Duncan Apollo Jazz Bass - neck Manual

Wiring Diagrams for
Pickup Models:
5427 hollister avenue, Santa Barbara, CA 93111
805.964.9610 • seymourduncan.com
Apollo Jazz Bass - neck
Apollo Jazz Bass - bridge
Apollo Jazz Bass - set
Apollo Jazz Bass - neck 67mm 5 strg
Apollo Jazz Bass - bridge 70mm 5 strg
Apollo Jazz Bass - set 67/70 5 strg
Apollo Jazz Bass - neck 70mm 5 strg
Apollo Jazz Bass - bridge 74mm 5 strg
Apollo Jazz Bass - set 70/74 5 strg
The basic steps for installation include:
1. Remove the strings from your bass.
2. Remove the control plate and flip it over.
3. De-solder the original pickup’s wires from the controls and
make sure to remember where they were connected.
4. Remove the pickup from the pickup cavity.
5. If the foam in the cavity of your bass has degraded, then
replace it with the foam included with your pickups.
6. Put your SD bass pickup into the pickup cavity.
7. Tin the wires from the SD bass pickup, and then solder them
into place.
8. Replace the control plate.
9. Re-string your bass, and adjust the pickup to string distance
to about 1/8” for the bridge and 3/16” for the neck.
Seymour Duncan
Solder
Solder
Tip (hot output)
Output Jack
.047
cap
Solder
Neck
Volume
250k
Bridge
Volume
250k
Master
Tone
250k
Sleeve (ground).
The inner, circular
portion of the jack
Solder
Solder
Tip (hot output)
Output Jack
.047
cap
Solder
Neck
Volume
250k
Bridge
Volume
250k
Master
Tone
250k
Sleeve (ground).
The inner, circular
portion of the jack
Visit seymourduncan.com for additional wiring diagrams.
Wiring for Apollo Jazz Bass 5 String
Wiring for Apollo Jazz Bass 4 String
P/N 501030-135
Jazz Bass and Fender are registered trademarks of FMIC, with which Seymour Duncan is not affiliated
Seymour Duncan
Seymour Duncan
Seymour Duncan
Bare +
Ground
White
White
White
Bare +
Ground
Bare +
Ground
Bare +
Ground
White
Congratulations on your purchase of a fine, hand-built,
Seymour Duncan bass guitar pickup! Installing this pickup
in your bass isn’t rocket science. And, if you’re already handy
with tools, it’ll be a snap for you,and fun too! But if you have
no experience handling red-hot soldering irons, you’d be
well advised to take your new pickup and your trusty
bass to a qualified guitar tech.

Wiring Diagrams for
Pickup Models:
5427 hollister avenue, Santa Barbara, CA 93111
805.964.9610 • seymourduncan.com
Quarter Pound P-Bass® - 5 strg
The basic steps for installation include:
1. Remove the strings from your bass.
2. Remove the control plate and flip it over.
3. De-solder the original pickup’s wires from the controls and
make sure to remember where they were connected.
4. Remove the pickup from the pickup cavity.
5. If the foam in the cavity of your bass has degraded, then
replace it with the foam included with your pickups.
6. Put your SD bass pickup into the pickup cavity.
7. Tin the wires from the SD bass pickup, and then solder them
into place.
8. Replace the control plate.
9. Re-string your bass, and adjust the pickups so they are set
about 3/16” from the strings when they are pressed down at
the highest fret on the neck.
Tip (hot output)
Output Jack
Volume
250k
Ground wire from bridge
Tone
250k
Sleeve (ground).
The inner, circular
portion of the jack
Seymour Duncan
Seymour Duncan
Solder
.047
cap
Solder
Visit seymourduncan.com for additional wiring diagrams.
P-Bass and Fender are registered trademarks of FMIC, with which Seymour Duncan is not affiliated
Wiring for 5 String Quarter-Pound for P-Bass®
White
Shield
Congratulations on your purchase of a fine, hand-built,
Seymour Duncan bass guitar pickup! Installing this pickup
in your bass isn’t rocket science. And, if you’re already handy
with tools, it’ll be a snap for you,and fun too! But if you have
no experience handling red-hot soldering irons, you’d be
well advised to take your new pickup and your trusty
bass to a qualified guitar tech.
