Dolby Accessibility Solution Theatre Staff Reference Guide
Introduction
This guide provides the steps for connecting the Dolby Accessibility Solution Receiver to an auditorium for a
patron.
Dolby Accessibility Solution Receiver diagram
Connecting the Dolby Accessibility Solution Receiver to an auditorium
Step 1
From the right side of the Dolby Accessibility Solution Receiver, press the power button to turn on the
device.
Step 2
For blind or low vision patrons, you can enable the Talkback feature by tapping the accessibility icon in the
upper right corner of the home screen. When Talkback is enabled, Audio Description is automatically
enabled when connecting to the auditorium.

Issue 1 Part number 8800312
10 June 2022
© 2022 Dolby Laboratories. All rights reserved.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories. All other trademarks remain the property of their
respective owners.
Step 3
From the Dolby Accessibility Solution Receiver home screen, tap the –or +
symbols to select the auditorium. You can also tap the number and then enter a
new number.
Step 4
Tap CONNECT.
Important: The connection is made only when the Dolby Accessibility Solution Receiver is within range of
the Wi-Fi router. You may need to ask the patron to tap CONNECT when they arrive in the auditorium.
Step 5
To make a selection, choose from the available options:
a) When AUDIO RESOURCE is selected, there are three choices. If you
select Audio Description, the descriptive narration audio plays in both
earpieces. If you select Amplified Audio, the amplified audio track plays
in both earpieces. If you choose Amplified Audio and Audio Description,
amplified audio will play in one earpiece and descriptive narration
audio will play in the other.
Important: If the patron chooses the audio option, give the patron a
stereo headphone set.
b) For deaf or hard of hearing patrons that prefer caption text, tap
CLOSED CAPTION. The closed captioning text starts when accessible
content is playing.
Adjusting the Dolby Accessibility Solution Receiver adjustable arm
Step 1
To adjust the size of the mount base, rotate the knob located above the cup-holder base.
Step 2
To adjust the mount neck, bend and position the rubberized extension with two hands.
Step 3
To adjust the receiver from portrait to landscape mode (or vice versa), loosen the butterfly nut,
rotate the touch-screen display, and then retighten the butterfly nut.
