Dometic PJS118 User manual

PJS118
Jump Starter
Operating manual
EN
POWER & CONTROL
JUMP STARTER

PJS118 Explanation of symbols
EN
3
Please read this instruction manual carefully before first use, and store it in a safe place.
If you pass on the product to another person, hand over this instruction manual along
with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6 Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8 Maintaining and cleaning the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
9 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
12 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1 Explanation of symbols
!
!
A
I
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided, could result in
death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided, could result in
minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.

General safety instructions PJS118
EN
4
2 General safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Damage to the product resulting from mechanical influences and incorrect connection voltage
• Alterations to the product without express permission from the manufacturer
•Useforpurposesother than those described in the operating manual
The declaration of conformity can be requested from the manufacturer (contact information on the
back).
Note the following basic safety information when using electrical devices to protect against:
• Electric shock
•Firehazards
•Injury
2.1 General safety
!WARNING! INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS.
• Only use the device as intended.
• Disconnect the device from the mains
– Before cleaning and maintenance
–Afteruse
• Do not use this product in the bathroom or other wet areas or near water.
• Do not dismantle the device.
• Keep the product away from children.
• Do not reverse the connections of output or input.
• Do not throw the product into fire.
• Do not use the charger whose charging.
Charging Voltage is more than the product to charge.
• Only charge the product when the ambient temperature is between 0°C to 40°C.
• Do not hit or throw the product.
• If there is problem with charging, contact your dealer.
• Keep the product away from the flammable objects (e.g. bedding or carpet).
• If the product becomes hot and/or discoloured please stop using as this may lead to
a fire.
•Electrical devices are not toys.
Always keep and use the device out of the reach of children.
• Children must be supervised to ensure that they do not play with the device.
ANOTICE! MATERIAL DAMAGE.
• Do not insert foreign objects into the output or input terminals.
• Do not put fingers or hands into the device.

PJS118 Scope of delivery
EN
5
• Before using for the first time, charge your jump starter using one of the methods
described in chapter “Charging the jump starter” on page 11.
• Before charging the jump starter for the first time, check that the voltage specification
on the rating plate matches that of the power supply.
• Never pull on the power cord to unplug the device from the power socket.
• Store the device in a dry and cool place.
2.2 Operating the device safely
!WARNING! INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS.
• Only use the jump starter for to the intended purpose described in chapter “Intended
use” on page 6.
Use of an attachment not recommended or sold by the manufacturer may result in a
risk of fire, electric shock, or personal injury.
• When charging the jump starter ensure that the power socket is readily accessible.
!CAUTION! FIRE AND/OR EXPLOSION HAZARD.
•Donot operate the device
– In the vicinity of corrosive fumes
– In the vicinity of combustible materials
– In areas where there is a danger of explosions
•Donot place the device next to heat sources such as fires.
• Place the device in a shady place. Avoid direct sun exposure in hot and humid sur-
roundings for a proper usage.
ANOTICE! MATERIAL DAMAGE.
• Do not disconnect any cables when the device is still in use.
3Scopeofdelivery
The jump starter comes with the following provided equipment:
•ProductManual
•PJS118unit
•Homecharger
•Carcharger
•Universal4-in-1USBCable
• Intelligent battery clamp
• Laptop charging cable
• 8 different laptop connectors/charging adapters ( fits most laptop charging ports)
• Storage case with zipper and handle

Intended use PJS118
EN
6
4Intendeduse
The PJS118 jump starter is designed for charging digital devices like tablets, mobile phones, lap-
tops etc. The device can also be used to jump start vehicles with 12V batteries (up to 6L petrol or
4L diesel engines).
Intended use also includes observing all the information and safety instructions in this manual.
The jump starter is suitable
• to be used as a jump battery for a vehicle,
• to be used as a charger or as a power source for USB devices.
The jump starter is not intended to be used by children and persons with limited mental abilities or
without the required specialist knowledge. Keep children away from the device.
The jump starter is not allowed
• to be used in parallel connection with other two jump starters.
• to jump start a deeply discharged or defective vehicle battery.
• for commercial use.
5 Technical description
The jump starter is a compact and handy starting aid & power station to jump empty vehicle batter-
ies. Mobile power consumers such as mobile phones, tablets, cameras, etc. can be quickly and
easily recharged.
The jump starter uses a powerful lithium polymer battery. The status of charge can also be quickly
read via a build in display.
The device includesan integrated LED work light with continuous light, strobelight and SOS signal
for emergency situations.

PJS118 Technical description
EN
7
5.1 Connections and indicators
No. in
fig. 1Description
1 LED work light
2Display
3 Power button
4 On-Off switch
5 Laptop charging port
6USBport
7USBport
8 Type-C input port for charging the jump starter
1

Technical description PJS118
EN
8
The jump starter enables mobile power supply for USB devices and as a jump starter for a vehicle
starter battery.
The device has the following protective functions:
• Voltage stabilization protection
• Over-voltage protection
• Overload protection
• Over discharge protection
• Over temperature protection
• Balanced charge
The intelligent battery clamp (fig. 210) has a build in indication LED and a buzzer.
It also has additional protective functions, refer to chapter “Protective functions” on page 17.
No. in
fig. 2Description
9 Socket for intelligent battery clamp
10 Intelligent battery clamp
2

PJS118 Technical description
EN
9
5.2 Display
The display shows the operational status of the jump starter.
The charging indicator (fig. 31) shows the current state of charge between 0% (discharged) up
to 100% (fully charged).
The input indicator (fig. 32) shows up in the display when the device is being charged.
The output indicator (fig. 33) shows up in the display when the device is supplying energy to any
USB port.
The supply indicator for USB voltage and current (fig. 34) shows the 5 V USB charging current
when a device is connected to the port.
The supply indicator for the laptop charging port (fig. 3or 5) shows the selected output Voltage
12V, 16V or 19V.
No. in
fig. 3Description
1 Charging indicator - state of charge as a percentage
2 Input indicator - device is being charged
3 USB output indicator - device is outputting power
4 Supply indicator - USB charging voltage and current
5 Supply indicator - Laptop charging port voltage
3

Using the appliance PJS118
EN
10
6 Using the appliance
6.1 Before first use
➤Before first use or storing, charge the jump starter until it is fully charged.
➤Observe the information given in chapter “Charging the jump starter” on page 11.
6.2 Starting and switching on/off
Switching on the jump starter
➤Slide the On-Off switch (fig. 14, page 7) to the On position.
➤Press the power button (fig. 13, page 7).
✓The device is ready to use.
✓The display (fig. 3, page 9) shows the operational status.
✓The display switches off automatically after 1 minute.
Switching the display on
➤When display is switched off press the power button (fig. 13, page 7).
✓The display (fig. 3, page 9) switches on.
Switching off the jump starter
The jump starter switches off automatically if no load and no charger are connected.
➤Slide the On-Off switch (fig. 14, page 7) to the Off position.

PJS118 Using the appliance
EN
11
6.3 Charging the jump starter
Charging takes 3-5 hours using either charging options. The charging function automatically stops
when the jump starter is fully charged.
The jump starter can be charged in two ways:
• Using the home charger (fig. 41),
• Using the car charger (fig. 42).
➤Place the jump starter on a firm base.
➤Switch On the device, following the instructions given in chapter “Starting and switching
on/off” on page 10.
No. in
fig. 4Description
1Homecharger
2 Car charger
4

Using the appliance PJS118
EN
12
Charging with the home charger
➤Connect the home charger (fig. 41, page 11) to the connection socket (fig. 110, page 7).
➤Connect the home charger to the AC mains.
✓The input indicator is shown in the display, see chapter “Display” on page 9.
The charging function automatically stops when the jump starter is fully charged.
Charging with the car charger
➤Connect the car charger (fig. 42, page 11) to the connection socket (fig. 110, page 7).
➤Connect the car charger to the socket in the car.
✓The input indicator is shown in the display, see chapter “Display” on page 9.
Checking the charge level
➤Press the power button (fig. 13, page 7).
✓The display shows the state of charge between 0% (discharged) to 100% (fully charged), see
chapter “Display” on page 9.
6.4 Using the LED work light
The LED work light (fig. 31, page 9) can be used with three different functions.
The different functions can be changed in sequence by pressing the power button (fig. 13,
page 7): Continuous light, strobe light, SOS signal - OFF
LED continuous light
➤Press and hold the power button for 3 seconds.
✓The LED work light lights up continuously.
Strobe light
➤Press the power button again.
✓The LED work light is flashing in constant intervals.
SOS signal
➤Press the power button again.
✓The LED work light is flashing the SOS signal pattern.
OFF
➤Press the power button again.
✓The LED work light is switched off.

PJS118 Using the appliance
EN
13
6.5 Charging digital devices via USB
➤Choose either the provided 4-in-1 USB cable or your own USB cable suitable for your digital
device.
➤Connect the digital device to be charged to either USB port (fig. 5).
➤Switch On the device, following the instructions given in chapter “Starting and switching
on/off” on page 10.
✓The output and the supply indicators are shown in the display, see chapter “Display” on page 9.
5

Using the appliance PJS118
EN
14
6.6 Charging Laptops
➤Select the suitable charging adapter and connect it to the short laptop charging cable pro-
vided.
➤Switch On the device, following the instructions given in chapter “Starting and switching
on/off” on page 10.
➤Press the power button (fig. 13, page 7) to select the correct voltage (12V, 16V or 19V) for
your laptop.
✓The selected output Voltage is shown on the supply indicator in the display, see chapter “Dis-
play” on page 9.
➤Connect the laptop to the laptop charging port (fig. 6).
✓The output and the supply indicators are shown in the display, see chapter “Display” on page 9.
6

PJS118 Using the appliance
EN
15
6.7 Starting Vehicles
The jump starter can be used to start vehicles with 12V batteries with up to 6L petrol or 4L diesel
engines.
I
➤Open the socket (fig. 71).
➤Connect the plug (fig. 73) of the intelligent battery clamp to the socket (fig. 71).
➤Switch On the device, following the instructions given in chapter “Starting and switching
on/off” on page 10.
A
No. in
fig. 7Description
1 Socket for intelligent battery clamp
2 Intelligent battery clamp
3 Plug for intelligent battery clamp
4 Battery clamps (red/black)
NOTE
Ensure that the jump starter is no less than 50% charged.
If it is below 50%, it may not be able to jump start a vehicle.
NOTICE! MATERIAL DAMAGE.
• Once the vehicle is started, disconnect the clamps (fig. 74) from the vehicle‘s bat-
tery within 30 seconds (negative terminal on the vehicle‘s battery first).
• Do not connect the red and black clams together.
7

Troubleshooting PJS118
EN
16
➤Ensure the vehicle‘s battery terminals are clean and free from corrosion.
➤Connect the red clamp to the + terminal on the vehicle‘s battery.
➤Connect the black clamp to the - terminal on the vehicle‘s battery.
✓The blue LED on the intelligent battery clamp (fig. 72, page 15) indicates that the jump starter
is ready to start the vehicle.
I
➤Start the vehicle.
➤Once the vehicle is started, disconnect the clamps (fig. 74) from the vehicle‘s battery as soon
as possible.
❱Disconnect the black clamp from the - terminal on the vehicle‘s battery first.
❱Disconnect the red clamp from the + terminal on the vehicle‘s battery last.
7 Troubleshooting
NOTE
A flashing red LED on the intelligent battery clamp indicates that a safety function is
active. Also the buzzer may sound.
For more information refer to chapter “Protective functions” on page 17.
After a flashing red LED, disconnect and reconnect the plug (fig. 73, page 15) before
using the device again.
Problem Cause Remedy
The power capacity of the
device is shown at 100%, but
did not fully charge in charg-
ing process.
This situation can occur when
the device is in a semi-state of
charge, which is conducive to
long-term storage when the
device is not in use for long
time.
Pull out the charge plug, then
reinsert.
The device is defective. Contact a service centre.
Nothing happens when
switching the device on, dis-
play stays dark.
Low voltage protection of the
device is active and the
device can not be turned on.
Insert the charger plug into
the 9V/2A input port to acti-
vate.
The display is defective. Contact a service centre.
Red LED on the intelligent bat-
tery clamp at the intelligent
battery clamp is flashing.
A flashing red LED on the
intelligent battery clamp indi-
cates that a safety function is
active.
See table in chapter “Protec-
tive functions” on page 17.

PJS118 Maintaining and cleaning the product
EN
17
7.1 Protect i ve f unct ions
8 Maintaining and cleaning the product
A
➤Occasionally clean the product with a damp cloth.
Details
Low voltage protection
Red LED flashing, buzzer active
Vehicle‘s battery voltage is below 10.5V
Power output is cut off automatically.
Reverse polarity protection
Red LED flashing, buzzer active
Clamps are not connected properly (reversed)
Power output is prevented.
Short circuit protection
Red LED flashing, buzzer active
When both camps are connected together
(short circuit).
Power output is prevented.
Reverse charging protection
Red LED flashing
Higher voltage of vehicle‘s battery than the
jump starter, normally when vehicle has started
Power output is prevented.
Automatic power shut off
Red LED flashing
After normal output, if no further operation
occurs for 60 seconds, the clamps will automati-
cally turn off.
NOTICE! MATERIAL DAMAGE.
• Do not use sharp or hard objects or cleaning agents for cleaning as these may dam-
age the product.
• Do not use alcohol based cleaning materials for cleaning.
• Fully charge the jump starter at leastevery three months. Overloading the device or
storing it for too long without charging it may cause permanent damage.

Warranty PJS118
EN
18
9Warranty
If the product does not work as it should, please contact your retailer or the manufacturer's branch
in your country (see dometic.com/dealer). The warranty applicable to your product is 1 year(s).
For repair and warranty processing, please include the following documents when you send in the
device:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
Australia only
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major fail-
ure.
New Zealand only
This warranty policy is subject to the conditions and guarantees which are mandatory as implied by
the consumer guarantees act 1993 (NZ).
10 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever possible.
MIf you wish to finally dispose of the product, ask your local recycling centre or specialist
dealer for details about how to do this in accordance with the applicable disposal
regulations.
BProtect the environment!
Do not dispose of any batteries with general household waste.
Return defective or used batteries to your retailer or dispose of them at collection points.

PJS118 Technical data
EN
19
11 Technical data
* depends on connected USB device and the connected cable
Power supply unit
12 Copyright
© 2020 Dometic Group. The visual appearance of the contents of this manual is protected by cop-
yright and design law. The underlying technical design and the products contained herein may be
protected by design, patent or be patent pending. The trademarks mentioned in this manual
belong to Dometic Sweden AB. All rights are reserved.
PJS118
Battery type: Lithium Polymer battery, Pure LiCo02
Battery rated capacity: 18000 mAh (66.6 Wh)
Start current: 450 A
Peak current: 900 A
Rated port DC output:
2 x USB Type A:
Laptop charging port:
5Vg/2 A, 9 Vg*/2 A
12 V/16 V/19Vg/max.3.5 A at 12 V
DC Input: Type -C: 5 Vg/1 A, 9 Vg/2 A
Ambient temperature for operation: -20 °C to +60 °C (-4 °F to +140 °F)
Dimensions (L x W x H): 190.5x 82.5 x 34 mm (75 x 32.5 x 1.3 in)
Weight: 608 g
Home charger
AC Input:
DC output:
100 – 240 Vw/ 50/60 Hz, max. 0.6 A
Type -C: 9 Vg, 2 A

YOUR LOCAL
SALES OFFICE
dometicĶ ,*ű0)"0Ŗ,= "s
YOUR LOCAL
DEALER
dometic.com/dealer
YOUR LOCAL
SUPPORT
dometic.com/contact
dometic.com
 *+-)"1")&01*#*+"1&  *+-,&"0ķ4%& % *+-/&0"1%"*+"1& /*2-ķ ,"#*2,!&,1%"-2)& 9)&,$0*#ĸ
DOMETIC GROUP AB"+3E/,0$1,ĉčŖĉďĉčČ*),4"!",
4445103027 02/2020
