DOM FAMILY Coast Rider User manual

Safety Cozy Fashion
Important: Keep these instructions for future reference.
This product is designed to comply with USA Standard: ASTM F833
Coast Rider
Instruction Manual
Item# 365
English - Page 2
Español - Página 16
Français - Page 31

02
WARNING
•ADULT ASSEMBLY REQUIRED.
•NEVER LEAVE CHILD UNATTENDED. Always keep child in view while in stroller.
•AVOID SERIOUS INJURY from falling or sliding out. Always use seat belt. After fastening buckles,
adjust belts to get a snug fit around your child.
•AVOID FINGER ENTRAPMENT: Use care when folding and unfolding the stroller. Be certain the
stroller is fully erected and latched before allowing your child near the stroller.
•NEVER USE STROLLER ON STAIRS or escalators. You may suddenly lose control of the stroller or
your child may fall out. Also, use extra care when going up or down a step or curb.
•AVOID STRANGULATION.
•DO NOT place items with a string around your child’s neck, suspend strings from this product, or
attach strings to toys.
•USE OF THE STROLLER with a child weighing more than 45 lb (20.5 kg) or taller than 37.8 in (96cm)
will cause excessive wear and stress on the stroller. Use the stroller with only one child at a time.
•TO PREVENT A HAZARDOUS, UNSTABLE CONDITION, never place purses, shopping bags, parcels
or accessory items on the handle (other than approved stroller bags). Never place anything on the
canopy.
•TO PREVENT A HAZARDOUS, UNSTABLE CONDITION, do not place more than 10 lb (4.5 kg) total
in the storage basket including the 2 lb (1 kg) in the basket pocket.(if supplied)
•TO AVOID BURNS, never put hot liquids in the cup holders.(if supplied)
•TO PREVENT TIPPING, do not place more than 3 lb (1.36 kg) total in the cupholders/snack tray.
•DO NOT use storage basket as a child carrier.
•DO NOT ALLOW your child to stand on the basket. It may collapse and cause injury.
•NEVER PLACE child in the stroller with head toward footrest.
•NEVER ALLOW YOUR STROLLER to be used as a toy.
•DISCONTINUE USING YOUR STROLLER should it become damaged or broken.
•STROLLER TO BE USED only at walking speed product not intended for use while jogging,
skating, etc.
•CAREGIVER MUST always help child get into and out of the stroller.
IMPORTANT!
Failure to follow these warnings and the assembly instructions could result in
serious injury or death. PLEASE SAVE INSTRUCTION MANUAL FOR FUTURE USE.
WARNING

03
12° or less more than 12°
X
THE STROLLER IS DESIGNED FOR USE ON FLAT OR GENTLY SLOPING SURFACES, AND MAY BE
UNSTABLE ON HIGHER SLOPING AND UNEVEN SURFACES AND USERS SHOULD BE AWARE OF
THE POSSIBILITY OF THE STROLLER ROLLING AWAY OR TIPPING OVER.
• WITH YOUR HAND THROUGH THE WRIST TETHER STRAP LOOP, PUSH THE STROLLER HOLDING BOTH
HANDLES.
• THE FRONT WHEELS MAY WOBBLE OR OSCILLATE WHEN WALKING FAST.
• THE STROLLER CAN BE TAKEN UP CURB BY EITHER PRESSING DOWN ON THE HANDLES AND RAISING
THE FRONT WHEELS AND MOUNTING THE CURB OR TURNING THE STROLLER AROUND AND PULLING
THE STROLLER UP THE CURB .
• CAUTION IS REQUIRED WHEN PUSHING THE STROLLER ACROSS STEEP SLOPES OR UNEVEN SURFACES
THIS MAY CAUSE STROLLER TO BECOME UNSTABLE AND FALL OVER. ALWAYS HOLD THE HANDLES
FIRMLY.
• DO NOT RUN WITH THE STROLLER.
• WHENEVER YOU STOP, ALWAYS APPLY THE BRAKES BEFORE YOU LEAVE THE STROLLER.
• DO NOT HANG BAGS OR GOODS FROM THE HANDLE AS THIS COULD CAUSE THE STROLLER TO TIP
OVER.
• THE UPRIGHT POSITIONS ARE NOT SUITABLE FOR A CHILD UNDER 6 MONTHS OLD.
WARNING

04
Guard Rail
Guard Rail
Support
Brake
Storage Latch
2nd Lock
PARTS LIST
Harness
Seat
Handle
Adjust Button
Handle Tube
Front Wheels
Rear Wheel
JoinPoint
Folding Plastic
Frame Guard Rail
Rear Wheel
L & R Canopy
Seat Simple Seat
Sold
Separately
BarT-
Front Wheel
L & R
Sold
Separately
Connector

05
F
1.ASSEMBLING THE RIDER
E
G
(1) Open storage latch, refer to
Fig. A, then Lift handle of stroller
up, refer to Fig B.
(2) Lift handle of stroller up until
heard “Click”, refer to Fig C/D,
CHECK that the stroller is
completely latched every time you
open the stroller and before
continuing with the rest of the
assembly steps.
(3) Front Wheels
Slide each Front wheel onto the
mounting post at the front of the
stroller as Fig. E, A “Click” will be
heard. Pull wheel to CHECK and
ensure that it is secure.
For easy transport or storage,
Push the wheel release tab
on the side of the stroller
frame and pull the wheel
away from the stroller. Fig. F.
(4)Rear Wheels
a. Attach Rear Wheel L into Rear
tube untill heard “Click” as Fig. G/H.
b. repeat for Rear Wheel R, Fig. I.
c. For easy transport or storage,
remove Rear wheel by pushing
the snap button and take the rear
wheels out.
BA
I
DC
H

06
2.ASSEMBLING THE SEAT
A
F
ED
I
CB
(5) Put Guard Rail Support go
through the hole on Seat, and
make sure seat back are inside
of the Gruard Rail as Fig. A.
Fix the Backrest to Guard Rail
by two Buckle as shown Fig. B;
Squeeze the side buckle
tongues can release the
buckle(Fig. C).
G
H
To detach the he Guard Rail/Seat
unit, simple reverse operation
(8/7/6/5).
(6) Put the Seat/Guard Rail on the
Frame Seat Board as Fig. D.
Press Guard Rail Support button
and push Guard Rail Support into
Frame Seat Board until heard
“Click” as Fig. E.
(7) Put the rope into the T washer
on the back of Frame Seat Board
as Fig. F, total 6pcs Ropes.
(8) Fix the Guard Rail to Handle
tube by Buckle as shown Fig. G;
Squeeze the side buckle tongues
can release the buckle (Fig. H).

07
DC
FE
HG
BA
(9) Press the Guard Rail
Support Button and take the
Guard Rail Support out, then put
into seat as Fig. A/B.
(10) Press the Handle Adjust
Button and push the handle
downward as Fig. C/D.
(11) Press the 2nd Lock and
pull the Folding Plastic upward
as Fig. E/F.
(12) Hold the action (11)
and pull the handle
downward untill
the Storage Latch is
locked as Fig. G/H
3. FOLDING THE RIDER
2nd Lock
Folding
Plastic

08
4.SECURING YOUR CHILD TO HARNESS
13
A
13
B
13
C
11
2
3
2
WARNING: USE THE HARNESS AT ALL TIMES.
When not in use disconnect shoulder straps from the waist
strap and buckle to prevent strangulation.
A five point harness is provided to restrain your child. Buckle tongues separate
for added safety. To reconnect buckle tongues and to secure the child in the
harness please follow the steps below carefully.
12 12
3
(15) Tighten or loosen crotch straps
by sliding up an down the 3 bar sliders.
Tighten or loosen the waist straps, hold
and lift the 3 bar slider and then pull the
harness strap, to adjust to the desired
fit. The waist strap needs to fit firmly
around the child (Fig C).
Shoulder straps
Buckle
housing
Crotch strap
Waist
strap Waist
strap
Shoulder
strap Shoulder
strap
Buckle
housing
Crotch strap
Waist
strap
3 bar
slider
Crotch strap
Waist
strap
3 bar
slider
(13) Position the shoulder strap
tongue (1) on the top of the waist
buckle tongue (2) on both sides
(Fig A).
(14) Push both buckle tongues
(1+2) into the buckle housing (3)
until the buckle tongues lock into
position (Fig B).

09
D E
5. SECURING YOUR CHILD TO HARNESS
FOR KIDS MORE THAN 3 YEARS OLD, YOU MAY USE T-BAR OR
GUARD RAIL WITHOUT SEAT.
7. USE GUARD RAIL ONLY
(16) Tighten or loosen the Shoulder strap, hold and lift the slider and then pull the harness
strap, to adjust to the desired fit. The waist strap needs to fit firmly around the child (Fig D).
(17) To release the buckle, squeeze the top button and buckle housing with enough pressure
so the buckle tongues can release from the buckle housing (Fig. E).
(19) Detach the Seat unit from the Rider. and add the Simple Seat into the Frame Seat
Board Put the rope into the T washer on the back of Frame Seat Board.
A
(18) Parking and loosen the brake:
Push the Brake Rail down to park;
Lift the Brake Rail up to loosen, Fig. A
WARNING: ALWAYS
APPLY THE BRAKES WHEN THE STROLLER
IS STATIONARY.
6. USING THE BRAKES
loosenTighten

10
IMPORTANT NOTES:To lifting or carrying the stroller, ensure that the storage
latch is engaged and grasp the frame approximately halfway along the stroller, so
the stroller is balanced.
Please refer to page 4 Manual handling techniques.
9. TO LIFT AND CARRY THE STROLLER
B
8. USE T-Bar GUARD RAIL ONLY
A
(20) Detach the Guard Rail from Guard
Rail Support Tube as shown Fig A.
(21) Press T-Bar quick release button
and then put T-Bar into Guard Rail
Support Tube as Fig. B.
WARNING:
This using position is ONLY for child older
than 36 months!

2. Hold the support bar from the back of the connector (Fig 3), then put the end
of the support bar into the connector with another hand (Fig 4 & 5).
1. Insert the support bar into the fabric cover.
USING THE CANOPY (sold separately)
Canopy Support Bar
Fabric
Cover
1 2
Connector
5
3 4
ASSEMBLY
PARTS LIST
11

7
8910
6
11 12
Handle
connector
Buckle
3. For the other side, pull out the center of the support bar slightly and insert the
support bar into the connector (Fig 6);
4. Adjust the support bar into place (Fig. 7 ).
5. Attach the holder to the handle bar connector. The cylinder on the handle bar
should be aligned with the hole in the bracket (Fig 8).
6. Firmly fasten the xing buckle to the left until completely ejected (Fig 9).
Try to shake and do not fall o to indicate that it is in place.
7. When disassembling the canopy, press the button and lift the xing buckle
toward the side to open (Fig 10).
8. Press the metal pin inward to adjust the height (Fig11 & 12).
12

USING THE STROLLER CONNECTOR Sold separately)
ASSEMBLY
13
BA
D
C
The connector can be used for
most compact baby strollers.
(1) Press the quick release
button on the connector to
connect it to the rider as
shown in figure A/B/C. To
detach the connector,press
the quick release button to
remove it.
(2) To attach the connector to
rear leg of your baby stroller,
use the strap located on the
other end of the connector.
Make sure that the strap is
tight enough to velcro it as
shown in figures D/E/F.
F
E
HGH
ATTENTION:
When using the connector on
the left rear leg of your baby
stroller, connect it to the right
front leg of your Coast Rider,
and vice versa. Refer to
Figures G/H.

14
CARE AND MAINTENANCE
• To prolong the life of your stroller keep it clean and do not leave it in the direct sunlight or in the car
boot for extended periods of time.
• Removable fabric covers and trims may be cleaned using warm water with a household soap or mild
detergent. Allow it to dry fully, preferably away from the direct sunlight.
• Non removable fabric covers and trims may be spot cleaned using a damp sponge with soap or a mild
detergent. Allow it to dry completely before folding or storing it away.
• In some climates the covers and trims may be affected by mold and mildew. To help prevent this
occurring, do not fold or store the product if it is damp or wet.
Always store the product in a well ventilated area.
• When using your stroller at the beach - completely clean your stroller afterwards to remove the sand
and salt from the mechanisms and wheel assembly. Sand and salt will cause premature wear and
corrosion.
• If there are compression marks on the wheels - Use a domestic hair dryer to gently warm (DO NOT
OVERHEAT) the wheels and the compression marks should slowly disappear.
• Always check parts regularly for tightness of screws, nuts, and other fasteners. Tighten if required.
To maintain the safety of your nursery product, seek prompt repairs for bent, torn, worn or
broken parts.
IMPORTED BY:
DREAM ON ME INC.
1532 SOUTH WASHINGTON AVE PISCATAWAY TWP,NJ 00854 USA.
For customer service, warranty information or replacement parts,
please call us at: 732-366-1788
or visit us online at: www.dreamonme.com
MADE IN CHINA

Follow us on
to get your nursery featured on our social media.
Enter our monthly giveaway!
Simply scan the QRcode to register.
@dreamonmeinc @dreamonmeinc

Seguro Comodo
Moda
Importante: Conserve estas instrucciones para futuras consultas.
Este producto está diseñado para cumplir con la norma estadounidense:
ASTM F833
Coast Rider
Manual de Instrucciones
Estilo#a 365
16

17
ADVERTENCIA
• SE REQUIERE MONTAJE ADULTO.
• NUNCA DEJE AL NIÑO DESATENDIDO. Mantenga siempre al niño a la vista mientras
esté en el cochecito.
• EVITE LESIONES GRAVES por caerse o deslizarse. Utilice siempre el cinturón de
seguridad. Después de abrochar las hebillas, ajuste los cinturones para que se ajusten
bien a su hijo.
• EVITE ATRAPAR LOS DEDOS: Tenga cuidado al plegar y desplegar la carriola.
Asegúrate de la carriola esté completamente erguida y asegurada antes de permitir que
su hijo se acerque a la carriola.
• NUNCA USE EL COCHECITO EN ESCALERAS o escaleras mecánicas. Puede perder
repentinamente el control del cochecito o su hijo puede caerse. Además, tenga mucho
cuidado al subir o bajar un escalón o un bordillo.
• EVITE LA ESTRANGULACIÓN.
• NO coloque artículos con una cuerda alrededor del cuello de su hijo, no suspenda
cuerdas de este producto ni sujete cuerdas a los juguetes.
• USO DEL COCHECITO con un niño que pesa más de 45 lb (20,5 kg) o mide más de 37, 8
pulgadas (96 cm) causará un desgaste excesivo y estrés en el cochecito. Utilice el
cochecito con un solo niño a la vez.
• PARA PREVENIR UNA CONDICIÓN PELIGROSA E INESTABLE, nunca coloque
carteras, bolsos de compras, paquetes o accesorios en el mango (que no sean bolsas de
cochecito aprobadas). Nunca coloque nada sobre el dosel..
• PARA PREVENIR UNA CONDICIÓN PELIGROSA E INESTABLE, no coloque más de 10
lb (4.5 kg) en total en la canasta de almacenamiento, incluido el 2 lb (1 kg) en el bolsillo
de la canasta (si se incluye)
• PARA EVITAR QUEMADURAS, nunca coloque líquidos calientes en los portavasos (si
se incluyen)
• PARA EVITAR VUELCAS, no coloque más de 3 lb (1,36 kg) en total en los portavasos/
bandeja de refrigerios.
• NO use la canasta de almacenamiento como portabebés.
• NO PERMITA que su hijo se pare sobre la canasta. Puede colapsar y causar lesiones.
• NUNCA COLOQUE al niño en la carriola con la cabeza hacia el reposapiés.
• NUNCA PERMITA QUE SU COCHECITO se use como juguete.
• DEJE DE USAR SU COCHECITO si se daña o se rompe.
• EL COCHECITO PARA SER UTILIZADO solo a la velocidad de caminar Producto no
diseñado para usar mientras se corre, patinaje, etc.
• EL CUIDADOR DEBE siempre ayudar al niño a subir y bajar del cochecito.
IMPORTANTE!
El incumplimiento de estas advertencias y las instrucciones de montaje podría
provocar lesiones graves o la muerte. GUARDE EL MANUAL DE INSTRUCCIONES
PARA USO FUTURO..
ADVERTENCIA

18
12° o menos mas de 12°
X
EL COCHECITO ESTÁ DISEÑADO PARA SU USO EN SUPERFICIES PLANAS O SUAVEMENTE
INCLINADAS, Y PUEDE SER INESTABLE EN SUPERFICIES MÁS ALTAS O DESIGUALES, Y LOS
USUARIOS DEBEN TENER EN CUENTA LA POSIBILIDAD DE QUE EL COCHECITO SE GIRE O SE
VUELVA..
• CON SU MANO A TRAVÉS DEL LAZO DE LA CORREA DE LA MUÑECA, EMPUJE EL
COCHECITO SOSTENIENDO AMBAS ASAS.
• LAS RUEDAS DELANTERAS PUEDEN TOMAR U OSCILAR AL CAMINAR RÁPIDO.
• EL COCHECITO PUEDE SUBIR EL BORDE O PRESIONAR HACIA ABAJO LAS MANIJAS Y
LEVANTAR LAS RUEDAS DELANTERAS Y MONTAR EL BORDE O GIRAR EL COCHECITO Y
SUBIR EL BORDE.
• SE REQUIERE PRECAUCIÓN AL EMPUJAR EL COCHECITO A TRAVÉS DE PENDIENTES
ESCONDIDAS O SUPERFICIES DESIGUALES, ESTO PUEDE HACER QUE EL COCHECITO SE
VUELVA INESTABLE Y SE CAE. SOSTENGA SIEMPRE LAS ASAS CON FIRMEZA.
• NO CORRER CON EL COCHECITO.
• SIEMPRE QUE SE DETENGA, SIEMPRE APLIQUE LOS FRENOS ANTES DE SALIR DEL
COCHECITO.
•NO COLGAR BOLSAS O MERCANCÍAS DEL ASA, YA QUE ESTO PODRÍA HACER QUE EL
COCHECITO SE PUEDE VOLCAR.
• LAS POSICIONES VERTICALES NO SON ADECUADAS PARA NIÑOS MENORES DE 6 MESES.
ADVERTENCIA

19
Barandilla
Suporte de Barandilla
Freno
Pestillo de Almacenamiento
2nd. Cerradura
LISTA DE PIEZAS
Arnés
Asiento
Manija
Botón de Ajuste
Tubo de Manija
Ruedas Delantera
Rueda Trasera
Punto de Unión
Plástico plegable
Marco Barandilla
Rueda Delantera
I& DRueda Trasera I & D Cubierta
Asiento
Barra -T
Asiento Simple
Se Vende Por
Separado

20
F
1.MONTAJE DEL COCHECITO
E
G
(1) Abra el pestillo de almacenamiento,
consulte la Fig. A, despues, levante la
manija de la silla de paseo hacia arriba,
consulte la Fig B.
(2) Levante la manija de la silla hasta
que escuche “clic” consulte la Fig. C / D,
VERIFIQUE que la silla esté
completamente asegurada cada vez
que abra la silla y antes de continuar
con el resto de los pasos de montaje.
(3) Ruedas delanteras
Deslice cada rueda delantera en el
poste de montaje en la parte delantera
de la carriola como se muestra en la
Fig. E, se escuchará un "clic". Tire de la
rueda para REVISAR y asegúrese de
que esté segura.Para facilitar el
transporte o almacenamiento, presione
la pestaña de liberación de la rueda
en el costado del cochecito
enmarcar y tirar de la rueda
lejos del cochecito. Fig. F.
(4) Ruedas Traseras
a. a. Coloque la rueda trasera I en
el tubo hasta que escuche un "clic"
como se muestra en la Fig. G / H.
b. Repita para la rueda trasera D,
Fig. I.
c. Para un fácil transporte o
almacenamiento,
desmontar la rueda trasera
presionando
el botón a presión y sacar las ruedas
traseras
BA
I
DC
H
