DOLFINOS The Cello Grip-Foot M6 Thread Edition User manual

DOLFINOS
P L AY YOU R WAY
WITH DOLFINOS
The Cello Grip-Foot - M6 Thread Edition
SWISS MADE

a. Plate c. Balljoint screw
d. Cylindric coupling partb. Grip sole
f. M6 coupling parte. Rubber sleeve
g. Silicon washer h. Allen key

1. HOW TO MOUNT
1. Insert the balljoint screw (c) with the pro-
vided allen key (h)
2. Start by putting the lip of the grip sole
(b) over the plate (a) by placing the keyway
(where the small logo is) into the notch of the
plate
3. Screw the cylindric coupling part (d) onto
the balljoint screw (c), sticking out of the
plate by using the allen key (h). Please read 2.
Special Remarks before doing this
4. Add the rubber sleeve (e) to your endpin.
The round end of the rubber sleeve should
face down. If the rubber sleeve is too tight,
wetten the M6 coupling part to make it easier
to mount
6. Slip the silicon washer (g) onto the M6
coupling part (f)
7. Then screw the M6 coupling part (f) onto
your endpin. Make sure to tighten the M6 cou-
pling part enough so that the washer is firmly
pressed together. This prevents the coupling
part from loosening (through vibrations)
8. The M6 coupling part has a built-in magnet
allowing for a convenient click and go mecha-
nism, making it easy to remove and reattach
9. For the best grip of the lamella, make sure
to put the Cello Grip-Foot in front with the
logo facing up towards you
10. The smoother and cleaner the floor, the
better the lamellar structure adheres
Caution: with very dirty or uneven surfaces,
the floor adhesion will be reduced!

3. CARE INSTRUCTIONS
1. For a rough cleaning: use a moist tooth-
brush to clean the grip sole
2 For a more thourough cleaning: Use a brush,
soap and water to remove dirt and dust. Rinse
it with water and let it dry completely before
reattaching
3. Always brush inline with the lamellas
Tipp: If you always keep the Cello Grip-Foot
clean, it will prolong its lifespan.
© 2021 DOLFINOS, All Rights Reserved.
Patent pending
2. SPECIAL REMARKS
THE BALLJOINT-SCREW:
The ballljoint screw is prepared with a
threadlocking varnish. When screwing it onto
the coupling part, this varnish prevents the
screw from loosening itself. Use the provided
allen key to adjust the tightening torque. The
friction torque in the balljoint system can be
adjusted to the desired value during initial use
(from loose to tight). Once locked, the friction
torque will remain and not loosen. You can
re-adjust the friction torque up to 3 times.
After that, the threadlocking varnish will lose
its effect. In this case, you can refresh the
threadlocking varnish yourself with Loctite
No. 243 or send your product in for a free re-
varnish. Over-tightening is not recommend-
ed. If the tightening torque is too strong, the
system may be damaged.
HIGHEST POSSIBLE INCLINATION
- Inclination towards the player: approx. 40°
- Pivot left and right: 35° to each side
DISCLAIMER
DOLFINOS is not liable for any damages caused by the application and use of the product, to the instrument,
other property and person. DOLFINOS is not liable if damage is caused to the product itself, the instrument,
other property or person as a result of improper assembly and/or adjustment of the product.
The product contains small parts which can be swallowed. Keep away from children as they pose a choking
hazard!
[email protected]
+41 0 56 222 66 33
4. ADD-ONS
1. Grip sole and rubber sleeve are wear parts.
You can order replacement parts on
www.dolfinos.com
2. If you want use the Cello Grip-Foot on a
endpin with a spike, you can order a locking
screw
