Dodge DURANO 2009 User manual
2009
QUICK REFERENCE GUIDE
DURANGO
175472_09a_Durango_QRG.indd 6 10/23/08 1:03:07 PM
MANUAL CLIMATE CONTROLS
AIR RECIRCULATION
Use recirculation for maximum A/C operation.
For window defogging, turn recirculation off.
Recirculation is not allowed in defrost or defrost/floor
(mix) modes.
ACTIVATING REAR PASSENGER CLIMATE CONTROLS
Rotate rear blower control, located on the instrument panel,
to the “Rear Control” position. This enables the rear passenger
climate controls located in the rear of the center console
between the front seats.
ElEctronic VEhiclE information cEntEr
(EVic) controls
the overhead console. Pressing the controls on the overhead
console allows the driver to select vehicle information and
Personal Settings.
the COMPASS/FUNCTION button down.
Push
On/Off -
Rotate Blower
Control
Rotate
Front Blower
Control
Slide Temp.
Control
Rotate
Mode
Control
Push
A/C
Button
Air
Recirc.
Modes
Rotate Rear
Wiper/Push
Rear Washer
Rotate
Rear Blower
Control
Push Rear
Window
Defroster
Button
175472_09a_Durango_QRG.indd 2 10/23/08 1:02:50 PM
AUTOMATIC TEMPERATURE CONTROL (ATC)
AUTOMATIC OPERATION
Press the AUTO button to turn the system on.
Select the desired temperature by pushing the Temperature
Control buttons (Driver & Passenger).
The system will maintain the set temperature automatically.
AIR CONDITIONING (A/C)
A/C compressor operation is automatic when you press the
AUTO button. The A/C symbol is not displayed in AUTO mode.
AIR RECIRCULATION
Use recirculation for maximum A/C operation.
For window defogging, turn recirculation off.
Recirculation is not allowed in defrost or defrost/floor (mix)
modes. If recirculation is selected when the mode control is in
defrost or defrost/floor (mix), the recirculation symbol will flash
three times indicating recirculation is not available.
ACTIVATING REAR PASSENGER CLIMATE CONTROLS
instrument panel to cycle through the four rear passenger
climate control modes:
and blower speed.
the center console between the front seats.
Push
On/Off -
Rotate Blower
Control
Push
Driver Temp.
Control
Push
A/C
Button
Push
AUTO
Button
Push Rear
Climate Control
Button
Push
Passenger/Rear
Temp. Control
Switches
Push
Air
Recirc.
Rotate Rear
Wiper/Push
Rear Washer
Push Mode
Buttons
Push Rear
Window
Defroster
Button
175472_09a_Durango_QRG.indd 3 10/23/08 1:02:52 PM
VEHICLE FEATURES
fuEl cap
LOOSE GAS CAP MESSAGE
tighten the gas cap until a “clicking” sound is heard.
tightening the gas cap, see your dealer.
tirE prEssurE monitoring systEm (tpms)
Monitoring Light will illuminate and an audible chime will sound.
Check the inflation pressure of each road tire on your vehicle and
inflate to the recommended cold pressure value, shown on the placard
located in the driver’s door opening. The TPMS display should not be
recognized. The vehicle may need to be driven for up to 10 minutes
above 15 mph (25 km/h) before the light will turn off.
Temperature changes can affect tire pressures, causing the TPMS light
to turn on. Colder temperatures will decrease tire pressure and
warmer temperatures will increase tire pressure.
Refer to your Owner’s Manual.
oil changE indicator
MESSAGE
Required) appears and a single chime sounds, it is time for your next
required oil change.
RESETTING LIGHT AFTER SERVICING
175472_09a_Durango_QRG.indd 4 10/23/08 1:02:54 PM
VEHICLE FEATURES
clock sEtting
NON-TOUCH-SCREEN RADIOS
TUNE/SCROLL control knob to set the hours.
turn the TUNE/SCROLL control knob to set the minutes.
TOUCH-SCREEN RADIOS
Radio Only).
backward button.
minute backward button.
is displayed.
DRIVER POWER SEAT ADJUSTMENT
The recline switch, located on the outboard side of the seat,
DRIVER MEMORY SEAT
The memory seat feature allows you to save two different driver
seating positions. The memory seat switches are located on the
driver’s door panel. With the key in the ON/RUN position,
push , then 1 or 2 within five seconds.
Push 1 or 2 to recall the saved positions.
Refer to Owner’s Manual for further details.
175472_09a_Durango_QRG.indd 5 10/23/08 1:02:56 PM
Headlight
Switch
Adjustable
Pedals Switch
(Behind Steering Wheel)
Turn Signals/Wiper/
Washer/High Beams Lever
(Behind Steering Wheel)
Speed Control
Switches
115v
Inverter
Switch
INSTRUMENT PANEL
175472_09a_Durango_QRG.indd 7 10/23/08 1:03:14 PM
Instrument Cluster
(Non-Hybrid
Shown)
Column
Shift Lever
Audio System
(Touch-Screen
Radio Shown)
Switch Panel
Power Outlet
Heated Seat Switches
Electronic Stability Program
(ESP) Off Switch
Climate
Controls
INSTRUMENT PANEL
175472_09a_Durango_QRG.indd 8 10/23/08 1:03:19 PM
kEy fob
twice within five seconds to unlock all the doors and liftgate.
POWER LIFTGATE
LIFTGATE button twice within five seconds.
PANIC ALARM
time to turn the panic alarm off.
REMOTE START
ignition and turn to the ON/RUN position.
unless the ignition key is placed in the ON/RUN position.
consecutive timeouts.
VEHICLE FEATURES
Remote
Start
Lock
Unlock
Power
Liftgate
175472_09a_Durango_QRG.indd 9 10/23/08 1:03:32 PM
hEadlight switch
the second detent for headlights.
on or off based on ambient light levels.
INSTRUMENT PANEL DIMMER
the instrument panel lights and prevent the interior lights from
illuminating when a door is opened.
instrument panel lights when the parking lights or headlights are on.
brighten the odometer and radio when the parking lights or
headlights are on. Refer to your multimedia or navigation user manual
for radio display dimming.
interior lighting.
FOG LIGHTS
once to turn the fog lights on. Push the switch a second time to turn the
fog lights off. Fog lights will not operate when the high beams are on.
fog lights are on.
VEHICLE FEATURES
Rotate
Headlight
Switch
AUTO
Push Fog
Lights
Rotate
Dimmer
175472_09a_Durango_QRG.indd 10 10/23/08 1:03:36 PM
spEEd control
CRUISE ON/OFF
Speed Control is on.
SET
(40 km/h), push and release the Set switch.
ACCEL/DECEL
save the new set speed.
switch once will increase or decrease the set speed approximately
1 mph (2 km/h).
CANCEL
and maintain the set speed memory.
speed memory.
RESUME
Resume/Accel switch and release.
Push
ON/OFF
Push Set
Push
Resume/Accel
Push
Cancel
Push
Decel
175472_09a_Durango_QRG.indd 11 10/23/08 1:03:43 PM
Wipers
Pull Lever for
High Beams
Washer
turn signals/wipEr/washEr/high bEams lEVEr
TURN SIGNALS/LANE CHANGE ASSIST
p the lever up or down once and the turn signal (right or left) will
flash three times then automatically turn off.
WIPERS
Intermittent, Low and High Operation
intermittent settings, the second detent for low wiper operation and
the third detent for high wiper operation.
Washer
High Beams
Pull the lever toward you past the detent to activate the High Beams.
High Beam lights are on.
REAR WIPER/WASHER
rotating switch on the Climate Control turns the rear wiper
ON/OFF. Pushing this switch inward activates the rear washer.
WIND BUFFETING
Wind buffeting can be described as a helicopter-type percussion
front and rear windows together.
175472_09a_Durango_QRG.indd 12 10/23/08 1:03:46 PM
Durango
First Printing
Quick Reference Guide
81-316-0991
Dodge is a registered trademark of Chrysler LLC.
www.DODGE.com
This guide has been prepared to help you get quickly acquainted
with your new Dodge and to provide a convenient reference source
for common questions. However, it is not a substitute for your
Owner’s Manual.
For complete operational instructions, maintenance procedures and
important safety messages, please consult your Owner’s Manual,
Navigation Radio User Manual, Multimedia User Manual and other
Warning Labels in your vehicle.
Not all features shown in this guide may apply to your vehicle.
For additional information on accessories to help personalize your
vehicle, visit www.mopar.com or your local Dodge dealer.
175472_09a_Durango_QRG.indd 1 10/23/08 1:02:49 PM
