Installation and
User Guide
HP MediaSmart Connect x280n

The only warranties for HP products and services are set forth in the
express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
HP assumes no responsibility for the use or reliability of its software on
equipment that is not furnished by HP.
This document contains proprietary information that is protected by
copyright. No part of this document may be photocopied,
reproduced, or translated to another language without the prior
written consent of HP.
Hewlett-Packard Company
P.O. Box 4010
Cupertino, CA 95015-4010
USA
Copyright © 2008 Hewlett-Packard Development Company, L.P.
This product incorporates copyright protection technology that is
protected by U.S. patents and other intellectual property rights. Use of
this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited pay-per-view
viewing uses only unless otherwise authorized by Macrovision.
Reverse engineering or disassembly is prohibited.
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
DivX, DivX certified, and associated logos are trademarks of
DivXNetworks, Inc. and are used under license.
Microsoft, Windows Vista, and Windows XP are U.S. registered
trademarks of Microsoft Corporation.
The Windows logo and Windows Vista are trademarks or registered
trademarks of Microsoft Corporation in the United States and/or other
countries/regions.
Wi-Fi CERTIFIED 802.11n based on Draft 2.0
Draft 2.0 refers to the version of the not-yet-ratified IEEE 802.11n
standard used in Wi-Fi Alliance testing as of June 2007.
The specifications of the 802.11n WLAN (wireless local area
network) are draft specifications and not final. If the final
specifications differ from the draft specifications, it may affect the
ability of this device to communicate with other 802.11n WLAN
devices.

HP supports lawful use of technology and does not endorse or
encourage the use of our products for purposes other than those
permitted by copyright law.
The information in this document is subject to change without notice.
nText set off in this manner indicates information
you need.
!IMPORTANT: Text set off in this manner indicates
important information you need.
cCAUTION: Text set off in this manner indicates that
failure to follow directions could result in damage to
equipment or loss of information.
wWARNING: This symbol is intended to alert the user to
the presence of important operating and maintenance
(servicing) instructions in the literature accompanying
the appliance.
eDANGEROUS VOLTAGE: Text set off in this manner
indicates the presence of uninsulated voltages within
the product enclosure that may be of sufficient
magnitude to constitute a risk of electrical shock to
persons.

Regulatory and Safety Information 4
Regulatory and Safety Information
wWARNING: Text set off in this manner indicates that
failure to follow directions could result in damage to
equipment, loss of information, bodily harm, or loss
of life.
eWARNING: This symbol is intended to alert the user to
the presence of uninsulated “Dangerous Voltages”
within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electrical shock to
persons. Refer servicing to qualified service personnel.
eWARNING: To reduce the risk of electrical shock, do not
remove cover (or back).
No user-serviceable parts inside.
Refer servicing to qualified service personnel.
eWARNING: To reduce the risk of fire or electrical shock,
do not expose this appliance to rain or moisture.
wWARNING: Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The product may
fall, causing serious personal injury and serious
damage to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the
manufacturer or sold with the product. Follow the
manufacturer’s instructions when installing the product.
A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to
overturn.

Regulatory and Safety Information 5
Digital Television Transition
Notice
Digital Television Transition Notice:
After February 17, 2009, a television receiver with only an
analog broadcast tuner will require a converter box to receive
full power over-the-air broadcasts with an antenna because of
the Nation’s transition to digital broadcasting. Analog-only TVs
should continue to work as before to receive low power, Class A
or translator television stations and with cable and satellite TV
services, gaming consoles, VCRs, DVD players, and similar
products.
Information about the DTV transition is available from
www.DTV.gov or 1-888-CALL-FCC, and from
www.dtv2009.gov or 1-888-DTV-2009 for information about
subsidized coupons for digital-to-analog converter boxes; and,
The DTV transition does not impact the functionality of this device
unless you use it to stream Live TV from a PC with an analog-only
tuner and an off-the-air antenna.
Interface Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.

Regulatory and Safety Information 6
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
This device complies with RSS-210 of the Industry Canada Rules.
High-power radars are allocated as primary users (meaning they
have priority) of the bands 5250-5350 MHz and 5650-5850
MHz and these radars could cause interference and/or damage
to LE-LAN devices.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme
NMB-003 du Canada.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
Modifications
Pursuant to 47CFR15.21 of the FCC Rules, any changes or
modifications to this equipment not expressly approved by the
Hewlett-Packard Company may cause harmful interference and
void the FCC authorization to operate this equipment.
FCC and IC Statements
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
For products available in the USA/Canada market, only channel
1~11 can be operated. Selection of other channels is not
possible.
This device is going to be operated in 5.15~5.25 GHz frequency
range, it is restricted in indoor environment only.

Regulatory and Safety Information 7
Cables
Connections to this device must be made with shielded cables
with metallic RFI/EMI connector hoods in order to maintain
compliance with FCC Rules and Regulations.
Responsible Party
Hewlett-Packard Company
Attn: Product Regulations Manager
10955 Tantau Avenue
Cupertino, CA 95014-0770 USA
Important Safety Instructions
Electricity is used to perform many useful functions, but it can also
cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured
with the highest priority on safety. However, improper use can
result in electric shock and/or fire. In order to prevent potential
danger, please observe the following instructions when installing,
operating, and cleaning the product. To ensure your safety and
prolong the service life of your product, please read the following
precautions carefully before using the product.
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this apparatus near water.
6Clean only with a microfiber cloth. If needed, dampen cloth
with water. Never use solvents or abrasive cleaning solutions
to clean this product or permanent damage may result.
7Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.

Regulatory and Safety Information 8
8Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11 Only use power supply/attachments/accessories specified
by the manufacturer.
12 Unplug this apparatus during lightning storms or when
unused for long periods of time.
13 Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
the power-supply, cord, or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
14 Power Sources—This product should be operated only from
the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For
products intended to operate from battery power, or other
sources, refer to the operating instructions.
15 Overloading—Do not overload wall outlets, extension cords,
or integral convenience receptacles as this can result in a risk
of fire or electric shock.

Regulatory and Safety Information 9
16 Replacement Parts—When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or which have the same
characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
17 Safety Check—Upon completion of any service or repairs to
this product, ask the service technician to perform safety
checks to determine that the product is in proper operating
condition.
18 The apparatus shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
19 Plug the power supply into a power outlet where access to
the power supply connector is readily accessible in case
power disconnection is required.
20 Servicing—The user should not attempt to service the
appliance beyond that described in the operating
instructions. All other servicing should be referred to qualified
service personnel.
Water and Moisture—Do not use this product near water; for
example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool;
and the like.
Stand—Do not place the product on an unstable cart, stand,
tripod, or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal injuries
as well as damage to the product. Use only a cart, stand,
tripod, bracket, or table recommended by the manufacturer
or sold with the product.

Regulatory and Safety Information 10
Ventilation—The vents and other openings in the cabinet are
designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause
overheating and/or shorten the life of the product. Do not
place the product on a bed, sofa, rug, or other similar
surface, since they can block ventilation openings. This
product is not designed for built-in installation; do not place
the product in an enclosed place such as a bookcase or rack,
unless proper ventilation is provided or the manufacturer’s
instructions are followed.
Heat—The product should be situated away from heat
sources such as fireplaces, chimneys, radiators, heat
registers, stoves, or other products (including amplifiers) that
produce heat.
Lightning—For added protection for this equipment during a
lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet. This will
prevent damage to the equipment due to lightning and
power-line surges.
To prevent fire, never place any type of candle or flames on
the top or near the receiver.
To prevent fire or shock hazard, do not expose this product to
dripping or splashing. No objects filled with liquids, such as
vases, should be placed on the product.
To prevent fire or shock hazard, do not place the power cord
under heavy items.
Turn off the main power and unplug the power supply from
the wall outlet before handling.

Regulatory and Safety Information 11
Important Information
The HP MediaSmart Connect must be serviced by an authorized
service technician. The HP MediaSmart Connect is not
user-serviceable.
Changes can damage your HP MediaSmart Connect and void
your warranty. Changes or modifications not expressly approved
by the manufacturer could void the user’s authority to operate the
equipment.
Recycling Information —
HP Planet Partners
For information about how to recycle this product through HP, see:
http://www.hp.com/recycle
Other recycling options may also be available in your area. If
located within the U.S. and Canada, you may also call
(1) [phone].
Materials disposal
For disposal or recycling information, please contact your local
authorities or the Electronic Industries Alliance (EIA)
(http://www.eia.org).
Cleaning precautions
Unplug the HP MediaSmart Connect before cleaning.
Using solvents, such as alcohol, or abrasive materials, such as a
premoistened or chemically treated towel, may affect the paint.
Do not expose the product to volatile gases or fluids such as
pesticides.
Do not put the HP MediaSmart Connect in contact with vinyl or
rubber products for an extended period of time. Extended contact
may result in the removal of or degradation of the surface.
Clean only with a microfiber cloth. If needed, dampen cloth with
water. Never use solvents or abrasive cleaning solutions to clean
this product or permanent damage may result.

Getting Started 12
Getting Started
Be sure to read all the safety information and precautions before
starting installation. See the following topics:
“Regulatory and Safety Information” on page 4
“Important Safety Instructions” on page 7
“Important Information” on page 11
Identifying Items in the Box
All other cables, components, and services are sold separately.
HP MediaSmart Connect
AC power adaptor
HDMI (High-Definition Multimedia
Interface) cable used to connect
the HP MediaSmart Connect to
the HDTV
Remote control
Documentation and
Installation CD
Installation and User Guide
HP MediaSmart Connect x280n

Getting Started 13
Other cables you may need
Installation Overview
This section provides the system requirements, setup time, items
you need, and an overview of the four steps to install the
HP MediaSmart Connect.
System requirements
Media streaming requires a computer, or NAS (network attached
storage) with a Digital Living Network Alliance (DLNA)-compliant
media server. A home network is also required. All items are sold
separately.
The Windows®-based computer you use should have one of the
following:
Media Center Edition 2005 with Rollup 2 operating system
Windows XP Home operating system (32-bit only) with
Service Pack 2 (SP2) or later
Windows XP Pro operating system (32-bit only) with Service
Pack 2 or later
Windows Vista®Home Basic operating system
(32-bit/64-bit)
Windows Vista Home Premium operating system
(32-bit/64-bit)
Windows Vista Ultimate operating system (32-bit/64-bit)
NOTE: You need the Premium or Ultimate edition of the Windows
Vista operating system to use the Extender for Windows Media
Center.
Optional cables Use
Component Video Connect video to the HDTV instead of the
HDMI cable. (Some limitations for
protected content.)
L/R (RCA-style)
audio Connect analog audio output to the HDTV with the Component Video cables, or to
an optional external audio system.
Optical digital audio Connect digital audio output to an
optional external audio system.
Ethernet Connect to the network with a wired
connection instead of a wireless one.

Getting Started 14
Some MediaSmart features may not be available on computers
with a 64-bit operating system.
Certain Windows Vista product features require advanced or
additional hardware.
For details, go to the Microsoft Web sites at
http://www.microsoft.com/windowsvista/getready/
hardwarereqs.mspx
Or
http://www.microsoft.com/windowsvista/getready/
capable.mspx
The Windows Vista Upgrade Advisor can help you determine
which features of Windows Vista can run on your computer. To
download the tool, visit the Microsoft Web site at
http://www.windowsvista.com/upgradeadvisor
Setup time
Allow at least 30 minutes to set up your HP MediaSmart Connect.
Before you begin, have on hand
Your HP MediaSmart Connect and items from the box; see
“Identifying Items in the Box” on page 12.
Your HDTV and the remote control for it.
Your existing (working) home network with a router/base
station (wired or wireless). For information about network
types, see “Chapter 2: Connecting your HP MediaSmart
Connect to your Home Network” on page 35.
NOTE: For a wireless network connection, you may need:
The name or SSID (service set identifier) of your network and
the network security information such as the Wired
Equivalent Privacy (WEP) key or the Wi-Fi Protected Access
(WPA) passphrase.
Your computer or NAS, on the home network.
For full functionality, high-speed Internet service is required
(sold separately).
Optional cables, depending on your setup. See “Other
cables you may need” on page 13.

Getting Started 15
Installation Steps
Step 1: Connect your HDTV to your HP MediaSmart
Connect.
Select the location to place the device.
Connect the device to the HDTV, and to optional equipment.
If you are using a wired (Ethernet) connection, connect the
device to your home network.
Connect the device to power.
Install the remote control batteries.
See “Step 1: Connect Your HDTV to Your HP MediaSmart
Connect” on page 16.
Step 2: Follow the setup wizard on your HDTV.
Select the input on the TV for the HP MediaSmart Connect.
Select the TV resolution by following the onscreen instructions.
See “Step 2: Follow the Setup Wizard on Your HDTV” on
page 22.
Step 3: On your computer, insert the Installation CD.
At the computer, insert the Installation CD from the box, and then
follow the wizard to:
Install the MediaSmart software (automatic).
Authorize Windows Media Player 11 to share media with the
HP MediaSmart Connect.
Register your device with HP.
Create your free HP Online Media Services account.
See “Step 3: On Your Computer, Insert the Installation CD” on
page 26.
Step 4: Return to your HDTV to complete the setup.
Finalize the set up of your network.
Set up the Extender for Windows Media Center (optional).
See “Step 4: Return to Your TV to Complete the Setup” on
page 28.
Begin playing and enjoying the media available through your
HP MediaSmart Connect. See “Enjoying” on page 29.

Getting Started 16
Step 1: Connect Your HDTV to
Your HP MediaSmart Connect
Selecting a good location
When selecting the location for your HP MediaSmart Connect,
consider the following conditions:
Orientation: Position the HP MediaSmart Connect so that it is
flat (horizontal).
Power adaptor length: Choose a location with easy access to
an AC power outlet.
Cable lengths and distances to attached units: Check that
cables can reach the TV, and other units, as needed.
The type of network (wired or wireless), and the wireless
router location: For more information, see “Chapter 2:
Connecting your HP MediaSmart Connect to your Home
Network” on page 35.
Connecting to the HDTV
Your HDTV video connectors and your external sound system
usage determine how you connect them to the HP MediaSmart
Connect.
For the best video connection to the television, use the HDMI
connector and the HDMI cable from the box.
If you have a surround sound receiver connected to the HDTV,
connect the HP MediaSmart Connect to the receiver, using the
setup instructions that follow. Choose the setup instructions that
match your receiver video connector and external sound system
usage.
!IMPORTANT: If you place the device in an enclosed
shelf, provide adequate air flow to keep it cool. See
“Environment” in “Chapter 9: Specifications” on
page 97.
wWARNING: The HP MediaSmart Connect does not
support standard-definition televisions or monitors.

Getting Started 17
If you have an external sound system:
Use an optical audio cable and the Optical Audio (digital)
connector on HP MediaSmart Connect to provide a digital
audio signal to a device such as a digital receiver or a
surround sound system.
Use an audio cable and the Analog Audio (left and right)
connectors on HP MediaSmart Connect to provide an analog
audio signal to a device such as an analog amplifier or
stereo system.
Choose the setup instructions that match your HDTV video
connector and external sound system usage.
HDMI connector
Connect the HDMI cable to the back of your device and to the TV.
Video connector Setup instructions
HDMI “HDMI connector” on page 17
“HDMI connector and external sound
system” on page 18
Component
(connector set) “Component connector set” on page 18
“Component connector set and external
sound system” on page 19
wWARNING: Before connecting the HP MediaSmart
Connect to any other electronic device, unplug each
device from the AC power outlet.

Getting Started 18
HDMI connector and external sound
system
1Connect the HDMI cable to the back of your device and to
the HDTV.
2For multichannel audio output, connect an optical digital
audio cable to the back of your device and to the optional
audio/video receiver.
Component connector set
1Connect the Component cables to the back of your device
and to the HDTV, matching the color-coded plugs to the
connectors.
2Connect the audio L/R cable to the back of your device and
to the HDTV, matching the color-coded plugs to the
connectors.
Audio In
Digital R L
(Optional)

Getting Started 19
Component connector set and external
sound system
1Connect the Component cables to the back of your device
and to the HDTV, matching the color-coded plugs to the
connectors.
2Connect an optical digital audio cable or analog audio
cables to the back of your device and to the optional
audio/video receiver.
Connecting to your home network
(LAN)
Connect the HP MediaSmart Connect to the router in your
home LAN:
For a wireless connection, the HP MediaSmart Connect
is ready to use; it has internal wireless antennas and no
external antenna or other connection is necessary.
Or
For a wired connection, connect an Ethernet cable to the
network router and to the Ethernet connector on your device.
Audio In
Digital RL

Getting Started 20
Connecting power
Connect the AC power adaptor to the connector on your device
and to the AC power outlet. The HP MediaSmart Connect
turns on.
Installing remote control batteries
Insert two AA batteries into the remote control, ensuring that you
place them with the polarity properly aligned.
1Press and open the cover on the rear of the remote control.
2Insert the batteries into the remote control, and ensure that
you match polarities.
3Close the cover.
!IMPORTANT: The HP MediaSmart Connect has no Power
button; press the On/Off button on the remote control
to put the device into standby mode and awaken it, or
unplug the power adaptor to turn it completely off.
