Domanoff NanoGrinder User manual

Mini disk sander
«NanoGrinder»
VERSION 2.0
ShipWorkshop.com

1
34 4
2 5
7
6
Basic features
• Microgrinding machine «NanoGrinder» is intended for working with wood,
nonferrous metals, steel, plastic, cork and rubber.
• Grinding disks of 60 mm in diameter are rmly attached with double side tape or
with hook & loop, which allows prompt replacement.
• Grinding disks rotating speed and direction are adjustable.
• e gap between the worktable and grinding disk is adjustable.
• So pads eliminate excessive noise and vibration.
• e opening in the table butt and at motor cover allow to fasten the machine
witha clamp.
Package contents
1. Guiding stop-protractor. Allows to set both free and preset angles with pitch of
15 and 22,5 degrees.
2. Two abrasive disks (with hook & loop and without it), grain 100.
3. Power supply.
4. Assemly and adjustments manual.
Parts of the machine
1. Motor
2. Disk (2)
3. Working table (3)
4. Table plates (4)
5. Stop-protractor (5)
6. Rotating direction switch (6)
7. Rotating speed adjustment knob (7)

Assembly and adjustments
1. If you plan to use disks with hook & loop, glue the hook & loop (included) to the
disk and cut o the excess.
2. If you do not plan to use hook & loop, use double side tape to attach the abrasive
disk to the disk of the machine.
3. For following replacements it is recommended to cut abrasive disks of 60 mm in
diameter prior to attaching them to the disk.
NOTE. Do not remove the disk from the motor axle! It is hard to put it back and this may
damage the motor itself. e motor cover is dead, i.e. it can not be removed.
4. Move Table (3) at against Disk (2).
5. Attach the rst Plate (4) to the Table (3) using double side tape. e edge of the
Plate should be parallel and at against Disk (2)
6. Move Table (3) from Disk (2) to make a small gap so that the Disk does not engage
the Table when rotating.
7. Fix the Table (3) by screws from both sides.
8. Place the stop-protractor (5) at against the rst Plate (4). Attach the second
Plate(4) to the Table (3) having pressed it rmly to the stop-protractor.
NOTE. When replacing abrasive disks the remains of double side tape can be cleaned
from the disk using solvent.
ATTENTION!
e design of the machine may dier
from that shown in this manual!
If necessary, remove the protective lm from the plastic parts
