used to lock the glove compartment.
WARNING!
• Never leave children alone in a vehicle, or with access to an unlocked vehicle.
Allowing children to be in a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or fatally injured. Children should be
warned not to touch the parking brake, brake pedal or the transmission gear
selector.
• Do not leave the Key Fob in or near the vehicle, or in a location accessible to
children, and do not leave the ignition of a vehicle equipped with Keyless
Enter-N-Go in the ACC or ON/RUN mode. A child could operate power windows,
other controls, or move the vehicle.
REMOTE START
• Push the REMOTE START button x2on the Key Fob twice within five seconds.
• Pushing the REMOTE START button a third time shuts the engine off.
• To drive the vehicle, push the UNLOCK button and cycle the ignition to the ON/RUN
position.
With remote start, the engine will only run for 15 minutes (timeout) unless the ignition is
cycled to the ON/RUN position.
The vehicle must be cycled to the ON/RUN position after two consecutive timeouts.
WARNING!
• Do not start or run an engine in a closed garage or confined area. Exhaust gas
contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide
is poisonous and can cause you or others to be severely injured or killed when
inhaled.
• Keep Key Fob transmitters away from children. Operation of the Remote Start
System, windows, door locks or other controls could cause you and others to be
severely injured or killed.
GETTING STARTED
9

KEYLESS ENTER-N-GO
The Keyless Enter-N-Go system is an enhancement to the vehicle's Key Fob. This feature
allows you to lock and unlock the vehicle's door(s) and trunk without having to push the
Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with the push
of a button.
To Unlock From The Driver Or Passenger Side
With a valid Keyless Enter-N-Go Key Fob located outside the vehicle and within 5 ft
(1.5m) of the driver or passenger side door handle, grab either front door handle to unlock
the door automatically.
To Lock The Vehicle
Both front door handles have buttons lo-
cated on the outside of the handle. With
one of the vehicle's Keyless Enter-N-Go Key
Fobs located outside the vehicle and within
5 ft (1.5 m) of the driver's or passenger front
door handle, push the door handle button to
lock all four doors and trunk.
DO NOT grab the door handle when pushing the door handle button. This could unlock the
door(s).
Grab The Door Handle To Unlock
Push The Door Handle To Lock Do NOT Grab The Handle When Locking
GETTING STARTED
10

NOTE:
• If “Unlock All Doors 1st Press” is programmed all doors will unlock when you grab hold
of the front driver's door handle. To select between “Unlock Driver Door 1st Press” and
“Unlock All Doors 1st Press”, refer to the “Electronic Vehicle Information Center
(EVIC)” or “Driver Information Display (DID)” in your vehicle's Owner's Manual on the
DVD or “Programmable Features” in this guide for further information.
• If “Unlock All Doors 1st Press” is programmed all doors and trunk will unlock when you
push the trunk button. If “Unlock Driver Door 1st Press” is programmed only the trunk
will unlock when you push the trunk button. To select between “Unlock Driver Door 1st
Press” and “Unlock All Doors 1st Press”, refer to the “Electronic Vehicle Information
Center (EVIC)” or “Driver Information Display (DID)” in your vehicle's Owner's Manual
on the DVD or “Programmable Features” in this guide for further information.
• If a Key Fob is detected in the vehicle when locking the vehicle using the power door
lock switch, the doors and trunk will unlock and the horn will chirp three times. On the
third attempt, your Key Fob can be locked inside the vehicle.
• After pushing the Keyless Enter-N-Go LOCK button, you must wait two seconds before
you can lock or unlock the vehicle using the door handle. This is done to allow you to
check if the vehicle is locked by pulling the door handle, without the vehicle reacting
and unlocking.
• If a Keyless Enter-N-Go door handle has not been used for 72 hours, the Keyless
Enter-N-Go feature for that handle may time out. Pulling the deactivated front door
handle will reactivate the door handle's Keyless Enter-N-Go feature.
To Enter The Trunk
With a valid Keyless Enter-N-Go Key Fob
located outside the vehicle and within 5ft
(1.5 m) of the deck lid, push the button on
the right side of the light bar which is
located on the deck lid above the license
plate.
NOTE:
Refer to “Keyless Enter-N-Go” in “Things
To Know Before Starting Your Vehicle” in
your Owner's Manual on the DVD for further
information.
Trunk Unlock Button
GETTING STARTED
11

Engine Starting/Stopping
Starting
1. With a valid Keyless Enter-N-Go Key Fob
inside the vehicle.
2. Place the shift lever in PARK or NEU-
TRAL.
3. While pushing the brake pedal, push the
ENGINE START/STOP button once. If
the engine fails to start, the starter will
disengage automatically after 10 sec-
onds.
4. To stop the cranking of the engine prior
to the engine starting, push the button
again.
NOTE:
In case the ignition switch does not change with the push of a button, the RKE transmitter
(Key Fob) may have a low or dead battery. In this situation a back up method can be used
to operate the ignition switch. Put the nose side of the Key Fob against the ENGINE
START/STOP button and push to operate the ignition switch.
Stopping
1. Bring the vehicle to a complete stop.
2. Shift the transmission to PARK (P).
3. Push the ENGINE START/STOP button once. The ignition switch will return to the OFF
position.
NOTE:
If the transmission is not in PARK and the vehicle is in motion, the ENGINE START/STOP
button must be held for two seconds with the vehicle speed above 5 mph (8 km/h) before
the engine will shut off.
Engine START/STOP Button
GETTING STARTED
12

Accessory Positions With Engine Off
NOTE:
The following functions are with the driver’s foot OFF the brake pedal (transmission in
PARK or NEUTRAL position).
Starting With The Ignition Switch In The OFF Position:
• Push the ENGINE START/STOP button once to change the ignition switch to the ACC
position.
• Push the ENGINE START/STOP button a second time to change the ignition switch to
the ON/RUN position.
• Push the ENGINE START/STOP button a third time to return the ignition switch to the
OFF position.
NOTE:
If the ignition switch is left in the ACC or
ON/RUN (engine not running) position and
the transmission is in PARK, the system will
automatically time out after 30 minutes of
inactivity and the ignition will switch to the
OFF position.
Ignition Positions
GETTING STARTED
13

VEHICLE SECURITY ALARM
The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the
ignition for unauthorized operation. While the Vehicle Security Alarm is armed, interior
switches for door locks and decklid release are disabled. If something triggers the alarm,
the Vehicle Security Alarm will provide the following audible and visible signals: the horn
will pulse, the park lamps and/or turn signals will flash, and the Vehicle Security Light in
the instrument cluster will flash.
To Arm The System
Vehicles Not Equipped With Keyless Enter-N-Go
Remove the key from the ignition switch and either push a power door LOCK switch while
the driver or passenger door is open or push the LOCK button on the Remote Keyless Entry
(RKE) transmitter. After the last door is closed, or if all doors are closed, the Vehicle
Security Alarm will arm itself in about 16 seconds. During that time, the Vehicle Security
Light will flash. If it does not illuminate, the Vehicle Security Alarm is not arming. In
addition, if you open a door during the arming period, the Vehicle Security Alarm will
cancel the arming process. If you wish to rearm the Vehicle Security Alarm after closing
the door, you must repeat one of the previously-described arming sequences.
You may also disarm the ultrasonic intrusion sensor during the 16 second arming period
by pushing the lock button three times with a delay of no more than five seconds between
key pushes. The horn will pulse twice to acknowledge that the ultrasonic intrusion sensor
has been disabled.
NOTE:
• The driver’s door key cylinder and the trunk button on the RKE transmitter cannot arm
or disarm the Vehicle Security Alarm.
• The Vehicle Security Alarm remains armed during trunk entry. Pushing the TRUNK
button will not disarm the Vehicle Security Alarm. If someone enters the vehicle
through the trunk, and opens any door, the alarm will sound.
• When the Vehicle Security Alarm is armed, the interior power door lock switches will
not unlock the doors.
• The ultrasonic intrusion sensor may be inadvertently activated by a child, pet or shifting
package left within the vehicle after the Vehicle Security Alarm is armed.
Vehicles Equipped With Keyless Enter-N-Go
Push the Keyless Enter-N-Go START/STOP button until the EVIC/DID indicates that the
vehicle ignition is “OFF” (refer to “Starting Procedures” in “Starting And Operating” in
your Owner's Manual on the DVD for further information). Then either push the power door
LOCK switch while the driver or passenger door is open, push the Remote Keyless Entry
(RKE) transmitter LOCK button or push the Passive Entry Door Handle LOCK button (refer
to “Keyless Enter-N-Go” in “Things To Know Before Starting Your Vehicle” in your Owner's
Manual on the DVD for further information).
GETTING STARTED
14

To Disarm The System
The Vehicle Security Alarm is designed to protect your vehicle; however, you can create
conditions where the Vehicle Security Alarm will give you a false alarm. If one of the
previously-described arming sequences has occurred, the Vehicle Security Alarm will arm
regardless of whether you are in the vehicle or not. If you remain in the vehicle and open
a door, the alarm will sound. If this occurs, disarm the Vehicle Security Alarm.
If the Vehicle Security Alarm is armed and the battery becomes disconnected the Vehicle
Security Alarm will remain armed when the battery is reconnected. The exterior lights will
flash, and the horn will sound. If this occurs, disarm the Vehicle Security Alarm.
Vehicles Not Equipped With Keyless Enter-N-Go
Either push the UNLOCK button on the RKE transmitter or insert a valid ignition key into
the ignition switch and turn the key to the ON/RUN position.
NOTE:
• The driver's door key cylinder and the trunk button on the RKE transmitter cannot arm
or disarm the Vehicle Security Alarm.
• The Vehicle Security Alarm remains armed during trunk entry. Pushing the TRUNK
button will not disarm the Vehicle Security Alarm. If someone enters the vehicle
through the trunk, and opens any door, the alarm will sound.
• When the Vehicle Security Alarm is armed, the interior power door lock switches will
not unlock the doors.
Vehicles Equipped With Keyless Enter-N-Go
Either push the UNLOCK button on the RKE transmitter or grasp the Passive Entry Unlock
Door Handle (refer to “Keyless Enter-N-Go” in “Things To Know Before Starting Your
Vehicle” in your Owner's Manual on the DVD for further information), push the Keyless
Enter-N-Go START/STOP button (requires at least one valid Key Fob in the vehicle), or
insert a valid Key Fob into the ignition switch (if the START/STOP button is removed) and
rotate it to the ON/RUN position.
Tamper Alert
If something has triggered the Vehicle Security Alarm in your absence, the horn will sound
three times and the exterior lights will blink three times when you disarm the Vehicle
Security Alarm. Check the vehicle for tampering.
GETTING STARTED
15

SEAT BELT SYSTEMS
Lap/Shoulder Belts
• All seating positions in your vehicle are equipped with lap/shoulder belts.
• Be sure everyone in your vehicle is in a seat and using a seat belt properly.
• Position the lap belt so that it is snug and lies low across your hips, below your
abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen
the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug seat belt
reduces the risk of sliding under the seat belt in a collision.
• Position the shoulder belt across the shoulder and chest with minimal, if any slack so
that it is comfortable and not resting on your neck. The retractor will withdraw any slack
in the shoulder belt.
Seat Belt Pretensioner
• The front seat belt system is equipped with pretensioning devices that are designed to
remove slack from the seat belt in the event of a collision.
• A deployed pretensioner or a deployed air bag must be replaced immediately.
WARNING!
• In a collision, you and your passengers can suffer much greater injuries if you are
not properly buckled up. You can strike the interior of your vehicle or other
passengers, or you can be thrown out of the vehicle. Always be sure you and others
in your vehicle are buckled up properly.
• A shoulder belt placed behind you will not protect you from injury during a collision.
You are more likely to hit your head in a collision if you do not wear your shoulder
belt. The lap and shoulder belt are meant to be used together.
• A seat belt that is too loose will not protect you properly. In a sudden stop, you could
move too far forward, increasing the possibility of injury. Wear your seat belt snugly.
• A frayed or torn seat belt could rip apart in a collision and leave you with no
protection. Inspect the seat belt system periodically, checking for cuts, frays, or
loose parts. Damaged parts must be replaced immediately. Do not disassemble or
modify the system. Seat belt assemblies must be replaced after a collision.
GETTING STARTED
16

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS
Air Bag System Components
Your vehicle may be equipped with the following air bag system components:
• Occupant Restraint Controller (ORC)
• Air Bag Warning Light
• Steering Wheel and Column
• Instrument Panel
• Knee Impact Bolsters
• Advanced Front Air Bags
• Supplemental Side Air Bags
• Supplemental Knee Air Bags
• Front and Side Impact Sensors
• Seat Belt Pretenioners
• Seat Belt Buckle Switch
• Seat Track Position Sensors
• Occupant Classification System
Advanced Front Air Bags
• This vehicle has Advanced Front Air Bags for both the driver and front passenger as a
supplement to the seat belt restraint systems. The Advanced Front Air Bags will not
deploy in every type of collision.
• Advanced Front Air Bags are designed to provide additional protection by supplement-
ing the seat belts. Advanced Front Air Bags are not expected to reduce the risk of injury
in rear, side, or rollover collisions.
• The Advanced Front Air Bags will not deploy in all frontal collisions, including some
that may produce substantial vehicle damage — for example, some pole collisions,
truck underrides, and angle offset collisions.
• On the other hand, depending on the type and location of impact, Advanced Front Air
Bags may deploy in crashes with little vehicle front-end damage but that produce a
severe initial deceleration.
•
Because air bag sensors measure vehicle deceleration over time, vehicle speed and damage
by themselves are not good indicators of whether or not an air bag should have deployed.
• Seat belts are necessary for your protection in all collisions, and also are needed to help
keep you in position, away from an inflating air bag.
• After any collision, the vehicle should be taken to an authorized dealer immediately.
• Do not drive your vehicle after the air bags have deployed. If you are involved in another
collision, the air bags will not be in place to protect you.
• If it is necessary to modify the air bag system for persons with disabilities, contact your
authorized dealer.
• Refer to the Owner's Manual on the DVD for further details regarding the Supplemental
Restraint System (SRS).
GETTING STARTED
17

Occupant Classification System
This vehicle is equipped with a right front passenger Occupant Classification System
(“OCS”) that is designed to provide Passenger Advanced Front Air Bag output appropriate
to the occupant’s seated weight input, as determined by the OCS.
The Occupant Classification System (OCS) consists of the following:
• Occupant Restraint Controller (ORC)
• Occupant Classification Module (OCM) and Sensor located in the front passenger seat
• Air Bag Warning Light
The OCS will NOT prevent deployment of the Passenger Advanced Front Air Bag. The OCS
may reduce the inflation rate of the Passenger Advanced Front Air Bag if the OCS
estimates that:
• The front passenger seat is unoccupied or has very light objects on it; or
• The front passenger seat is occupied by a small passenger, including a child; or
• The front passenger seat is occupied by a rear-facing child restraint; or
• The front passenger is not properly seated or his or her weight is taken off of the seat
for a period of time.
Front Passenger Seat Occupant Status Front Passenger Air Bag Output
Rear-facing child restraint Reduced-power deployment
Child, including a child in a forward-facing
child restraint or booster seat*
Full-power deployment OR reduced-
power deployment
Properly seated adult Full-power deployment OR reduced-
power deployment
Unoccupied seat Reduced-power deployment
* It is possible for a child to be classified as an adult, allowing a full-power Passenger
Advanced Front Air Bag deployment. Never allow children to ride in the front passenger
seat and never install a child restraint system, including a rear-facing child restraint, in the
front passenger seat.
The OCS determines the front passenger’s most probable classification.
The OCS estimates the seated weight on the front passenger seat and where that weight
is located. The OCS communicates the classification status to the ORC. The ORC uses the
classification to determine whether the Passenger Advanced Front Air Bag inflation rate
should be adjusted. In order for the OCS to operate as designed, it is important for the
front passenger to be seated properly and properly wearing the seat belt. Properly seated
passengers are:
• Sitting upright
• Facing forward
GETTING STARTED
18
