Dolmar AS1925 User manual

AS1925
AS1925C
EN Cordless Chain Saw INSTRUCTION MANUAL 8
FR Tronçonneuse sans Fil MANUEL D’INSTRUCTIONS 20
DE Akku-Kettensäge BETRIEBSANLEITUNG 33
IT Motosega a batteria ISTRUZIONI PER L’USO 47
NL Accukettingzaag GEBRUIKSAANWIJZING 60
ES Electrosierra Inalámbrica MANUAL DE
INSTRUCCIONES 73
PT Motosserra a Bateria MANUAL DE INSTRUÇÕES 86
DA Akku-kædesav BRUGSANVISNING 99
EL Φορητό αλυσοπρίονο ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ 111
TR Akülü Ağaç Kesme KULLANMA KILAVUZU 126

Fig.1
12 34
5
6
12
13
14
7
8
10
9
11
16
17
18 15
Fig.2
1
2
3
Fig.3
1
2
Fig.4
2

1
2
Fig.5
1
2
Fig.6
1
23
23
Fig.7
1
Fig.8
12
Fig.9
1
2
Fig.10
2
3
4
1
Fig.11
3

1
Fig.12
1
Fig.13
1
2
3
Fig.14
1
Fig.15
12
Fig.16
1
2
Fig.17
Fig.18
Fig.19
4

Fig.20
1
2
Fig.21
Fig.22
Fig.23
Fig.24
A
B
A
B
Fig.25
1
2
Fig.26
22
11
31
Fig.27
5

30
30
55 55
Fig.28
1
2
Fig.29
30 1/5
1
Fig.30
Fig.31
Fig.32
Fig.33
1
2
Fig.34
1
2
Fig.35
6

12
Fig.36
7

8ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: AS1925 AS1925C
Overall length (without guide bar) 256 mm
Rated voltage D.C. 18 V
Net weight 2.8 - 3.3 kg
Standard guide bar length 250 mm
Recommended guide bar length with 90PX 250 mm -
with 91PX 250 mm -
with 25AP -250 mm
Applicable saw chain type
(refer to the table below) 90PX 91PX 25AP
Standard sprocket Number of teeth 6 9
Pitch 3/8″ 1/4″
Chain speed 0 - 24 m/s
(0 - 1,440 m/min) 0 - 22.5 m/s (0 - 1,350 m/min)
Chain oil tank volume 140 cm3
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge
BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 / BL1840B / BL1850 / BL1850B / BL1860B /AP-183
• Some of the battery cartridges listed above may not be available depending on your region of residence.
WARNING: Only use the battery cartridges listed above. Use of any other battery cartridges may cause
injuryand/orre.
Saw chain, guide bar, and sprocket combination
Saw chain type 90PX
Number of drive links 40
Guide bar Guide bar length 250 mm
Cutting length 244 mm
Pitch 3/8″
Gauge 1.1 mm
Type Sprocket nose bar
Sprocket Number of teeth 6
Pitch 3/8″
Saw chain type 91PX
Number of drive links 40
Guide bar Guide bar length 250 mm
Cutting length 244 mm
Pitch 3/8″
Gauge 1.3 mm
Type Sprocket nose bar
Sprocket Number of teeth 6
Pitch 3/8″

9ENGLISH
Saw chain type 25AP
Number of drive links 60
Guide bar Guide bar length 250 mm
Cutting length 250 mm
Pitch 1/4″
Gauge 1.3 mm
Type Carving bar
Sprocket Number of teeth 9
Pitch 1/4″
NOTICE: When using 25AP saw chain, use with Sprocket 9 (optional accessory).
WARNING:Useappropriatecombinationoftheguidebarandsawchain.Otherwisepersonalinjurymay
result.
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
Read instruction manual.
Wear safety glasses.
Wear ear protection.
Wear a helmet, goggles and ear protection.
Use appropriate protection for foot-leg and
hand-arm.
This saw is to be used by properly trained
operators only.
Do not expose to moisture.
Maximum permissible cut length
Always use two hands when operating the
chain saw.
Direction of chain travel
Sawchainoiladjustment
Ni-MH
Li-ion Only for EU countries
Do not dispose of electric equipment or battery
pack together with household waste material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries andAccumulators
and Waste Batteries andAccumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.
Intended use
The tool is intended for cutting branches and pruning
trees. It is also suitable for tree service.
Noise
The typicalA-weighted noise level determined accord-
ing to IEC62841-4-1:
Model AS1925
Sound pressure level (LpA) : 92.2 dB(A)
Sound power level (LWA) : 103.2 dB (A)
Uncertainty (K) : 2.5 dB(A)
Model AS1925C
Sound pressure level (LpA) : 92.2 dB(A)
Sound power level (LWA) : 103.2 dB (A)
Uncertainty (K) : 2.5 dB(A)
WARNING: Wear ear protection.
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to IEC62841-4-1:
Model AS1925
Work mode: cutting wood
Vibration emission (ah,W) : 3.1 m/s2
Uncertainty (K) : 1.5 m/s2
Model AS1925C
Work mode: cutting wood
Vibration emission (ah,W) : 4.1 m/s2
Uncertainty (K) : 1.5 m/s2
NOTE: The declared vibration emission value has
been measured in accordance with the standard test
method and may be used for comparing one tool with
another.
NOTE: The declared vibration emission value
may also be used in a preliminary assessment of
exposure.

10 ENGLISH
WARNING: The vibration emission during actual
use of the power tool can differ from the declared
emission value depending on the ways in which the
tool is used.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it is
running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
The EC declaration of conformity is included asAnnex A
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Cordless Chain saw safety warnings
1. Keep all parts of the body away from the saw
chain when the chain saw is operating. Before
you start the chain saw, make sure the saw
chain is not contacting anything.A moment of
inattention while operating chain saws may cause
entanglement of your clothing or body with the
saw chain.
2. Always hold the chain saw with your right
hand on the top handle and your left hand on
the front handle. Holding the chain saw with a
reversedhandcongurationincreasestheriskof
personalinjuryandshouldneverbedone.
3. Hold the power tool by insulated gripping
surfaces only, because the saw chain may con-
tact hidden wiring. Saw chains contacting a "live"
wire may make exposed metal parts of the power
tool "live" and could give the operator an electric
shock.
4. Wear safety glasses and hearing protection.
Further protective equipment for head, hands,
legs and feet is recommended.Adequate protec-
tiveclothingwillreducepersonalinjurybyying
debris or accidental contact with the saw chain.
5. Always keep proper footing.
6.
When cutting a limb that is under tension be alert
for spring back.Whenthetensioninthewoodbres
is released the spring loaded limb may strike the
operator and/or throw the chain saw out of control.
7. Use extreme caution when cutting brush and
saplings. The slender material may catch the saw
chain and be whipped toward you or pull you off
balance.
8. Carry the chain saw by the front handle with
the chain saw switched off and away from your
body. When transporting or storing the chain
saw always t the guide bar cover. Proper
handling of the chain saw will reduce the likelihood
of accidental contact with the moving saw chain.
9. Follow instructions for lubricating, chain ten-
sioning and changing accessories. Improperly
tensioned or lubricated chain may either break or
increase the chance for kickback.
10. Keep handles dry, clean, and free from oil and
grease. Greasy, oily handles are slippery causing
loss of control.
11. Cut wood only. Do not use chain saw for pur-
poses not intended. For example: do not use
chain saw for cutting plastic, masonry or non-
wood building materials. Use of the chain saw for
operations different than intended could result in a
hazardous situation.
12. Causes and operator prevention of kickback:
Kickback may occur when the nose or tip of the
guidebartouchesanobject,orwhenthewood
closes in and pinches the saw chain in the cut.
Tip contact in some cases may cause a sudden
reverse reaction, kicking the guide bar up and
back towards the operator. Pinching the saw chain
along the top of the guide bar may push the guide
bar rapidly back towards the operator. Either of
these reactions may cause you to lose control of
the saw which could result in serious personal
injury.Donotrelyexclusivelyuponthesafety
devices built into your saw. As a chain saw user,
you should take several steps to keep your cutting
jobsfreefromaccidentorinjury.
Kickback is the result of tool misuse and/or incor-
rect operating procedures or conditions and can be
avoided by taking proper precautions as given below:
• Maintainarmgrip,withthumbsandngers
encircling the chain saw handles, with both
hands on the saw and position your body
and arm to allow you to resist kickback
forces. Kickback forces can be controlled by
the operator, if proper precautions are taken.
Do not let go of the chain saw.
►Fig.1
• Do not overreach and do not cut above
shoulder height. This helps prevent unin-
tended tip contact and enables better control
of the chain saw in unexpected situations.
• Only use replacement bars and chains spec-
iedbythemanufacturer.Incorrectreplace-
ment bars and chains may cause chain
breakage and/or kickback.
• Follow the manufacturer’s sharpening and
maintenance instructions for the saw chain.
Decreasing the depth gauge height can lead
to increased kickback.
