DomoClip DOM330 User manual

User manual
WWW.DOMOCLIP.COM
Référence : DOM330
Version : 1.3
Langue : English
Draft beer dispenser

User manual
1
There are numerous beers to choose from available in 5 liters party kegs. Before using the dispenser,
please read the instruction for use and safety information. You will now be able to enjoy cool, draught beer
Attention: The optimum ambient temperature for ice making is within 20-25℃，If you give the device to
other people, please pass on the operating instructions.
SAFETY INSTRUCTIONS
Note: Read the below safety instructions carefully and put the
device in safe place.
1. When the device is not in use, swich off the dispenser and
always disconnect the plug from the main socket!
2. Before using the dispenser, read the operating
instructions carefully. Keep the device away from sources
of heat, direct sunlight.
3. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
4. Children shall not play with the appliance.
5. Cleaning and user maintenance shall not be made by
children without supervision.
6. Only use original accessories. When transporting the beer
dispenser, always carry it holding the bottom edge and
not by the beer tap, lid or power cord.
7. Only use the dispenser with the correct beer keg. Do not
attempt to change or repair the dispenser, if you have any

User manual
2
problems or difficulties, to protect yourself safety, please
contact to our customer service. It may lead electric shock
if fit or repair by youself. Please refer to our offical service
department , otherwise we take no responsibility.
8. Inoffical or nonregular repair will lead dangerous.
9. Keep packaging out of the reach of children(danger of
suffocation). Keep the dispenser out of the reach of
children, as can’t recognize the danger of electrical
appliance.
10. Regularly check the dispenser and cable for damage. Do
not use the appliance if it is damaged.
11. Ensure your standard power supply comply with the
technical data.
12. Only use the parts match with the device or recommend
by the local dealer.
13. Do not squeeze or bend cable, do not connect with any
heating.
14. Ensure do not trip the cable.
15. Do not put the dispenser on the gas container or near
electric cooking appliance. Keep away from
inflammables.
16. Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
17. Never immerse the dispenser and plug on water or other
liquid, it may lead short circuit,fire etc.
18. If the dispenser can’t work or damaged, unplug it
immediately.

User manual
3
19. When remove the plug from the socket, do not pull the
plug out by the cable.
20. Before cleaning the dispenser, pull the plug out of the
mains socket
21. The dispenser is not suitable for outdoor use.
22. Do not sit or stand on the dispenser.
23. Do not place glasswork on the lid.
24. Do not touch working parts with hair, clothes, fingers or
other parts of body.
25. Do not place any objects in the air vents.
26. Before fitting or removing any parts, always disconnect
the plug from the mains socket.
27. Do not cover the air vents. Overheating can occur.
28. Only use this dispenser when the temperature is 12-28℃.
29. No legal right or entitlements may be obtained from the
description made in this manual, it also apply to the wear
of conponent.
30. Do not use leaked or damaged keg.
31. The appliance is not intended to be operated by means of
external timer or separate remote control system.
32. If the power cord is damaged, it must be replaced by the
manufacturer, its service or similarly qualified person in
order to avoid a hazard. (*)
33. This appliance is intended for household use and similar
applications such as:

User manual
4
staff kitchen areas in shops, offices and other working
environments
farm houses
by clients in hotels, motels and other residential type
environments
bed and breakfast type environments
(*) Competent qualified electrician: after sales department of the producer or importer or any person
who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In
any case you should return the appliance to this electrician.
This instruction manual is also available on our website www.domoclip.com
TECHNICAL DATA
Power: 230V AC/50Hz
Power: 72W
Protection class: II
Dimension(L/W/H mm): 565×290×440
Beer keg: Standard 5 litre party keg, pressurized or unpressurized.
Accessories and technical data subject to change without notice!

User manual
5
LIST OF PARTS
1. Lid
2. Dispensing unit handle
3. Gas outlet valve
4. Tap handle
5. Pressure regulator
6. Main body
7. LED temperature indicator
8. Drip tray cover
9. Drip tray
10. Front tube cover
11. Coolingchamber
12. Lid opener
13. Keg tap
14. Power cord
15. Switch
16. beer keg stoppers
17. connecting tube
18. tools for removing keg stopper
19. adapter
Warning: Before fitting or removing related parts, please cut off the mains socket, remove the plug from
the socket.
OPERATING INSTRUCTIONS
1. Remove the beer dispenser from the packaging.
2. Place the beer dispenser on a stable, horizontal, level and non-slip surface. Ensure that there is at least
10cm of space around the dispenser for optimal operating.
3. Fit the collecting tray/drip tray does not protrude beyond the surface.
4. Fit the silicon ring in the threaded part of the tap. Screw the tap tool below the dispensing unit.
5. Clean the dispensing unit as described in the instructions in Chapter “Dismantling and cleaning the beer
dispenser”.
6. Check that the main switch at the back of the dispenser is set to “0” and plug the plug into the main
socket.
7. Set the main switch to “I”.
8. Check the LED indicator to ensure that the dispenser is on.

User manual
6
INSTALLATION
For non-pressurized containers
1. Buy one standard 5 litre barrel
Attention: only use 5L beer keg stoppers as below :
The Beertender® barrels can be used on this beer engine (see "for pressurized drums")
Note: If the keg has been shaken(transport,etc.), the beer must be allowed to stand for a sufficient time
prior to use.
2. Cool the 5 litre party keg prior to use. The optimal drinking temperature is about 6-8℃. The beer from
a warmer keg is less refreshing. Heavy foaming can also result. To cool the keg in the beer dispenser, it
is recommended to place ir in the connected dispenser the day before. At a keg temperature of about
23℃, it is recommended to wait 16 hours before pulling the first glasses of beer.
Note: The cooling time in the refrigerator is between 6 and 12 hours depending on the brand and capacity
due to the sophisticated cooling technology. This allows the cooling to process to be accelerated. Storing
the 5 litre party keg in a refrigerator offers the advantage of always having a second keg ready to use.
Attention: Never cool the party keg in a freezer as it can burst. Shock cooling can impair the quality of
beer.
3. No matter what stopper you choose for 5 litre keg, it is necessary to use the supplied tools for removing
the stopper.
4. Note: Before removing the stopper, always first vent the keg as stated on the keg and allow to stand for
a sufficient period so that the foam does not escape from the vent opening;
5. Once the stopper has been removed, the supplied universal beer keg stoppers can be inserted into the
bunghole in the keg.
Note: Do not dispose of the universal beer keg stoppers after emptying the keg, but remove and clean
with warm water and a small amount of mild washing up liquid and retain for reuse. Remove the beer
keg stoppers by gripping the edge of the rubber ring and pulling firmly with the other hand to ensure

User manual
7
that it does not tip over.
6. Subsequently place it vertically on the tap opening of the stopper and push it downwards firmly and
evenly into the keg. First attach the dispensing unit to the back of the keg. Push down on the front of the
unit until it clicks in place. The dispensing unit is now ready to use.
Attention : Before using the 5 litre party keg, always check the best before date!
Attention: Ensure that the keg lid is not dented so that the clamps of the dispensing unit can grip
under the edge of the lid..
7. Open the dispenser lid by pressing the lid open button.
8. Lift the dispenser unit (including keg) into the cooling chamber of the dispenser.
9. Attach the end of the dispensting unit to the gas outlet valve.
Attention: Never fill liquid into the gas outlet valve.

User manual
8
10. Close the dispenser lid so that it locks with a click.
11. Turn the pressure regulator slightly clockwise,until the sound of working air pump automatically
closed.
12. Pull the tap towards you standing, then you can taste fresh beer.
Warning: If there is enough pressure in the keg or pressure regulator is closed, the air pump can not work, if
there is no enough pressure in the beer keg, open the pressure regulator,the air pump will work
automatically.

User manual
9
For pressurized containers
If you choose the type of barrels Beertender® already containing CO2, do as follows:
1. Attach the photo, install the supplied adapter on the keg
2. Disassemble the tap
3. Assemble the connector to the plastic tube and position it on the beer keg as on the below pictures.

User manual
10
The adapter must be positioned as in the picture below, with the hollow of the valve down.
4. Press the valve to raise beer and close the cover as shown below
5. Pull the tap towards you standing, then you can taste fresh beer.
NOTES
Attention: Before switching of the beer dispenser, always ensure that no 5 litre party keg is present in the
dispenser as the beer in the keg becomes warm and is no longer fresh.

User manual
11
1. Preparing glasses:
Wash the glasses in hot water with a small amount of washing / up liquid. Rinse the glasses thoroughly
each time before dispensing with cold, clear water. Ensure that all grease and residues are removed
completely to avoid impairing foam formation.
2. Dispensing beer:
Hold the glass under the beer tap at an angle. The tip of the outlet tube should not come into contact
with the glass as this can impair the foam formation.
Note: The foam produced when dispensing beer can be influenced by changing the angle of the glass.
Note: If the tap is only partly open, the beer may foam excessively as it is not able to flow out freely.
Note: The tap locks in position when the tap is fully open. This enables several glasses of beer to be
dispensed simultaneously.
Allow the beer to run down the inside of the glass and slowly straighten the glass while dispensing until
it is upright towards the end. Place the glass on the drip plate and wait about 1 minute until the foam
has settled. Ensure that the glass is not located directly under the beer tap so that no drops fall into the
bear foam.
Repeat the dispensing process until the beer and foam are in the correct proportion. This is the case
when the head is about two finger’s breadth high and slightly over the rim of the glass.
CLEANING
To clean the beer dispenser and/or to replace the keg, the procedure for this is as follows:
1. Press the lid opener.
2. Take out the tap and the keg
Note: The silicon sealing ring is a wearing part. If excessive carbon losses are noticed during use,replace
the silicon sealing ring with the supplied spare seal
3. Remove the clamps from the rim of the keg and pull the dispensing unit out of the keg quickly and evenly.
As the beer tap may not be moist during extraction, removal may take some effort.
Attention: Never remove the dispensing unit from the keg when pressurised. To change the keg before it is
empty, remove the keg together with the dispensing unit from the dispenser. Position it in such a way that
the beer is able to flow out into a suitable container and pull the tap handle until no more beer is dispensed.

User manual
12
Cleaning
In order to keep the quality of the dispensed beer at a consistently high level, it is important to clean the
dispenser thoroughly.
The cleaning intervals are specified in the following
Attention: Never use scouring pads, aggressive scouring agents, acetone, benzene, acids, thinner, vinegar or
similar for cleaning purposes.
Cleaning after each use:
Both the collecting tray and drip tray should be cleaned after each use of the dispenser to ensure perfect
hygiene. For this purpose, remove both the collecting tray and drip tray from the dispenser and pour the
collected beer into the drain, Subsequently clean both parts with hot water(using a small amount of
washing/up liquid if necessary). Attention, to avoid scald when washing, water can not be very hot.Drip tray
can wash with washer,but painted collecting tray is not dishwasher proof.
It is recommended to also clean the tube at the front of the beer tap after each use.
Find a empty plastic bottle, fill in clear water, as the photo below see, must open the beer tap ,squeez the
bottle, water flow from the tap, the tube in tap can clear after repeat several times,then wash the silicon
ring with clear water.
Note: It is recommended to use hot water and a small amount of washing-up liquid. In this case, the tube
should be rinsed again with clear, warm water in order not to prevent impairment of the taste and foam
formation.
Attention: The dispensing unit is not dishwasher proof.
Attention: If the dispenser is not used for an extended period, it should be thoroughly cleaned beforehand.
Regular cleaning
Regularly clean the cooling chamber and all surfaces of the dispenser with a moist cloth and small amount
of mild washing-up liquid.
Attention: Before cleaning the dispenser, always disconnect the plug from the mains socket and never
immerse the dispenser in water.
Attention: The cooling chamber must not be filled with liquid as this can cause permanent breakdown.

User manual
13
TROUBLESHOOTING
Problem
Possible cause
Remedy
The unit does not switch
on
The plug is not plugged into the mains
socket The main switch is set to “0”
Plug the plug into the mains socket Set
the main switch to “I”
E1 an E2 error program,
etc.
The temperature of the beer within the
barrel is too low, -1 ° C, -2 ° C, etc.
Switch off the appliance and wait for
beer resume a positive temperature
Not enough foam
is produced while
dispensing
The beer is too cold
Allow the keg to stand in the dispenser
For while.The temperature is then
Corrected by the unit
There are grease,washing-up
Liquid or residues in the glass
Wash the glass thoroughly and
subsequently rinse with cold water
The glass is too warm
Rinse the glass with cold water
The glass is dry
Rinse the glass with cold water
The beer turns cloudy
The beer is too cold
Allow the keg to stand in the dispenser
For while.The temperature is then
Corrected by the unit
The beer tube is not clean
Clean the dispensing unit
The beer was incorrectly shock-chilled
prior to using the beer dispenser
Use a correctly chilled keg
No beer is dispensed
The 5 litre party keg is empty
Place a new 5 litre party keg in the
dispenser
Pressure regulator is closed
Open the pressure regulator
The keg tap is not fitted.
The keg is not correctly tapped.
Screw the keg tap to the dispensing
unit.Tap the keg correctly
The tap handle is not correctly installed
Install the tap handle ccorrectly
Too much foam is
produced when
dispensing
The 5 litre party keg is not cold enough
Cool the 5 litre party keg longer
The 5 litre party keg was shaken
Allow the 5 litre party keg to stand in the
beer dispenser for a while
The beer does not flow freely out of the
tube
Open the beer tap fully
The outlet tube touches the glass when
dispensing
Hold the glass slightly further away from
the outlet tube
The glass is held upright when
dispensing
Tilt the glass when dispensing so that
the beer is able to run down the side of
the glass

User manual
14
Correct disposal of the unit
(Electrical and Electronic Equipment)
(Applicable in the European Union and the rest of Europe that have adopted separate collection systems
countries)
The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that
old household electrical appliances must not be disposed of in the normal household waste stream.
Old appliances must be collected separately in order to optimize the recovery and recycling of the
materials they contain and reduce the impact on human health and the environment.
The symbol of the crossed out dustbin is marked on all products to remind the obligations of separate collection.
Consumers should contact their local authority or retailer for information concerning the correct disposal of their product.
Non contractual illustration
Product information is subject to change without prior notice.
DOMOCLIP
BP 61071
67452 Mundolsheim - FRANCE
