FOREWORD

Thank you very much for purchasing a DOLMAR POWER GENERATOR.

This manual covers operation and maintenance of the DOLMAR POWER GENERATOR.

This DOLMAR POWER GENERATOR can be used for general electrical equipments, appliances, lamps, tools

as an AC power source. With regards to DC application, the terminals are used only for charging 12 volt battery.

Never use this generator for any other purposes.

Please take a moment to familiarize yourself with the proper operation and maintenance procedures in order

to maximize the safe and efficient use of this product.

Keep this owner’s manual at hand, so that you can refer to it at any time.

Due to constant efforts to improve our products, certain procedures and specifications are subject to change

without notice.

When ordering spare parts, always give us the MODEL, PRODUCTION NUMBER (PROD No.) and

SERIAL NUMBER (SER No.) of your Product.

Please fill in the following blanks after checking the production number on your product.

(Location of label is different depending on the product model.)

CONTENTS

1. SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2. COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3. CONTROLS AND INDICATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

4. PRE-OPERATION CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

5. OPERATING PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

6. WATTAGE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

7. MAINTENANCE SCHEDULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

8. "HOW-TO" MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

PERIODIC OPERATION AND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

10.

TRANSPORTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

. PREPARATION FOR STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

. WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

PROD No. SER No.

(Label)

Please refer to the illustrations on the back page of the front cover or back cover

for Fig. 11to 66indicated in the sentence.

NOTE

GE-1700I(GB)GU216905.11.711:25AMページ1

1. SAFETY PRECAUTIONS

Please make sure you review each precaution carefully.

Pay special attention to statement preceded by the following words.

“WARNING” indicates a strong possibility of severe personal injury or loss

of life if instructions are not followed.

“CAUTION” indicates a possibility of personal injury or

equipment damage if instructions are not followed.

Do not operate the generator near gasoline or gaseous fuel because of the potential

danger of explosion or fire.

Do not fill the fuel tank with fuel while the engine is running. Do not smoke or use open

flame near the fuel tank. Be careful not to spill fuel during refueling. If fuel is spilt, wipe

it off and let dry before starting the engine.

WARNING

Operate the generator on a level surface.

It is not necessary to prepare a special foundation for the generator.

However, the generator will vibrate on an irregular surface, so choose a level place without surface

irregularities.

If the generator is tilted or moved during operation, fuel may spill and / or the generator may tip over, causing

a hazardous situation.

Proper lubrication cannot be expected if the generator is operated on a steep incline or slope. In such a case,

piston seizure may occur even if the oil is above the upper level.

WARNING

Pay attention to the wiring or extension cords from the generator to the connected device.

If the wire is under the generator or in contact with a vibrating part, it may break and

possibly cause a fire, generator burnout, or electric shock hazard.

Replace damaged or worn cords immediately.

WARNING

Do not operate the generator inside a room, cave, tunnel, or other

insufficiently ventilated area. Always operate it in a well-ventilated area,

otherwise the engine may become overheated, and the poisonous carbon

monoxide gas contained in the exhaust gases will endanger human lives.

Keep the generator at least 1 meter (3 feet) away from any structure or

building during use.

If the generator must be used indoors, the area must be well-ventilated and

extreme caution must be taken regarding the discharge of exhaust gases.

WARNING

Do not place in flammables near the generator.

Be careful not to place fuel, matches, gunpowder, oily cloths, straw, trash, or any other in flammables near

the generator.

WARNING

Do not enclose the generator nor cover it with a box.

The generator has a built-in forced air cooling system, and may become overheated if it is enclosed.

If generator has been covered to protect it from the weather during non use, be sure to remove it and keep

it well away from the area during generator use.

WARNING

CAUTION

GE-1700I(GB)GU216905.11.711:25AMページ2

Do not contact the generator to a commercial power line. Connection to a commercial

power line may short circuit the generator and ruin it or cause electric shock hazard. Use

the transfer switch for connecting to domestic circuit.

WARNING

Engine becomes extremely hot during and for some time after operation. Keep

combustible materials well away from generator area.

Be very careful not to touch any parts of the hot engine especially the muffler area or

serious burns may result.

WARNING

No smoking while handling the battery. The battery emits flammable hydrogen gas,

which can explode if exposed to electric arcing or open flame.

Keep the area well-ventilated and keep open flames/sparks away when handling the battery.

WARNING

Do not operate in rain, in wet or damp conditions, or with wet hands.

The operator may suffer severe electric shock if the generator is wet due to rain or snow.

WARNING

Keep children and all bystanders at a safe distance from work areas.

WARNING

If wet, wipe and dry it well before starting. Do not pour water directly over the generator, nor wash it with water.

WARNING

Be extremely careful that all necessary electrical grounding procedures are followed during each and every

use. Failure to do so can be fatal.

WARNING

It is absolutely essential that you know the safe and proper use of the power tool or appliance that you intend

to use. All operators must read, understand and follow the tool/appliance owners manual. Tool and appliance

applications and limitations must be understood. Follow all directions given on labels and warnings. Keep all

instruction manuals and literature in a safe place for future reference.

WARNING

Use only "LISTED" extension cords.

When a tool or appliance is used outdoors, use only extension cords marked "For Outdoor Use". Extension

cords, when not in use should be stored in a dry and well ventilated area.

WARNING

Always switch off generator's AC circuit breaker and disconnect tools or appliances when not in use, before

servicing, adjusting, or installing accessories and attachments.

WARNING

Make sure the engine is stopped before starting any maintenance, servicing or repair.

Make sure maintenance and repair of the generator set are performed by properly trained personnel only.

CAUTION

GE-1700I(GB)GU216905.11.711:25AMページ3

Symbols and Meanings

In accordance with the European requirements (eec Directives),the specified symbols as shown in the

following table are used for the products and this instruction manual.

Read the operator's instruction manual.

Stay clear of the hot surface.

Exhaust gas is poisonous.

Do not operate in an unventilated room.

Stop the engine before refueling.

Fire, open light and smoking

prohibited.

Caution, risk of electric shock.

HOT, avoid touching the hot area.

Do not connect the generator to

the commercial power lines.

Engine oil

(power and Engine)

Add oil

Battery charging

condition

OFF

(power and Engine)

Alternating current

Direct current

Plus ;

positive polarity

Minus ;

negative polarity

OUT-position of a

bistable push control

IN-position of a

bistable push control

Protective earth

(ground)

Fuse

Choke ;

cold starting aid

Engine start

(Electric start)

Engine stop

Gasoline

Fast

Slow

Fuel start / Open

Fuel stop / Close

PrRated power (kW) COP Continuous power

COS

rRated power factor

frRated frequency (Hz) UrRated voltage (V) IrRated current (A)

Hmax

Maximum site altitude

above sea-level (m) Tmax

Maximum ambient

temperature ( )

mMass (kg)

GE-1700I(GB)GU216905.11.711:25AMページ4

2. COMPONENTS (See Fig. 11)

CONTROLS AND INDICATORS

(See Fig. 22)

1. ENGINE SWITCH (See Fig. 22-qq)

Please refer to the illustrations on the back

page of

the front cover or back cover for

Fig. 11to 66

indicated in the sentence.

NOTE

qRECOIL STARTER (HANDLE)

wCONTROL PANEL

eSIDE PANEL (L)

rAIR CLEANER

tFUEL DRAIN SCREW

yCARRING HANDLE

uTANK CAP COVER

iEXHAUST OUTLET

oOIL DRAIN PLUG

!0 SIDE PANEL (R)

!1 OIL GAUGE (OIL FILLER)

!2 SPARK PLUG CAP

The engine switch is designed for easy operation

with the interlocking mechanism between the fuel

cock and the choke furnished.

2. PILOT LAMP and OVERLOAD LAMP

(See Fig. 22-ww)

These lamps are turned on in the following conditions;

PILOT LAMP (Green) --- The lamp is turned on

while generating properly.

OVERLOAD LAMP (Red) --- The lamp is turned on in the

overload condition.

* The breaker will be activated after the lamp is

turned on for 20 seconds in the 120% electric

power condition, and results in no load condition.

* If the lamp is turned on, stop and start the engine

again to resume the operation.

3. OIL SENSOR LAMP (See Fig. 22-ee)

When the level of the engine oil falls below the

prescribed value, the alarm lamp lights up and the

engine stops automatically. When the engine stops

due to oil shortage, it can not be started anymore

even by pulling the start knob (just the alarm lamp

flickers). In such a case, replenish engine oil up to

the mouth of the oil filling port.

(Refer to page 6 for details about the oil

replenishing procedure).

6. DC TERMINALS (See Fig. 22-tt)

DC electric power for battery charge is available.

- Red is positive (+) terminal.

- Black is negative (

) terminal.

4. AUTO POWER SAVE SWITCH (See Fig. 22-rr)

With the switch in the " "( ) marking position,

the engine speed is reduced automatically when no

electricity is taken out, while the engine speed is

automatically adjusted in accordance with the load

condition when the electricity is taken out.

When using in the heavy load condition, set the switch

into the " "( ) marking position to maintain the

electric power level in the stable condition.

When using DC power, turn the switch into the

""(OFF) position.

5. AC RECEPTACLES

AC electric power is available through this receptacle.

Use a ground type, three-leg plug as shown.

■■Do not plug more than two appliances

into the generator at a time.

■■Do not put foreign objects into the plug

receptacle.

CAUTION

(CHOKE)

To start the engine, turn the knob to the

position. (Choke valve is closed.)

""(RUN)

Keep the knob in this position after the

engine starts. (The engine can be

started with the knob at this position

when the engine is warm.)

""(STOP)

To stop the engine, return the knob to

the position.

(The fuel cock is closed as well.)

GE-1700I(GB)GU216905.11.711:25AMページ5

Ambient

temperature

Single grade

Multigrade

10W

20W

#20

#30

#40

10W

8. RECOIL STARTER (See Fig. 22-uu)

Pull this handle to start the generator.

qRECOIL STARTER HANDLE

7. DC CIRCUIT BREAKER (See Fig. 22-yy)

DC circuit breakers shut off electric current when

the current exceeds its limit or a malfunction occurs

in the connected appliance.

Check for excessive current consumption or defects

in the appliance. After making sure everything is in

order, push the button to the " ON " position.

qBUTTON eIN (ON) " "

wKNOB rOUT (OFF) " "

If circuit breaker continues to be

activated, discontinue use and check

generator and/or appliance for

malfunction with their respective service

representatives.

Never interfere with the operation of the

circuit breaker knob or keep pushing it in

the "ON" position.

CAUTION

4. PRE-OPERATION CHECKS

(See Fig. 33)

1. CHECK ENGINE OIL (See Fig. 33-qq,ww)

Before checking or refilling oil, be sure generator is

located on stable and level surface with engine stopped.

■■

Remove oil filler cap and check the engine oil level.

■■If oil level is below the lower level line, refill

with suitable oil (see table) to upper level line.

Do not screw in the oil filler cap when

checking oil level.

■■Change oil if contaminated.

(See "How-To" Maintenance.)

Oil capacity . . . . 0.4 liters

2. CHECK ENGINE FUEL (SeeFig. 22-oo, 33-ee)

Recommended engine oil:

Use 4-stroke automotive detergent oil of API service class

SE or higher grade (SG, SH or SJ is recommended).

SAE 10W-30 or 10W-40 is recommended for

general, all-temperature use. If single viscosity oil is

used, select the appropriate viscosity for the

average temperature in your area.

Do not refuel while smoking or near open

flame or other such potential fire hazards.

Otherwise fire accident may occur.

WARNING

■■If fuel level is low, refill with unleaded

automotive gasoline.

■■Fuel level should never over the RED marking

at the inlet portion. (SeeFig. 33-ee-q

)

qRED MARKING

■■Be sure to use the fuel filter screen on the fuel

filter neck.

qFUEL TANK CAP

wFUEL FILTER SCREEN

eTANK CAP COVER

Fuel tank capacity . . . . . . . . . 3.5 liters

■■

When using the generator first time or stopping

due the fuel running out, pull the recoil handle

several times after filling fuel up to the RED

marking at the inlet portion of the fuel tank.

qFUEL TANK CAP

wFUEL FILTER SCREEN

eTANK CAP COVER

9. GROUND TERMINAL (See Fig. 22-ii)

Terminal for grounding the generator.

11. SIDE PANEL (L.R.) (See Fig. 22-!!00)

To access the following items for servicing, take the

applicable side panel out by removing the screw

with screwdriver or coin.

LH-side panel ---- Air cleaner etc.

RH-side panel ---- Oil level gauge, Ignition coil,

Spark plug etc.

. FUEL TANK CAP (See Fig. 22-oo)

The fuel tank cap is located behind the cover.

To open the cover, lift up with the dent portion

depressed backward as shown in the illustration.

Remove the fuel tank cap by turning

counterclockwise.

GE-1700I(GB)GU216905.11.711:25AMページ6

■■If such grounding conductor or grounding

electrode is unavailable, connect the

grounding lug of the generator to the

grounding terminal of the using electric tool or

appliance. (See Fig. 22-ii, 33-rr)

qGROUND TERMINAL

wGROUNDING SPIKE

OPERATING PROCEDURES

(See Fig. 44)

1. STARTING THE GENERATOR

(a) Make sure the appliance is disconnected.

(b)Turn engine switch to " "(CHOKE) position.

(When engine is warm or temperature is high,

start engine with the switch at " "( RUN)

position.) (See Fig. 44-qq)

compression point (resistance will be felt), then

return the handle to its original position and pull

briskly. (See Fig. 44-ww)

qRECOIL STARTER HANDLE

wPULL BRISKLY

(d)After starting, allow the starter handle to return to

its original position with the handle still in your hand.

Check the oil level before each operations

as outlined on page 6.

CAUTION

■■Do not connect defective appliances

including lines and plugs.

■■Be sure appliances are not connected

to generator when starting up.

Starting the generator with an

appliance connected could result in

damage to the generator and/or

appliance and in personal injury.

CAUTION

NOTE

When engine fails to start after several attempts,

repeat the starting procedures mentioned above

with the engine switch placed at " "( RUN)

position.

Make sure you review each warning in

order to prevent fire hazard.

■■Do not refill tank while engine is

running or hot.

■■Before filling fuel, turn the engine switch

into " "( STOP) position.

■■

Be careful not to admit dust, dirt, water

or other foreign objects Into fuel.

■■Wipe off spilt fuel thoroughly before

starting engine.

■■Keep open flames away.

WARNING

3. CHECKING COMPONENT PARTS

Check following items before starting engine:

■■Fuel leakage from fuel hose, etc.

■■Bolts and nuts for looseness.

■■Components for damage or breakage.

■■Generator not resting on or against any

adjacent wiring.

5. GROUNDING THE GENERATOR

■■To ground the generator to the earth, connect

the grounding lug of the generator to the

grounding spike driven into the earth or to the

conductor which has been already grounded

to the earth. (See Fig. 33-rr)

4. CHECK GENERATOR SURROUNDINGS.

Make sure you review each warning in

order to prevent fire hazard.

■■Keep area clear of in flammables or

other hazardous materials.

■■

Keep generator at least 1 meter

away

from buildings or other structures.

■■

Only operate generator in a dry, well

ventilated area.

■■Keep exhaust pipe clear of foreign

objects.

■■Keep generator away from open flame.

No smoking!

■■Keep generator on a stable and level

surface.

■■Do not block generator air vents with

paper or other material.

WARNING

■■When listening the radio near by the

generator, the radio sound may be

disturbed

on account of the radio wave

condition and the

radio performance.

GE-1700I(GB)GU216905.11.711:25AMページ7

■■Make sure that the appliance is switched OFF before connecting it to the generator.

■■Do not move the generator while it is running.

■■Be sure to ground the generator if the connected appliance is grounded. Failure to

ground unit may lead to electrical shock.

WARNING

2. USING ELECTRIC POWER

CONTROL PANEL

GE-1700 I (50Hz-230V)

1 5

2 3 4

(e) After 20 to 30 seconds of warm-up is completed, turn the engine switch to

""(

RUN)

position.

(See Fig. 44-ee)

(f) Make sure the pilot lamp is on. This indicates that the generator is properly operating.

NOTE

Please consult with the authorized DOLMAR factory or authorized service center

if the pilot lamp is turned off during the proper operation.

(1) AC APPLICATION (See Fig. 44-rr)

(a) Make sure the pilot lamp is turned on.

(b) Turn off the switch(es) of the electrical appliance(s) before

connecting to the generator.

qPILOT LAMP

wOVERLOAD LAMP

eOIL SENSOR LAMP

rAUTO POWER SAVE LAMP

tAUTO POWER SAVE SWITCH

yAC RECEPTACLES

uDC TERMINALS

iDC CIRCUIT BREAKER

oGROUND TERMINAL

!0 ENGINE SWITCH

■■Be sure to ground the generator if the

connected

electrical device is grounded.

■■

Failure to ground unit could lead to electrical shock.

WARNING

GE-1700I(GB)GU216905.11.711:25AMページ8

(d) Turn on the switch of the appliance.

NOTE

If the generator is stopped with the overload pilot

lamp turned on, the generator will be in the

overload condition and/or the electrical

appliance(s) would be out of order.

In this case, stop the engine immediately and

check the appliance and/or generator for overloading.

After the check and remedy, restarting the engine

will resume displaying in the normal manner.

(2) DC APPLICATION (See Fig. 44-tt)

The DC terminal is used only for charging 12 volt

batteries. It provides up to 12V-8.3A (100W) of

maximum power.

qPositive terminal (RED)

wNegative terminal (BLACK)

CONNECTION OF CABLE :

■■Connect positive terminal (red) on generator

to positive (+) terminal on battery.

■■Connect negative terminal (black) on

generator to negative (

) terminal on battery.

SAFETY PRECAUTIONS WHILE CHARGING

■■An explosive hydrogen gas is discharged

through vent holes in the battery during the

charging process. Do not allow spark or open

flame around the generator or battery during the

charging process.

■■Electrolyte fluid can burn eyes and clothing.

Be extremely careful to avoid contact. If injured,

wash the affected area immediately with large

quantities of water and consult a doctor for

treatment.

■■When charging a large capacity battery or

totally discharged battery, excessive current

may force the DC breaker to turn off.

In such cases, use a battery charger to charge

a large battery with AC output.

■■

Battery defects may cause the DC breaker to turn off.

Check the battery before replacing the DC breaker.

3. STOPPING THE GENERATOR

(a) Turn off the power switch of the electric

equipment and unplug the cord from receptacle

of the generator.

(b) Allow the engine about 3 minutes to cool down

at no load before stopping.

(c)

Turn the engine switch to the position " "( STOP).

(See Fig. 44-yy)

4. OIL SENSOR (See Fig. 44-uu)

(a) The oil sensor detects the fall in oil level in the

crankcase and automatically stops the engine

when the oil level falls below a predetermined level.

(b) When engine has stopped automatically, switch

off generator's AC circuit breaker, and check the

oil level.

Refill engine oil to the upper level as instructed

on page 6 and restart the engine.

(c)

If the engine dose not start by usual starting

procedures, check the oil level

qOIL SENSOR

Do not remove OIL SENSOR PROBE when

refilling with oil.

Remove oil filler cap on the opposite side

of carburetor.

CAUTION

■■

Do not put foreign objects into the

plug receptacle.

CAUTION

■■

Check the amperage of the receptacles, and be sure not

to take a current exceeding the specified amperage.

■■Be sure that the total wattage of all appliances

dose not exceed the rated output of the generator.

GE-1700I(GB)GU216905.11.711:25AMページ9

■■Electrical loads such as incandescent lamps and hot plates require the same wattage to start as is

needed to maintain use.

■■Loads such as fluorescent lamps require 1.2 to 2 times the indicated wattage during start-up.

■■Loads for mercury lamps require 2 to 3 times the indicated wattage during start-up.

■■Electrical motors require a large starting current. Power requirements depend on the type of motor and

its use. Once enough "surge" is attained to start the motor, the appliance will require only 50% to 30%

of the wattage to continue running.

■■Most electrical tools require 1.2 to 3 times their wattage for running under load during use. For example,

a 5000 watt generator can power a 1800 to 4000 watt electrical tool.

■■Loads such as submersible pumps and air compressors require a very large force to start. They need 3

to 5 times the normal running wattage in order to start.

For example, a 5000 watt generator would only be able to drive a 1000 to 1700 watt pump.

Some appliances need a "surge" of energy when starting.

This means that the amount of electrical power needed to start the appliance may exceed the amount

needed to maintain its use.

Electrical appliances and tools normally come with a label indicating voltage, cycles / Hz, amperage (amps)

and electrical power needed to run the appliance or tool.

Check with your nearest dealer or service center with questions regarding power surge of certain appliances

or power tools.

6. WATTAGE INFORMATION

To determine the total wattage required to run a

particular electrical appliance or tool, multiply the

voltage figure of the appliance/tool by the amperage

(amps) figure of same. The voltage and amperage

(amps) information can be found on a name plate

which is normally attached to electrical appliances

and tools.

NOTE

The following wattage chart is general guide only. Refer to your specific appliance for

correct wattage.

Applicable Wattage (approx. W)

50 Hz

1350

700

400

300

Applications

Incandescent lamp, Heater

Fluorescent lamp, Electric tool

Mercury lamp

Pump, Compressor

VOLTAGE DROP IN ELECTRIC EXTENSION CORDS

When a long electric extension cord is used to connect an appliance or tool to the generator, a certain amount of

voltage drop or loss occurs in the extension cord which reduces the effective voltage available for the appliance or tool.

The chart below has been prepared to illustrate the approximate voltage loss when an extension

cord of 300 feet

(approx. 100 meters) is used to connect an appliance or tool to the generator.

Nominal

cross

section

A.W.G.

Allowable

current

No.of strands

/ strands dia.

Resistance

Current Amp.

No./mm Ω/100m

mm2No. A1A 3A 5A 8A 10A 12A 15A

0.75 18 730/0.18 2.477 2.5V 8V

12.5V

─ ─ ─ ─

Voltage drop

1.27 16 12 50/0.16 1.486 1.5V 5V 7.5V 12V 15V 18V ─

2.0 14 17 37/0.26 0.952 1V 3V 5V 8V 10V 12V 15V

3.5 12 to 10 23 45/0.32 0.517 ─1.5V 2.5V 4V 5V 6.5V 7.5V

5.5 10 to 8 35 70/0.32 0.332 ─1V 2V 2.5V 3.5V 4V 5V

GE-1700I(GB)GU216905.11.711:25AMページ10

7. MAINTENANCE SCHEDULE

DAILY

■Check oil level.

■Check all components according to "PRE-OPERATION

CHECKS."

EVERY 50 HOURS

■Wash cleaner element. -more often if used in dirty or dusty

environments.

■Check spark plug, clean if necessary.

EVERY 100 HOURS ■Change engine oil. *-more often if used in dusty or dirty

environments.

EVERY 200 HOURS

■Adjust spark plug gap.

■Clean fuel strainer.

EVERY 500 HOURS

■Replace spark plug and cleaner element.

■Clean and adjust carburetor,valve clearance, and valve seat

along with cylinder head.

EVERY 1,000 HOURS

(24 MONTHS)

■Inspect control panel parts.

■Check rotor and starter.

■Replace engine mount rubber.

■Overhaul engine.

■Change fuel lines.

NOTE : (*)

■■Initial oil change should be performed after first twenty (20) hours of use. Thereafter change oil every

100 hours.

■■Before changing the oil, check for a suitable way to dispose of the old oil.

Do not pour it down sewage drains, onto garden soil or into open streams.

Your local zoning or environmental regulations will give you more detailed instructions on proper

disposal.

GE-1700I(GB)GU216905.11.711:25AMページ11

2. SERVICING THE AIR CLEANER

(See Fig. 55-ww)

Maintaining an air cleaner in proper condition is

very important.

Dirt induced through improperly installed,

improperly serviced or inadequate elements

damages and wears out engines. Keep the

element always clean.

(a)

Unhook the cover and remove the cleaner element.

qELEMENT

wAIR CLEANER COVER

(b) Paper element: Clean by tapping gently to

remove dirt and blow off dust. Never use oil.

Clean paper element every 50 hours of

operation, and replace element every 200 hours

or once a year.

water. Squeeze out the water then dry the

element. (Do not twist.)

8. "HOW-TO" MAINTENANCE

(See Fig. 55)

1. ENGINE OIL CHANGE (See Fig.

55-qq)

qOIL DRAIN PLUG

■■Change engine oil every 50 hours.

(For new engine, change oil after 20 hours.)

(a) Drain oil by removing the drain plug and the oil

filler cap while the engine is warm.

(b)

Reinstall the drain plug and fill the engine with oil

until it reaches the upper level on the oil filler cap.

■■Use fresh and high quality lubricating oil to the

specified level as directed on page 6.

If contaminated or deteriorated oil is used or the

quantity of the engine oil is not sufficient, the

engine damage will result and its life will be

greatly shortened.

Make sure the engine is stopped before

starting any maintenance, servicing or

repair.

CAUTION

NOTE

It is recommended to use ear protection

when performing operation, maintenance

and repair of the generator set. Spark plug : BMR4A (NGK)

SPARK

ARRESTER

SCREEN

SCREW

MUFFLER

3. CLEANING AND ADJUSTING

SPARK PLUG (See Fig. 55-ee,rr)

qSPARK PLUG

wPLUG WRENCH

(a) If the plug is contaminated with carbon, remove

it using a plug cleaner or wire brush.

(b) Adjust the electrode gap to 0.6 to 0.7 mm.

When replacing with new spark plug, use the

above-recommended one.

If not available by all means, make sure to

replace with equivalent one of resistance type.

4. SPARK ARRESTR

The spark arrester must be cleaned regularly to

keep it functioning as designed.

A clogged spark arrester :

■■Prevents the flow of exhaust gas

■■Reduces engine output

■■Increases fuel consumption

■■Makes starting difficult

If the engine has been running, the muffler and the

spark arrester will be very hot. Allow the muffler to

cool before cleaning the spark arrester.

How to remove the spark arrester

(a) Remove the flange bolts from the muffler cover

and remove the muffler cover.

(b) Remove the special screw from the spark

arrester and remove the spark arrester from the

muffler.

GE-1700I(GB)GU216905.11.1411:34AMページ12

10. TRANSPORTING

When transporting the generator, make sure that

the fuel (gasoline) should be drained from the tank.

(a) Turn the engine switch to the " "( STOP)

position.

(b) Drain the fuel from the tank.

position.

■■To prevent fuel spillage due to the

vibration and impact, never transport

the generator with the fuel (gasoline)

filled in the tank.

■■Secure the tank cap thoroughly.

■■To avoid the risk of the gasoline

flammability, never leave the generator

in an area exposed to direct sunlight or

high temperatures for a long time.

■■

Keep the fuel (gasoline) in the exclusive

gasoline storage tank made by steel

when transporting.

WARNING

TANK CAP COVER

FUEL TANK CAP

■■Do not place any heavy objects on the

generator.

■■Select and place the generator in the

proper position of the transport vehicle

so that the generator not be moved or

fallen down.

Fix the generator with rope as necessary.

CAUTION

9. PERIODIC OPERATION AND

INSPECTION

When furnishing the generator as emergency

electric power source, periodic operation and

inspection are needed.

Fuel (gasoline) and engine oil will be deteriorated

with time, and this causes that the engine is

difficult to start and as the results improper

engine operation and fault.

Since the fuel (gasoline) will be deteriorated

with time, replace fuel (gasoline) with fresh

one periodically; once every three (3)

months is recommended.

CAUTION

(a) Check the fuel (gasoline), engine oil and air

cleaner.

(b) Start engine.

run the engine for over ten minutes.

(d) Check for the following items;

■■Proper engine running.

■■Adequate output and the indicator lamp

turned on properly.

■■The engine switch normally operated.

■■

No leakage of engine oil and fuel (gasoline).

Clean the spark arrester screen

Use a brush to remove carbon deposits from the

spark arrester screen.

Be careful to avoid damaging the screen.

The spark arrester must be free of breaks and

holes. Replace the spark arrester if it is damaged.

Install the spark arrester, and muffler protector in

the reverse order of disassembly.

SPARK ARESSTER SCREEN

GE-1700I(GB)GU216905.11.711:25AMページ13

When generator engine fails to start after several attempts, or if no electricity is available at the output

socket, check the following chart. If your generator still fails to start or generate electricity, contact your

nearest DOLMAR factory or authorized service center for further information or corrective procedures.

12. TROUBLESHOOTING

Check if engine switch is in its proper position. Turn engine switch to " "(CHOKE) position.

When Engine Fails to Start:

When No Electricity Is Generated at Receptacle:

Check if the DC circuit breaker

is turned OFF.

Check if the Overload Lamp

is turned ON (Red).

Check AC receptacle and DC terminals for

loose connection.

Check to see if engine starting was

attempted with appliances already

connected to generator.

Depress the circuit breaker into " "(ON)

position, after making sure the electric

appliances are in the normal condition.

Stop the engine and check the appliances

and/or generator for overloading.

Secure connection if necessary.

Turn off switch on the appliance, and

disconnect cable from receptacle. Reconnect

after generator has been started properly.

Check fuel level.

Check to make sure generator is not

connected to an appliance.

Check spark plug for loose spark plug cap.

Check spark plug for contamination.

Check engine oil level.

Check if the recommended spark plug

would be adopted.

If empty, refill fuel tank making sure not to overfill.

If connected, turn off the power switch on the

connected appliance and unplug.

If loose, push spark plug cap back into place.

Remove spark plug and clean electrode.

If the engine oil level is low, add the oil to the

upper level line on the oil gauge.

If not, replace with the recommended spark plug.

If the recommended spark plug is not available

by all means, make sure to replace with

equivalent one of resistance type.

11. PREPARATION FOR STORAGE

(See Fig. 66)

The following procedures should be followed prior to storage of your generator for periods of 6 months or longer.

■■Drain fuel from fuel tank carefully by disconnecting the fuel line.

Gasoline left in the fuel tank will eventually deteriorate making engine-starting difficult.

■■When draining fuel from the fuel tank, use the hand pomp and set it into the refilling port. (See Fig. 66-qq)

■■Remove the drain screw of the carburetor.(See Fig. 66-ww)

qDRAIN SCREW

■■Change engine oil.

■■Check for loose bolts and screws, tighten them if necessary.

■■Clean generator thoroughly with oiled cloth. Spray with preservative if available. NEVER USE WATER

TO CLEAN GENERATOR !

■■Pull starter handle until resistance is felt, leaving handle in that position.

■■Store generator in a well ventilated, low humidity area.

GE-1700I(GB)GU216905.11.711:25AMページ14

13. SPECIFICATIONS

GE-1700 I

Type

Rated power COP kW

Rated voltage V

Rated current A

DC output V-A

Safety device ; type

Auto power save

Model

Type

Displacement mL

Fuel

Fuel tank capacity L

Rated continuous operation

[Approx.] hours

Oil sensor

Length mm

Width mm

Height mm

Dry weight kg

1.35

Rated power factor 1.0

Rated frequency Hz 50

230

5.8

3.5

12 - 8.3

Circuit breaker

Safety device ; type Electronic breaker

Standard

EH09-2

85.8

20.5

Forced air-cooled, 4-cycle, Single cylinder, OHV type gasoline engine

Automotive Unleaded Gasoline

3.5

Spark plug BMR4A (NGK)

Standard

Maximum site altitude

above sea-level m 1,000

Maximum ambient

temperature °C 40

Starting system

Engine oil capacity L 0.4

Recoil starter

490

295

445

Multipole, revolving field inverter type

MODEL

GeneratorEngineDimensions

GE-1700I(GB)GU216905.11.711:25AMページ15

14.WIRING DIAGRAM

GE-1700 I (50Hz-230V)

Blk : Black

Wiring color code

Blk/W : Black/White

Blu : Blue

LBlu : Light blue

Brn : Brown

Brn/W : Brown/White

Grn : Green

Grn/W : Green/White

Org : Orange

Gry : Gray

R : Red

W : White

Y : Yellow

Grn/Y : Green/Yellow

W/Blk : White/Black

Pin : Pink

Y/Blu : Yellow/Blue

Pur : Purple

LED INDICATOR

Main

coil

Gry

Org

Blu

Gry

INVERTER&ENGINE

CONTROL UNIT

Grn/Y

Blk

Grn/Y

ENGINE

Grn/Y

DC coil

Gry

Blk

Brn

Grn/Y

Brn

Grn

Blu

Pur

Gry

Blk

Gry

Org

Blk

Brn

Blu

GENERATOR

CONTROL PANEL

Engine

switch

Earth

plate

Y/Blu

Auto power

save switch

Ignition

coil

Pickup

coil

Circuit

breaker

Earth

(ground)

terminal

Oil level

sensor

Step

motor

DC output

terminal

receptacle

GE-1700I(GB)GU216905.11.711:25AMページ16

Table of contents

Languages:

Other Dolmar Portable Generator manuals

Dolmar

Dolmar GE-2800 IS User manual

Popular Portable Generator manuals by other brands

BorMann

BorMann Pro BGB9000 manual

Briggs & Stratton

Briggs & Stratton PowerBoss 30211 Operator's manual

Generac Power Systems

Generac Power Systems 005688-0 owner's manual

Keysight

Keysight E8257D Option H1K user guide

RVMP

RVMP Flex Power 4000i owner's manual

AL-KO

AL-KO 2500-C Instructions for use

Coleman

Coleman Powermate PM0545007 Insert manual

EINHELL

EINHELL TC-PG 4000 Original operating instructions

Tektronix

Tektronix TSG4102A user manual

EcoFlow

EcoFlow DELTA user manual

Ulvac

Ulvac EMP-14A instruction manual

BLUEPALM

BLUEPALM BP-S500F instruction manual

Bioclimatic

Bioclimatic Aerotron 30 Installation, operation and maintenance guide

Dynaset

Dynaset HG 3,5 user manual

GW Instek

GW Instek ASR-3000 Series user manual

Honda

Honda EB3500X owner's manual

PeakTech

PeakTech 1006 Operation manual

Champion

Champion 46554 Owner's manual & operating instructions

Dolmar GE-1700 I User manual

Popular Portable Generator manuals by other brands
