Dometic COE-C User manual

Operating and Installation Instructions
for
CRAMER COE Gas Cooker
Models:
COE-C Cooker
(4 gas burners)
COE-CG Cooker + grill
(4 gas burners)
COE-CGO Cooker + grill + oven
(4 gas burners)
COE-FULL Cooker + grill + oven + pot store
(4 gas burners)
COE-C-DUFU Cooker
(3 gas burners + 1 electric burner)
COE-CG-DUFU Cooker + grill
(3 gas burners + 1 electric burner)
COE-CGO-DUFU Cooker + grill + oven
(3 gas burners + 1 electric burner)
COE-FULL-DUFU Cooker + grill + oven + pot store
(3 gas burners + 1 electric burner)
EN
UK
CE-0085

2
Important
This appliance is a class 3 appliance intended for installation in a kitchen unit.
Output of the hob (Hs) 4 x 1.6 = 6.4 kW (Mn = 465 g/h, propane/butane)
or, in the case of the DUFU (dual fuel) model:
Output of the hob (Hs) 3 x 1.6 = 4.8 kW (Mn = 465 g/h, propane/butane)
1 x 800W (230V AC / 3.5 A)
Output of the grill (Hs) 1.4 kW (Mn = 100 g/h, propane/butane)
Output of the oven (Hs) 1.1 kW (Mn = 80 g/h, propane/butane)
The appliance requires 12 V DC to power any internal light and the timed spark ignition.
The pressure regulators used between the gas cylinder and the appliance must comply with
the categories in the following table:
Appliance category Supply pressure Gas
I3+ 28-30/37 mbar butane/propane
I3B 30 mbar butane
I3B/P 28-30 mbar butane/propane
I3B/P 30 mbar butane/propane
I3P 28-30 mbar propane
I3B 50 mbar butane
I3B/P 50 mbar butane/propane
It is also possible to operate a 30 mbar appliance in campers with a 50 mbar gas system, but
only if a 50/30 mbar primary pressure regulator is pre-fitted. ! !
The user must read these operating instructions to familiarise himself/herself with use of the
appliance. The appliance fitter must hand these operating instructions to the user. We
recommend concluding a service contract.
If the gas tap becomes sluggish or jammed, then it must either be replaced or the affected tap
removed from the chamber, cleaned in benzene and lubricated with a special gas tap grease,
e.g. type "Staburgas no. 32" from the Klüber company in Munich. This work must be carried
out by a professional gas technician.
The appliance must be installed by an authorized technician! Particular attention must
be paid to the EN 1949 standard in addition to the usual regulations!
This appliance must be installed and connected according to the applicable installation
conditions. Special attention must be paid to suitable ventilation.
Before connecting the appliance, ensure that the local conditions (gas type and gas pressure)
match the appliance settings. The gas type and gas pressure for this appliance are indicated on
an information label (or on the identification plate).
Gas-bearing parts and the connected exhaust lines (waste gas pipe) must be inspected by an
expert before the initial start-up and at intervals of 2 years in accordance with the applicable
standards, in particular EN 1949 (in Germany also in accordance with DVGW Worksheets G
607 and G 608).

3
The operator is responsible for having the necessary inspections conducted. S/he must be
notified in writing of the inspection requirement by the technician who installs the appliance.
The appliance may be used only for cooking, baking and grilling under the conditions
specified elsewhere in these instructions. Under no circumstances may it be used for other
purposes (e.g. heating, etc.).
Use of the appliance can result in the accumulation of humidity or heat in the installation
location. Make sure that the kitchen is well-ventilated: keep the normal ventilation openings
open or provide for a mechanical ventilation device.
Intensive or prolonged used of the appliance may require additional ventilation, e.g. opening a
window or operation of the mechanical ventilation device at a higher setting.
A sign must be fitted above the cooker, stating that the closable vent must be opened while
the cooker is in use, and that the burners must not be used for heating. The sign must be
clearly visible.
IMPORTANT: When using gas kitchen appliances, the closable vents in the installation
location must be open. Naked burners must not be used for heating!
IMPORTANT: THE APPLIANCE MUST BE INSTALLED BY AN AUTHORIZED
TECHNICIAN IN ACCORDANCE WITH THE APPLICABLE STANDARDS (EN
1949).
THE ELECTRIC COMPONENT (IN THE CASE OF THE COE … DUFU MODELS)
MUST BE INSTALLED BY AN AUTHORISED TECHNICIAN IN ACCORDANCE
WITH THE APPLICABLE REGULATIONS (IN PARTICULAR EN 60335, EN 1648).
IMPORTANT: TO PREVENT ANY RISK OF ACCIDENT, IT IS NECESSARY THAT
THE APPLIANCE BE INSTALLED ACCORDING TO THESE INSTRUCTIONS.
IMPROPER INSTALLATION WILL VOID THE WARRANTY.
“ANY MODIFICATION TO THE APPLIANCE MAY BE DANGEROUS AND IS
PROHIBITED!”
1. ROOM VENTILATION
Any room in which one or more appliances are to be installed must have one or more vents
enabling fresh air to enter. One or more vents must be located above the appliance to
ensure sufficient disposal of combustion products and sufficient fresh air supply for the
user.
These vents must comply with the requirements specified in the EN 1949, EN 1646-1 and
EN 721 standards.
The user must check and, if necessary, clean these vents from time to time (for example,
they must be cleaned of snow or slush during the winter).

4
The following applicable regulations must be observed when installing the gas appliance
EN 1645-1
EN 1646-1
EN 1648
EN 1949
EN 60335
EN 721
(In Germany, the 1988 Technical Rules Governing Liquid Gas,
and the rules specified in the DVGW worksheets G 607 (vehicles) and/or G 608 (boats)
must also be observed).
2. CONNECTING THE APPLIANCE TO THE GAS SUPPLY
Only gas-tight connection fittings may be used to connect the appliance to the gas supply
line.
The pipes for connecting the appliance should be made of galvanized iron or copper. These
pipes must be used with a gas-tight connection fitting. After the connection has been
established, the gas lines should be checked by applying a soap solution to the connecting
points; any leaks can be detected by the formation of bubbles.
IMPORTANT: DURING INSTALLATION AND CONNECTION OF THE
APPLIANCE, MAKE SURE THAT THE GAS INLET PIPE IS NOT TWISTED,
PULLED OR OTHERWISE STRAINED.
3. GAS CYLINDERS
Use gas cylinders that are commercially available in the country where the appliance was
purchased. The type of gas is indicated clearly on the package and on the indelible type
plate on the back of the appliance.
THE USE OF DIFFERENT GAS PRESSURES OR GAS TYPES FROM THOSE
SPECIFIED IN THE REGULATIONS CAN RESULT IN IRREGULAR
OPERATION OF THE APPLIANCE; THEREFORE, THE MANUFACTURER
SHALL ASSUME NO RESPONSIBILITY FOR IMPROPER USE OF THE
APPLIANCE.
Always comply with the following instructions:
The gas cylinder, including valves and pressure reducers (regulators), must be installed
vertically in the cabinet provided; the cylinders must be freely accessible.
It must be possible to replace the gas cylinder easily and without obstructions.
THE GAS CYLINDER VALVE SHOULD BE CLOSED WHEN NOT IN USE.

5
CAUTION!
The following safety precautions must be taken when replacing the gas cylinder:
a) Close the gas taps (turn rotary knob to 0 position).
b) Close the shut-off valve for the appliance in the vehicle.
c) Make sure that there are no naked flames or glowing embers nearby.
d) Close the valve of the gas cylinder to be replaced.
e) Unscrew the pressure reducer (regulator) from the empty gas cylinder, remove the
cylinder from the cabinet and insert a new cylinder – then reverse the above
procedure to connect the new cylinder.
f) Check seals with a soap solution as described above.
g) Ignite the burners and check for proper functioning; in case of problems, contact a
specialized technician.
3.1 GAS CYLINDER CABINET
The cabinet for the gas cylinder must be large enough to hold the specified type of gas
cylinder with the pressure regulator attached. In Germany, it must have a width and depth
of at least 325 mm and a height of at least 620 mm.
4. VISUAL CHECK OF FLAME
a) The flame must burn steadily. It must be primarily blue, and display clear contours.
b) If the flame does not burn steadily, check to make sure that the inlet and outlet
openings are unobstructed. If not, remove any obstructions.
c) If in doubt, consult a specialized gas technician.
5. POWER SUPPLY AND ELECTRICAL CONNECTION:
The appliance requires 12 V DC to power any internal light and the timed spark ignition.
The electrical circuit must be protected with a 3 A safety fuse (not included).
The model COE ... DUFU also requires a 230 V AC / 10 A power supply (rated current
3.5 A).
The connection terminals are on the rear of the appliance.
A dual-conductor connection cable should be used for the appliance’s 12 V connection.
The + conductor is red. The two poles are marked + and – on the terminal. Make sure to
use the correct polarity when connecting the cable!
A triple-conductor 230 V AC connection cable should be used for the model COE …
DUFU. This connection cable must comply with the applicable regulations. The cross-

6
section of each cable must be at least 1.0 mm2. All three poles are marked with the
appropriate symbols on the terminal.
THE ELECTRIC SYSTEM (IN THE CASE OF THE COE … DUFU MODELS)
MUST BE INSTALLED BY AN AUTHORISED TECHNICIAN IN
ACCORDANCE WITH THE APPLICABLE REGULATIONS.
NEVER CONNECT THE 12 V DC CONNECTION TERMINAL TO THE 230 V
AC MAINS NETWORK. THIS WOULD NOT ONLY DESTROY THE
ELECTRICAL AND ELECTRONIC COMPONENTS, BUT WOULD ALSO
ENDANGER THE USER.
6. GAS LEAKS
When inspecting for gas leaks, we recommend the use of an electronic type-tested gas
detector. In the event of a fault, the valve of the gas supply network must be closed.
Consult your fitter, dealer or specialised technician.

7
7. FITTING THE APPLIANCE
7.1 MOUNTING THE APPLIANCE
For the installation of the appliance, there must be a free space as indicated in Fig. 1,
depending on the individual model (see type plate on appliance).
Fig. 1
The installation location is limited only as follows:
The appliance must rest on a firm and stable base with mounted in the cabinet. The
appliance must be firmly fixed to the front of the cabinet using the 4 screws supplied. Do
not use the gas lines, taps or parts of the burner as fixing aids.

8
Fig. 2
The following minimum distances shown in the sketch must always be observed when
installing the appliance.
a:The minimum distance (a) between the burner edge and side moveable walls made
of flammable materials is 200 mm. If a flame guard is used, the distance between it
and the side moveable wall must be at least 3 mm. In that event, the minimum
distance between the burner edge and the moveable wall is 100 mm. In respect of
the COE appliance, the glass burner cover is considered to be a rear flame guard
when raised.
b:The minimum distance between the cooker and flammable fittings above it (wall
cabinets etc.) is b = 500 mm.
DO NOT INSTALL THE APPLIANCE NEAR HIGHLY FLAMMABLE
MATERIALS.

9
7.2 REMOVING THE APPLIANCE FROM THE CABINET
a) Close the gas taps on the appliance
b) Close the shut-off valve.
c) Close the valve of the gas cylinder to be replaced.
d) Remove fastening screws
e) Disconnect the gas supply and any electric cables
8. ONLY USE THE APPLIANCE IN A WELL-VENTILATED ROOM
The air vents must be kept clear while the appliance is in use.
CAUTION: The burners must not be used in garages or while re-fuelling.
9. USING THE APPLIANCE
Caution: The glass lid may shatter if heated. Turn off all burners before closing the
lid.
If the burners’ gas outlet openings are dirty or blocked, they must be cleaned.
The thermal element must be clean, and care must be taken to maintain the correct
distance between the burner head and the thermal element (approx. 1-3 mm).
9.1. Pots
9.1.1 When placing a pot on the cooker make sure that it is centred on the pot rest and that
no flames protrude beyond the base of the pot.
9.1.2 Pots with curved bases may not be used.
9.1.3 The appliances' various burners may be equipped with pot rests of different sizes.
The pots used should not be larger than the pot rest on the burner.
The minimum pot diameter is 120 mm.

10
9.2 Caring and cleaning for your appliance
9.2.1 CLEANING INSTRUCTIONS
Only clean your appliance using a mild household cleaner.
9.2.2 Allow the appliance to cool down before cleaning it.
9.2.3 To avoid damaging the appliance, clean the exterior surfaces using a damp cloth
without the addition of chemical or granular cleaning agents.
9.2.4 Do not remove the burner lids and heads to clean the appliance.
9.2.5 Please make sure that no cleaning agent penetrates the burners.
9.2.6 After long journeys, the appliance should be visually checked for damage or loose
parts.
9.3 LIGHTING THE APPLIANCE
The appliance (hob, grill and oven) is equipped with an electronic timed spark ignition.
a) In order to light the oven or grill, the grill or oven door must be fully open.
b) Push the rotary knob in slightly and turn it to the left to the ignition position. (The
oven can be lit when the knob is in any position). Now operate the timed spark
ignition button.
Once the burner has ignited, hold the knob down for around 10 seconds until the
safety pilot is activated.
c) Release the knob and turn to the required setting.
The grill may only be operated at the high setting!
The grill door may be open or closed while the grill is in use.
The grill and the oven can also be used simultaneously.
The oven is equipped with an automatic thermostat. The various knob settings
correspond to temperatures ranging from 120 oC to 250 oC.
If the oven temperatures differ excessively from the settings, the thermostat should be
repaired.
IMPORTANT: If the ignition fails, repeat the process from the start (in the case of the
grill or oven, wait for at least 1 minute). If necessary, have the gas and or power
supply to the appliance checked. If the appliance continues to malfunction, close the gas
supply tap and consult your dealer. When first using the oven, run the empty oven
(without food) for around 1/2 hour at the maximum heat setting. If the burner flame is
extinguished by accident, turn the burner control knob off and leave the burner off for at
least 1 minute before re-igniting it.
The COE … DUFU model is equipped with one electric burner. This burner is
controlled using a rotary knob. The various knob settings correspond to nominal outputs
of between around 10% and 100% of the rated output.
GLOVES SHOULD BE USED WHEN HANDLING HOT OBJECTS

11
9.4 OPERATING THE OVEN
a) Push the oven rack into the guide track (see Fig. 2).
b) You can choose between four levels.
CAUTION: The appliance will become very hot when in use. Keep children away!
9.5 OPERATING THE GRILL
Light the grill burner while the door is fully open.
CAUTION: The appliance will become very hot when in use. Keep children away!
10. APPLIANCE FAULTS
Consult a specialist technician in the event of appliance faults.
DOMETIC CRAMER SR s. r. o.
●Tehelná 8 ●SK – 986 01 Fiľakovo ●Telephone: [phone] ●
●Fax: [phone] ●
●E-mail: [email protected] ●
●Website: www.cramer.sk ●www.dometic.com ●
